Avalon Camano User manual

“
Camano
Wood Stove
Owner's Manual
•Freestanding Stove
•Mobile-Home Approved
•Alcove Approved
•Hearth-Stove Approved
Save these instructions
for future reference
SAFETY NOTICE:
If this appliance is not properly installed, a house fire may
result. For your safety, follow the installation directions.
Contact local building or fire officials about restrictions and
installation inspection requirements in your area.
©Copyright 2010,
Travis Industries, Inc.
$10.00
100-01252_000
4101004 Listed
Tested to: U.L. 1482, ULC S627, & ULC S628

2 Introduction
© Travis Industries 100-01252_000 4101004
Introduction
We welcome you as a new owner of an Avalon Camano wood-burning stove. In purchasing a Camano
you have joined the growing ranks of concerned individuals whose selection of an energy system reflects
both a concern for the environment and aesthetics. The Avalon Camano is one of the finest appliances
the world over. This manual will explain the installation, operation, and maintenance of this appliance.
Please familiarize yourself with the Owner's Manual before operating your appliance and save the
manual for future reference. Included are helpful hints and suggestions which will make the installation
and operation of your new appliance an easier and more enjoyable experience. We offer our continual
support and guidance to help you achieve the maximum benefit and enjoyment from your appliance.
Important Information
No other Avalon Camano appliance has the same
serial number as yours. The serial number is
stamped onto the label on the back of the appliance.
This serial number will be needed in case you require
service of any type.
Model: Avalon Camano
Serial Number:
Purchase Date:
Purchased From:
Mail your Warranty Card Today, and Save Your Bill
of Sale.
To receive full warranty coverage, you will need to
show evidence of the date you purchased your
appliance. Do not mail your Bill of Sale to us.
We suggest that you attach your Bill of Sale to this
page so that you will have all the information you need
in one place should the need for service or information
occur.

Table of Contents 3
© Travis Industries 100-01252_000 4101004
General Information
Introduction & Important Information.......................... 2
Safety Precautions..................................................... 4
Features & Specifications .......................................... 6
Stove Installation
Planning The Installation............................................ 7
Center Divider............................................................ 7
Floor Protection Requirements .................................. 8
Stove Placement Requirements................................. 8
Clearances................................................................. 8
Chimney Requirements.............................................. 10
Chimney Termination Requirements.......................... 12
Outside Air Requirements.......................................... 12
Alcove Installation Requirements............................... 13
Mobile Home Requirements....................................... 14
INSTALLATION DIAGRAMS
Standard Ceiling with a Factory Built Chimney .......... 15
Cathedral Ceiling with a Factory Built Chimney ......... 15
Exterior Factory Built Chimney................................... 16
Hearth Stove Positive Connection.............................. 16
Hearth Stove Direct Connection................................. 17
Interior Masonry Chimney.......................................... 17
Operating Your Appliance
Safety Notice.............................................................. 18
Before Your First Fire................................................. 18
Opening the Door....................................................... 18
Starting a Fire ............................................................ 19
Adjusting the Burn Rate............................................. 20
Ash Removal.............................................................. 20
Optional Blower Operation......................................... 21
Re-Loading the Stove ................................................ 21
Overnight Burn........................................................... 21
Normal Operating Sounds.......................................... 21
Hints for Burning........................................................ 22
Selecting Wood.......................................................... 22
Troubleshooting ......................................................... 23
Maintaining Your Appliance
Daily Maintenance...................................................... 24
Remove Ash .............................................................. 24
Clean The Glass........................................................ 24
Monthly Maintenance................................................. 25
Door and Glass Inspection......................................... 26
Check For Creosote Buildup...................................... 25
Yearly Maintenance ................................................... 26
Touch Up Paint.......................................................... 26
Blower Cleaning......................................................... 26
Firebrick and Baffle Inspection................................... 26
Door Parts.................................................................. 27
Replacing the Glass................................................... 27
Replacing the Door Gasket........................................ 27
Replacing the Door Handle........................................ 27
Firebox Parts.............................................................. 28
Floor & Side Firebrick Removal & Replacement........ 28
Baffle Removal and Replacement.............................. 29
Air Tube Removal and Replacement ......................... 29
Warranty....................................................................... 30
Listing Information.................................................... 32
Optional Equipment
Rear Blower Installation............................................. 33
Index.............................................................................. 34

