Avalon 564 Series User manual

Seattle Victorian Lace Face
564
Black 95400261
Page 1 of 4 17601476 7/25/14 © Travis Industries, Inc.
Compatibility:
• 564 SS & DF Fireplace
• 564 HO Fireplace
• 564 564 EF-I Fireplace
Packing List:
• Face
• (2) 564 SS Upper Mounting Brackets
• (2) 564 SS Lower Mounting Brackets
• (4) 10-24 1-1/2" Screws
The center deflectors must be in place when using this face to prevent
the facing above the fireplace from becoming too hot. If this face is
replacing a Louvered Grill (96200801), make sure to replace the center
deflectors.
Installation Details – 564 SS, DF, HO
SIDE OF FIREPLACE
1”
3/4”
27-1/2”











32-3/8”

Seattle Victorian Lace Face
564
Black 95400261
Page 2 of 4 17601476 7/25/14 © Travis Industries, Inc.
Installation
1 Remove the glass frame from the fireplace (see the owner's manual for details).
2 Install the face mounting brackets onto the fireplace following the directions below.
Repeat these steps for the opposite side.
Upper
Bracket
Lower
Bracket
Upper
Left
Lower
Left
Upper
Right
Lower
Right
Bracket
Identification
Remove the nuts and bushings above and
below the firebox. Place the brackets into
position then replace the bushings and nuts
to secure the brackets in place.

Seattle Victorian Lace Face
564
Black 95400261
Page 3 of 4 17601476 7/25/14 © Travis Industries, Inc.
Installation (continued)
3 Install the glass frame cover following the directions below.
NOTE FOR 564 FIREPLACES WITH BARRIER SCREEN:
On 2014 564 fireplaces that include a barrier screen, discard the cover and use the cover
included with the fireplace. The cover included with the fireplace is placed over the barrier
screen – see manual for details.
Push these tabs inwards
to lock the cover in place.
Place the cover over the top of the door frame.
4 Attach the glass frame to the fireplace.

Seattle Victorian Lace Face
564
Black 95400261
Page 4 of 4 17601476 7/25/14 © Travis Industries, Inc.
Installation (continued)
5 Install the face with the four included screws (see the illustration below).














































































HINT: Use a magnetic-tipped
screwdriver on the upper
screws. This prevents the
screws from falling while
installing.
Phillips
Screwdriver
Plated Surfaces
Use denatured alcohol and a soft cloth to clean plated surfaces. Marks
left on the surface may damage the face.
Denatured
Alcohol
Soft Cloth
