Avalue Technology ECM-KA User manual

Part No. E2047391601R
ECM-KA
AMD G-Series SoC Platform
3.5” Micro Module
User’s manual
2nd Ed –29 October 2013

ECM-KA User’s Manual
2 ECM-KA User’s Manual
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2013 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that
these products are free from patent, copyright, or mask work right infringement, unless

ECM-KA User’s Manual
ECM-KA User’s Manual 3
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

ECM-KA User’s Manual
4 ECM-KA User’s Manual
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example,
CPU type and speed, Avalue’s products model name, hardware & BIOS
revision number, other hardware and software used, etc.) Note anything
abnormal and list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material
authorization) number from your dealer. This allows us to process your good
return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales
receipt) in a shippable container. A product returned without proof of the
purchase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it
prepaid to your dealer.

ECM-KA User’s Manual
ECM-KA User’s Manual 5
Content
1. Getting Started............................................................................................................8
1.1 Safety Precautions .........................................................................................8
1.2 Packing List....................................................................................................8
1.3 Document Amendment History.......................................................................9
1.4 Manual Objectives........................................................................................10
1.5 System Specifications ..................................................................................11
1.6 Architecture Overview –Block Diagram.......................................................13
2. Hardware Configuration...........................................................................................14
2.1 Product Overview.........................................................................................15
2.2 Installation Procedure...................................................................................17
2.2.1 Main Memory ........................................................................................18
2.3 Jumper and Connector List ..........................................................................20
2.4 Setting Jumpers & Connectors.....................................................................22
2.4.1 Clear CMOS (JPCMOS1)......................................................................22
2.4.2 Touch connector select jumper (JTOUCH_SEL) (option)......................22
2.4.3 LCD backlight brightness adjustment (JVR1)........................................23
2.4.4 AT/ ATX Input power select (JAT1).......................................................23
2.4.5 COM 1 pin 9 signal select (JRI1)...........................................................24
2.4.6 5VSB connector in ATX (PWR_SB1)....................................................24
2.4.7 Battery connector (BAT1)......................................................................25
2.4.8 CPU fan connector (CPU_FAN1)..........................................................25
2.4.9 System fan connector (SYS_FAN1)......................................................26
2.4.10 COM 1 RS-422-485 mode (J422/1) ......................................................26
2.4.11 LCD inverter connector (JBKL1) ...........................................................27
2.4.12 Low pin count connector (JLPC1).........................................................27
2.4.13 Audio connector (JAUDIO1)..................................................................28
2.4.13.1 Signal Description –Audio connector (JAUDIO1)...................28
2.4.14 Serial port 2 connector (JCOM2)...........................................................29
2.4.15 General purpose I/O connector (DIO1) .................................................29
2.4.16 Miscellaneous setting connector (JFP1)................................................30
2.4.17 SPI connector (JSPI1)...........................................................................30
2.4.18 EC_Program (EC_SPI1) .......................................................................31
2.4.19 Power connector (PWR_IN1)................................................................31
2.4.20 HDD power connector (HD_PWR1)......................................................32
2.4.21 Touch connector (JTOUCH1) (option)...................................................32

ECM-KA User’s Manual
6 ECM-KA User’s Manual
2.4.22 LVDS connector (JLVDS1)....................................................................33
2.4.23 On-board box header for USB2.0 (JUSB1)...........................................34
2.4.24 On-board box header for USB2.0 (JUSB2) ...........................................34
2.4.25 On-board box header for USB2.0 (JUSB3) ...........................................35
2.4.26 PS/2 keyboard & mouse connector (JKBMS)........................................35
3. BIOS Setup...................................................................................................................36
3.1 Introduction...................................................................................................37
3.2 Starting Setup...............................................................................................37
3.3 Using Setup..................................................................................................38
3.4 Getting Help .................................................................................................39
3.5 In Case of Problems.....................................................................................39
3.6 BIOS setup...................................................................................................40
3.6.1 Main Menu ............................................................................................40
3.6.1.1 System Language...................................................................40
3.6.1.2 System Date ...........................................................................40
3.6.1.3 System Time...........................................................................40
3.6.2 Advanced Menu ....................................................................................41
3.6.2.1 PCI Subsystem Settings .........................................................41
3.6.2.1.1 PCI Express Settings..............................................................42
3.6.2.2 S5 RTC Wake Settings...........................................................44
3.6.2.3 APCI Settings..........................................................................44
3.6.2.4 CPU Configuration..................................................................45
3.6.2.4.1 Node 0 Information .................................................................46
3.6.2.5 IDE Configuration....................................................................47
3.6.2.6 USB Configuration..................................................................47
3.6.2.7 SMART Settings .....................................................................48
3.6.2.8 Super IO Configuration ...........................................................49
3.6.2.8.1 Serial Port 0 Configuration......................................................50
3.6.2.8.2 Serial Port 1 Configuration......................................................51
3.6.2.9 H/W Monitor............................................................................52
3.6.2.10 UEFI PXE................................................................................52
3.6.2.11 Network Stack.........................................................................53
3.6.3 Chipset................................................................................................54
3.6.3.1 GFX Configuration ................................................................54
3.6.3.2 South Bridge .........................................................................56
3.6.3.2.1 SB SATA Configuration.........................................................56
3.6.3.2.2 SB USB Configuration...........................................................57
3.6.3.2.3 SB HD Azalia Configuration...................................................58
3.6.3.3 North Bridge............................................................................59
3.6.3.3.1 Memory Configuration ...........................................................59