4 Safety Precautions
© Travis Industries 100-01252_000 4101004
The viewing door must be
closed and latched during
operation.
Smoke from this appliance may
active a smoke detector when
the door is open.
Never block free airflow through
the air vents on this appliance.
Gas
Gasoline or other flammable
liquids must never be used to
start the fire or "Freshen Up" the
fire. Do not store or use
gasoline or other flammable
liquids in the vicinity of this
appliance.
This appliance is designed and
approved for the burning of cord
wood only. Do not attempt to
burn any other type of fuel other
than cord wood in this
appliance, it will void all
warranties and safety listings.
ASHES
Ashes must be disposed in a
metal container with a tight lid
and placed on a non-
combustible surface well away
from the home or structure.
Do not touch the appliance while
it is hot and educate all children
of the danger of a high-
temperature appliance. Young
children should be supervised
when they are in the same room
as the appliance.
36"
Keep furniture, drapes, curtains,
wood, paper, and other
combustibles a minimum of 36"
away from the front of the
appliance.
This appliance must be properly
installed to prevent the
possibility of a house fire. The
instructions must be strictly
adhered to. Do not use
makeshift methods or
compromise in the installation.
Ok
Contact your local building
officials to obtain a permit and
information on any installation
restrictions or inspection
requirements in your area.
Notify your insurance company
of this appliance as well.
Inspect the chimney connector
and chimney at least twice
monthly and clean if necessary.
Creosote may build up and
cause a house fire.
Do not connect this appliance to
any chimney serving another
appliance.
Type
HT Clay
Liner
This appliance must be
connected to a listed high
temperature (UL 103 HT)
residential type chimney or an
approved masonry chimney with
a standard clay tile, or stainless
steel liner.

Safety Precautions 5
© Travis Industries 100-01252_000 4101004
Mobile
Home
When installed in a mobile
home, this appliance must be
bolted to the floor, have outside
air, and not be installed in the
bedroom (Per H.U.D.
requirements). Check with local
building officials.
Do not place clothing or other
flammable items on or near this
appliance.
Never try to repair or replace
any part of this appliance unless
instructions are given in this
manual. All other work must be
done by a trained technician.
Do not make any changes or
modifications to an existing
masonry fireplace or chimney to
install this appliance.
Do not make any changes to the
appliance to increase
combustion air.



Allow the appliance to cool
before carrying out any
maintenance or cleaning.
Overfiring the appliance may
cause a house fire. If a unit or
chimney connector glows, you
are overfiring.
Maintain the door and glass seal
and keep them in good
condition.
Do not operate this heater with
broken or missing glass.
Avoid placing wood against the
glass when loading. Do not
slam the door or strike the glass.
Do not use a grate or other
device to elevate the fire off of
the firebox floor. Burn the fire
directly on the bricks.
This
Manual
Do not throw this manual away.
This manual has important
operating and maintenance
instructions that you will need at
a later time. Always follow the
instructions in this manual.
Travis Industries, Inc. grants
no warranty, implied or
stated, for the installation or
maintenance of your
appliance,and assumes no
responsibility of any
consequential damage(s).

6 Features & Specifications
© Travis Industries 100-01252_000 4101004
Installation Options
•Freestanding
•Freestanding in an Alcove
•Freestanding in a Mobile Home
Features
•EPA Phase II Approved
•1.6 Cubic Foot Firebox Volume
•Single Operating Control
•Accepts Logs Up to 18" Long
•Steel Plate Construction (1/4" & 3/16")
•Heavy Duty Refractory Firebrick
•Optional High-Tech Blower
Heating Specifications
Approximate Maximum Heating Capacity (in square feet)* 750 to 1,400
Maximum BTU's per Hour (Cord Wood Calculation) 66,800
Maximum Burn Time Up to 8 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
Dimensions
a
29-1/2"
749mm
17-3/8"
441mm
5/8"
16mm
24-1/2"
622mm
5-3/4"
146mm
b
Figure 1
(a) Dimensions are measured from the stove top.
(b) Rubber-Tipped Leveling Bolts (at each corner).
Emissions
4.4 Grams Per Hour (EPA Phase II Approved) – Tests conducted by E.E.S.P.C.

