Av e-book Av-e701 User manual

AV-E701 E-book Reader

User’s Manual v02

Introduction

Thank you for purchasing this EBook Reader.

This manual contains important safety information and operation instructions, so please read all these

instructions carefully before using the EBook Reader and keeps it for future reference.

This manual will help you use all of the exiting features to make your EBook Reading more enjoyable.

We have done our best to produce a complete and accurate manual; however, we cannot ensure

there are no errors or omissions. We also have no responsibility for damages or loss of data caused

by improper operation.

The instruction manual is subject to change for improvement without notice.

Their respective companies or organizations own trademarks and trade names used in this user’s

manual.

CONTENT

Regulatory Information: FCC Part 15 / Copyright 3

Important Safety Precautions 3-4

Main Features 6

Overview 7

Getting Started 8

Turn on the E-Book reader 8

Connect to the PC & Download files from PC 8

Information about e-Books, epub, DRM, Adobe Digital Edition 9

Inserting SD/MMC card 10

Charging the battery 11

Using home menu 12

Item introduction 12

Tips for your using 13

Reading E-Book 14

Now reading 15

Reading a book from history 15

EBook function menu 16

Reading EBook with background music 17

Listening to Music 18

Playing music 19

Music function menu 19

Repeat / Equalizer 20

Lyric Displaying 20

Viewing Photos 21

Playing a slide show 21

Calendar 22

Applications 22

Settings 22

Brightness /Backlight time / G Sensor / Erase Activation Record 23

Media Lib Update / Language / Time/ Date 24

System Information 24

Explorer 25

Troubleshooting 26

Specifications 27

Regulatory Information: FCC Part 15

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

yReorient or relocate the receiving antenna.

yIncrease the separation between the equipment and receiver.

yConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.

yConsult the dealer or an experienced radio/TV technician for help.

WARNING: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY

UNAUTHORIZED MODIFICATIONS TO THE DEVICE. ANY SUCH MODIFICATIONS COULD VOID THE USER'S

AUTHORITY TO OPERATE THE EQUIPMENT.

Contains Reader®Mobile technology by Adobe Systems Incorporated

Important Safety Precautions

Always follow these basic safety precautions when using your device. This will reduce the risk of product

damage and personal injury.

yDo not disassemble, repair or modify the device by yourself. Refer servicing to qualified personnel.

yDo not dispose of the device in fire to avoid explosion because the device has built-in battery.

yDo not touch the device with bare hands if the built-in battery is leaking. In this case, contact service

center for help since the liquid may remain in the device. If your body or clothes has contacted with the

battery liquid, wash it off thoroughly with water. Also, if some of liquid gets into your eyes, do not rub

your eyes but immediately wash them with clean water, and consult a doctor.

yKeep the device away from direct sunlight and heat source.

yDo not expose the unit to rain or moisture to avoid any malfunction.

yDo not use the device in rather dry environment to avoid static.

yNever apply heavy impact on the device like dropping it or placing it on the magnet.

yRoute USB cable so that people and pets are not likely to trip over or accidentally pull on them as they

move around or walk through the area.

yDisconnect the USB cable from the computer when you do not use the device for a long time.

yClean only with dry cloth. Make sure the device is turned off before cleaning. Do not use liquid

cleanser.

yBe sure to back up your files. We will not be liable for the loss of data due to improper operation, repair

or other causes.

yAt full power, the prolonged listening of the walkman can damage the ear of the use.

Precautions in using the headphone

yDo not use the headphone while driving an automobile or riding a bicycle. It is not only dangerous, but

also against the law. To avoid an accident, do not turn up the volume of the headphones too high while

walking.

yIt’s not recommended that you use the headphones at a high volume for an extended time as this may

cause hearing damage.

BOX CONTENT:

e-Reader

Soft protective pouch

Earphone

USB cable

100-240 Volt adapter

User Manual

Main Features

y7” TFT color display 800*480

yBuilt-in rechargeable lithium battery

yReading EBook in PDF/e-PUB/TXT format

yQuick reading EBook in browse history

yRotate the screen to toggle between vertical and horizontal display while reading EBook

yPlayback of WAV, APE, FLAC, OGG, MP3, WMA, and AAC audio files

yMultiple equalizers (EQ) and 3D sound effects

yDisplay titles, artists and albums of music files (ID3 tag)

yLyrics synchronization while music is playing

ySupports JPEG/GIF/PNG photo formats

yFolder navigation

yCompatible with SD/MMC card (up to 16G)

yUSB 2.0 high speed transmission

Overview 1. Display screen

2. [OK] Confirm the selection

3. [MENU] Open the function menu for each mode

4. [ ] Open Zoom-in option window

5. [ ] Previous option; Fast backward search;

