Avatar BM-A01 User manual
16mm(D)*70mm(L)*2pcs
20 g
LED*2
Bluetooth Ver 4.0 and above;
MIDI interface *2 (IN, OUT)
MIDI OUT
20 mw
iOS 8 or later, OS X Yosemite or later, Windows 10 Autumn Creators
Update or later.
Color
Size
Weight
Indicator Light
Bluetooth Standard
Connector
Power Supply
Power Consumption
Supporting System
Black
Specification:
Take “GarageBand” for example:
BM-A01
Application Range
The Connection Guide
CAUTION
By using this product, you can achieve wireless MIDI
communication between MIDI equipped instrument with smart
device supporting wireless MIDI, such as iPhone, iPad, iPod touch,
Mac, and PC with Windows 10 Autumn Creators Update and
above and Bluetooth 4.0. MIDI adaptor needs the software
supporting Bluetooth MIDI. Please ensure your software can
transmit Bluetooth MIDI.
There is few MIDI equipment not meeting MIDI standard, in
which No.2 hole as below is not connected to the ground wire
and cannot be used for the power supply of this product.
Do not use the product near medical products or inside
medical units.
Please close power supply of the MIDI device , and exit the
software that has been opened on the iPhone/iPad/PC.
This product uses magnets. Persons having heart pacemaker
implants or defibrillator implants must not use this product.
Because of this danger, do not bring this product close to
people with pacemaker or defibrillator implants.
The following figure：
Always follow these instructions, including but not limited to the
following instructions:
Create a wireless MIDI connection between MIDI devices and
iPhone/iPad:
Note：
The product is a wireless product and can generates a
magnetic field.
Never use or store in places that are
Use the product on the specified device
If any abnormality is found
Do not open and repair
Over-temperature site (e.g., direct sunlight in an enclosed
vehicle, near a heating duct, on top of heat-generating
equipment)
Damp or humid locations such as baths, washrooms, on wet
floors, or are exposed to rain.
Dusty places；A place of intense vibration；A place with
extremely low temperatures.
Do not open the unit and try to analyze the parts. Do not make
any changes for any internal parts. The unit has not parts
repairable for users.
If any abnormality is found, immediately disconnect the power
switch of the connected device and remove it from the device,
especially if they smell or smoke.
Do not connect this product to devices other than MIDI devices.
Do not bring this product within 22cm(9 in.)of anyone having
a heart pacemaker or defibrillator implant. Radio waves
emanating from this product or magnetism emanating from
internal magnets of this product may adversely affect a heart
pacemaker implant or defibrillator implant.
Do not use this product in the vicinity of a TV, radio, stereo
equipment, or other electric devices. Otherwise, this product,
TV, or radio may generate noise. When you use this product
along with an application on your iPad, iPhone or iPod touch,
we recommend that you set “Airplane Mode” to “ON” on that
device in order to avoid noise caused by communication.
HXW company shall not be responsible for the damage,
loss of data and equipment damage caused by the user's
failure to follow the instructions.
The MIDI adaptor is not visible in the Settings menu of iOS
operating system.It is visible only in applications that
support Bluetooth MIDI.
1.
Open “GarageBand” application
1.
Click the "Settings" button in upper right corner;
2.
Click "Advanced";
3.
Click "Bluetooth MIDI Devices";
4.
Choose "BM - A01";
5.
Wait for "Not Connected" to become "Connected".
6.
Connect the MIDI adaptor to the MIDI port as shown below.
2.
Open the power supply of equipment, the light on product will
be flashing rapidly.
3.
Enter the iPhone/ipod/PC’s setting interface, open bluetooth
function.
4.
Start iPhone/ipod/PC application, and then make the
appropriate wireless connection settings. If the wireless
connection is successful, the light will enter slow breathing
pattern.
5.
User Manual Wireless MIDI Adaptor
16mm(D)*70mm(L)*2pcs
20 g
LED*2
Bluetooth Ver 4.0及以上；
MIDI接口*2（IN，OUT）
MIDI OUT 供电
20 mw
iOS 8 或更新，OS X Yosemite或更新，Windows 10创意者更新或以上。
颜色
尺寸
重量
指示灯
蓝牙标准
连接器
电源
功耗
支持操作系统
黑色
产品规格：
以GarageBand为例：
BM-A01
蓝牙MIDI适配器使用手册
适用对象
连接指南
注意事项
通过使用该产品，您可以在兼容的传统MIDI设备与支持蓝牙MIDI的平
台进行无线MIDI传输。支持该设备的平台有：带蓝牙4.0版本以上的
iPhone，iPad，iPod touch，Mac，带Windows 10创意者更新及以上版
本且带蓝牙4.0适配器的PC机。蓝牙MIDI需要软件支持，请确认您使用
的软件支持蓝牙MIDI。
注意：
有极少部分MIDI设备不符合MIDI标准。
2号MIDI孔未接地线，无法为本产品供电，因此无法使用。
请勿在医疗产品或医疗单位中使用该产品。
请先关闭被连接的MIDI设备电源，同时请退出iPhone/iPad/PC等
平台上已打开的程序软件。
去纤颤器或心脏起搏器使用者不允许使用此产品。为避免此类风
险，请勿携带此产品靠近使用去纤颤器或心脏起搏器的人群。
如下图：
请始终遵循以下指示，包括但不限于以下指示：
为MIDI设备和iPhone/iPad之间建立无线MIDI连接：
此产品为无线产品，会产生磁场
请勿将本产品放置到以下场所
请在指定的设备上使用该产品
假如发现任何异常
请勿拆卸
备注：
温度过高的场所（例如阳光直射下的封闭车辆中、热输送管附近
或者发热机器上方）
湿气重或者被雨淋，或者潮湿处（例如浴室、洗手间、超市的地
面）
灰尘多的场所；有强烈震动的场所；温度过低的场所等。
请勿自行拆开产品或试图分析其中的部件，也不要对内部作任何更改。
本产品没有用户可维修部件，即使其发生故障或者间歇性不工作。
如果任何异常情况发现，请立即断开所连接设备的电源开关，并将其
从设备上取下。尤其是有异味或者冒烟。
请勿将此产品连接到除MIDI设备之外的设备上。
此产品释放的电磁辐射，磁场可能会影响去纤颤器或心脏起搏器
的工作。请勿在距离去纤颤器或心脏起搏器22cm（9英寸）距离
内携带此产品。
请勿在音响设备，电视机，收音机附近使用该产品，否则将有可能
在这些设备上产生噪声。当您在iPhone上使用该产品时，我们建议
您请将“飞行模式”打开以避免通信所带来的噪声。（飞行模式下
可以继续使用蓝牙）
本公司对用户未按照注意事项指示使用本产品造成的伤害，数
据丢失，及设备损害等不负责任。
1.
点击右上角“设置”按钮；
1.
点击“高级”；
2.
点击“蓝牙MIDI设备”；
3.
选择“BM-A01”；
4.
等待“离线”变成“已连接”即可使用。
5.
如下图所示，把蓝牙MIDI连接到MIDI端口：
2.
打开设备电源，产品的指示灯将会快速闪烁。
iPhone，iPad，iPod touch, Mac, 和 OS X 是美国苹果公司的注册商标。
本手册中所涉及的公司名称和产品名称分别属于其各自公司商标或注册商标。
3.
进入iPhone/iPad/PC等平台的设置界面，开启蓝牙功能。
4.
打开iPhone/iPad/PC等平台兼容蓝牙MIDI的应用程序，选择正确
的设置。如果蓝牙连接正确，产品指示灯将进入慢速呼吸模式。
5.
