Avenli 17618 series User manual

SPA

Installation and user’s manual

Read carefully and keep it for later reference

Instruction Video

Carefully read, understand, and follow all information in this user manual before installing and

using the swimming pool.

These warnings, instructions, and safety guidelines address some common risks of water

recreation, but they cannot cover all risks and dangers in all cases. Always use caution, common

sense, and good judgment when enjoying any water activity. Please read carefully and keep for

future reference.

Non Swimmers safety

1.Continuous, active, and vigilant supervision of weak swimmers and non-swimmers by a com-

petent adult is required at all times (remember that children under ve are at the highest risk of

drowning)

2.Designate a competent adult to supervise the pool each time it is being used;

3.Weak swimmers or non-swimmers should wear personal protection equipment when using

the pool;

4. When the pool is not in use, or unsupervised, remove all toys from the swimming pool and its

surrounding to avoid attracting children to the pool.

Safety devices

1. It is recommended to install a barrier (and secure all doors and windows, where applicable) to

prevent unauthorized access to the swimming pool;

2. Barriers, pool covers, pool alarms, or similar safety devices are helpful aids, but they are not substi-

tutes for continuous and competent adult supervision.

Safety equipment

1. It is recommended to keep rescue equipment (e.g. a ring buoy) by the pool;

2. Keep a working phone and a list of emergency phone numbers near the pool.

Safe use of the pool

1. Encourage all users especially children to learn how to swim;

2. Learn Basic Life Support (Cardiopulmonary Resuscitation - CPR) and refresh this knowledge regu-

larly. This can make a life-saving difference in the event of an emergency;

3. Instruct all pool users, including children, what to do in case of an emergency;

4. Never dive into any shallow body of water. This can lead to serious injury or death;

5. Do not use the swimming pool when using alcohol or medication that may impair your ability to

safely use the pool;

6. When pool covers are used, remove them completely from the water surface before entering the

pool;

7. Protect pool occupants from water related illnesses by keeping the pool water treated and practi-

cing good hygiene.Consult the water treatment guidelines in the user’s manual;

8. Store chemicals (e.g. water treatment, cleaning or disinfection products) out of the reach of child-

ren.

9. Use the signage as outlined below;

10. Removable ladders shall be placed on horizontal surface.

WARNING: drained pool outdoors may cause unknown hazards.

WARNING: Installation and assembly shall be done by adults.

WARNING: Read and follow the the instruction for use and maintenance

to ensure a safe use of the swimming pool kit. Not following the instructions

for use and maintenance can cause serious health hazards, in particular for children.

WARNING: Only for domestic outdoor use.

WARNING: Drowning hazard. Children have drowned in portable swimming-pools.

WARNING: Empty the pool when not in use. Do not leave a small pool empty outdoor.

WARNING: Keep children under supervision in the aquatic environment.

WARNING: No diving.

WARNING

READ ALL INSTRUCTIONS AND SAFETY WARNINGS IN THIS MANUAL

Failure to follow the warnings and instructions in this manual may result in

serious injury, drowning or electric shock.

The safety of your children is left on your hand! The risk is the highest for

children aged below 5. Be high alert all the time.

Always comply with the following instructions:

- The children should be under close and constant supervision;

- Designate one security responsible;

- Always designate a responsible person to mange pool and pool area;

- Adult supervision should always be relevant to the number of people using the

pool;

- Wet the nape, chest and legs before entering the water;

- Learn the safety gestures and especially the specics to children;

- Prohibit diving and jumping;

- Prohibit running, splashing games around the pool;

- Do not let an unattended child who does not swim use the pool with no life-jack-

ets on;

- Do not leave any players around and in the basin unattended;

- Always keep the water treatment products out of reach of all children.

If incident occurs remove the injured person or child from the pool and pool area

Contact emergency services for advice and guidance on how to treat injured per-

son or child

Zone 2 Zone 2Zone 1

1,5 m 1,5 m2 m 2 m

2,5 m

Zone 0 h

The hot tub’s electrical connections must be installed in the electrical safety zones labelled 1, 2 or

outside all safety zones. The measured zones are limited by walls and xed partitions.

2 3

For your own safety and that of your product, make sure to following the safety precautions below.

Failure to follow the instruction may result in serious injury, property damage or death. Improper

installation or operation will void the warranty.

Read, understand and follow all instructions:

DANGER

Risk of accidental drowning:

- Extreme caution must be exercised to prevent unauthorized access by children.

- Inspect the spa cover regularly for leak, premature wear and tear, damage or signs of deterioration.

Never use a worn or damaged cover: it will not provide the level of protection required to prevent unsuper-

vised access to the spa by a child.

- Always lock the spa cover after each use.

Risk of injury:

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly quali-

ed persons in order to avoid a hazard.

Risk of Electric Shock:

- Do not permit any electrical appliances, such as a light, telephone, radio or television within 1.5m (5 feet)

of a spa tub.

- Do not use the spa when it is raining, thundering or lightning..

WARNING

To reduce the risk of electric shock, do not use an extension cord, timers, plug adapters or converter

plugs to connect the unit to electric supply; provide a properly located outlet.

The spa electrical appliance should be supplied through a residual current device (RCD) having a rated

residual operating current not exceeding 10mA.

Parts containing live parts, except parts supplied with safety extra-low voltage not exceeding 12V, must

be inaccessible to occupants in the spa.

