Avalue Technology ECM-US15WP User manual

Part No. 2047381800R
ECM-US15WP
3.5" Intel® Atom™ processor Z510P / Z530P Micro Module
User’s Manual
1st Ed – 13 October 2009

ECM-US15WP
2 ECM-US15WP User’s Manual
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Copyright Notice
Copyright 2009 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.

User’s Manual
ECM-US15WP User’s Manual
3
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose failure
to perform can be reasonably expected to cause the failure of the life support device or
system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.

ECM-US15WP
4 ECM-US15WP User’s Manual
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/
Headquarters and Branch
Avalue Technology Inc.
7F, 228, Lian-cheng Road, Chung Ho City, Taipei, Taiwan
Tel: [phone] Fax: [phone]
Information: [email protected] Service:[email protected]
Avalue USA Avalue Europe
Avalue Technology Inc.
200 Tornillo Way, Suite 210, Tinton Falls,
NJ 07712
Tel: [phone]
Fax: [phone]
Information: [email protected]
Service: [email protected]
Avalue Europe A/S
Moelledalen 22C, 3140
Aalsgaarde, Denmark
Tel: [phone]
Fax:[phone]
Information: [email protected]
Service: [email protected]
BCM Advanced Research Avalue China
BCM Advanced Research
an Avalue Company
7 Marconi, Irvine, CA92618
Tel: [phone]
Fax: [phone]
Information: [e-mail]
Web: www.bcmcom.com
Avalue Technology Inc.
Room 805, Building 9,No.99 Tianzhou Rd.,
Caohejing Development Area,
Xuhui District, Shanghai
Tel: [phone]
Fax:[phone]
Information: [e-mail]
Service: [email protected]

User’s Manual
ECM-US15WP User’s Manual
5
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU type and
speed, Avalue’s products model name, hardware & BIOS revision number, other
hardware and software used, etc.) Note anything abnormal and list any on-screen
messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any
helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material authorization)
number from your dealer. This allows us to process your good return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement Order Card
and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your
dealer.
If you still cannot find the answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our dealers are well trained
and ready to give you the support you need to get the most from your Avalue’s products. In
fact, most problems reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Avalue’s engineers every business day.
We are always ready to give advice on application requirements or specific information on
the installation and operation of any of our products. Please do not hesitate to call or e-mail
us.

ECM-US15WP
6 ECM-US15WP User’s Manual
Contents
1. Getting Started..........................................................................................................10
1.1 Safety Precautions ..................................................................................................10
1.2 Packing List.............................................................................................................10
1.3 Document Amendment History ...............................................................................11
1.4 Manual Objectives...................................................................................................12
1.5 System Specifications .............................................................................................13
1.6 Architecture Overview – Block Diagram..................................................................15
2. Hardware Configuration...........................................................................................16
2.1 Product Overview....................................................................................................17
2.2 Installation Procedure .............................................................................................18
2.3 Jumper and Connector List .....................................................................................19
2.4 Setting Jumpers & Connectors ...............................................................................21
2.4.1 Clear CMOS (JABT1)..................................................................................................................... 21
2.4.2 CF Card mode select (JCF1) ......................................................................................................... 21
2.4.3 Touch Panel mode select (JTOUCH1)........................................................................................... 22
2.4.4 AT/ATX power mode select (PWR_SEL1)..................................................................................... 22
2.4.5 Serial port 1 – Ring, +5V, +12V power select (RI1) ....................................................................... 23
2.4.6 Serial port 2 – Ring, +5V, +12V power select (RI2) ....................................................................... 23
2.4.7 ATX power connector (ATXPW1) .................................................................................................. 24
2.4.8 Battery connector (BBAT1) ............................................................................................................ 24
2.4.9 Serial Port 1 connector (COM1)..................................................................................................... 25
2.4.10 Serial Port 2 connector (COM2) ................................................................................................ 25
2.4.11 Digital Input/ Output connector (DIO1) ...................................................................................... 26
2.4.12 Primary IDE connector (IDE1) ................................................................................................... 27
2.4.13 IrDA connector (IR1) .................................................................................................................. 28
2.4.14 Audio connector (JAUDIO1) ...................................................................................................... 28
2.4.15 LCD inverter power connector (J1)............................................................................................ 29
2.4.16 Serial port 2 in RS-422/485 mode (J422/485) ........................................................................... 29
2.4.17 LCD Inverter Connector (JBKL1)............................................................................................... 30
2.4.17.1 Signal Description – LCD Inverter Connector (JBKL1) ......................................................... 30
2.4.18 CD-ROM audio input Connector (JCD1) ................................................................................... 31
2.4.19 Keyboard & mouse connector (JKB/MS) ................................................................................... 31
2.4.20 LVDS connector (JLVDS1) ........................................................................................................ 32
2.4.21 USB connector 5&6 (JUSB1) .................................................................................................. 32
2.4.22 LCD backlight brightness adjustment (JVR1) ............................................................................ 33
2.4.23 Power connector (PWRCON1) .................................................................................................. 33
2.4.24 SDIO connector (SDIO_J1) ....................................................................................................... 34