ECM-KA User’s Manual
ECM-KA User’s Manual 7
3.6.3.3.2 Socket 0 Information ...............................................................60
3.6.4 Boot.....................................................................................................61
3.6.4.1 CSM16 Parameters ................................................................62
3.6.4.2 CSM Parameters ....................................................................63
3.6.5 Security ...............................................................................................64
3.6.6 Save and exit.......................................................................................64
3.6.6.1 Save Changes and Reset.......................................................65
3.6.6.2 Discard Changes and Reset...................................................65
3.6.6.3 Restore Defaults.....................................................................65
3.6.6.4 Launch EFI Shell from filesystem device ................................65
4. Drivers Installation.......................................................................................................66
4.1 Install VGA/Chipset Driver............................................................................67
4.2 Install Audio Driver (For Realtek ALC892)....................................................68
4.3 Install Ethernet Driver (For Realtek 8111E)..................................................69
5. Mechanical Drawing ....................................................................................................70

ECM-KA User’s Manual
8 ECM-KA User’s Manual
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x 3.5” ECM-KA Micro Module
1 x Quick Installation Guide for ECM-KA
1 x AUX-032 daughter board W/Audio/4USB
1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
1 x Cable set contains the followings:
—1 x Audio cable (12pin,2.0 pitch)
—1 x USB 2.0 cable (10P/2.0mm-10P/2.0mm)
—1 x Serial ATA cable (7-pin, standard)
—1 x Wire SATA power cable (15-pin,4P/2.5mm)
—1 x Flat cable 9P(M)-PHD 10P/2.0mm)
3M foam (VHB-4622 10mm*20mm*1.1mm)

ECM-KA User’s Manual
ECM-KA User’s Manual 9
1.3 Document Amendment History
Revision
Date
Comment
1st
September 2013
Initial Release
2nd
October 2013
Update Drivers Installation

ECM-KA User’s Manual
10 ECM-KA User’s Manual
1.4 Manual Objectives
This manual describes in detail the Avalue Technology ECM-KA Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to interface
with ECM-KA series or change the standard configurations. Whilst all the necessary
information is available in this manual we would recommend that unless you are confident,
you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors concerning this manual and want to inform
us of these, please contact our Customer Service department with the relevant details.

ECM-KA User’s Manual
ECM-KA User’s Manual 11
1.5 System Specifications
System
CPU
On board AMD Embedded G-Series BGA SoC
BIOS
AMI uEFI BIOS, 32Mbit SPI Flash ROM
System Chipset
AMD SoC APU integrated chips
I/O Chip
ITE8518VG
System Memory
1 x 204-pin s DDR3 SODIMM up to 8GB DDR3 1600 SDRAM
SSD
1 x CompactFlash Type I/II socket (support InnoDisk CF-SATA)
Watchdog Timer
H/W Reset, 1sec. –65535sec.
H/W Status
Monitor
CPU & system temperature monitoring
Voltages monitoring
Expansion
1 x mini-PCIe (mSATA supported)
Display
Chipset
AMD SoC APU integrated Graphics
Resolution
CRT Mode: 1920 x 1200 @ 60Hz
HDMI Mode: 1920 x 1080 @ 60Hz
LCD/ Simultaneous Mode: 1920 x 1080 @ 60Hz (Through eDP)
Multiple Display
CRT ＋LVDS, HDMI ＋LVDS, CRT ＋HDMI
LCD Interface
Dual-channel 18/ 24-bit LVDS
Ethernet
Chipset
2 x RTL8111E Gigabit Ethernet
Ethernet Interface
10/100/1000 Base-Tx compatible
Audio
Chipset
Realtek ALC892 support 5.1 –CH Audio
Audio Interface
Mic-In, Line-In and Line-Out
I/O
MIO
2 x SATA III
2 x serial (COM2 with 5x2 pitch 2.0mm wafer connector, One COM can be set as
RS-232/422/485(4-wire)selectable by BIOS
1 x K/B & Mouse
USB
2x USB 3.0, 6xUSB 2.0
DIO
4-bit GPI,4-bit GPO
Built-in Touch
screen (optional)
Chipset
PenMount 6000
Touch screen
interface
With 9-pin 2.0mm Box Header (can be selected to support 4/5/8 wire touch screen)

