Avalue Technology EMX-CDV User manual

Part No. E2047XCDV00R
EMX-CDV
Intel® Atom™EMX-CDV Mini ITX Motherboard
with Intel® ICH10R Chipset
User’s Manual
1st Ed –17 Septemper 2012

EMX-CDV
2 EMX-CDV User’s Manual
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2012 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that
these products are free from patent, copyright, or mask work right infringement, unless

User’s Manual
EMX-CDV User’s Manual
3
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose failure
to perform can be reasonably expected to cause the failure of the life support device or
system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

EMX-CDV
4 EMX-CDV User’s Manual
If you still cannot find the answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our dealers are well trained
and ready to give you the support you need to get the most from your Avalue’s products. In
fact, most problems reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Avalue’s engineers every business day.
We are always ready to give advice on application requirements or specific information on
the installation and operation of any of our products. Please do not hesitate to call or e-mail
us.
Headquarters and Branch
Avalue USA
Avalue Technology Inc.
7F, 228, Lian-cheng Road, Chung Ho City, Taipei,
Taiwan
Tel:[phone]
Fax: [phone]
Information:[e-mail]
Service: [e-mail]
Avalue Technology Inc.
9 Timber Lane, Marlboro, NJ 07746-1443
Tel: [phone]
Fax: [phone]
Information: [e-mail]
Service: [e-mail]
BCM Advanced Research
Avalue Europe
BCM Advanced Research
an Avalue Company
7 Marconi, Irvine, CA92618
Tel: [phone]
Fax: [phone]
Information: [e-mail]
Web: www.bcmcom.com
Avalue Europe A/S
Moelledalen 22C, 3140
Aalsgaarde, Denmark
Tel: [phone]
Fax:[phone]
Information: sales.e[email protected]
Service: service.europ[email protected]
Avalue China
Avalue Japan
Avalue Technology Inc.
Room 805, Building 9,No.99 Tianzhou Rd.,
Caohejing Development Area,
Xuhui District, Shanghai
Tel: [phone]
Fax:[phone]
Information: sales.chi[email protected]
Service: [e-mail]
Avalue Technology Inc.
3F Ishiyama-Bldg, 1-6-1 Taito,
Taito-ku, Tokyo 110-0016 Japan
Tel: [phone]
Fax: [phone]
Information: sales.japa[email protected]
Service: [e-mail]

User’s Manual
EMX-CDV User’s Manual
5
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU type and
speed, Avalue’s products model name, hardware & BIOS revision number, other
hardware and software used, etc.) Note anything abnormal and list any on-screen
messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any
helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material authorization)
number from your dealer. This allows us to process your good return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement Order Card
and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your
dealer.

EMX-CDV
6 EMX-CDV User’s Manual
Content
1. Getting Started............................................................................................................9
1.1 Safety Precautions ....................................................................................................9
1.2 Packing List...............................................................................................................9
1.3 Document Amendment History ...............................................................................10
1.4System Specifications.............................................................................................12
1.5 Architecture Overview –Block Diagram..................................................................14
2. Hardware Configuration...........................................................................................15
2.1 Product Overview....................................................................................................16
2.2 Before you Proceed ................................................................................................18
2.3 Motherboard Overview............................................................................................19
2.3.1 Placement Direction ..................................................................................................................... 19
2.3.2 Screw Holes ................................................................................................................................. 19
2.4 Setting Jumpers & Connectors ...............................................................................23
2.4.1 Serial Port Setting - RS232/422/485 (JRS1, JRS2, JRS3, JRS4)............................................... 23
2.4.2 Serial Port 1 Select - RS-232/422/485 (JCOM1)......................................................................... 24
2.4.3 Serial Port 3 RI Pin Signal Select –Ring/+5V/+12V (JCOM3) .................................................... 25
2.4.4 Power Mode Select –AT or ATX (AT_CN).................................................................................. 26
2.4.5 Clear CMOS (CLR_CMOS).......................................................................................................... 26
2.4.6 System Fan Connector (SYS_FAN)............................................................................................. 27
2.4.7 Serial Port 3 Connector (COM3).................................................................................................. 27
2.4.8 Serial Port 4 Connector (COM4).................................................................................................. 28
2.4.9 Serial Port 5 Connector (COM5).................................................................................................. 28
2.4.10 Serial Port 6 Connector (COM6)................................................................................................ 29
2.4.11 LVDS Connector (LVDS)........................................................................................................... 29
2.4.12 LCD Inverter Connector (BKL_CN) ........................................................................................... 30
2.4.13 Front Panel Connector (F_PANEL) ........................................................................................... 30
2.4.14 Front Panel Audio Connector (F_AUDIO).................................................................................. 31
2.4.14.1 Signal Description –Audio connector (F_AUDIO) ................................................................ 31
2.4.15 Audio Amplifier Connector (SPK_OUT)..................................................................................... 32
2.4.16 SATA Power (SATAPW_1)........................................................................................................ 32
2.4.17 SATA Power (SATAPW_2)........................................................................................................ 33
2.4.18 USB Connector (F_USB1)......................................................................................................... 33
2.4.19 USB Connector (F_USB2)......................................................................................................... 34
2.4.20 GPIO Connector (GPIO_CNT)................................................................................................... 34
2.4.21 Low Pin Count Connector (LPC)................................................................................................ 35