Parts incorporating electrical components, except remote control devices, must be located or xed so

that they cannot fall into the spa.

Residential electrical connection box must be located safely with a distance of at least 2m away from the

spa.

Electric installation should fulll the local requirement or standards.

This appliance can be used by children aged from 8 years and above and persons with reduced physi-

cal, sensory or mental capabilities or lack of experience and knowledge if they have been given supervi-

sion or instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children

without supervision.

To reduce the risk or injury, do not permit children use this product unless they are closely supervised all

times.

To reduce the risk of child drowning, supervise children all times. Attach and lock spa cover after each

use.

Make sure the oor is capable of supporting the expected load (≥ 500kg/m²).

Adequate draining system must be provided around the spa to deal with overow water.

To avoid damage do not leave the appliance empty for an extended period.

To avoid damage to the pump, the spa must never be operated unless the spa is lled with water.

Immediately leave spa if uncomfortable or sleepy.

To reduce the risk of injury :

- Lower water temperatures are recommended for young children and when spa use exceeds 10 minutes.

IMPORTANT SAFETY INSTRUCTIONS

In order to avoid the possibility of hyperthermia (heat stress) occurring it is recommended that the average

temperature of spa-pool water should not exceed 40°C (104°F).

- Since excessive water temperatures have a high potential for causing fetal damage during the early

months of pregnancy, pregnant or possibly pregnant women should limit spa water temperatures to 38°C

(100°F).

- Before entering a spa or hot tub the user should measure the water temperature with an accurate ther-

mometer since the tolerance of water temperature regulating devices varies.

- The use of alcohol, drugs or medication before or during spa use may lead to unconsciousness with the

possibility or drowning.

- The use of alcohol, drugs, or medication can greatly increase the risk of fatal hyperthermia in spas.

The causes and symptoms of hyperthermia may be described as follows:

Hyperthermia occurs when the internal temperature of body reaches a level several degrees above

the normal body temperature 37°C (98.6°F). The symptoms of hyperthermia include an increase in the

internal temperature of body, dizziness, lethargy, drowsiness, and fainting. The effect of hyperemia include

failure to perceive heat; failure to recognize the need to exit spa; unawareness of impending hazard; fetal

damage in pregnant women; physical inability to exit the spa; and unconsciousness resulting in the danger

of drowning.

- Obese persons or persons with a history of heart disease, low or high blood pressure, circulatory system

problem, or diabetes should consult a physician before using a spa.

- Persons using medication should consult a physician before using a spa since some medication may

induce drowsiness while other medication may affect heart rate, blood pressure and circulation.

- Check with doctor before use if pregnant, diabetic, in poor health, or under medical care.

People with infectious disease should not use a spa or hot tub.

To avoid injury exercise care when entering or existing the spa or hot tub.

Water temperature in excess of 40°C (104°F) may be injurious to your health.

Never use a spa or hot tub alone or allow others to use the spa alone.

Do not use a spa or hot tub immediately following strenuous exercise.

Do not put the spa under 0°C (32°F) environment in order to avoid freezing if there is still water in the

pool.

Do not turn on the spa when the water is frozen.

Never pour water with a temperature higher than 40°C(104°F) into the spa directly.

Always unplug this product from the electrical outlet before removing, cleaning, servicing or making any

adjustment to the product.

Never jump or dive into a spa or any shallow body of water.

Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn mowers, hedge

trimmers and other equipment.

Do not attempt to plug in or unplug this product while standing in water or when your hands are wet.

Do not use the spa if damaged in delivery and/or malfunctioning in any way.

Keep all pets away from the spa to avoid any damage.

Do not add bath oil or bath salt to the spa water.

Do not leave an empty pool outside.

To prevent resetting of the thermal cut out, this appliance must not be supplied through an external swit-

ching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.

4 5

4 persons 6 persons

Model 17618XX 17691XX

Capacity 4 persons 6 persons

Dimension (outer) 156 cm × 70 cm

(Ø 61.4″ × 27,6″)

184 cm × 73 cm

(Ø 72.4″ × 28,7″)

Dimensions (inner) 140 cm × 70 cm

(Ø 55″ × 27,6″)

160 cm × 73 cm

(Ø 63″ × 28,7″)

Water capacity 860 L (227 gal) 1200 L (317 gal)

Power supply 220-240 V , 50 Hz , 2040 W 220-240 V , 50 Hz , 2040 W

Max heat temperature 40°C 40°C

Test certicate CE / GS CE / GS

Heating efciency

Ambient temperature : 20°C 1.5 - 2.5°C/h 1.5 - 2.5°C/h

1. SPECIFICATIONS

1.1. Specications

This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). This symbol indicates

that this appliance may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical

and electronic equipment. Disposal of the appliance shall be carried out in accordance with the local environment regulations for waste disposal.

The CE mark indicates that the product complies with European directives in relation to 2014/35/CE (low voltage), 2014/30/CE (Compliance with the

Electromagnetic Compatibility), 2011/65/UE (restriction of the use of certain hazardous substances in electrical and electronic equipment), 2009/125/CE

(Ecodesign directive).

Ensure to check all parts are present:

2. PACKAGE LIST

2.1. Package list

Outer liner

2 Caps

Pump unit

8 Foam walls Inner liner

Top cover

RCD plug

Couverture Structure gonﬂable Base de protection Bloc moteur

Prise diﬀérentielle Valve d’air Bouchon de vidange Tube de gonﬂage