ECM-KA User’s Manual
12 ECM-KA User’s Manual
Mechanical &
Environmental
Power Requirement
+12V~+26V
Power Type
AT/ATX
ACPI
Single power ATX Support S0,S3,S5
ACPI 3.0 Compliant
Operating Temp.
0°C ~ 60°C
Storage Temp.
-40°C ~ 75°C
Operating Humidity
0%~90% relative humidity, non-condensing
Size (L x W)
5.7" x 4" (146mm x 101mm)
Weight
0.44lbs (0.2kg)

ECM-KA User’s Manual
ECM-KA User’s Manual 13
1.6 Architecture Overview –Block Diagram
The following block diagram shows the architecture and main components of ECM-KA.

ECM-KA User’s Manual
14 ECM-KA User’s Manual
2.Hardware
Configuration

ECM-KA User’s Manual
ECM-KA User’s Manual 15
2.1 Product Overview

ECM-KA User’s Manual
16 ECM-KA User’s Manual

ECM-KA User’s Manual
ECM-KA User’s Manual 17
2.2 Installation Procedure
This chapter explains you the instructions of how to setup your system.
1. Turn off the power supply.
2. Insert the SODIMM module (be careful with the orientation).
3. Insert all external cables for hard disk, floppy, keyboard, mouse, USB etc. except for flat
panel. A CRT monitor must be connected in order to change CMOS settings to support
flat panel.
4. Connect power supply to the board via the ATXPWR.
5. Turn on the power.
6. Enter the BIOS setup by pressing the delete key during boot up. Use the “LOAD BIOS
DEFAULTS” feature. The Integrated Peripheral Setup and the Standard CMOS Setup
Window must be entered and configured correctly to match the particular system
configuration.
7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before
connecting the display cable and turning on the power.
Note: Make sure the heat sink and the CPU top surface are in total contact to
avoid CPU overheating problem that would cause the system to hang or
unstable

ECM-KA User’s Manual
18 ECM-KA User’s Manual
2.2.1 Main Memory
ECM-KA provides one 204-pin DDR3L SODIMM socket, supports up to 8GB DDR3L 1600
SDRAM.
(Rear side)
Make sure to unplug the power supply before adding or removing SODIMMs
or other system components. Failure to do so may cause severe damage to
both the board and the components.
Locate the SODIMM socket on the board.
Hold two edges of the SODIMM module carefully. Keep away of touching its
connectors.
Align the notch key on the module with the rib on the slot.
Firmly press the modules into the socket automatically snaps into the mounting notch.
Do not force the SODIMM module in with extra force as the SODIMM module only fit
SODIMM

ECM-KA User’s Manual
ECM-KA User’s Manual 19
in one direction.
To remove the SODIMM modules, push the two ejector tabs on the slot outward
simultaneously, and then pull out the SODIMM module.
Note:
(1) Please do not change any DDR3 SDRAM parameter in BIOS setup to increase
your system’s performance without acquiring technical information in advance.
(2) Static electricity can damage the electronic components of the computer or
optional boards. Before starting these procedures, ensure that you are
discharged of static electricity by touching a grounded metal object briefly.

ECM-KA User’s Manual
20 ECM-KA User’s Manual
2.3 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label
Function
Note
JPCMOS1
Clear CMOS
3 x 1 header, pitch 2.54 mm
JTOUCH_SEL
Touch connector select jumper
(option)
3 x 1 header, pitch 2.54 mm
JVR1
LCD backlight brightness adjustment
3 x 1 header, pitch 2.54 mm
JRI1
COM 1 pin 9 signal select
3 x 2 header, pitch 2.00 mm
JAT1
AT/ ATX Input power select
3 x 1 header, pitch 2.00 mm
Connectors
Label
Function
Note
JTOUCH1
Touch connector (option)
9 x 1 wafer, pitch 2.00 mm
BAT1
Battery connector
2 x 1 wafer, pitch 1.25 mm
CPU_FAN1
CPU fan connector
4 x 1 wafer, pitch 2.54 mm
