Avenview HDM-C6MWIP4K-SET User manual

VIDEO WALLS VIDEO PROCESSORS
VIDEO MATRIX SWITCHES
EXTENDERS SPLITTERS WIRELESS
CABLES & ACCESSORIES
Control Your Video
M-Series - 4K HDMI over IP with Video Wall &
Matrix Support Encoder and Decoder
PRODUCT MANUAL
Model: HDM-C6MWIP4K-SET
Rev. 00 - 10/2017

www.avenview.com
Copyright
© 2017 Avenview Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview
makes no representations or warranties with respect to the accuracy or completeness of the contents of this publication
and reserves the right to make changes to specifications and product descriptions at any time without notice. No license,
whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set
forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any
express or implied warranty, relating to its products of Avenview Inc. is strictly prohibited.
Rev. 00 - 10/2017

3
TABLE OF CONTENTS
www.avenview.com
Rev. 00 - 10/2017
1. GETTING STARTED ..........................................................................................................................1
1.1 IMPORTANT SAFE GUARDS..............................................................................................................1
................................................................................................................1
1.2 NSTRUCTIONSSAFETY I
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISIION (FCC) ........................... 2
2. INTRODUCTION ..............................................................................................................................3
AGE CONTENTS .....................................................................................................................4 2.1 PACK
2.2 BEFORE INSTALLATION ................................................................................................................... 4
2.3 APPLICATION DIAGRAM ..................................................................................................................5
2.4 PANEL DESCRIPTION ......................................................................................................................6
2.4.1 FRONT PANEL (SENDER/ENCODER, HDM-C6MWIP4K-S)................................................6
2.4.2 REAR PANEL (SENDER/ENCODER, HDM-C6MWIP4K-S) ..................................................6
3. INSTALLATION (HDM-C6MWIP4K-SET) POINT to POINT..........................................................8
3.1 IP MATRIX SWITCH GUIDE................................................................................................................8
3.2 SINGLE SWITCH NETWORKING GUIDE .........................................................................................9
4. PC CONFIGURATOR ........................................................................................................................11
6. SPECIFICATIONS .............................. ................................................................................................14
7. TROUBLESHOOTING ......................................................................................................................16
2.4.3 FRONT PANEL (RECEIVER/DECODER, HDM-C6MWIP4K-R).............................................7
2.4.4 REAR PANEL (RECEIVER/DECODER, HDM-C6MWIP4K-R).................................................7
3.3 NETWORKING GUIDE .....................................................................................................................10
6.1 SUPPORTED ENCODER RESOLUTIONS.........................................................................................15
6.2 SUPPORTED DECODER RESOLUTIONS........................................................................................15
4.1 PRODUCTS AND VERSIONS.............................................................................................................11
5. CONFIGURING YOUR OPERATING SYSTEM..................................................................................13

www.avenview.com 1
SECTION 1: GETTING STARTED
1.1 IMPORTANT SAFEGUARDS
•Any product on which the serial number has been defaced, modified or removed.
•Damage, deterioration or malfunction resulting from:
•Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to
follow instructions supplied with the product.
•Repair or attempted repair by anyone not authorized by us.
•Any damage of the product due to shipment.
•Removal or installation of the product.
•Causes external to the product, such as electric power fluctuation or failure.
•Use of supplies or parts not meeting our specifications.
•Normal wear and tear.
•Any other causes which does not relate to a product defect.
•Removal, installation, and set-up service charges.
1.2 SAFETY GUIDELINES
The HDM-C6MWIP4K-SET M-Series - 4K HDMI over IP Encoder and Decoder has been tested for conformance to safety
regulations and requirements, and has been certified for international use. However, like all electronic equipments, the
HDM-C6MWIP4K-SET should be used with care. Read the following safety instructions to protect yourself from possible
injury and to minimize the risk of damage to the unit.
!Do not dismantle the housing or modify the module.
!Dismantling the housing or modifying the module may result in electrical shock or burn.
!Refer all servicing to qualified service personnel.
!Do not attempt to service this product yourself as opening or removing housing may expose you to dangerous voltage
or other hazards.
!Keep the device away from liquids.
!Spillage onto the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on
to the housing, unplug the module immediately.
!If the unit appears damaged, have the module checked by a qualified service engineer before using it again.
!Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.
Please read all of these instructions carefully before you use the device. Save this manual
for future reference. Avenview warranty certificate please refer to page #18
Warranty does not include:-
Rev. 00 - 10/2017