Stove Installation (for qualified installers only) 7
© Travis Industries 100-01252_000 4101004
SAFETYNOTICE:
Please readthis entire manualbefore you installand use your new room heater. Failure tofollow
instructionsmay result inproperty damage, bodilyinjury, or even death. Contact localbuilding orfire
officialsabout restrictionsand installationinspection requirementsin your area.
Planning The Installation
We suggest that you have an authorized Travis Industries dealer install your stove. If you install the
stove yourself, your authorized dealer should review your installation plans.
Check with local building officials for any permits required for installation of this stove and notify your
insurance company before proceeding with installation.
We recommend using a slip-joint connector above the stove. This allows the flue to be disconnected
when removing the door (see “Removing the Door” on page 27).
Preparation for Installation
•Check for damage to the exterior of the stove (dents should be reported, scratches can be fixed by
applying touch up paint).
•Check the interior of the firebox (replace cracked firebrick and make sure baffle is in place).
The stove can be lightened by removing the firebricks and baffle (pg 28) - replace before operation.
Stove Installation Considerations
The table below details the six most common types of installations and the considerations for each type.
Alternative methods of installation are available if they comply with local building codes.
Installation Type Considerations
Standard Ceiling with a Factory Built Chimney
(Page 15) •Requires ceiling and roof penetration
•Provides best draft
Cathedral Ceiling with a Factory Built Chimney
(Page 15) •Cathedral style chimney support required
•Provides best draft
Exterior Factory Built Chimney
(Page 16) •Uses two elbows to route chimney outside
•Exterior chimney is hidden from the room
•Elbows reduce draft
•Optional exterior chase reduces cold air blockage
Hearth Stove Positive Connection
(Page 16) •Utilizes existing masonry or zero clearance (metal) chimney
•Provides good draft due to full reline
•Easier to clean than direct or horizontal hearth stove
Hearth Stove Direct Connection
(Page 17) •Utilizes existing masonry or zero clearance (metal) chimney
•Requires construction of a "block-off plate"
•Draft reduced due to elbows & chimney cross section
Interior Masonry Chimney
(Page 17) •Utilizes existing masonry chimney (not approved for zero
clearance (metal) fireplaces)
Center Divider
The center divider allows the installer to conceal the area
under the stove. It is shipped in the forward position to
allow for outside air and blower connection. If not using
these accessories, it may be moved to the rear to allow
more room under the stove. The divider has keyhole-slots
to ease installation and removal. Pre-thread the screw
holes before installing.
Back of Stove

