Avalue Technology ACP-IMX6POS-B1 User manual

Part No. E2047IMX603R
ACP-IMX6POS-B1
NXP i.MX6 Cortex-A9 SBC (B Version)
User’s manual
1st Ed –11 November 2019

ACP-IMX6POS-B1 User’s Manual
2 ACP-IMX6POS-B1 User’s Manual
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2019 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that
these products are free from patent, copyright, or mask work right infringement, unless

ACP-IMX6POS-B1 User’s Manual
ACP-IMX6POS-B1 User’s Manual 3
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

ACP-IMX6POS-B1 User’s Manual
4 ACP-IMX6POS-B1 User’s Manual
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example,
CPU type and speed, Avalue’s products model name, hardware & BIOS
revision number, other hardware and software used, etc.) Note anything
abnormal and list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material
authorization) number from your dealer. This allows us to process your good
return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales
receipt) in a shippable container. A product returned without proof of the
purchase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it
prepaid to your dealer.

ACP-IMX6POS-B1 User’s Manual
ACP-IMX6POS-B1 User’s Manual 5
CONTENT
1. Getting Started............................................................................................................7
1.1 Safety Precautions.........................................................................................7
1.2 Packing List....................................................................................................7
1.3 Document Amendment History.......................................................................8
1.4 Manual Objectives..........................................................................................9
1.5 System Specifications ..................................................................................10
1.6 Architecture Overview –Block Diagram.......................................................12
2. Hardware Configuration...........................................................................................13
2.1 Product Overview.........................................................................................14
2.2 Jumper and Connector List ..........................................................................15
2.3 Setting Jumpers & Connectors.....................................................................17
2.3.1 Boot mode selector (JBTSL1)...............................................................17
2.3.2 Serial port 1/2 pin9 signal select (JCOM12-RI).....................................18
2.3.3 Serial port 3/4 pin9 signal select (JCOM34-RI).....................................18
2.3.4 Serial port connector 3/4 (JCOM3/4).....................................................19
2.3.5 USB connector 1 (JUSB1).....................................................................19
2.3.6 USB connector 2 (JUSB2).....................................................................20
2.3.7 LED connector (JLED1) ........................................................................20
2.3.8 General purpose I/O connector (JDIO)..................................................21
2.3.9 Power connector (JPWR2)....................................................................21
2.3.10 Speaker Out_L connector (JSPK1).......................................................22
2.3.11 Speaker Out_R connector (JSPK2) ......................................................22
2.3.12 Line In, MIC connector (JMIC1) ............................................................23
2.3.13 LCD inverter connector (JBKLT1) .........................................................23
2.3.14 VGA connector (JVGA1).......................................................................24
2.3.15 Battery holder (BAT-1) ..........................................................................24
2.3.16 LVDS connector (JLVDS1)....................................................................25
2.3.17 I2C device connector (JI2C1)................................................................26
3. Software User Guide....................................................................................................27
3.1 Build and install U-boot & Kernel image for ACP-IMX6POS.........................28
3.1.1 Requirements.........................................................................................28
3.1.2 Setting Up the Standalone Cross-Development Environment................28
3.2 Get U-boot & Kernel source code and Complier ..........................................28
3.2.1 Get U-boot & Kernel source code ..........................................................28
3.2.2 Complier U-boot & Kernel image............................................................29

ACP-IMX6POS-B1 User’s Manual
6 ACP-IMX6POS-B1 User’s Manual
3.3 Flash U-boot & Kernel image to eMMC or MicroSD.....................................30
3.3.1 Flash U-boot & Kernel image to eMMC..................................................30
3.3.2 Get MFG tool..........................................................................................32
3.3.3 Flash OS to eMMC by MFG tool ............................................................32
3.3.4 Flash OS to SD card by MFG tool..........................................................34

ACP-IMX6POS-B1 User’s Manual
ACP-IMX6POS-B1 User’s Manual 7
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x ACP-IMX6POS-B1 Module

ACP-IMX6POS-B1 User’s Manual
8 ACP-IMX6POS-B1 User’s Manual
1.3 Document Amendment History
Revision
Date
Comment
1st
November 2019
Initial Release

ACP-IMX6POS-B1 User’s Manual
ACP-IMX6POS-B1 User’s Manual 9
1.4 Manual Objectives
This manual describes in detail the Avalue Technology ACP-IMX6POS-B1 Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to interface
with ACP-IMX6POS-B1 series or change the standard configurations. Whilst all the
necessary information is available in this manual we would recommend that unless you are
confident, you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors concerning this manual and want to inform
us of these, please contact our Customer Service department with the relevant details.