www.avenview.com 2
1.3 REGULATOR Y N OTICES FEDERAL ICATIONCOMMUN COMMISSION (FCC)
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Warning symbols Description
ONLY USE THE PROVIDED POWER CABlE OR POWER
ADAPTER SUPPLIED. DO NOT TAMPER WITH THE
ELECTRICAL PARTS. THIS MAY RESULT IN
ELECTRICAL SHOCK OR BURN.
DO NOT TAMPER WITH THE UNIT. DOING SO WILL VOID
THE WARRANTY AND CONTINUED USE OF THE
PRODUCT.
THE VIDEO BOARDS ARE VERY SENSITIVE TO STATIC. PLEASE
ENSURE IF RACK MOUNTED OR INSTALLED ON A SURFACE,
IT SHOULD BE IN A GROUNDED ENVIROMENT.
THIS WARNING SYMBOL MEANS DANGER. WHEN THIS
SYMBOL IS PLACED, YOU ARE IN AN ENVIROMENT THAT
CAN CAUSE BODILY INJURY.
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Avenview is
not responsible for any radio or television interference caused by using other than recommended cables and connectors or
by unauthorized changes or modifications to this equipment.
Rev. 00 - 10/2017

3
2. INTRODUCTION
The Avenview HDM-C6MWIP4K-SET, HDMI H.264 IP Videowall and Matrix 4K Decoder/Encoder delivers end-to-end
streaming media over IP networks. The HDM-C6MWIP4K-SET is composed of two units a Decoder and an Encoder. The
Decoder H.264/MPEG-4 AVC video compression format, it receives the encoded IP signal through LAN port and decodes
video/audio signal out through HDMI interface, it also supports stereo de-embeding and streaming resolutions up to 4K@60Hz
- NOTE: The QUALITY and TRANSMISSION of the video signals depends on the characteristics and quality of the STP/ UTP
cables and Network Infrastructure . We recommend any Network Switches with 1GB POE IGMP v2.0 support . Tested and
configured on the below models
FEATURES:
- HDMI 2.0, HDCP compliant
- Flexible PC,WEB GUI iPad control;
- Built in-auto scaler;
- Encoder supports- video stream encoding 480p@60Hz to 3840 x 2160@30;
- Decoder supports- video stream decoding 480p@60Hz to 3840 x 2160@60;
- Supports POE;
- Allows video previewing via iPad App and Windows 7/8/10 software 352x288@5Hz;
- Supports multiple interfaces HDMI, DVI signals over IP networks;
- Supports audio embedding and de-embedding;
- Supports H.264 features baseline profile, main profile and high profile;
- Supports H.264, TCP/IP, Telnet, UDP and IGMP;
- Support Telnet, WEB GUI control and 3rd Party control sytems API commands;
- Supports Auto IP, Zero-configuration networking (zeroconf)
- Seamless switching, no black screen, no frame lock. (Industry standard<500ms)
- Configurable encoding bit rate up to 20 Mbps
- Auto input format detection
- CEC Function on the RX;
- Compatible with other Avenview IP products like the HDM-C6MWIP-SET, HDM-C6MWIPL-R and HDM-C6MVIP-R (1080p only)
- Capable of upscaling 1080p@60Hz content to 4K@60Hz.
www.avenview.com
Rev. 00 - 10/2017
Recommended Network Switch for Video over IP applications
Switching capacity: 336 Gbit/s
Models: S5720-28X-PWR-SI-AC, S5720-28X-PWR-SI-DC
S5720-52X-PWR-SI-ACF

