Avid Technology MediaDock 2 Plus Safety guide

a
Avid®MediaDock™2+
Setup and User’s Guide

2
Copyright and Disclaimer
Product specifications are subject to change without notice and do not represent a commitment on the part of Avid Technology, Inc.
The software described in this document is furnished under a license agreement. You can obtain a copy of that license by visiting
Avid’s Web site at www.avid.com. The terms of that license are also available in the product in the same directory as the software. The
software may not be reverse assembled and may be used or copied only in accordance with the terms of the license agreement. It is
against the law to copy the software on any medium except as specifically allowed in the license agreement. Avid products or
portions thereof are protected by one or more of the following United States patents: 4,746,994; 4,970,663; 5,045,940; 5,063,448;
5,077,604; 5,245,432; 5,267,351; 5,309,528; 5,325,200; 5,355,450; 5,396,594; 5,440,348; 5,452,378; 5,467,288; 5,513,375;
5,528,310; 5,557,423; 5,568,275; 5,577,190; 5,583,496; 5,584,006; 5,627,765; 5,634,020; 5,640,601; 5,644,364; 5,654,737;
5,701,404; 5,715,018; 5,719,570; 5,724,605; 5,726,717; 5,729,673; 5,731,819; 5,745,637; 5,752,029; 5,754,180; 5,754,851;
5,781,188; 5,799,150; 5,812,216; 5,828,678; 5,842,014; 5,852,435; 5,883,670; 5,889,532; 5,892,507; 5,905,841; 5,912,675;
5,929,836; 5,929,942; 5,930,445; 5,930,797; 5,946,445; 5,966,134; 5,977,982; 5,986,584; 5,987,501; 5,995,079; 5,995,115;
5,999,190; 5,999,406; 6,009,507; 6,011,562; 6,014,150; 6,016,152; 6,016,380; 6,018,337; 6,023,531; 6,023,703; 6,031,529;
6,035,367; 6,038,573; 6,052,508; 6,058,236; 6,061,758; 6,072,796; 6,084,569; 6,091,422; 6,091,778; 6,105,083; 6,118,444;
6,128,001; 6,128,681; 6,130,676; 6,134,379; 6,134,607; 6,137,919; 6,141,007; 6,141,691; 6,154,221; 6,157,929; 6,160,548;
6,161,115; 6,167,404; 6,174,206; 6,192,388; 6,198,477; 6,208,357; 6,211,869; 6,212,197; 6,215,485; 6,223,211; 6,226,005;
6,226,038; 6,229,576; 6,239,815; 6,249,280; 6,269,195; 6,271,829; 6,301,105; 6,310,621; 6,314,403; 6,317,142; 6,317,153;
6,317,515; D352,278; D372,478; D373,778; D392,267; D392,268; D392,269; D395,291;
D396,853; D398,912. Additional U.S. and foreign patents pending. No part of this document may be reproduced or transmitted in any
form or by any means, electronic or mechanical, including photocopying and recording, for any purpose without the express written
permission of Avid Technology, Inc.
Copyright © 2002 Avid Technology, Inc. and its licensors. All rights reserved. Printed in USA.
The following disclaimer is required by Apple Computer, Inc.
APPLE COMPUTER, INC. MAKES NO WARRANTIES WHATSOEVER, EITHER EXPRESS OR IMPLIED, REGARDING THIS PRODUCT,
INCLUDING WARRANTIES WITH RESPECT TO ITS MERCHANTABILITY OR ITS FITNESS FOR ANY PARTICULAR PURPOSE. THE
EXCLUSION OF IMPLIED WARRANTIES IS NOT PERMITTED BY SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY PROVIDES YOU WITH SPECIFIC LEGAL RIGHTS. THERE MAY BE OTHER RIGHTS THAT YOU MAY HAVE WHICH
VARY FROM STATE TO STATE.
The following disclaimer is required by Sam Leffler and Silicon Graphics, Inc. for the use of their TIFF library:
Copyright © 1988–1997 Sam Leffler
Copyright © 1991–1997 Silicon Graphics, Inc.
Permission to use, copy, modify, distribute, and sell this software [i.e., the TIFF library] and its documentation for any purpose is
hereby granted without fee, provided that (i) the above copyright notices and this permission notice appear in all copies of the
software and related documentation, and (ii) the names of Sam Leffler and Silicon Graphics may not be used in any advertising or
publicity relating to the software without the specific, prior written permission of Sam Leffler and Silicon Graphics.
THE SOFTWARE IS PROVIDED “AS-IS” AND WITHOUT WARRANTY OF ANY KIND, EXPRESS, IMPLIED OR OTHERWISE,
INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL SAM LEFFLER OR SILICON GRAPHICS BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR
PROFITS, WHETHER OR NOT ADVISED OF THE POSSIBILITY OF DAMAGE, AND ON ANY THEORY OF LIABILITY, ARISING OUT OF
OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
The following disclaimer is required by the Independent JPEG Group:
Portions of this software are based on work of the Independent JPEG Group.
The following disclaimer is required by Paradigm Matrix:
Portions of this software licensed from Paradigm Matrix.

