Avalon Whidbey User manual

4
4
5
6
7
3
2
1
1” to 1-1/2” Thick Cement Board
41 1/2”
10” Min 25” Min
™
Visit us online:
www.avalonfirestyle.com
We reserve the right to improve our products at any time without prior notification. Photos and illustrations are for descriptive purposes only. Copyright ©2007 #98800001
All Avalon firestyles are proudly made in the U.S.A.
Framing Dimensions: See Installation Manual
1. Hearth Requirements: Extends 10” from face and 49 1/2” wide
when installed flush. Not required when raised 6”
(See Installation Manual for details)
2. Non-combustible facing - Two side and two top
pieces are provided with the fireplace
3. Side Wall Clearance: 11”
4. Mantle Clearances: 50”from base of fireplace.
4. Maximum allowed mantle depth: 12”
5. Minimum fireplace enclosure height 60”.
5. Measured from base of fireplace.
6. Minimum framing: 50” wide x 56 3/4” tall x 25” deep.
7. Facing Requirements: Provided fiber board or other
7. non-combustible material must extend from the base of the
7. fireplace to the header and to the framing members on both sides.
Standard Features:
• No grills for a traditional masonry fireplace look.
• Durable, high temperature, tempered glass with safety mesh
• screen (removable if desired).
• 1080 sq. in. of fireviewing area
• Realistic, 4 piece detailed log set cast from real firewood.
• Digital Home Comfort™ Control System can be operated by
•the hand-held remote control and the wireless wall control.
•
The Electronic Gas Valve can be run for greater efficiency in
•the “Intermittent Pilot Mode” with the gas pilot turned off
•until you need it or“Standing Pilot Mode” with the gas pilot
•always on, for reliable cold weather operation.
• Natural (NG) or Propane (LP) operation.
• Uses Simpson Duravent 8 5/8” x 6” chimney.
• Seven Year “Real World”Warranty.
Gas Input Rating & Performance:
• Adjustable High Heat Systems
- 20,800 -38,000 Btu’s (NG)
- 23,500 - 38,000 Btu’s (LP)
• Heater Rated Fireplace: Heat up to 1,000 sq. ft.*
*Heating capacity will vary depending on the temperature
zone you live in.
Tested and Certified by OMNI-Test Lab. Inc. to ANSI Z21.88b “Vented Gas-Fired Direct
Fireplace Heater”.
Must be installed in accordance with all local codes, if any, if not, follow ANSI Z223.1 and the requirements listed in the Owner’s Manual.
Note: Improper installation of your gas appliance or failure to operate it in accordance to the guidelines detailed in the Owner’s Manual may
negate your warranty.We recommend all Avalon appliances be installed and maintained on an annual basis by your specialty hearth retailer.
Maintain a 14”min.
width between studs
and max.3 1/2”depth
of studs for chimney
clearance
™
Whidbey Clean Face Gas Fireplace

™
Wrought Iron
Andiron
Arabesque
Andiron
Colonial
Andiron
Personalize Your Fireplace With These Beautiful Options
Herringbone Brick Option
Weathered Brick Option
Ceramic Fireback Options
While not required, the Whidbey fireplace gives you the ability finish off the inside of the fireplace with the reversible
brick fireback - Weathered Brick on one side Herringbone Brick on the other.
Andiron Options
Enhance the look of yourWhidbey fireplace
even further with a choice of three optional
cast andirons.All our andirons feature finely
cast details and attach to the existing grate.
Change the look of your fireplace in a matter
of minutes!
Accent Light
Highlight your Whidbey’s
interior with the optional
decorative accent lighting kit.
Bring out the details in the
fireback and logset. Use it
with the fire on or off to
enhance the mood or for year
round enjoyment of your
fireplace.
Firescreen
Add the finishing touch to
your installation with an
optional decorative fire-
screen.The firescreen features
detailed legs and handle for
a traditional fireplace look.
Ideal if you have small
children in your home.