4
2.1 PACKAGE CONTENTS
Before you start the installation of the HDMI Extender, please check the package contents.
1HDM-C6MWIP4K-SET
(HDM-C6MWIP4K-S)
(HDM-C6MWIP4K-R)
X1
2
Power Adapter (+12V DC 1A)+International Adapters X2
User Guide X 1
2.2 BEFORE INSTALLATION
Right and Left Ear Rack Sets X2
3
5
6
Phoenix connector (Male, 3.5 mm, 3 pins)
x3 Sender
x3 Receiver
www.avenview.com
X1
X6
QTY
QTY
QTY
QTY
QTY
•Place the product on an even and stable surface. If the product falls, it may cause an injury to a person or malfunction.
•Do not place the product in high temperatures (over 50°C), or low temperature (under 0°C) or high humidity.
•Use the DC power adapter with correct specifications. If inappropriate power supply is used then it may cause a fire.
•Do not twist or pull by force ends of the UTP /HDMI cable. It can cause malfunction.
•Keep the device away from water. If the unit becomes wet, power off immediately.
•Installation of the equipment must comply with local and national electrical codes.
•Take care when connecting units to the electrical power circuit, incase the maximum rated circuit is not overloaded
ATTENTION
•To prevent airflow restriction, allow clearance around the ventilation openings to be at least: ONE Inch (25.4 mm).
•Unauthorized changes or modifications could void the user's authority to operate the equipment.
Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard
practices for preventing accidents.
•
Rev. 00 - 10/2017

5
2.3 APPLICATION DIAGRAM
www.avenview.com
Rev. 00 - 10/2017

6
2.4 PANEL DESCRIPTION
2.4.1 FRONT PANEL (Sender/Encoder, HDM-C6MWIP4K-S)
1. Power LED: Indicates if the unit is powered OFF or ON by a RED LED
2. Status LED: Steady Blue Light ON indicates unit is communicating properly. LED blinking waiting on Source
2.4.2 REAR PANEL (Sender/Encoder, HDM-C6MWIP4K-S)
3.
HDMI IN: Connect to HDMI/DVI Source.
4.
5. Stereo Audio OUT: Connects to an audio output
device such as an amplifier for audio de-embedding.
6.
CAT5/6: Used for transporting video/audio streams
to decoder RX units connected.
7.
RS 232-2: RS-232 Data pass-through port for
receiving /sending commands to RS 232 controllers.
8.
1 2
Power Jack: DC 12V 1A
Reset Button: Reboots the device. Hold down for
5 seconds on power up to restore factory defaults
www.avenview.com
Rev. 00 - 10/2017
LOCAL HDMI OUT: Connect to local display
for monitoring*
9. 10.
RS 232-1: Debug use
34 5 678910
*Note: Local output will display resolutions beyond the capabilities of the encoder. See Resolution Table for supported
encoder resolutions.

3
7
2.4.3 FRONT PANEL (Receiver/Decoder, HDM-C6MWIP4K-R)
1. Power LED: Indicates if the unit is powered OFF or ON by a RED LED.
2. Status LED: Steady Blue Light ON indicates unit is communicating properly. LED blinking waiting on Encoder.
2.4.4 FRONT PANEL (Receiver/Decoder, HDM-C6MWIP4K-R)
12
4567810
www.avenview.com
Rev. 00 - 10/2017
4.
HDMI OUT: Connect to display.
5.
6.Stereo Audio OUT: Connects to an audio output
device such as an amplifier for audio de-embedding.
7.
CAT5/6: Used for transporting video/audio streams
to decoder RX units connected.
8.RS 232-2: RS-232 Data pass-through port for
receiving /sending commands to RS 232 controllers.
9.
Power Jack: DC 12V 1A
Reset Button: Reboots the device. Hold down for
5 seconds on power up to restore factory defaults
10.
RS 232-1: Debug use
9
3.PUSH Button : To activate the internal ID of the unit to be displayed on the display. For easy Decoder identification

3. INSTALLATION (HDM-C6MWIP4K-SET) POINT to POINT
To setup Avenview HDM-C6MWIP4K-SET please follow these steps for connecting to a device:
1.
2.
3.
4.
5.
6.
7.
Turn off all devices including monitors / TV.
Connect an HDMI source (such as a Blu-Ray Disc player or PC) to the Encoder HDM-C6MWIP4K-S.
Connect CAT5/6 from Encoder to Decoder at the CAT5/6 port.
Connect an HDMI out from HDM-C6MWIP4K-R decoder to a Display/Monitor.
Connect Audio out to Speakers or Amplifier.
Ensure all cable connections are secure and not loose.
Plug in 12V DC power (supplied) and connect the HDM-C6MWIP4K-S and HDM-C6MWIP4K-R to power jack
respectively. Power on HDMI Source.
Power on the HDMI display.
3.1 IP MATRIX SWITCH GUIDE
8.
NOTE: For network setup please see the Network switch configuration guide and Network Connection guide to
acheive best results.
TX and RX Guide Networking Switch Guide
Distribution Status Total
Quantity
Network
Topology Recommended Switches
Centralized
Less than or
equal to 20
TX/RX Single Switch
Networking
Less than or
equal to 40
TX/RX
More than
40 TX/RX Cascading
Switch
Networking
Huawei Switches for Stacking topology
Core switches uses 1000 Mbps Ethernet switches.
Extended switches use 1000 Mbps Ethernet switches
Distributed No
requirement
www.avenview.com 8
Rev. 00 - 10/2017
Huawei Network Switch for Video over IP applications
Switching capacity: 336 Gbit/s
Models: S5720-28X-PWR-SI-AC, S5720-28X-PWR-SI-DC
S5720-52X-PWR-SI-ACF
Hauwei Network Switch for Video over IP applications
Switching capacity: 336 Gbit/s
Models: S5720-52X-PWR-SI-ACF