User’s Manual
ECM-US15WP User’s Manual
7
2.4.25 SDIO connector (SDIO_J2) ....................................................................................................... 34
2.4.26 Touch panel connector (TOUCH1) ............................................................................................ 35
2.4.27 SDVO port connector (JSDVO1) ............................................................................................... 35
2.4.27.1 SDVO to DVI/ LVDS/ CRT ............................................................................................................ 36
SDVO to DVI (V_DVI1) ............................................................................................................................... 36
SDVO to LVDS (V_LVDS1)......................................................................................................................... 36
3. BIOS Setup...................................................................................................................37
3.1 Starting Setup .........................................................................................................38
3.2 Using Setup ............................................................................................................39
3.3 Getting Help ............................................................................................................40
3.4 In Case of Problems................................................................................................40
3.5 Main Menu ..............................................................................................................41
3.5.1 Standard CMOS Features.............................................................................................................. 42
3.5.1.1 Main Menu Selection .............................................................................................................42
3.5.1.2 IDE Adapter Setup................................................................................................................. 43
3.5.2 Advanced BIOS Features .............................................................................................................. 44
3.5.2.1 CPU Feature.......................................................................................................................... 44
3.5.2.2 Hard Disk Boot Priority .......................................................................................................... 45
3.5.2.3 Virus Warning ........................................................................................................................ 45
3.5.2.4 CPU L1 & L2 & L3 Cache...................................................................................................... 46
3.5.2.5 Hyper-Threading Technology ................................................................................................ 46
3.5.2.6 Quick Power On Self Test ..................................................................................................... 46
3.5.2.7 First/Second/Third/Other Boot Device................................................................................... 46
3.5.2.8 Boot Up NumLock Status ...................................................................................................... 46
3.5.2.9 Gate A20 Option.................................................................................................................... 46
3.5.2.10 Typematic Rate Setting ......................................................................................................... 47
3.5.2.11 Typematic Rate (Chars/Sec) ................................................................................................. 47
3.5.2.12 Typematic Delay (Msec)........................................................................................................ 47
3.5.2.13 Security Option ...................................................................................................................... 47
3.5.2.14 APIC Mode ............................................................................................................................ 47
3.5.2.15 MPS Version Control For OS ................................................................................................ 48
3.5.2.16 OS Select for DRAM > 64MB ................................................................................................ 48
3.5.2.17 Report No FDD For WIN95 ................................................................................................... 48
3.5.2.18 Small Logo (EPA) Show ........................................................................................................ 48
3.5.3 Advanced Chipset Features........................................................................................................... 49
3.5.3.1 System BIOS Cacheable....................................................................................................... 49
3.5.3.2 Video BIOS Cacheable.......................................................................................................... 50
3.5.3.12 VGA Setting ........................................................................................................................... 50
3.5.4 Integrated Peripherals.................................................................................................................... 50
3.5.4.1 OnChip IDE Device ...............................................................................................................51