3
The following disclaimer is required by Ray Sauers Associates, Inc.:
“Install-It” is licensed from Ray Sauers Associates, Inc. End-User is prohibited from taking any action to derive a source code
equivalent of “Install-It,” including by reverse assembly or reverse compilation, Ray Sauers Associates, Inc. shall in no event be liable
for any damages resulting from reseller’s failure to perform reseller’s obligation; or any damages arising from use or operation of
reseller’s products or the software; or any other damages, including but not limited to, incidental, direct, indirect, special or
consequential Damages including lost profits, or damages resulting from loss of use or inability to use reseller’s products or the
software for any reason including copyright or patent infringement, or lost data, even if Ray Sauers Associates has been advised,
knew or should have known of the possibility of such damages.
The following disclaimer is required by Videomedia, Inc.:
“Videomedia, Inc. makes no warranties whatsoever, either express or implied, regarding this product, including warranties with
respect to its merchantability or its fitness for any particular purpose.”
“This software contains V-LAN ver. 3.0 Command Protocols which communicate with V-LAN ver. 3.0 products developed by
Videomedia, Inc. and V-LAN ver. 3.0 compatible products developed by third parties under license from Videomedia, Inc. Use of this
software will allow “frame accurate” editing control of applicable videotape recorder decks, videodisc recorders/players and the like.”
The following notice is required by Altura Software, Inc. for the use of its Mac2Win software and Sample Source
Code:
©1993–1998 Altura Software, Inc.
The following notice is required by Ultimatte Corporation:
Certain real-time compositing capabilities are provided under a license of such technology from Ultimatte Corporation and are
subject to copyright protection.
Attn. Government User(s). Restricted Rights Legend
U.S. GOVERNMENT RESTRICTED RIGHTS. This Software and its documentation are “commercial computer software” or “commercial
computer software documentation.” In the event that such Software or documentation is acquired by or on behalf of a unit or agency
of the U.S. Government, all rights with respect to this Software and documentation are subject to the terms of the License Agreement,
pursuant to FAR §12.212(a) and/or DFARS §227.7202-1(a), as applicable.
Trademarks
AirPlay, AudioVision, Avid, Avid Xpress, CamCutter, Digidesign, FieldPak, Film Composer, HIIP, Image Independence, Marquee,
Media Composer, Media Recorder, NewsCutter, OMF, OMF Interchange, Open Media Framework, Pro Tools, and Softimage are
registered trademarks and 888 I/O, AirSPACE, AirSPACE HD, AniMatte, AudioSuite, AutoSync, AVIDdrive, AVIDdrive Towers, AvidNet,
Avid Production Network, AvidProNet, AvidProNet.com, AVIDstripe, Avid Unity,
AVX, DAE, D-Fi, D-fx, Digidesign Audio Engine, DINR, D-Verb, ExpertRender, FilmScribe, HyperSPACE, HyperSPACE HDCAM,
Intraframe, iS9, iS18, iS23, iS36, Lo-Fi, Magic Mask, make manage move | media, Matador, Maxim, MCXpress, MEDIArray,
MediaDock, MediaDock Shuttle, Media Fusion, Media Illusion, MediaLog, Media Reader, MediaShare, Meridien, NaturalMatch,
NetReview, OMM, Open Media Management, ProEncode, QuietDrive, R&A, Recti-Fi, Review & Approval, rS9, rS18, Sci-Fi,
Sound Designer II, SPACE, SPACEShift, Symphony, Trilligent, UnityRAID, Vari-Fi, Video Slave Driver, and VideoSPACE are trademarks
of Avid Technology, Inc.
iNEWS and Media Browse are trademarks of iNews, LLC.
FireWire, Mac, and Macintosh are registered trademarks of Apple Computer, Inc., registered in the U.S. and other countries.
Microsoft, MS-DOS, and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or
other countries. All other trademarks contained herein are the property of their respective owners.
Avid MediaDock 2+ Setup and User’s Guide •
Part 0130-05192-01 Rev. A •January 2002

4
Contents
Using This Guide
Who Should Use This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Symbols and Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
If You Need Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Related Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
If You Have Documentation Comments . . . . . . . . . . . . . . . . . . . . . . . 14
How to Order Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Chapter 1 Overview
MediaDock 2+ Enclosure Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MediaDock 2+ Enclosure Slots. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
LVD Shuttle Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
LVD Shuttle Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Drive-Filler Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
SCSI Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
SCSI LVD Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Rack-Mount Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