Move cursor left

6. [ ] Decrease the volume; Move cursor down

7. Mini USB connector

8. 5V 2A DC Input socket

9. SD/MMC-card slot

10. [PREV PAGE] Go to previous page

11. [NEXT PAGE] Go to next page

12. [ ] Increases the volume; Move cursor up

13. [ ] Exit button

14. [ ] Starts/Pause/Resume playback;

15. [ ] Next option; Fast forward search; Move

cursor right

16. [ ] Power on/off

17. Earphone jack

18. Loud speaker

19. RESET hole

Getting Started

Turn on the E-Book reader

Press and hold the [ ] button to turn on the E-Book reader, if the device with low battery, plug one end of the

power adaptor into the DC socket in the E-Book reader, and the other into a wall outlet.

Note: To turn off the E-Book reader, please press and hold the [ ] button again.

Connect to the PC & Download files from PC

Connect the device to computer for downloading files or charging the device.

1. Make sure that your computer has been started before you start.

2. Connect the mini plug of the USB cable to the mini USB port on the device, and push the other end into a

free USB port on your computer.

3. When the device is connected to your computer, a “Removable Disk” will be created in “My computer”.

4. Open the Windows Explorer or My computer. “Removable Disk” is displayed.

5. Drag and drop the files on your computer to the “Removable Disk”. .

6. If you authorized the device by using EBook website tools, there will be a hidden folder such like

“adobe-digital-editions” generate in your device. Please do not delete this hide “adobe-digital-editions”

folder or format the device unless you want to re-authorize the device.

Note: The battery of the device is charging automatically when the device is connected to the computer.

Don’t disconnect the USB cable during file transferring. It may cause malfunction of the device and files.

IMPORTENT NOTE ABOUT eBooks:

EBooks in ePub format, ere secured by met DRM (Digital Rights Management)

To download digital EBooks, put it on your eReader and read it, ePub format, you need the program “Adobe

Digital Editions” (ADE).

You can find this program via the website link: http://www.adobe.com/products/digitaleditions/help/

Download and install the program on your pc.

Then you can create an account, Adobe-id, and you have to authorize your e-Reader with your pc.

If you authorized the device by using EBook website tools, there will be a hidden folder such

like“adobe-digital-editions” generate in your device. Please do not delete this hide “adobe-digital-editions”

folder or format the device unless you want to re-authorize the device.

Disconnect the device from PC

After finishing transferring, please disconnect the device from the computer as the following:

1 Left click the” ” icon at the taskbar.

2 Click the pop-up mini-window with message of “Stop the USB Mass Storage Device –Driver (X)”.

3 When you are prompted to remove the device, you can unplug the device safely.

Inserting SD/MMC card

You can attach a SD or MMC card to the E-Book reader.

1. Align your card with the slot. Put it in place.

2. Push the card until it is locked.

To remove the SD/MMC card: press the card to release it and pull out the card.

Note: Please insert or pull out the card when the E-Book Reader is off, or the internal files of the device will

be lost or damaged.

Charging the battery

yThe battery of the E-Book reader is charging automatically when the device is connected to the computer

or connected to a wall outlet. When charging, the indicate lighter is red, and it will turn green after it full

charged.

yRead the battery level indication of your device:

Full Three-quarters full Half

full Low Empty

Important:

yRecommended temperature for battery charging is 0

℃

to 35

℃

yFully charge it before you use the device for the first time or when you have not used it for a long time.

yCharge the device right now when the “Low battery” message is displayed.

yDo not over charge or discharge the device. Over charging or discharging will shorten the battery life.

yThe battery could be over discharged if the device is not used for a long time (over three months). To

avoid over discharge, fully charge the device every three months and always keep the voltage of the

battery above 50%.

yIf the device is not used for a long time, keep it under the temperature of 23

℃

and the moisture of 65

20% RH to maintain the performance of the battery

Using home menu

1. Press and hold the [ ] button, the home menu appears on the screen.

Or, in another modes, press the [ ] button to return to the home menu.

2. Press the [ ], [ ], [ ] or [ ] button to select: Now reading, Browser History, My

Favorite, eBook, Music, Photo, Calendar and App.

3. Then press the [OK] button to enter the desired mode.

Item introduction

Home menu

items Description Home menu

items Description

Now reading Read further in the eBook you

were reading. My Favorite Find your favorite eBook you have

saved.

Browser History Browse your EBook reading

history, Music Play music tracks.

eBook List all your EBooks in the device Photo View photos.