ECM-US15WP
8 ECM-US15WP User’s Manual
3.5.4.1 Onboard Device..................................................................................................................... 52
3.5.4.2 Watch Dog Timer................................................................................................................... 53
3.5.4.3 USB Device Setting ............................................................................................................... 53
3.5.5 Power Management Setup............................................................................................................. 54
3.5.5.1 PCI Express PM Function ..................................................................................................... 54
3.5.5.2 ACPI Function........................................................................................................................ 55
3.5.5.3 ACPI Suspend Type .............................................................................................................. 55
3.5.5.4 Soft-Off by PWR-BTTN ......................................................................................................... 55
3.5.5.5 HEPT Feature........................................................................................................................ 55
3.5.6 PnP / PCI Configuration ................................................................................................................. 56
3.5.6.1 Reset Configuration Data ...................................................................................................... 57
3.5.6.2 Resources Controlled By....................................................................................................... 57
3.5.6.3 PCI / VGA Palette Snoop ...................................................................................................... 57
3.5.6.4 Maximum Payload Size ......................................................................................................... 57
3.5.7 PC Health Status............................................................................................................................ 58
3.5.8 Frequency/Voltage control ............................................................................................................. 58
3.5.9 Load Fail-Safe Defaults.................................................................................................................. 58
3.5.10 Load Optimized Defaults............................................................................................................ 59
3.5.11 Set Supervisor / User Password ................................................................................................ 60
3.5.12 Save & Exit Setup ...................................................................................................................... 62
3.5.13 Exit Without Save....................................................................................................................... 63
4. Drivers Installation.......................................................................................................64
4.1 Install Chipset Driver (For Intel US15WP)...............................................................65
4.2 Install Display Driver (For Intel 945GSE) ................................................................66
4.3 Install Ethernet Driver (For Intel® 82574L Gigabit LAN) .........................................67
4.4 Install Audio Driver (For Realtek ALC883) ..............................................................69
5. Mechanical Drawing ....................................................................................................70
Appendix A: AWARD BIOS POST Messages ................................................................73
Overview............................................................................................................................74
Post Beep ..........................................................................................................................74
Error Messages .................................................................................................................74
1. CMOS BATTERY HAS FAILED .........................................................................................................74
2. CMOS CHECKSUM ERROR .............................................................................................................74
3. DISK BOOT FAILURE, INSERT SYSTEM DISK AND PRESS ENTER ............................................ 74
4. DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP.............................................. 74
5. DISPLAY SWITCH IS SET INCORRECTLY...................................................................................... 75
6. DISPLAY TYPE HAS CHANGED SINCE LAST BOOT ..................................................................... 75
7. EISA Configuration Checksum Error PLEASE RUN EISA CONFIGURATION UTILITY................... 75
8. EISA Configuration Is Not Complete PLEASE RUN EISA CONFIGURATION UTILITY ................... 75
9. ERROR ENCOUNTERED INITIALIZING HARD DRIVE.................................................................... 75

User’s Manual
ECM-US15WP User’s Manual
9
10. ERROR INITIALIZING HARD DISK CONTROLLER ..................................................................... 75
11. FLOPPY DISK CNTRLR ERROR OR NO CNTRLR PRESENT ................................................... 75
12. Invalid EISA Configuration PLEASE RUN EISA CONFIGURATION UTILITY .............................. 76
13. KEYBOARD ERROR OR NO KEYBOARD PRESENT ................................................................. 76
14. Memory Address Error at ... ........................................................................................................... 76
15. Memory parity Error at ................................................................................................................... 76
16. MEMORY SIZE HAS CHANGED SINCE LAST BOOT ................................................................. 76
17. Memory Verify Error at ... ............................................................................................................... 76
18. OFFENDING ADDRESS NOT FOUND ......................................................................................... 76
19. OFFENDING SEGMENT: ..............................................................................................................76
20. PRESS A KEY TO REBOOT ......................................................................................................... 76
21. PRESS F1 TO DISABLE NMI, F2 TO REBOOT ........................................................................... 77
22. RAM PARITY ERROR - CHECKING FOR SEGMENT ... ............................................................. 77
23. Should Be Empty But EISA Board Found PLEASE RUN EISA CONFIGURATION UTILITY....... 77
24. Should Have EISA Board But Not Found PLEASE RUN EISA CONFIGURATION UTILITY ....... 77
25. Slot Not Empty ............................................................................................................................... 77
26. SYSTEM HALTED, (CTRL-ALT-DEL) TO REBOOT ... ................................................................. 77
27. Wrong Board In Slot PLEASE RUN EISA CONFIGURATION UTILITY........................................ 77
28. FLOPPY DISK(S) fail (80) Unable to reset floppy subsystem................................................... 78
29. FLOPPY DISK(S) fail (40) Floppy Type dismatch..................................................................... 78
30. Hard Disk(s) fail (80) HDD reset failed.................................................................................... 78
31. Hard Disk(s) fail (40) HDD controller diagnostics failed.......................................................... 78
32. Hard Disk(s) fail (20) HDD initialization error.......................................................................... 78
33. Hard Disk(s) fail (10) Unable to recalibrate fixed disk............................................................. 78
34. Hard Disk(s) fail (08) Sector Verify failed................................................................................ 78
35. Keyboard is locked out - Unlock the key. ....................................................................................... 78
36. Keyboard error or no keyboard present. ........................................................................................ 78
37. Manufacturing POST loop.............................................................................................................. 78
38. BIOS ROM checksum error - System halted. ................................................................................ 78
39. Memory test fail. ............................................................................................................................. 78
40. POST Codes .................................................................................................................................. 78
40.1 Normal POST Code ................................................................................................................... 79
40.2 Quick POST Codes.................................................................................................................... 85
40.3 S4 POST Codes ........................................................................................................................ 87
40.4 BootBlock POST Codes............................................................................................................. 88