User’s Manual
EMX-CDV User’s Manual
7
3. BIOS Setup...................................................................................................................36
3.1 Introduction .............................................................................................................37
3.2 Starting Setup .........................................................................................................37
3.3 Using Setup ............................................................................................................38
3.4 Getting Help............................................................................................................39
3.5 In Case of Problems................................................................................................39
3.6 BIOS setup..............................................................................................................40
3.6.1 Main Menu...................................................................................................................................... 40
3.6.1.1 System Date.......................................................................................................................... 40
3.6.1.2 System Time.......................................................................................................................... 40
3.6.2 Advanced BIOS settings ................................................................................................................ 41
3.6.2.1 PCI Subsystem Settings........................................................................................................ 41
3.6.2.1.1 PCI Express Settings........................................................................................................ 42
3.6.2.2 ACPI Settings ........................................................................................................................ 43
3.6.2.3 S5 RTC Wake settings .......................................................................................................... 44
3.6.2.4 Trusted Computing................................................................................................................ 44
3.6.2.5 CPU Configuration................................................................................................................. 45
3.6.2.6 SATA Configuration............................................................................................................... 46
3.6.2.7 Legacy USB Configuration.................................................................................................... 47
3.6.2.8 F81214 Second Super IO Configuration ............................................................................... 48
3.6.2.8.1 Serial Port 1 Configuration .................................................................................................. 49
3.6.2.8.2 Serial Port 2 Configuration .................................................................................................. 49
3.6.2.9 IT8783F Super IO Configuration ........................................................................................... 50
3.6.2.9.1 Serial Port 3 Configuration .................................................................................................. 51
3.6.2.9.2 Serial Port 4 Configuration .................................................................................................. 51
3.6.2.9.3 Serial Port 5 Configuration .................................................................................................. 52
3.6.2.9.4 Serial Port 6 Configuration .................................................................................................. 52
3.6.2.10 IT8783F H/W Monitor ............................................................................................................ 53
3.6.3 Advanced Chipset Features........................................................................................................... 53
3.6.3.1 Intel IGD Configuration.......................................................................................................... 55
3.6.4 Boot settings................................................................................................................................... 56
3.6.5 Security........................................................................................................................................... 57
3.6.5.1 Administrator Password......................................................................................................... 57
3.6.5.2 User Password ...................................................................................................................... 57
3.6.6 Save & Exit..................................................................................................................................... 58
3.6.6.1 Save Changes and Exit......................................................................................................... 58
3.6.6.2 Discard Changes and Exit..................................................................................................... 59
3.6.6.3 Save Changes and Reset...................................................................................................... 59
3.6.6.4 Discard Changes and Reset.................................................................................................. 59
3.6.6.5 Save Changes....................................................................................................................... 59

EMX-CDV
8 EMX-CDV User’s Manual
3.6.6.6 Discard Changes................................................................................................................... 59
3.6.6.7 Restore Defaults.................................................................................................................... 59
3.6.6.8 Save as user defaults............................................................................................................ 59
3.6.6.9 Restore user defaults ............................................................................................................ 59
3.6.6.10 Boot override ......................................................................................................................... 59
4. Mechanical Drawing ....................................................................................................61