3.2 SINGLE SWITCH NETWORKING GUIDE
www.avenview.com 9
The illustration above is an example of how the user can connect using a 24 port network switch.
The following brands are recommended and was tested resulting in stable working conditions.
1. HUAWEI brand
2. HUAWEI Brand
Rev. 00 - 10/2017
Network Switch for Video over IP applications
Switching capacity: 336 Gbit/s
Models: S5720-28X-PWR-SI-AC, S5720-28X-PWR-SI-DC
S5720-52X-PWR-SI-ACF
Network Switch for Video over IP applications
Switching capacity: 336 Gbit/s
Models: S5720-28X-PWR-SI-AC, S5720-28X-PWR-SI-DC

3.3 NETWORKING GUIDE
www.avenview.com
It is not necessary to change the IP addresses of the encoders and decoders units – factory default AutoIP is used to configure correct
IP addresses to simply work out of the box.
DHCP addresses are not recommended, while Static addresses are for supervised setups and network strict enviroments.
Failure to note the IP settings of any unit changed may result in a complicated reset procedure.
Most M-Series installations use the POE (Power Over Ethernet) function to power the encoder & decoders units.
HDM-C6MWIP & HDM-C6MWIP4K devices are Class 0 rated POE devices, they can require up to 15.4W of power each, but tested
their actual power draw is between 5-7W. In order to calculate the number of devices that is recommeneded on a network switch
please divide the total POE power capacity of the switch by 15.4.
Please see the example:
CISCO SG300-52P with a POE power output of 375W: 375 / 15.4 = 24.35.From the answer 24 devices can be powered by this switch.
In order to have all ports powered by POE on a network switch, please see this example:
SG300-52MP which provides 740W. 740 / 15.4 = 48. From the answer 48 devices can be powered by this switch.
3.3.3 Data Bandwidth
Each HDM-C6MWIP4K-S encoder will produce up to 50Mb/s of data > therefore 10 x encoders will require 10 x 50Mb/s = 0.5 Gbps.
Avenview M-Series 4K HDMI over IP units can be networked together with a recommended Layer 2 Gigabit Smart Switches. As
mentioned previously in section 3 the importance of calculation for the capacity of the switch meets the requirements of the number of
encoders/decoders you have on your network. These units can perform well over a standard network infrastructure, however the
quality of this infrastructure is critical. We have tested many brands of switches all of which perform well in small system configurations
of around 10 Encoders and Decoders. However, for larger installations, Avenview highly recommends using HUAWEI series switches.
3.3.1 Simple Setup Guide for Network switch
M-series should be connected to a Layer 2 managed switch which supports Multicast & IGMP snooping.
Do not connect any units to the switch until all the network switch configuration has been. For recommended switches and PDF
configuration guides please see the ‘downloads’ section of any M-series device at avenview.com.
3.3.2 POE Requirements
10
Rev. 00 - 10/2017