ACP-IMX6POS-B1 User’s Manual
10 ACP-IMX6POS-B1 User’s Manual
1.5 System Specifications
System
Mother Board
ACP-IMX6POS(B)
CPU
NXP i.MX6 Cortex-A9 Quad / Dual Lite 1GHz
CPU Cooler (Type)
Aluminum CPU Sink
E1961213015000R, Heatsink for CPU 41*41*20mm
Memory
2GB DDR3L
Storage
8G eMMC
Power Supply
DC in 12V~24V
Display
Chipset
NXP i.MX6
Resolution
Up to 1920x1080
Multiple Display
Quad(VGA+HDMI or LVDS+HDMI or VGA+LVDS)
Dual Lite(LVDS+HDMI)
HDMI
From NXP i.MX6
LCD Interface
Dual channel 24bit LVDS
Ethernet
LAN1
Giga Lan From i.MX6 MAC, PHY is Micrel KSZ9031RNX
LAN2
Giga Lan Intel I210 by PCIe Interface
Ethernet Interface
RJ45 x2
Audio
I2S Codec
Wolfson WM8962
Audio Port
2Pin Wafer Box P=2.0m x2 (Speaker out R & L ) (Driver per channel max 2W)
Mic
4Pin Wafer Box P=2.0m x1(Microphone)
Internal I/O
Connectors
Front panel
JLED1 2 x 5P x1
mini-PCIe socket
MPCIE1 x1
SIM socket
SIM1 x1
OTG jumper
JBTSL1 x1
I2C
JI2C1 x1
MIC
JMIC1 x1
LVDS
JLVDS1 x1
Black Light
JBKLT1 x1
VGA
JVGA1 x1
USB
JUSB2 x1

ACP-IMX6POS-B1 User’s Manual
ACP-IMX6POS-B1 User’s Manual 11
JUSB1 x1
Mic or SD socket
JMSD x1
GPIO
JDIO 16bit x1
power input
JPWR2 Pin header 4P power input connector
Speaker
JSPK1 x1
JSPK2 x1
RS232
JCOM 3&4 x1 as pin header only RS232.
Debug
JUART1 x1
External I/O
USB
USB Type A Double Deck x 1
LAN
RJ45 connector with indicate LED x 2
HDMI
HDMI connector x 1 (Vertical type)
Mini-USB
Mini-USB connector x 1
COM Port
DB9 male connector x2
JCOM1&2 can be select from RS232/422/485
(RS485 auto flow control)
DC Jack
JPWR1 x1
Mechanical &
Environmental
Power Type
12V ~ 24V wide voltage DC input
Power Connector
Type
1. DC jack
2. Pin header 4P power input connector
Weight
TBD
Fanless
Yes
Size (L x W)
175 x 110mm
OS Support
(listed in accordance with
Intel document)
Android 4.4.2
Linux Ubuntu 14.04
Linux Yocto 1.5.1
Note: Specifications are subject to change without notice.

ACP-IMX6POS-B1 User’s Manual
12 ACP-IMX6POS-B1 User’s Manual
1.6 Architecture Overview –Block Diagram
The following block diagram shows the architecture and main components of
ACP-IMX6POS-B1.

