Thank you for purchasing the
LSI SAS 9200-8e Host Bus Adapter
(HBA). Please take a few minutes to
read this quick installation guide
before you install the HBA.
For more information about any
topic covered in this guide, refer to
the documents listed with your
product at the following link:
http://go.lsi.com/hbas
After navigating to your product, select
Software Downloads to locate necessary
device drivers.
ATTENTION: Perform all installation work
at an electrostatic discharge
(ESD)-safe workstation that
meets the requirements of
EIA-625. Requirements for
Handling Electrostatic Discharge
Sensitive Devices. You must
perform all actions in
accordance to the latest
revision of the IPC-A-610 ESD-
recommended practices.
Quick Installation Guide
LSI® SAS 9200-8e PCI Express® to 6Gb/s SAS Host Bus Adapter
42611-01B
To install the LSI® SAS 9200-8e HBA, follow these steps:
1. Unpack the HBA, and inspect it for damage. Unpack the HBA in a static-free environment.
Remove the HBA from the antistatic bag, and carefully inspect the device for damage. If you notice
any damage, contact LSI or your reseller support representative.
ATTENTION: To avoid the risk of data loss, make a backup of your data before changing your
system configuration.
2. Prepare the computer. Turn off the computer, and remove the power cord from the rear of
the power supply.
CAUTION: Disconnect the computer from the power supply and from any networks to which
you will install the HBA, or you risk damaging the system or experiencing
electrical shock.
3. Remove the cover from the chassis.
4. Check the mounting bracket on the HBA (system dependent). If required for your system,
replace the full-height mounting bracket that ships on the HBA with the low-profile bracket
supplied. Complete step a through step d to attach the short bracket.
a. Using a #1 Phillips screwdriver that is ESD safe, remove the two Phillips screws that
connect the full-profile bracket to the board. Unscrew the two screws located at the top and
bottom edges of the board. Avoid touching any other board components with the
screwdriver or bracket.
CAUTION: Damaging the screw can void the warranty. To prevent damage to the screw,
center the screwdriver in the top of the screw.
b. Remove the full-profile bracket from the HBA. Do not damage the board.
c. Place the HBA on top of the low-profile bracket. Position the bracket so that the screw
holes in the tabs align with the openings in the board.
d. Using a #1 Phillips torque screwdriver that is ESD safe, set to a maximum torque of
4.8 ± 0.5 inch-pounds. Replace the two Phillips screws removed in step a.
CAUTION: Exceeding these torque specifications can damage the board, connectors, or
screws, and can void the warranty on the HBA.
5. Insert the HBA in an available PCIe® slot. Locate an empty PCIe slot. Remove the blank
bracket panel on the back of the computer that aligns with the empty PCIe slot. Save this bracket
screw, if applicable. Align the HBA to a PCIe slot. Press down gently, but firmly, to seat the HBA
correctly in the slot. The following figure shows how to insert the HBA in a PCIe slot.

TECHNICAL SUPPORT
For assistance installing, configuring, or
running the LSI SAS 9200-8e HBA, contact LSI
Technical Support:
WARRANTY NOTICE
1. The warranty does not cover the return
of parts damaged by changing the bracket.
2. The warranty does not cover ESD
damage to the HBA. HBAs returned without a
bracket mounted on the board will be
returned without return merchandise
authorization (RMA) processing.
E-mail: [email protected]
Web Site: www.lsi.com/support/
Avago, Avago Technologies, the A logo, LSI, and Storage by LSI are trademarks of Avago Technologies in the United States and/or other countries.
All other brand and product names may be trademarks of their respective companies.
Corporate Headquarters Email Website
San Jose, CA [email protected] www.lsi.com
Document Number: 42611-01B
Copyright © 2014 Avago Technologies
All Rights Reserved. December 2014.
NOTE: The shape, size, and locations of the components on your HBA and its bracket might vary
from this illustration. The HBA requires a x8 PCIe slot.
6. Secure the HBA bracket to the system’s chassis. Install the bracket screw, if applicable, or
engage the system retention mechanism to secure the HBA to the system’s chassis.
7. Replace the cover of the chassis.
8. Connect SAS cables between the HBA and the SAS enclosure that contains SATA or SAS
devices. The LSISAS9200-8e HBA has two external X4 mini-SAS connectors, each connecting to
four 6Gb/s SAS ports. Use the appropriate cable to connect the HBA to SAS or SATA disk
drive enclosures.
For connection to external disk drive enclosures, use an external cable with a standard mini-SAS
connector (SFF-8088) on both ends of the cable.
9. Reconnect any power cords, and power up the system. Reconnect any power cords and
reconnect any network cables. Turn on the power.
The hardware installation of your LSI 6Gb/s SAS HBA is complete. The next procedure is to install
the appropriate operating system drivers.
DRIVER INSTALLATION
All driver installation instructions are available at http://go.lsi.com/hbas. Select 6Gb/s SAS HBAs >
Product Name > Software Downloads.