11
4. PC CONFIGURATOR
Before using the Avenview PC Configurator, please ensure you download the most recent version from the product
HDM-C6MWIP4K-S Sender and HDM-C6MWIP4K-R Receiver website link /downloads PC control software. Refer
to the chart above for correct version numbers.
All devices must be in the same network segment. To verify and properly control the devices, please set a static IP on
your computer. See the instructions below on how to proceed:
The Sender and Receiver units are pre-configured with AutoIP. Upon connecting the units to a stand alone network
switch (without router attached), the units will be on IP address range at 169.254.1.1 and subnet mask 255.255.0.0.
Set your computer's IP address as 169.254.X.X and subnet mask as 255.255.0.0.
A Windows 7 PC/Laptop is used as an example to configure a static IP address.
You can connect multiple HDM-C6MWIP4K-S and the HDM-C6MWIP4K-R H.264 decoder to build a modular IP matrix.
With the PC configurator, you can configure and manage this function. For more information, see the user guide of PC
configurator on the M-Series product page available here.
Minimum System Requirements for PC Software:
Operating System: Microsoft® Windows® XP, Windows® Vista, Windows® 7 or Windows® 8
CPU: 1.5 GHz
Memory: 1 GB of RAM
HDD: 32 GB of available hard disk space
Network: 10/100 NIC
www.avenview.com
Rev. 00 - 10/2017
Products Versions
HDM-C6MWIP4K-S v3.1.1
HDM-C6MWIP4K-R v3.1.1
HDM-C6MWIP-R v2.11.4
HDM-C6MWIPL-R v2.11.4
CTRLPRO-MIP API V1.3/V7.6.1 (V7.6.0)
M-SERIES PC Console v8.0.9
Firmware Update Tool v3.0.2
Products and Versions
4.1 SETTING A STATIC IP ON YOUR COMPUTER

12
2. Double-click Internet Protocol Version 4 (TCP/IPv4).
www.avenview.com
Rev. 00 - 10/2017
1. Click Start > Choose Control Panel > Network and Internet > Network and Sharing Center > Change
Adapter Settings, right click Local Area Connection, and then choose Properties.
3. Select Use the following IP address. After configuring the settings in the following
example, click OK.
IP address: 169.254.2.5
Subnet mask: 255.255.0.0
4. Click OK.

13
Firewall
Your operating system firewall may block some features of PC Configurator and prevent it from communicating with Sender and
Receiver. A computer running Windows 7 is used as an example to configure your operating system firewall through either of the
following two approaches.
www.avenview.com
Rev. 00 - 10/2017
Method 1
You can configure the firewall in the Windows Firewall panel on your computer, for example select both Home/Work (Private) and
Public for PC Configurator & Matrix.
You can also configure the firewall in the Windows Security Alert window. When starting MaintainTool, the Windows
Security Alert may display. If so, use the administrator privileges to select a network you allow this software to
communicate on, for example select both private and public networks, and then click Allow access.
Method 2
5. CONFIGURING YOUR OPERATING SYSTEM

www.avenview.com Page
14
Item Description
Units HDM-C6MWIP4K-S HDM-C6MWIP4K-R
Unit Description HDMI Transmitter/Encoder HDMI Receiver/Decoder
Input Video Port
Input Video Type
Input Resolution
1 x HDMI IN
HDMI, DVI 1.0 H.264/MPEG-4 AVC
1 x CAT5/6
6. SPECIFICATIONS
Rev. 00 - 10/2017
Input Video Signal
Encoding Data Rate
Output Video Ports
Output Video Type
Output Resolutions
Up to 20 Mbps, configurable
Video Impedence 100 Ω 100 Ω
Input DDC Signal 5 V p-p (TTL)
End-to-End Time Latency About 60ms-90ms (Low latency mode)
About 250ms-300ms (High quality
mode)* (1080P Signals)
Input Audio Format Stereo
Output Audio Ports 1 x Phoenix connector
Control Method Rear panel CAT5/6 port,
PC configurator and RS-232
Environmental
OPERATING TEMPERATURE 32˚ ~ 104˚F (0˚ to 40˚C)
STORAGE TEMPERATURE -4˚ ~ 140˚F (-20˚ ~ 60˚C)
RELATIVE HUMIDITY 20~90% RH (no condensation)
1 x CAT5/6, 1 x HDMI
H.264/MPEG-4 AVC
Power Supply 12 V 1 A DC
Power Consumption 12W (Max.)
Shipping Dimensions (L X H X D) 12.2'' x 3.0'' x 7.1''
Product Dimensions (L X H X D) 9.3'' x 1.0'' x 3.7"
Weight 1 lbs
ESD Protection
Human body model:
-±8kV (air-gap discharge)
-±4kV (contact discharge)
Output Audio Format Stereo
About 60ms-90ms (Low latency mode)
About 250ms-300ms (High quality
mode)*(1080P Signals)
Audio embedded in streaming media input
1 x Phoenix connector
Stereo
PC configurator and RS-232
12 V 1 A DC
12W (Max.)
Human body model:
-±8kV (air-gap discharge)
-±4kV (contact discharge)
32˚ ~ 104˚F (0˚ to 40˚C)
-4˚ ~ 140˚F (-20˚ ~ 60˚C)
20~90% RH (no condensation)
12.2'' x 3.0'' x 7.1''
10.5'' x 1.0'' x 4.4''
Local HDMI output will mirror whatever
resolution is connected to input
NA
1 x HDMI
HDMI 2.0
1.3 lbs
NA
NA
See resolution table on next page
See resolution table on next page NA
0.5~1.2V p-p
*Note: See M-Series Latency Summary available here.