8 Stove Installation (for qualified installers only)
© Travis Industries 100-01252_000 4101004
Floor Protection Requirements
•Floor protection must extend to the sides, rear, and front of the stove (see “Clearances” below for
minimum floor protection).
•Floor protection must be non-combustible and at least .018" thick (26 guage).
Stove Placement Requirements
Clearances may be reduced by methods specified in NFPA 211, listed wall shields, pipe shields, or
other means approved by local building or fire officials.
•Stove must be placed so that no combustibles are within, or can swing within (e.g. drapes, doors),
36" of the front of the stove
•If the stove is placed in a location where the ceiling height is less than 7', it must follow the
requirements in the section "Alcove Installation Requirements"
•Must maintain the clearances to combustibles listed below (drywall, furniture, etc.):
Clearances
•The following clearances must be met (see Figure 2 and Figure 3)
Minimum Clearance Singlewall
Connector Reduced Clearance*
A Sidewall to stove 18" 13"
B Backwall to stove 16-1/2” 9"
C Cornerwall to stove 10" 7-1/2"
D Connector to sidewall 27" 21-1/2"
E Connector to backwall 19-1/2" 11-1/2"
F Connector to cornerwall 19-1/2" 16-1/2"
G Floor protection side and back 6” US 8” Canada 6” US 8” Canada
H Floor protection front 16” US 18” Canada 16” US 18” Canada
*Reduced clearance installations require one of the chimneys and connectors listed below:
AMERI-TEC model DCC with model HS chimney
DURAVENT model DVL with DURATEC or DURA-PLUS chimney
GSW Super Chimney Twenty-One connected directly to appliance
I.C.C. Excel (2100-2 Can.) (103-HT USA) chimney with HP connector
METALFAB model DW connector with TG chimney
OLIVER MACLEOD PROVENT model PV connector with model 3103 chimney
SECURITY model DP connector with SECURITY model ASHT or S2100 chimney
SELKIRK METALBESTOS model DS connector with model SSII chimney
Standard Masonry Chimney with any one of the above listed connectors
NOTE: Reduced clearance connectors may not connect to the flue collar – an appliance adapter may be required.
NOTE: Standard residential installations with reduced clearance connector may use the clearance
determined by the manufacturer of the connector for the connector to wall clearance or the clearance
listed in this manual. Offsets must be used to maintain the stove to wall clearance.

Stove Installation (for qualified installers only) 9
© Travis Industries 100-01252_000 4101004
Top View -
Straight Installation
(i) Measure rear and side
clearances from the stove
top.
(j) Vent diameter varies
depending on brand and
model.
(k) Measure front
clearances from the stove
top.
































24-1/2"
622mm
17-3/8" 441mm
5-3/4" 146mm
i
j
k
g
g
h
a
b
d
e
Figure 2
Top View -
Corner Installation



































24-1/2"
622mm
17-3/8" 441mm
5-3/4" 146mm
c
f
i
j
k
g
g
h
Figure 3

10 Stove Installation (for qualified installers only)
© Travis Industries 100-01252_000 4101004
Chimney Connector Requirements
•Chimney connector is required from the flue collar of the stove to the factory-built chimney or
masonry chimney.
•The chimney connector must be 6” diameter and a minimum 24 gauge black steel, or one of the
reduced-clearance connectors listed on page 8.
NOTE: Aluminum or galvanized steel is not allowed – these materials can not withstand the flue
temperatures and may give off toxic fumes when heated.
NOTE: Standard residential installations may use single-wall connector (Mobile-Homes may not).
•The chimney connector may not pass through a ceiling, attic, roof, closet, or any other concealed
space (use listed UL 103 HT chimney – see “Chimney Requirements for details). DO NOT USE
CONNECTOR PIPE AS CHIMNEY.
•IN CANADA: Where passage through a wall, or partition of combustible construction is desired, the
installation shall conform to CAN/CSA-B365, Installation Code for Solid-Fuel-Burning Appliances and
Equipment.
•The chimney connector should be as short and direct as possible. No more than 180oof elbows (two
90oelbows, or two 45o& one 90oelbow, etc.) may be used for the entire system (connector and
chimney).. Horizontal runs should slope upwards 1/4” per foot and be a maximum 36” long.
•The chimney connector must be installed with the crimped end pointing downwards. This prevents
creosote from leaking to the exterior of the pipe.
•The chimney connector must be fastened to the stove and each adjoining section (and chimney).
•Standard residential installations may use single-wall connector (Mobile-Homes may not)
•Standard residential installations with reduced clearance connector may use the clearance
determined by the manufacturer of the connector for the connector to wall clearance or the clearance
listed in this manual. Offsets must be used to maintain the stove to wall clearance. Mobile homes
must use the clearances listed in this manual under "Additional Requirements for Mobile Home
Installations".