ACP-IMX6POS-B1 User’s Manual
ACP-IMX6POS-B1 User’s Manual 13
2.Hardware
Configuration

ACP-IMX6POS-B1 User’s Manual
14 ACP-IMX6POS-B1 User’s Manual
2.1 Product Overview

ACP-IMX6POS-B1 User’s Manual
ACP-IMX6POS-B1 User’s Manual 15
2.2 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label
Function
Note
JBTSL1
Boot Mode selector
Switch, 2bit
JCOM12-RI
Serial port 1/2 pin9 signal select
6 x 2 header, pitch 2.00mm
JCOM34-RI
Serial port 3/4 pin9 signal select
6 x 2 header, pitch 2.00mm
Connectors
Label
Function
Note
BAT-1
Battery holder
1 x 2 wafer, pitch 1.25mm
JCOM1/2
Serial port connector 1/2
D-sub 9-pin, male
JCOM3/4
Serial port connector 3/4
5 x 2 wafer, pitch 2.00 mm
JDIO
General purpose I/O connector
10 x 2 header, pitch 2.00 mm
JUSB1
USB connector 1
5 x 2 wafer, pitch 2.00mm

ACP-IMX6POS-B1 User’s Manual
16 ACP-IMX6POS-B1 User’s Manual
JUSB2
USB connector 2
5 x 1 wafer, pitch 2.00mm
JUSB3
USB connector 3
USB Type-A x2
JMUSB1
Mini USB connector for Boot/Debug
MINI USB-MAB_5P
JPWR1
DC-IN power connector
Power Jack mini din 4P
JPWR2
Power connector
2 x 2 wafer, pitch 4.20 mm
MPCIE1
Mini PCI Express connector
JLAN1/2
RJ-45 Ethernet connector 1/2
JVGA1
VGA connector
8 x 2 wafer, pitch 2.00mm
JLED1
LED connector
5 x 2 wafer, pitch 2.00mm
JSPK1
Speaker Out_L connector
2 x 1 wafer, pitch 2.00 mm
JSPK2
Speaker Out_R connector
2 x 1 wafer, pitch 2.00 mm
JLVDS1
LVDS connector
2 x 20 wafer, pitch 1.25 mm
SIM1
SIM Card Slot
SDCARD_9H
JMIC1
Line In, MIC connector
4 x 1 wafer, pitch 2.00mm
JBKLT1
LCD inverter connector
5 x 1 wafer, pitch 2.00mm
JMSD1
Micro SD Card Slot
JHDMI1
HDMI connector
JI2C1
I2C device connector
5 x 1 header, pitch 2.00mm

ACP-IMX6POS-B1 User’s Manual
ACP-IMX6POS-B1 User’s Manual 17
2.3 Setting Jumpers & Connectors
2.3.1 Boot mode selector (JBTSL1)
Mode
Description
OTG load
eMMC boot
SD boot

ACP-IMX6POS-B1 User’s Manual
18 ACP-IMX6POS-B1 User’s Manual
2.3.2 Serial port 1/2 pin9 signal select (JCOM12-RI)
* Default
+5V
+12V
Ring*
2.3.3 Serial port 3/4 pin9 signal select (JCOM34-RI)
* Default
+5V
+12V
Ring*

ACP-IMX6POS-B1 User’s Manual
ACP-IMX6POS-B1 User’s Manual 19
2.3.4 Serial port connector 3/4 (JCOM3/4)
Signal
PIN
PIN
Signal
NC
1
2
COM_RXD
COM_TXD
3
4
NC
GND
5
6
NC
COM_RTS#
7
8
COM_CTS#
COM_RI_A
9
10
GND
2.3.5 USB connector 1 (JUSB1)
Signal
PIN
PIN
Signal
+5V
1
2
+5V
USB_NP2
3
4
USB_NP1
USB_PP2
5
6
USB_PP1
GND
7
8
GND
GND
9
10
GND
JCOM4
JCOM3

ACP-IMX6POS-B1 User’s Manual
20 ACP-IMX6POS-B1 User’s Manual
2.3.6 USB connector 2 (JUSB2)
Signal
PIN
+5V
1
USB_NP3
2
USB_PP3
3
GND
4
GND
5
2.3.7 LED connector (JLED1)
Signal
PIN
PWR-LED+
1
PWR-LED-
2
WIFI-LED+
3
WIFI-LED-
4
LAN-LED+
5
LAN-LED-
6
Reset Switch
7
8
Power button
Switch
9
10
