Avalue Technology LPC-1009 Series User manual

Part No. E2017L090A2R
LPC-1009/1209/1509/
1709 Series
Fanless Multifunctional Touch Panel Computer
Quick Reference Guide
3rd Ed –02 September 2015
Copyright Notice
Copyright 2015 Avalue Technology Inc., ALL RIGHTS RESERVED.

LPC-1009/1209/1509/1709 Series
2 LPC-1009/1209/1509/1709 Series Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2015 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide
3
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.cn/

LPC-1009/1209/1509/1709 Series
4 LPC-1009/1209/1509/1709 Series Quick Reference Guide
Content
1. Getting Started.................................................................................................5
1.1 Safety Precautions.............................................................................................5
1.2 Packing List.......................................................................................................5
1.3 Document Amendment History............................................................................6
1.3 System Specifications ........................................................................................7
1.4 System Overview............................................................................................. 11
1.4.1 Top View......................................................................................................................11
1.4.2 Bottom View.................................................................................................................11
1.5 System Dimensions .........................................................................................12
1.5.1 LPC-1009 Front and Rear side ......................................................................................12
1.5.2 LPC-1209 Front and Rear side ......................................................................................13
1.5.3 LPC-1509 Front and Rear side ......................................................................................14
1.5.4 LPC-1709 Front and Rear side ......................................................................................15
2. Hardware Configuration................................................................................. 16
2.1 LPC-1009/1209/1509/1709 Series connector mapping .......................................17
2.1.1 Serial port 1 connector (COM1)......................................................................................17
2.1.2 Serial port 2 connector (COM2)......................................................................................18
2.2 Installing Hard Disk & Memory (For LPC-1009/1209)...........................................19
2.3 Installing Hard Disk & Memory (For LPC-1509/1709)...........................................20

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide
5
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord fromyour
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x LPC-1009/1209/1509/1709 Panel PC
1 x Power Cord-
1 x Power Adapter
1 x antenna

LPC-1009/1209/1509/1709 Series
6 LPC-1009/1209/1509/1709 Series Quick Reference Guide
1.3 Document Amendment History
Revision
Date
By
Comment
1st
November 2014
Avalue
Initial Release
2nd
June 2015
Avalue
Update Specifications
3rd
Apr 201
6
Avalue
Update Specifications

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide
7
1.3 System Specifications
Panel
Model
LPC-1009
LPC-1209
LCD size
10.4", 4:3
12.1", 4:3
Display type
XGA TFT
XGA
Resolution 1024 x 768
Pixel pitch
0.0685mm(H) x 0.2055mm(V)
0.240mm(H) x 0.240mm(V)
Luminance
500 cd/m²
600 cd/m²
Contrast ratio
1200
700
Viewing angle
88(U), 88(D), 88(L), 88(R)
70(U), 70(D), 80(L), 80(R)
Response time
25 ms
16 ms
Backlight
LED
Touch type
5 Wires resistive
Touch Light
transmission
80
Touch interface
USB (EETI)
System
Board
EBM-BYT
CPU
Onboard Intel® Atom Quad-Core E3845 1.91GHz with Integrated Chipset
I/O Chipset
E/C IT8528E
System Memory
One 204-pin DDR3L SODIMM Socket Supports Up to 8GB DDR3L 1333 SDRAM
SSD
One CompactFlash Type I/ II Socket
Hard Driver Bay
One 2.5" SATA HDD
Watchdog Timer
H/W Reset, 1sec. ~ 65535sec./1sec.step
H/W Status
Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto throttling
control when CPU overheats
Expansion
1 x mPCIe with SIM Slot, 1 x mPCIe Supports mSATA
Rear I/O
Serial Port
1 x RS-232
Ethernet
2 x RJ-45
HDMI
1 x HDMI
Audio Port
1 x Line-out
USB
1 x USB 3.0, 1 xUSB 2.0 (Optional Extra 2 x USB 2.0)
Display
Chipset
Intel Bay Trail SoC Integrated Graphics
Resolution
HDMI 1.4a resolutions up to 1920 x 1200@ 60 24bpp
Dual Display LVDS + HDMI

LPC-1009/1209/1509/1709 Series
8 LPC-1009/1209/1509/1709 Series Quick Reference Guide
Audio
AC97 Codec
Realtek ALC892 supports 5.1-CH Audio
Audio Interface
Connector: Line out
Ethernet
LAN Chip
Dual Intel I210IT PCI-E Gigabit LAN
Ethernet
Interface
10/100/1000 Base-Tx Fast Ethernet compatible
Mechanical & Environment
Color
Front Silver & Rear panel Black
Mounting
Wall/Stand/VESA 75 mm x 75 mm
System Power
Requirement
+12 V ~ +26 V
Power Adapter
Input: 100~240 Vac/ 50~60 Hz
Output: +12 Vdc / 5 A (60W)
Power Type
AT/ATX
Operating Temp.
-20°C ~ 60°C (-4°F ~ 140°F)
Storage Temp.
-30 to 70°C
Operating
Humidity
0% ~ 90% Relative Humidity, Non-condensing
Dimensions
259 x 196 x 41 mm
283 x 222 x 45 mm
Weight
2.11 Kgs
2.84 Kgs