Stove Installation (for qualified installers only) 11
© Travis Industries 100-01252_000 4101004
Chimney Requirements
•DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
•DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCTWORK
UNLESS SPECIFICALLY APPROVED FOR SUCH INSTALLATIONS
•IN CANADA: This appliance must be connected to a factory-built chimney conforming to CAN/ULC-
S629, Standard for 650°C Factory-Built Chimneys.
•UL 103 HT Chimney must be used from the first ceiling or floor penetration to the chimney cap.
•Use 6" diameter type UL 103 HT chimney from one manufacturer (do not mix brands) or code
approved masonry chimney with a flue liner.
•Chimney must be fastened to each adjoining section.
•Follow the chimney manufacturer's clearances and requirements.
•Use the chimney manufacturer's fire stops, attic guards, roof supports, and flashings when passing
through a ceiling (see “b” below).
•No more than 180oof elbows (two 90oelbows, or two 45o& one 90oelbow, etc.) may be used for the
entire system (connector and chimney).
NOTE: Additional elbows may be allowed if draft is sufficient. Whenever elbows are used the draft is
adversely affected. Additional chimney height may be required to boost draft.
(a) Min. System Height 15’
Max. System Height 33’
(b) Roof Penetration and Termination (see
chimney manufacturer’s requirements)
(c) Chimney Sections
(d) Floor Penetration (see chimney manufacturer’s
requirements)
(e) Min. air space to combustibles (see chimney
manufacturer’s requirements – typically 2”)
(f) Connector – see “Chimney Connector” on the
previous page.











}
}


}
a
b
c
de
f
f
b
Figure 4
Drafting
Performance This appliance relies upon natural draft to operate. External forces, such as wind,
barometric pressure, topography, or factors of the home (negative pressure from exhaust
fans, chimneys, air infiltration, etc.), may adversely affect draft. Travis Industries can not be
responsible for external forces leading to less than optimal performance.

12 Stove Installation (for qualified installers only)
© Travis Industries 100-01252_000 4101004
Chimney Termination Requirements
•Must have an approved cap (to prevent water from entering)
•Must not be located where it will become plugged by snow or other material
•Must terminate at least 3' above the roof and at least 2' above any portion of the roof within 10' (see
Figure 5)
Slanted Roofs
Flat Roofs




Chimney must
extend 3'
above the roof

Chimney must extend 2'
above any portion of the roof
within 10' of the chimney



Chimney must
extend 3'
above the roof
Chimney must extend 2'
above any portion of the roof
within 10' of the chimney
Figure 5
Outside Air Requirements
•Required for mobile homes & in certain localities (check with local building official)
•Must not be drawn from an enclosed space (garage, unventilated crawl space)
•Requires the outside air kit (sku 99200139 – see “a” below). The outside air kit attaches to the
bottom of the stove (see “c” below).
•Outside air duct must have a rodent screen and rain hood (“b”).
•NOTE: Make sure the center divider under the stove is in the farthest forward position (see page 7).









ab
Back of Stove
c
Figure 6

Stove Installation (for qualified installers only) 13
© Travis Industries 100-01252_000 4101004
Alcove Installation Requirements
Whenever the stove is placed in a location where the ceiling height is less than 7' tall, it is considered an
alcove installation. Because of the reduced height, the special installation requirements listed below must
be met.
•Chimney connector and chimney must be one of the following types:
AMERI-TEC model DCC with model HS chimney
DURAVENT model DVL with DURATEC or DURA-PLUS chimney
GSW Super Chimney Twenty-One connected directly to appliance
I.C.C. Excel (2100-2 Can.) (103-HT USA) chimney with HP connector
METALFAB model DW connector with TG chimney
OLIVER MACLEOD PROVENT model PV connector with model 3103 chimney
SECURITY model DP connector with SECURITY model ASHT or S2100 chimney
SELKIRK METALBESTOS model DS connector with model SSII chimney
Standard Masonry Chimney with any one of the above listed connectors
NOTE: Reduced clearance connectors may not connect to the flue collar – an appliance adapter may be required.
•Alcoves are classified as combustible or non-combustible. Non-combustible alcoves must have walls
and a ceiling that are 3 1/2" thick of a non-combustible material (brick, stone, or concrete - see Figure
7). This non-combustible material must be spaced and ventilated at least 1" off of all combustible
materials (walls, ceiling, etc.) to allow air to move around the non-combustible walls and ceiling. All
other alcoves are considered combustible. The clearances below must be met:
Minimum Clearance
(See the Figure 7 below) Combustible Alcove Non-Combustible Alcove
A Sidewall to stove 13" 6"
B Backwall to stove 9" 2"
D Connector to sidewall 21-1/2" 14-1/2"
E Connector to backwall 11-1/2" 4-1/2"
G Maximum depth of alcove 48" 48"
H Minimum width of alcove 49-5/8" 35-5/8"
J Minimum height of alcove 84" 6" above stove top
Non-Combustible Alcove
(a) Non-Combustible (brick)
(b) Air Space with non-combustible
reinforcement
(c) Combustible material
Min. 3 1/2"
(89mm)
Min. 1"
(25mm)
a
c
b
a
b
de
h
j
g
Figure 7