User’s Manual
EMX-CDV User’s Manual
9
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
Always note that improper disassembling action could cause damage to the
motherboard. We suggest not removing the heatsink without correct
instructions in any circumstance. If you really have to do this, please contact
us for further support.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x EMX-CDV Mini-ITX Motherboard
1 x CD-ROM contains OS drivers/QIG/User’s Manual
1 x COM cable
2 x SATA cable
2 x SATA Power Cable
1 x DC Jack to ATX Power Cable
1 x I/O shield
㑨

EMX-CDV
10 EMX-CDV User’s Manual
1.3 Document Amendment History
Revision
Date
Comment
1st
June 2012
Initial Release

User’s Manual
EMX-CDV User’s Manual
11
Manual Objectives
This manual describes in detail the Avalue Technology EMX-CDV Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to interface
with EMX-CDV series or change the standard configurations. Whilst all the necessary
information is available in this manual we would recommend that unless you are confident,
you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors concerning this manual and want to inform
us of these, please contact our Customer Service department with the relevant details.

EMX-CDV
12 EMX-CDV User’s Manual
1.4 System Specifications
System
CPU
Onboard Intel® Atom™ D2550(N2800/N2600 for Option)
BIOS
AMI 16Mb SPI BIOS
System Chipset
Intel® ICH10R
I/O Chip
ITE8783+ FINTEK F81214
System Memory
2x 204-pin DDR3 SODIMM, up to 4GB (N2600 support 1 x DDR3
SODIMM only)
Watchdog Timer
H/W Reset : 1 to 255 sec/min per step
H/W Status Monitor
Monitoring temperature, voltage, and cooling fan
status. Auto throttling control when CPU overheats
TPM
Infineon TPM1.2 SLB9635 (Optional)
Expansion
1x PCI
2 x mini-PCI-E connectors
SSD
1 x mSATA supports on the 2nd mini-PCIe (Optional)
Smart Fan Control
Yes
Display
Chipset
Cedarview Integrated graphics
Dual Display
LVDS+VGA, VGA+HDMI, HDMI+LVDS
VGA
HDMI
Max resolution: 1920 x 1200
Max resolution: 1920 x 1200
LVDS
eDP to LVDS translator, Dual channel 18/24 bit
Max resolution: 1920 x 1080
LVDS Backlight
Yes, through internal LVDS Backlight Connector
Audio
Audio Codec
Azalia Realtek ALC269
Audio Interface
Mic-In, Line-In and Line-Out, speaker out
Audio Amplifier(W)
Build-in 2W Audio amplifier on chip
Ethernet
Chipset
2 x Realtek 8111E
Ethernet Interface
10/100/1000 Gigabit Ethernet Compatible
I/O
MIO
2 External(COM1, RS-232/422/485; COM2, RS-232), 4 Internal
(COM3, RS-232 with 5V/12V selected by jumper, COM4~6, RS-232),
4 SATA II, 1 HDMI, 1 VGA, 1 LVDS, 2 LAN, 1 PS/2
USB
7 USB 2.0 (4 Rear, 3 Internal)

User’s Manual
EMX-CDV User’s Manual
13
Back Panel I/O Port
Back Panel I/O Port
1 DC-in Connector (4-pin)
1 VGA Port
1 HDMI Port
2 COM Ports
4 USB 2.0 Ports
2 LAN RJ45 Ports
1 Audio I/O (3 Jacks)
1 PS/2 Mini-Din (KB/MS support by external Y-cable)
Internal I/O Connector
Internal I/O Connector
1 USB Connector supports 2 USB Ports
1 USB Connector supports 1 USB Port
4 COM RS-232 Connectors
4 SATA II Connectors, RAID 0,1,5,10 supported
2 SATA Power Connectors
1 Front Panel Connector
1 Front Audio Connector
1 System Fan Connector
1 GPIO Connector
2 Mini PCI-E Connectors
1 Speaker-out L/R Connector
1 LVDS Connector
1 LVDS Backlight Connector
1 LPC Connector
Power
Power Requirement
DC 12V
Power Type
AT / ATX mode (selectable by Jumper)
Power Connector
4-pin DC-in Power Connector,
4-pin ATX 12V Power Connector
Mechanical & Environmental
Operating Temperature
0°C to 60°C (32°F to 140°F)
Operating Humidity
0% to 90% relative humidity, non-condensing
Size
6.69" x 6.69" (170 x 170 mm)
Weight
0.77 Ibs (0.35 Kg)

EMX-CDV
14 EMX-CDV User’s Manual
1.5 Architecture Overview –Block Diagram
The following block diagram shows the architecture and main components of EMX-CDV.

