AV Access BizEye 80 User manual

4K UHD USB Camera
User Manual
BizEye 80

Introduction
Introduction
Overview
This product is a 4K Ultra HD USB camera. It features an ultra-wide angle
and distortion-less lens. It also supports high-quality video up to 4K
30fps, auto color-correction and white balance, performing well in
different lighting environments or sunlight. Its built-in auto noise
reducing mic can pick up clear sound within the distance of 3m.
It is easy to install. It is fully compatible with most operating systems,
such as Windows 7/10/11 and Mac OS, and works with popular calling
and streaming platforms including OBS (Open Broadcasting Software)
and XSplit Broadcaster for abundant application scenarios.
Features
Supports 4K Ultra HD up to 4K@30fps encoding output, and
down-compatible with 1080p and 720p.
Supports MJPEG, YUY2, NV12, H.264 and H.265 video compression to
comply with most application platforms.
Full functional USB 3.0 / USB 2.0 connection, power supply, video
and audio all in one via USB 3.0 Type-A to Type-C cable.
120° ultra-wide-angle distortion-less lens.
Built-in auto noise reducing mic, which can pick up clear sound in
the distance of 3m.
Fully supports UC and web conferencing platform, like Skype
business, Zoom, WebEx, etc.
Auto Framing / Presenter Tracking based on AI technology makes
meetings more intimate and friendly.
Supports ePTZ with a maximum of 5x digital Zoom.
Equips multiple-purpose mounting clip for easy installation on the
top of a laptop, a display or a universal tripod.
Package Contents
USB Camera x 1
USB 3.0 Type-A to USB Type-C Cable x 1
User Manual x 1

Installation and Application
Panel
Installation and Application
For placement on a monitor
1. Place your webcam on a computer, laptop or monitor at a position
or angle you desire.
2. Adjust the webcam to make sure the foot on the universal mounting
clip is flush with the back of your device.
3. Manually adjust the webcam up/down to the best position to frame
yourself.
1 2 3
For placement on a tripod
1. Locate the M12 tripod thread on the bottom of the webcam.
2. Secure the webcam on your tripod by twisting it into the M12
thread.
1 2
3
11
2
4
1. Microphone
2. Camera Lens
3. Status LED
•When USB camera is powered on,
the LED will light green for 6
seconds and off.
•When USB camera is transferring
data, the LED will light green
constantly.
4. USB Type-C port

Specifications
3. Place your webcam with the tripod anywhere you desire to the best
position to frame yourself.
Note:
•Tripod is not included in the package.
•For best performance, install this device within the height of 100cm
above the desktop is recommended.
Application
Connect the USB-C port of this device to the USB-A port on your
computer using the cable provided.
Note:
1. After this device is connected to a computer, its camera and
microphone can be detected by the system and specific application
in the name of the following:
Camera Name: BizEye 80 | Microphone Name: BizEye 80
2. By default, the microphone is turned off. To access to its features,
please visit www.avaccess.com to download and install AV Access
BizEye App.
Specifications
Camera
Lens
Fixed Focus
Sensor
CMOS, Effective Pixel: 8.0M
Scanning Mode
Progressive
Viewing Angle 120° (FOV)
Horizontal Rotation Range
Leftward: 30°, Rightward: 30°
Vertical Rotation Range
Downward: 90°
ePTZ
Supported | 5 x Digital Zoom
Shutter
1/30s ~ 1/10000s
Tracking Mode
Auto Framing (default) / Presenter Tracking / Off
White Balance Auto
Backlight Compensation
Auto
Digital Noise Reduction
2D, 3D digital noise reduction
Note: The tracking mode can be switched among the above modes through AV Access
BizEye App. To download this App, visit www.avaccess.com.

Specifications
USB
Operating System
Windows 7/10/11, Mac OS™ 10.10 or higher
Color / Compression
MJPEG (default) /YUY2/NV12/H.265/H.264
Resolution and Frame Rate

MJPEG: 320x240@30fps, 640x360@30fps, 640x480@
30fps, 1280x720@90fps*/60fps/30fps, 1920x1080@
60fps*/30fps, 2560x1440@30fps*, 3840x2160@30fps*
YUY2/NV12: 320x240@30fps, 640x 360@30fps,
640x480@30fps, 1280x720@30fps*, 1920x1080@
30fps*, 2560x1440@30fps*, 3840x2160@15fps*
H.265/H.264: 320x240@30fps, 640x360@30fps,
640x480@30fps, 1280x720@30fps, 1920x1080
@30fps, 2560x1440@30fps*, 3840x2160@30fps*
Note:
(1) Resolutions and frame rates
that marked with
asterisks (*) are not available in USB 2.0 mode.
(2) In USB 3.0 mode, default resolutions and frame rates
are 1280x720@30fps.
(3) In USB 2.0 mode, default resolutions and frame rates
are 1280x720@30fps for MJPEG/H.265/ H.264, and
640x480@30fps for YUY2/NV12.
USB Communication
Protocol
UVC 1.1
USB Cable Length
1.5m/4.92ft
Input/Output Interface
USB Interface
1 x USB Type-C: USB 3.0, up to 5Gbps (USB 3.0 Type-A to
USB Type-C cable is recommended)
Mic
2 x Mic
Physical Parameter
Operating Temperature
0°C ~ 40°C (32°F to 104°F)
Storage Temperature
-20°C ~ 60°C (-4°F to 140°F)
Input Voltage
5V (USB power supply)
Power Consumption
2.1W (Max)
MTBF
＞
30000h
Size 140.3mm x 61.5mm x 73.7mm/5.52” x 2.42” x 2.9” (with
Bracket)
Net Weight
0.14 kg/0.31lb (with Bracket)

Warranty
Warranty
Products are backed by a limited 1-year parts and labor warranty. For the
following cases AV Access Technology Limited shall charge for the service(s)
claimed for the product if the product is still remediable and the warranty card
becomes unenforceable or inapplicable.
1. The original serial number (specified by AV Access Technology Limited)
labeled on the product has been removed, erased, replaced, defaced or is
illegible.
2. The warranty has expired.
3. The defects are caused by the fact that the product is repaired, dismantled
or altered by anyone that is not from an AV Access Technology Limited
authorized service partner. The defects are caused by the fact that the
product is used or handled improperly, roughly or not as instructed in the
applicable User Guide.
4. The defects are caused by any force majeure including but not limited to
accidents, fire, earthquake, lightning, tsunami and war.
5. The service, configuration and gifts promised by salesman only but not
covered by normal contract.
6. AV Access Technology Limited preserves the right for interpretation of
these cases above and to make changes to them at any time without notice.
Thank you for choosing products from AV Access.
If you have any question, please contact us via the following emails:
General Enquiry: [e-mail]
Customer/Technical Support: [e-mail]