14 Stove Installation (for qualified installers only)
© Travis Industries 100-01252_000 4101004
Mobile Home Requirements
•Outside air must be installed - see "Outside Air Requirements" on page 12
•Chimney connector and chimney must be one of the following types:
AMERI-TEC model DCC with model HS chimney
DURAVENT model DVL with DURATEC or DURA-PLUS chimney
GSW Super Chimney Twenty-One connected directly to appliance
I.C.C. Excel (2100-2 Can.) (103-HT USA) chimney with HP connector
METALFAB model DW connector with TG chimney
OLIVER MACLEOD PROVENT model PV connector with model 3103 chimney
SECURITY model DP connector with SECURITY model ASHT or S2100 chimney
SELKIRK METALBESTOS model DS connector with model SSII chimney
Standard Masonry Chimney with any one of the above listed connectors
NOTE: Reduced clearance connectors may not connect to the flue collar – an appliance adapter may be required.
•Stove placement must maintain the following clearances to combustibles (drywall, furniture, etc.)
a
b
de
c
f
Figure 8
Minimum Clearance
(See the illustration above) Reduced Clearance Connector
A Sidewall to stove 13"
B Backwall to stove 9"
C Cornerwall to stove 7-1/2"
D Connector to sidewall 21-1/2"
E Connector to backwall 11-1/2"
F Connector to cornerwall 16-1/2"
•If using offsets, use the connector clearance listed in Figure 9, not the
connector manufacturer's clearance.
•The appliance must be secured to the floor (consult your building official).
Use an “L” bracket or other suitable means to secure the stove.
•Mobile home installations require a spark arrester at the chimney
termination.
•The appliance must be grounded to the chassis of the mobile home
(consult your building official).
•WARNING:DO NOT INSTALL IN SLEEPING ROOM.
•CAUTION:THE STRUCTURAL INTEGRITY OF THE MOBILE HOME
FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED.
12” Min.
Connector Clearance
(as outlined above)
Stove Clearance
(as outlined above)
Figure 9

Stove Installation (for qualified installers only) 15
© Travis Industries 100-01252_000 4101004
Standard Ceiling
with a Factory
Built Chimney
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)













Chimney Sections
Minimum Air Space to
Combustibles (See
Chimney Manufacturer's
Instructions)
Chimney Connector Sections
Follow the chimney
manufacturer's instructions
and clearances for roof
penetrations. A storm collar
and flashing are required
(some require a radiation
shield).
}
}
Stove Clearances
(See the section "Stove
Placement Requirements"
for more details)
Floor Protection
(See the section "Floor
Protection Requirements"
for more details)
Follow the chimney
manufacturer's instructions
and clearances for floor
penetrations. A ceiling
support is required, an attic
insulation shield is required
where insulation is present.
Insulation
Minimum 15'
(4.57M)
Maximum 33'
(10.05M)
Figure 10
Cathedral Ceiling
with a Factory
Built Chimney
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)