User’s Manual
EMX-CDV User’s Manual
15
2. Hardware
Configuration
Pr

EMX-CDV
16 EMX-CDV User’s Manual
oduct Overview
2.1 Product Overview
EMX-CDV is designed to unleash the power of the new Intel® Atom™ processor D2000 /
N2000 which supports the new revolutionary two–chip layout. The Intel® Cedarview
processor also provides additional flexibility and upgradeability with two slots of single
channel DDR3 memory at 1066 MHz supporting up to 4GB maximum.
2. With breakthrough low-power silicon, EMX-CDV can be used with a passive thermal
solution based on the recommended boundary conditions.1
3. EMX-CDV represents a fundamental shift in system design—small, yet powerful
enough to enable a big Internet experience for all audiences.
2.1.1 Platform Features and Benefits
•DirectX® 10.1 let you enjoy awesome graphics performance, stunning 3D visual effect
and dynamic interactivity
•Memory support, integrated DDR3 memory controller
•Operating system support:
- Microsoft Windows XP 32/64bit
- Microsoft Windows 7 32/64bit
2.1.2 Key Architecture Features
•Supports Intel® Atom™ processor D2000 / N2000.series
- Supports 2 lanes in each direction for N2000 processor and 4 lanes in each direction
for D2000 processor (Gen 1 2.5gbps) per lane per direction point- to- point DMI
interface.
- Compatible with high speed DDR3-1066MHz
-TDP: 16W
•Intel® HD Audio Technology
•Integrated Display Interfaces
- HDMI
- VGA
- Dual Channel LVDS
•Doubles the transfer speed of SATA, running at speed up to 3.0Gb/s
•Provides 10/100/1000 Mbps solution to your network or broadband connection without
having to buy an
•Onboard audio CODEC supports uncompromising DVD audio quality, bringing a move
vivid sound experience and high-quality audio without having to buy advanced sound
cards.

User’s Manual
EMX-CDV User’s Manual
17
•Main Memory
EMX-CDV provides 2x 204-pin DDR3 SODIMM, up to 4GB (N2600 support 1 x DDR3
SODIMM only).
SODIMM module.
Note:
(1) Please do not change any DDR SDRAM parameter in BIOS setup to increase
your system’s performance without acquiring technical information in advance.
(2) Static electricity can damage the electronic components of the computer or
optional boards. Before starting these procedures, ensure that you are
discharged of static electricity by touching a grounded metal object briefly.
(3) The Platform requires DDR3 SODIMMs to be populated starting with the
SODIMM at the far end from the processor.
Here, SODIMM2 is situated at the far end from the processor.
SODIMM

EMX-CDV
18 EMX-CDV User’s Manual
• I/O
- One PCI slot
- Two Mini-PCIe sockets
- Four SATA2 ports
- Two 10/100/1000 Mbps Ethernet Controller
- High Definition Audio
- USB: USB 2.0/1.1, up to 7 ports
- Hardware Monitor
Fan control (Voltage, Temp)
2.2 Before you Proceed
Take note of the following precautions before you install motherboard components or
change any motherboard settings.
Unplug the power cord from the wall socket before touching any
component.
Use a grounded wrist strap or touch a safely grounded object or a
metal object, such as the power supply case, before handling
components to avoid damaging them due to static electricity
Hold components by the edges to avoid touching the ICs on
them.
Whenever you uninstall any component, place it on a grounded
anti-static pad or in the bag that came with the component.
Before you install or remove any component, ensure that the ATX
power supply is switched off or the power cord is detached from
the power supply. Failure to do so may cause severe damage to
the motherboard, peripherals, and/or components.

User’s Manual
EMX-CDV User’s Manual
19
2.3 Motherboard Overview
Before you install the motherboard, study the configuration of your chassis to ensure that
the motherboard fits into it. Refer to the chassis documentation before installing the
motherboard.
Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so can cause you physical injury and
damage motherboard components.
2.3.1 Placement Direction
When installing the motherboard, make sure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
2.3.2 Screw Holes
Place four (4) screws into the holes indicated by circles to secure the motherboard to the
chassis.
Place this side towards the rear
of the chassis.
Do not over tighten the screws! Doing so can damage the
motherboard.

EMX-CDV
20 EMX-CDV User’s Manual