Page 15
www.avenview.com
Rev. 00 - 10/2017
6.1 SUPPORTED ENCODER RESOLUTIONS
6.2 SUPPORTED DECODER RESOLUTIONS

16
7. TROUBLESHOOTING
Problem Possible Solution
PC Configurator cannot find
devices
1. Check the Windows Firewall.
Taking Windows 7 as an example: Click Start menu, go to Control Panel
> System and Security > Windows Firewall > Allowed Programs, select
Home/Work (Private) and Public for PC configurator.
2. Check the IP address and subnet mask of your computer.
The computer, Sender, Receiver and switch should be in the same
network segment. Therefore, set your computer's IP address as
169.254.X.X and subnet mask as 255.255.0.0.
For more information, see the description in the networking guide.
Display Showing No Picture
1. Check all devices are powered on.
2. Check all cables are securely seated and connected properly.
3. Check the LED STATUS indicators on the Receivers to see if Senders and
Receivers are linked correctly. Blue Steady=OK Blue Blinking=standby
To link the devices use the PC configurator on your PC/Laptop, drag the
TX to the RX and click apply.
4. Check that source device is powered on and the HDMI cable is
connected.
PC Configurator (HDMI over IP) Maintain Tool
3. Check the switch configuration, and that IGMP snooping and all the
other functions are enabled.
Check the displays are powered on and the correct input selection.
Check the HDMI cable is plugged into the correct port.
www.avenview.com
Rev. 00 - 10/2017

17
1. All HDMI over CATx transmission distances are measured using Belden CAT6A (625MHz),
4-Pair,UTP-Unshielded, Riser-CMR, Premise Horizontal Cable, 23 AWG Solid Bare Copper
Conductors, Polyolefin Insulation, Patented Double-H spline, Ripcord, PVC Jacket using
Quantum 980 signal HDMI Video Generator Module with Video Pattern Testing and shielded
ends.
2. The transmission length is largely affected by the type of category cables, also the type of HDMI
sources, and the type of HDMI display. The testing result shows solid UTP cables (usually in the
form of 300m or 1000ft bulk cable) can transmit a lot longer signals than stranded UTP cables
(usually in the form of patch cords). Shielded STP connectors are better suit than unshielded
UTP connectors. A solid UTP CAT6A cable shows longer transmission length than solid UTP
CAT5E/6E cable.
3. EIA/TIA-568-B termination (T568B) for category cables is recommended.
4. To reduce the interference among the unshielded twisted pairs of wires in category cable, you
can use shielded STP cables with shielded connector to improve EMI problems, which occurs in
poor wiring environments with unplanned cable runs situated away from EMI interference.
5. Because the quality of the category cables has the major effects in how long transmission distance
will be made and how good is the received signal on the display, the actual transmission length
is subject to high quality category cables. For resolution greater than 1080i or 1280x1024, a
solid CAT6E 250MHz cable is the only viable choice.
PERFORMANCE GUIDE FOR HDMI OVER CATEGORY CABLE TRANSMISSION
PERFORMANCE RATING TYPE OF CATEGORY CABLE
WIRING SHIELDING CAT5 CAT5E CAT6
SOLID UNSHIElLDED (UTP)✶✶✶ ✶✶✶✶ ✶✶✶✶
SHIEl DED (STP)✶✶✶ ✶✶✶✶ ✶✶✶✶✶
STRANDED u NSHIEl DED (UTP)✶ ✶✶ ✶✶
SHIEl DED (STP)✶ ✶ ✶✶
TERMINATION PLEASE USE EIA/TIA-568-B TERMINATION (T568B) AT ANY TIME
www.avenview.com
Rev. 00 - 10/2017