Chimney Sections
Minimum Air Space to
Combustibles (See Chimney
Manufacturer's Instructions)
Follow the chimney
manufacturer's instructions
and clearances for roof
penetrations. A storm
collar, flashing, and
cathedral-style chimney
support are required
(some require a radiation
shield).
}
Minimum 15'
(4.57M)
Maximum 33'
(10.05M)
Stove Clearances
(See the section "Stove
Placement Requirements"
for more details)
Floor Protection
(See the section "Floor
Protection Requirements"
for more details)
Chimney
Connector
Sections
Figure 11

16 Stove Installation (for qualified installers only)
© Travis Industries 100-01252_000 4101004
Exterior Factory
Built Chimney






Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)


Chimney Sections
Minimum Air Space to
Combustibles (See
Chimney Manufacturer's
Instructions)
Chimney Connector
Sections





Follow the chimney
manufacturer's
instructions and
clearances for roof
penetrations. A storm
collar and flashing are
required (some
require a radiation
shield).
}













Stove Clearances
(See the section "Stove
Placement Requirements"
for more details)
}
Follow the chimney
manufacturer's
instructions and
clearances for wall
penetrations. A
wall radiation shield
(thimble) is
required.
Optional
insulated
chase
Wall Bands
and
Supports
Insulated Tee
(with cleanout )
Min. 18"
(457mm)
clearance to
ceiling
Floor Protection
(See "Floor
Protection
Requirements"
for details)
Minimum 15' (4.57M)
Maximum 33' (10.05M)
Figure 12
Hearth Stove
Positive
Connection














Remove damper
or wire it open
Airtight Insulated
Clean-Out
Min. 18"
(457mm)
Combustible
Mantle
NOTE: The entire fireplace and
chimney must be clean, undamaged,
and meet all local building codes
(UBC, etc.). Damage must be
repaired prior to installation. The
chimney must be 15' (4.57M) to 33'
(10.05M) tall.
Floor Protection
(See the section
"Floor Protection
Requirements"
for more details)
See the section
"Stove Placement
Requirements" for
minimum clearances
required.

The liner must be
stainless steel connector
or flexible vent. Follow
the liner manufacturer's
instructions for installation
and support.
Cap and flashing
prevents water from
entering
Figure 13

Stove Installation (for qualified installers only) 17
© Travis Industries 100-01252_000 4101004
Hearth Stove Direct
Connection
NOTE: This type on
installation is not
allowed in Canada.
NOTE:
Direct connections require
installation of an airtight,
non-combustible block-off
plate or damper adapter.












Block-off plate or
damper adapter
Remove damper
or wire it open
Airtight
Insulated
Clean-Out
Stainless steel
chimney connector
must Extend 1' past
the block-off plate or
to the flue liner
NOTE: The chimney must have a clay tile
liner. If it does not, the installation must use
a positive connection (full reline). The entire
fireplace and chimney must be clean,
undamaged, and meet all local building
codes (UBC, etc.). Damage must be
repaired prior to installation. The chimney
must be 15' (4.57M) to 33' (10.05M) tall.
Clay
Liner
Floor Protection
(See the section
"Floor Protection
Requirements" for
more details)
Combustible Mantle
Min. 18"
(457mm)
See the section
"Stove Placement
Requirements" for
minimum clearances
required.
Figure 14
Interior or Exterior
Masonry Chimney
NOTE: This type on
installation is not
allowed in Canada.
NOTE:
This type of installation
requires a UBC approved
masonry connector or
other method approved by
the NFPA 211 standard.
See Chimney Connector
Requirements on page 10
for further details.
Make sure the
clean-out seals in
place.
Clay Liner
See the section "Stove
Placement Requirements" for
minimum clearances required.
Min. 18"
(457mm)
clearance
to ceiling
This type of
installation requires
a UBC approved
masonry connector
or a factory built
(U.L. Listed) wall
thimble.
Chimney connector sections
NOTE: The chimney must have a
clay tile liner. If it does not, the
installation must use a positive
connection (full reline). The entire
fireplace and chimney must be
clean, undamaged, and meet all
local building codes (UBC, etc.).
Damage must be repaired prior to
installation. The chimney must be
15' (4.57M) to 33' (10.05M) tall.
See the section
"Floor Protection
Requirements"
Figure 15