Optional Extra Room
Power Heat Duct Kit
The Power Heat Duct Kit can be added at the time
of installation and allows you to direct heat off the
fireplace and direct it to an additional room in your
home. A remote fan, attached to the end of the duct,
pulls heat off the fireplace and delivers it to any
adjoining room, up to 20 feet away.
PLACE
HOLDER
Whidbey Clean Face Gas Fireplace
Introducing the Whidbey“
Clean Face Fireplace by Avalon“˚˚
The Whidbey CF clean face fireplace offers the beautiful look of a traditional masonry fireplace
with the convenience found in today’s modern, direct vent gas fireplaces. The Whidbey CF
offers a 1080 sq. in.of fire viewing glass in a clean, louverless fireplace design with tall,dramatic
flames, exceptional hand-carved logs and a glowing red ember bed.
Don't need the heat and still want to enjoy the fire? The Whidbey’s remarkable gas control
system allows you to reduce the BTU input to your fireplace by up to 40% while still maintaining
a beautiful fire within your fireplace.
The Whidbey CF features low BTU gas input. This makes it ideal for reducing energy cost.The
Whidbey CF is tested as a ‘Heater Rated” appliance and can heat a room up to 1,000 sq. ft.With
it’s Electronic IPI (Intermittent Pilot Ignition) Gas Valve you can run your fireplace in either the
“Electronic Ignition”or“Standing Pilot”modes. This fireplace makes the Whidbey CF ideal choice
for those looking an economical solution to the open fireplace look.
Convenience
At Your
Fingertips
The Whidbey CF features
the Home Comfort™
Control System. This built-
in control center is com-
pletely hidden within the
fireplace, so all you see is
the amazing fire!
You control all functions
including on/off, room
temperature and flame
height adjust-ment all from
the standard hand-held
remote or wireless
modulating wall mounted
control - both included with
fireplace.
Thermostatic Modulating
Remote Control -
Allows controls ON/OFF,
High/Low Fire Settings
and Room Thermostat.
Wireless Modulating
Wall Mounted Control -
Allows control of ON/OFF
and High/Low Fire Settings
Standard Black Interior

™
Wrought Iron
Andiron
Arabesque
Andiron
Colonial
Andiron
Personalize Your Fireplace With These Beautiful Options
Herringbone Brick Option
Weathered Brick Option
Ceramic Fireback Options
While not required, the Whidbey fireplace gives you the ability finish off the inside of the fireplace with the reversible
brick fireback - Weathered Brick on one side Herringbone Brick on the other.
Andiron Options
Enhance the look of yourWhidbey fireplace
even further with a choice of three optional
cast andirons.All our andirons feature finely
cast details and attach to the existing grate.
Change the look of your fireplace in a matter
of minutes!
Accent Light
Highlight your Whidbey’s
interior with the optional
decorative accent lighting kit.
Bring out the details in the
fireback and logset. Use it
with the fire on or off to
enhance the mood or for year
round enjoyment of your
fireplace.
Firescreen
Add the finishing touch to
your installation with an
optional decorative fire-
screen.The firescreen features
detailed legs and handle for
a traditional fireplace look.
Ideal if you have small
children in your home.
Optional Extra Room
Power Heat Duct Kit
The Power Heat Duct Kit can be added at the time
of installation and allows you to direct heat off the
fireplace and direct it to an additional room in your
home. A remote fan,attached to the end of the duct,
pulls heat off the fireplace and delivers it to any
adjoining room, up to 20 feet away.
PLACE
HOLDER
Whidbey Clean Face Gas Fireplace
Introducing the Whidbey“
Clean Face Fireplace by Avalon“˚˚
The Whidbey CF clean face fireplace offers the beautiful look of a traditional masonry fireplace
with the convenience found in today’s modern, direct vent gas fireplaces. The Whidbey CF
offers a 1080 sq. in. of fire viewing glass in a clean, louverless fireplace design with tall,dramatic
flames, exceptional hand-carved logs and a glowing red ember bed.
Don't need the heat and still want to enjoy the fire? The Whidbey’s remarkable gas control
system allows you to reduce the BTU input to your fireplace by up to 40% while still maintaining
a beautiful fire within your fireplace.