Calendar See the Calendar App Settings and Explorer

Tips for your using

yPage up/down: while reading a book, you can press the [PREV PAGE] and [NEXT PAGE] button to page up

and page down.

yZoom in: while reading a book, you can press the [ ] button to open zoom-in options pop-up window.

yFunction menu: while reading a book, watching a video, listen to music or browsing photos, you can

press the [MENU] button to open function menu.

yExit: press the [ ] button, you can exit and return to previous screen.

yReset the E-Book reader: If a malfunction of the E-Book reader occurs, take a metal pin, e.g. the end of a

paper clip, and press it into the RESET hole to re-initialize the system of your E-Book reader.

Reading E-Book

1. In the home menu, press the [ ], [ ], [ ] or [ ] button to select the eBook mode.

2. Press the [OK] button to enter your EBook library.

3. Use the [ ], [ ] ,[ ] or [ ] button to the desired EBook.

4. Press the [OK] button to start reading the book.

Note: The EBook reader can synchronize the EBooks with DRM to itself by using

EBook website tools. Different eBooks takes different time to open; normally the big

size eBook takes more time to open.

While reading a book, you can:

yPage up/down: Press the [PREV PAGE] and [NEXT PAGE] button to page up and down.

yZoom in: Press the [ ] button to open the zoom-in options pop-up window (A,A,A). please use [ ] or

[] to chose the font size and press the [OK] button to confirm.

yRotate: Press the [ ] button to toggle between vertical and horizontal display. (Note: you also can set

the screen to rotate automatically in the Setting function. Then the device can rotate automatically

when you rotate it )

yExit: Press the [ ] button to return to eBook library

Now reading

You can enter immediately the last read eBook directly through the “Now reading” function

on the main menu.

Reading a book from history

1. In the home menu, press the [ ], [ ], [ ] or [ ] button to select the Browse

History mode.

2. Use the [ ] or [ ] button select a desired book.

3. Press the [OK] button to start reading the book.

EBook function menu

While reading a book, press the [MENU] button to open the EBook setting function menu,

1. Use the [ ] or [ ] button to select the desired item.(include Favorite, Goto, Background, Brightness))

2. Press the [OK] button to select the item.

yFavorite: save the eBook as My Favorite eBook, press the [OK] button to confirm.

yGoto: you can use the [ ] or [ ] button to select the percentage (or table of content, This function is

only available for the book contains the table of content) you like to start to read, and press the [OK]

button to confirm.

yBackground: you can use the [ ] or [ ] button to select a background, and press the [OK] button to

confirm. This function can be only used in the TXT format eBooks.

yBrightness: you can use the [ ] or [ ] button to select the brightness while reading the eBook, and

press the [OK] button to confirm.

While reading a book, press the [OK] button to open the EBook bookmark function menu,

ySave Mark: Save the current page to mark. Use the [ ] or [ ] button to select a column, and then

press the [OK] button to confirm.

yLoad, delete and replace Mark: Load the saved mark. Use the [ ] or [ ] button to select a mark,

press the [OK] ,then use the [ ] or [ ] button to select the load this mark, select the to delete

this mark, and to replace this old mark.

Reading EBook with background music

1. In the home menu, press the [ ], [ ], [ ] or [ ] button to select the Music mode.

2. Press the [OK] button to enter music list.

3. Use the [ ] or [ ] button to select desired audio file, and then press the [OK] button to start playing the

song.

4. Press the [ ] button repeatedly to go back to the home menu.

5. In the home menu, press the [ ], [ ], [ ] or [ ] button to select the EBook mode.

6. Press the [OK] button to enter your EBook library.

7. Use the [ ] or [ ] button to select desired EBook, and then press the [OK] button the open the EBook

library.

8. Select the desired EBook.

9. Press the [OK] button to start reading the book.

Now, you can read your book with background music.

Listening to Music

Playing music

1. In the home menu, press the [ ], [ ], [ ] or [ ] button to select the Music mode.

2. Press the [OK] button to enter your music list.

3. Use the [ ] or [ ] button to select desired audio file.

4. Press the [OK] button to start listening to the song.

While music playing, you can:

yPause/Resume Playing: Press [ ] button to pause playing. To resume playing, press [ ] button

again.

ySkipping Tracks: Press [ ] or [ ] button to skip to previous/next track.

ySearching: Press and hold [ ] button to fast rewind within a track; Press and hold [ ] button to fast

forward within a track.

yAdjust Volume: Press the [ ] or [ ] button to increase/decrease the volume.

yExit: Press the [ ] button to return to music list menu.

yPower Off: Press and hold the [ ] button to turn off the EBook Reader.

Table of contents

AV E-Book AV-E701 User manual

Popular Ebook Reader manuals by other brands