ECM-US15WP
10 ECM-US15WP User’s Manual
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
z1 x Intel® US15WP Micro Module
z1 x Quick Installation Guide for ECM-US15WP
z1 x SDVO to VGA daughter board
z1 x DVD-ROM contains the followings:
— User’s Manual (this manual in PDF file)
— Ethernet driver and utilities
— VGA drivers and utilities
— Audio drivers and utilities
z1 x Cable set contains the followings:
— 1 x VGA cable (DB 15P(F) – 10P/2.0mm)
— 1 x IDE HDD cable (44-pin, pitch 2.0mm)
— 1 x Serial ATA cables (7-pin, standard)
— 1 x PS/2 Keyboard & mouse Y cable (7-pin, Mini-DIN)

User’s Manual
ECM-US15WP User’s Manual
11
1.3 Document Amendment History
Revision Date Comment
1st Oct. 2009 Initial Release

ECM-US15WP
12 ECM-US15WP User’s Manual
1.4 Manual Objectives
This manual describes in detail the Avalue Technology ECM-US15WP Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to interface
with ECM-US15WP series or change the standard configurations. Whilst all the necessary
information is available in this manual we would recommend that unless you are confident,
you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors concerning this manual and want to inform
us of these, please contact our Customer Service department with the relevant details.

User’s Manual
ECM-US15WP User’s Manual
13
1.5 System Specifications
System
CPU Intel® Atom™ processor Z510P / Z530P CPU
BIOS Award 8 Mbit Flash BIOS
System Chipset Intel® US15WP
I/O Chip Winboard W83627DHG
System Memory Onboard 1GB Memory
SSD One CompactFlash Type I/II socket
Watchdog Timer Reset: 1 ~ 255min and 1 sec. or 1 min./ step
Expansion 1 x SDIO, 1 x SDVO
I/O
MIO
1 x EIDE, 2 x Serial (COM1 with DB9 connector &COM2 with 5 x 2, pitch
2.0mm pin header. COM2 can be set as RS-232/422/485. Pin-9 +5/+12V
Set by Jumper), 2 SATA
USB 6 x USB 2.0 ports
IrDA 115 kbps 1.0 compliant
DIO 8-bit GPI and 8-bit GPO
Display
Chipset Intel® Advanced Low Power Graphics Supporting 3.0 Shader and Texture
Display Memory
Intel® Poulsbo Graphics Core Supports up to 256 MB for Dynamic Video
Memory
Resolution LCD/Simultaneous mode: 1366 x 768
Multiple Display SDVO + LVDS
LCD Interface Single-channel 24-bit LVDS
Built-in Touch Screen (Optional)
Chipset PenMount 6000
Touch Screen Interface
With 9-pin 2 mm box header (can be selected to support 4/5/8-wire touch
screen)
Audio
AC97 Codec Realtek ALC883 supports 5.1 CH Audio
Audio Interface Mic in, Line in, CD Audio in, Line out

ECM-US15WP
14 ECM-US15WP User’s Manual
Ethernet
LAN Intel82583V PCI-E Gigabit Ehternet
Ethernet Interface 10/ 100/ 1000 Base-Tx Gigabit Ethernet Compatible
Mechanical & Environmental
Power Requirement +12 V
Power Type Single Power AT / ATX
Operation Temperature 0~60°C (32~140°F)
Operating Humidity 0%~90% relative humidity, non-condensing
Size ( L x W ) 5.7" x 4.2" (146 mm x 101 mm)
Weight 0.44 lbs (0.2 Kg)

User’s Manual
ECM-US15WP User’s Manual
15
1.6 Architecture Overview – Block Diagram
The following block diagram shows the architecture and main components of
ECM-US15WP.