The Whidbey CF features low BTU gas input. This makes it ideal for reducing energy cost.The
Whidbey CF is tested as a ‘Heater Rated” appliance and can heat a room up to 1,000 sq. ft.With
it’s Electronic IPI (Intermittent Pilot Ignition) Gas Valve you can run your fireplace in either the
“Electronic Ignition”or“Standing Pilot”modes. This fireplace makes the Whidbey CF ideal choice
for those looking an economical solution to the open fireplace look.
Convenience
At Your
Fingertips
The Whidbey CF features
the Home Comfort™
Control System. This built-
in control center is com-
pletely hidden within the
fireplace, so all you see is
the amazing fire!
You control all functions
including on/off, room
temperature and flame
height adjust-ment all from
the standard hand-held
remote or wireless
modulating wall mounted
control - both included with
fireplace.
Thermostatic Modulating
Remote Control -
Allows controls ON/OFF,
High/Low Fire Settings
and Room Thermostat.
Wireless Modulating
Wall Mounted Control -
Allows control of ON/OFF
and High/Low Fire Settings
Standard Black Interior

4
4
5
6
7
3
2
1
1” to 1-1/2” Thick Cement Board
41 1/2”
10” Min 25” Min
™
Visit us online:
www.avalonfirestyle.com
We reserve the right to improve our products at any time without prior notification. Photos and illustrations are for descriptive purposes only. Copyright ©2007 #98800001
All Avalon firestyles are proudly made in the U.S.A.
Framing Dimensions: See Installation Manual
1. Hearth Requirements: Extends 10” from face and 49 1/2” wide
when installed flush. Not required when raised 6”
(See Installation Manual for details)
2. Non-combustible facing - Two side and two top
pieces are provided with the fireplace
3. Side Wall Clearance: 11”
4. Mantle Clearances: 50” from base of fireplace.
4. Maximum allowed mantle depth: 12”
5. Minimum fireplace enclosure height 60”.
5. Measured from base of fireplace.
6. Minimum framing: 50” wide x 56 3/4” tall x 25” deep.
7. Facing Requirements: Provided fiber board or other
7. non-combustible material must extend from the base of the
7. fireplace to the header and to the framing members on both sides.
Standard Features:
• No grills for a traditional masonry fireplace look.
• Durable, high temperature, tempered glass with safety mesh
• screen (removable if desired).
• 1080 sq. in. of fireviewing area
• Realistic, 4 piece detailed log set cast from real firewood.
• Digital Home Comfort™ Control System can be operated by
•the hand-held remote control and the wireless wall control.
•
The Electronic Gas Valve can be run for greater efficiency in
•the “Intermittent Pilot Mode” with the gas pilot turned off
•until you need it or“Standing Pilot Mode” with the gas pilot
•always on, for reliable cold weather operation.
• Natural (NG) or Propane (LP) operation.
• Uses Simpson Duravent 8 5/8” x 6” chimney.
• Seven Year “Real World”Warranty.
Gas Input Rating & Performance:
• Adjustable High Heat Systems
- 20,800 -38,000 Btu’s (NG)
- 23,500 - 38,000 Btu’s (LP)
• Heater Rated Fireplace: Heat up to 1,000 sq. ft.*
*Heating capacity will vary depending on the temperature
zone you live in.
Tested and Certified by OMNI-Test Lab. Inc. to ANSI Z21.88b “Vented Gas-Fired Direct
Fireplace Heater”.
Must be installed in accordance with all local codes, if any, if not, follow ANSI Z223.1 and the requirements listed in the Owner’s Manual.
Note: Improper installation of your gas appliance or failure to operate it in accordance to the guidelines detailed in the Owner’s Manual may
negate your warranty.We recommend all Avalon appliances be installed and maintained on an annual basis by your specialty hearth retailer.
Maintain a 14”min.
width between studs
and max.3 1/2”depth
of studs for chimney
clearance
™
Whidbey Clean Face Gas Fireplace