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide
9
Panel
Model
LPC-1509
LPC-1709
LCD size
15", 4:3
17", 4:3
Display type
XGA
SXGA
Resolution
1024 x 768
1280 x 1024
Pixel pitch
0.297mm(H) x 0.297mm(V)
0.264mm(H) x 0.264mm(V)
Luminance
400 cd/m²
350 cd/m²
Contrast ratio
700
800
Viewing angle
70(U), 70(D), 80(L), 80(R)
60(U), 80(D), 80(L), 80(R )
Response time
16 ms
30 ms
Backlight
LED
Touch type
5 Wires resistive
Touch Light
transmission
80
Touch
interface
USB (EETI)
System
Board
EMX-BYT2
CPU
Onboard Intel® Atom Quad-Core J1900 2.0GHz with Integrated Chipset
I/O Chipset
E/C IT8528E
System
Memory
2 x 204-pin DDR3L SODIMM Socket Supports Up to 8GB DDR3L 1333 SDRAM
Hard Driver
Bay
One 2.5" SATA Support HDD or SSD
Watchdog
Timer
H/W Reset, 1sec. ~ 65535sec./1sec.step
H/W Status
Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto throttling control
Expansion
1 x Mini PCIe Slot, Support mSATA,1SD card slot support
Rear I/O
Serial Port
Ethernet
2 x RJ-45
HDMI/VGA
1 x HDMI,1 x VGA
Audio Port
1 x Line
-out,1 x Mic
USB
4 x USB 3.0, 1 x USB 2.0(Options)
Speaker
2 x 1W(Options)
Display
Chipset
Intel Celeron SoC Integrated Graphics
SD/SDHC card,1 x SIM card slot
1 x RS-232/422/485,2 x RS-232
GPIO
1 x GPIO connector

LPC-1009/1209/1509/1709 Series
10 LPC-1009/1209/1509/1709 Series Quick Reference Guide
Resolution
HDMI 1.4a resolutions up to 1920x1200@ 60 24bpp
Dual Display
LVDS + HDMI,LVDS + VGA,HDMI + VGA
Audio
AC97 Codec
Realtek ALC662 supports 5.1-CH Audio
Ethernet
LAN Chip
Dual Intel I211AT-Gigabit Ethernet
Ethernet
Interface
10/100/1000 Base-Tx Fast Ethernet compatible
Mechanical & Environment
Color
Front Silver & Rear panel Black
Mounting
Wall/Stand/VESA
75 mm x 75 mm,100mm x 100mm
System Power
Requirement
DC+12 V
Power Adapter
Input: 100~250 Vac/ 47~63 Hz
Output: +12 Vdc / 5 A (60W)
Power Type
AT/ATX
Operating
Temp.
0°C ~ 60°C
Storage Temp.
-30 to 80°C
Operating
Humidity
5% ~ 90% Relative Humidity, Non-condensing
Dimensions
350 x 273.9 x 62 mm
382 x 320.4 x 68 mm
Weight
4.2 Kgs
5.84 Kgs
Note: Specificationsare subject to change without notice.

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide 11
1.4 System Overview
1.4.1 Top View
LPC-1009/1209
LPC-1509/1709
Connectors
Label Function Note
POWER Power on button
COM1-3
Serial port 1-3 connector
DB-9 male connector
Audio Port 1x Line-out,1 x Mic
USB 1 x USB 2.0 connector
4 x USB 3.0 connector
Dock USB
LAN1-2 RJ-45 Ethernet connector 1-2
VGA/HDMI VGA/HDMI connector
DC-IN DC Power-in connector
GPIO GPIO connector DB 9 male connector
Power Button Power switch
1.4.2 Bottom View

LPC-1009/1209/1509/1709 Series
12 LPC-1009/1209/1509/1709 Series Quick Reference Guide
1.5 System Dimensions
1.5.1 LPC-1009 Front and Rear side
(Unit: mm)
(The I/O will be justified without notice)

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide
13
1.5.2 LPC-1209 Front and Rear side
(Unit: mm)
(The I/O will be justified without notice)

LPC-1009/1209/1509/1709 Series
14 LPC-1009/1209/1509/1709 Series Quick Reference Guide
1.5.3 LPC-1509 Front and Rear side
(Unit: mm)
(The I/O will be justified without notice)

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide
15
1.5.4 LPC-1709 Front and Rear side
(Unit: mm)
)ecitontuohtiwdeifitsujeblliwO/IehT(

LPC-1009/1209/1509/1709 Series
16 LPC-1009/1209/1509/1709 Series Quick Reference Guide
2.Hardware
Configuration
For advanced information, please refer to:
1- EMX-BYT2 User’s Manual
Note: If youneed more information, please visit our website:
http://www.avalue.com.cn

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide 17
2.1 LPC-1009/1209/1509/1709 Series connector mapping
2.1.1 Serial port 1 connector (COM1)
2.1.2 Serial port 2 connector (COM2-3)
Signal PIN PIN Signal
DCD 1 6 DSR
RXD 2 7 RTS
TXD 3 8 CTS
DTR 4 9 RI
GND 5
RS-232
Signal PIN PIN Signal
DCD 1 6 DSR
RXD 2 7 RTS
TXD 3 8 CTS
DTR 4 9 RI
GND 5
RS-422/485

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide
18
2.1 LPC-1009/1209/1509/1709 Series connector mapping
2.1.3 GPIO port 1 connector (GPIO )
Signal PIN PIN Signal
GPIO1 1 6 GPIO6
GPIO2 2 7 GPIO7
GPIO3 3 8 GPIO8
GPIO4 4 9 +5V
GPIO5 5
GPIO
GND(CASE)
Lockable DC Jack +12
2.1.3 DC-IN port connector (DC-IN)

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide 19
2.2 Installing Hard Disk & Memory (For LPC-1009/1209)
Unfasten 6 screws from the case. Then take off the top chassis.
VESA installation

Quick Reference Guide
LPC-1009/1209/1509/1709 Series Quick Reference Guide
20
2.3 Installing Hard Disk & Memory (For LPC-1509/1709)
Unfasten 6 screws from the case to take off the top chassis.
VESA installation