ECM-US15WP
16 ECM-US15WP User’s Manual
2. Hardware
Configuration

User’s Manual
ECM-US15WP User’s Manual
17
2.1 Product Overview

ECM-US15WP
18 ECM-US15WP User’s Manual
2.2 Installation Procedure
This chapter explains you the instructions of how to setup your system.
1. Turn off the power supply.
2. Insert the SODIMM module (be careful with the orientation).
3. Insert all external cables for hard disk, floppy, keyboard, mouse, USB etc. except for flat
panel. A CRT monitor must be connected in order to change CMOS settings to support
flat panel.
4. Connect power supply to the board via the ATXPWR.
5. Turn on the power.
6. Enter the BIOS setup by pressing the delete key during boot up. Use the “LOAD BIOS
DEFAULTS” feature. The Integrated Peripheral Setup and the Standard CMOS Setup
Window must be entered and configured correctly to match the particular system
configuration.
7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before
connecting the display cable and turning on the power.

User’s Manual
ECM-US15WP User’s Manual
19
2.3 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board's jumpers and connectors.
Jumpers
Label Function Note
JBAT1 Clear CMOS 3 x 1 header, pitch 2.0mm
JCF1 CF card mode select 3 x 1 header, pitch 2.0mm
JTOUCH1 Touch panel mode select 3 x 1 header, pitch 2.0mm
PWR_SEL1 AT/ATX power mode select 3 x 1 header, pitch 2.0mm
RI1 Serial port 1 – Ring, +5V, +12V power
select 3 x 1 header, pitch 2.0mm
RI2 Serial port 2 – Ring, +5V, +12V power
select 3 x 1 header, pitch 2.0mm

ECM-US15WP
20 ECM-US15WP User’s Manual
Connectors
Label Function Note
ATXPW1 ATX power connector 3 x 1 wafer, pitch 2.54mm
BBAT1 Battery connector 2 x 1 wafer, pitch 1.25mm
COM1 Serial port1 connector D-sub 9-pin, male
COM2 Serial port 2 connector 5 x 2 header, pitch 2.0mm
DIO1 Digital Input/ Output connector 10 x 2 header, pitch 2.0mm
IDE1 Primary IDE connector 22 x 2 header, pitch 2.0mm
IR1 IrDA connector 5 x 1 header, pitch 2.54mm
J1 LCD Inventer power connector 2 x 1 wafer, pitch 2.54mm
J422/485 Serial port 2 in RS-422/485 mode
connector 3 x 2 header, pitch 2.0mm
JAUDIO1 Audio connector 3 x 2 header, pitch 2.0mm
JBKL1 LCD Inverter connector 5 x 1 wafer, pitch 2.0mm
JCD1 CD-ROM audio input connector 4 x 1 header, pitch 2.54mm
JKB/MS1 PS/2 Keyboard & Mouse connector 4 x 2 header, pitch 2.0mm
JLPC1 (Reserved for BIOS programming) 3 x 2 header, pitch 2.0mm
JLVDS1 LVDS connector HIROSE DF13-200P-1.25C
JSDVO1 SDVD port connector 12 x 2 header, pitch 2.0mm
CON1 (Reserved for BIOS programming) 5 x 2 header, pitch 2.0mm
JUSB1 USB connector 5&6 5 x 2 header, pitch 2.0mm
JVR1 LCD backlight brightness adjustment 3 x 1 header, pitch 2.0mm
LAN1 RJ-45 Ethernet connector
LED4 Power & HDD indicator
LINEOUT1 Audio out connector
MICPHONE1 MIC connector
PWRBTN1 Power button connector 2 x 1 header, pitch 2.0mm
PWRCON1 Power connector 2 x 2 wafer, pitch 4.2mm
RSTBTN1 Reset button
SATA1 SATA 1 connector
SATA2 SATA 2 connector
SDIO_J1 SDIO connector 5 x 1 header, pitch 2.54mm
SDIO_J2 SDIO connector 6 x 1 header, pitch 2.54mm
USB1 USB connector 2&3 Double deck
USB2 USB connector 0&1 Double deck