18 Operating Your Appliance
© Travis Industries 100-01252_000 4101004
Safety Notice
If this appliance is not properly installed, a house fire may result. For your safety, follow the installation
directions. Contact local building or fire officials about restrictions and installation inspection
requirements in your area.
Read and follow all of the warnings on pages 4 and 5 of this manual.
Before Your First Fire
Verify the Installation
Before starting the stove, verify that the stove is properly installed and all of the requirements in this
manual have been followed.
Keep all flammable materials 36" away from the front of the stove (drapes, furniture, clothing, etc.).
Curing the Paint
This heater uses a heat-activated paint that will emit some fumes while
starting the first fire. Open doors and windows to the room to vent these
fumes. This typically lasts two to four hours. You may also notice oil burning
off of the interior of the heater. This rust-stopping agent will soon dissipate.
Door Gasket - The door gasket might adhere to the paint on the front of the
heater. Leave the door slightly ajar for the first fire and be careful when
opening the door after the first fire.








2 to 4 hours
Over-Firing the Stove
This stove was designed to operate at a high temperature. But due to differences in vent configuration,
fuel, and draft, this appliance can be operated at an excessive temperature. If the stove top or other area
starts to glow red, you are over-firing the stove. Shut the air control down to low and allow the stove to
cool before proceeding.
Over-firing may lead to damage. If you are uncertain of over-firing conditions, we suggest placing a
stove thermometer (e.g. Rutland® Model 710) directly over the door on the stove top - temperatures
exceeding 800° are generally considered over-firing and will void the warranty.
Opening the Door
Swing
the door
open.
Lift the
door
handle.
The door becomes hot during use. Use a glove to open the door if the handle is hot.
To prevent smoke from entering the room, open the air control before opening the door. You can also
open the door a small amount and let air enter the firebox.

Operating Your Appliance 19
© Travis Industries 100-01252_000 4101004
Starting a Fire
Since the dawn of time man has debated the best way to start a fire. Some use the boy-scout "tee-pee",
some prefer the "tic-tac-toe" stack. Either way, review the hints and warnings below to ensure proper fire
starting.
•Make sure the air control is pushed in. If additional air is needed, open the doors 1/4" during the first
five minutes of start-up.
Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start
or "freshen up" a fire in this stove. Keep all such liquids well away from the stove while it is in use.
DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE. DO NOT BURN GARBAGE OR
FLAMMABLE FLUIDS SUCH AS GASOLINE, NAPHTHA OR ENGINE OIL. Do not place such fuel
within space heater installation clearances or within the space required for charging and ash removal.
If using a firestarter, use only products specifically designed for stoves - follow the manufacturer's
instructions carefully.
HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT
MAY CAUSE SKIN BURNS.
If the smoke does not pass up the chimney, ball up one sheet of newspaper, place it in the center of the
firebox and light it. This should start the chimney drafting (this eliminates "cold air blockage").
Use plenty of kindling to ensure the stove reaches a proper temperature. Once the kindling is burning
rapidly, place a few larger pieces of wood onto the fire.

20 Operating Your Appliance
© Travis Industries 100-01252_000 4101004
Adjusting the Burn Rate
Use the air control slider to control the burn rate of the stove. See the illustration below for details.




Approximate Air Control Settings
Overnight Burn Fully out to 9/32" open
Medium Burn 9/32" to 5/16" open
Medium High Burn 5/16" to 7/16" open
High Burn 7/16" to full in
The air control becomes hot during operation - use gloves or a tool to prevent burns.
The air control may take several minutes to influence the burn rate. When making adjustments, you
may wish to let the stove burn for 10 minutes to gauge performance.
Ash Removal
ASHES
Ashes should be placed in a metal container with a tight fitting lid. The closed container of ashes
should be placed on a noncombustible floor or on the ground, away from all combustible
materials, pending final disposal. If the ashes are disposed of by burial in soil or otherwise locally
dispersed, they should be retained in the closed container until all cinders have thoroughly
cooled.