5
Chapter 2 Installation
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Unpacking the MediaDock 2+ Enclosure. . . . . . . . . . . . . . . . . . . 30
Power Cord Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Connecting Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Connecting the MediaDock 2+ Enclosure . . . . . . . . . . . . . . . . . . 31
Maximum Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
SCSI LVD Terminator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Determining SCSI IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
SCSI IDs on Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Setting the LVD Shuttle SCSI ID. . . . . . . . . . . . . . . . . . . . . . . . . . 36
Installing an LVD Shuttle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Removing an LVD Shuttle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Replacing an LVD Shuttle Using Any Operating System . . . . 40
Replacing an LVD Shuttle on a Windows 2000 System. . . . . . . 41
Replacing an LVD Shuttle on a Macintosh System . . . . . . . . . . 43
Chapter 3 Preparing Your Drives
Managing LVD Shuttles on Windows 2000 Systems . . . . . . . . . . . . 48
Supported Windows File Systems. . . . . . . . . . . . . . . . . . . . . . . . . 49
Creating Primary Partitions and Formatting Drives with the
Windows 2000 Operating System. . . . . . . . . . . . . . . . . . . . . . . . 50
Creating a Disk Configuration Floppy Disk from
Windows NT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Transferring Disk Drives or Stripe Sets from the
Windows NT System to the Windows 2000 System . . . . . . . . 54
Importing the Disk Configuration into the
Windows 2000 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Managing LVD Shuttles on Macintosh Systems . . . . . . . . . . . . . . . . 56
Checking LVD Shuttles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Using Disk First Aid to Repair LVD Shuttles . . . . . . . . . . . . . . . 58
Erasing LVD Shuttles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Problems Specific to Macintosh Systems. . . . . . . . . . . . . . . . . . . 61

6
Striping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Diagnostic Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Chapter 4 Installing an Optional DVD Writer
Interface Panel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
DVD Writer Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
IEEE 1394 Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
IEEE 1394 Configuration Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Appendix A Specifications
Dimensions and Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Power Supply Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Power Cord Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
CEE-22 Power Cord Requirements . . . . . . . . . . . . . . . . . . . . . . . . 78
United States and Canada Power Cord Requirements . . . . . . . 78
European Countries Power Cord Requirements. . . . . . . . . . . . . 79
Appendix B Regulatory and Safety Notices
FCC Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Canadian ICES-003. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
European Union Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Australia and New Zealand EMC Regulations . . . . . . . . . . . . . . . . . 83
Taiwan EMC Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Index

7
Figures
Figure 1-1 Slot Allocation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 1-2 MediaDock 2+ Front Panel . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 1-3 MediaDock 2+ Back Panel . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 1-4 LVD Shuttle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 1-5 Drive-Filler Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 1-6 Rack-Mount Holes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 1-7 Rack-Mount Brackets. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 2-1 Power Supply Connector . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 2-2 Dual-Channel SCSI LVD Board Connectors . . . . . . . . 32
Figure 2-3 MediaDock 2+ Enclosure SCSI Connectors . . . . . . . . . 32
Figure 2-4 Configuration Using Four MediaDock 2+
Enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Figure 2-5 Avid SCSI LVD Terminator . . . . . . . . . . . . . . . . . . . . . . 34
Figure 2-6 Setting SCSI IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 2-7 SCSI ID Switch Location . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 2-8 SCSI ID Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 2-9 LVD Shuttle Latch and Handles . . . . . . . . . . . . . . . . . . 38
Figure 2-10 Inserting the LVD shuttle . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 2-11 Letting the LVD Shuttle Spin Down . . . . . . . . . . . . . . . 40
Figure 2-12 Computer Management Window . . . . . . . . . . . . . . . . . 42
Figure 2-13 ADU2 Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Figure 2-14 Identify Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Figure 2-15 ADU2 Window - Unmount . . . . . . . . . . . . . . . . . . . . . . 45
Figure 3-1 Disk First Aid Main Window Functions. . . . . . . . . . . . 59
Figure 3-2 Disk First Aid Message Box . . . . . . . . . . . . . . . . . . . . . . 60

8
Figure 3-3 Disk First Aid Verification Results . . . . . . . . . . . . . . . . 60
Figure 4-1 Top Cover Screws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Figure 4-2 Interface Panel Screws. . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Figure 4-3 IEEE 1394 Interface Panel . . . . . . . . . . . . . . . . . . . . . . . . 68
Figure 4-4 Blank Panel Tabs and Metal Plate Screw . . . . . . . . . . . 69
Figure 4-5 Bracket Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Figure 4-6 Securing the Optional DVD Writer to the Bracket . . . 71
Figure 4-7 Optional DVD Writer Cabling . . . . . . . . . . . . . . . . . . . . 72
Figure 4-8 Connecting the IEEE 1394 Cables . . . . . . . . . . . . . . . . . 73
Figure A-1 Receptacle (CEE-22). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Figure A-2 NEMA 5-15P Style Plug . . . . . . . . . . . . . . . . . . . . . . . . . 78

9
Tables
Tab le 1 -1 MediaDock 2+ LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Tab le 1 -2 LVD Shuttle LED Functions . . . . . . . . . . . . . . . . . . . . . . 21
Tab le 1 -3 SCSI LVD Cables Available Through Avid . . . . . . . . . 26
Tab le A -1 Dimensions and Weights . . . . . . . . . . . . . . . . . . . . . . . . 75
Tab le A -2 Environmental Specifications. . . . . . . . . . . . . . . . . . . . . 76
Tab le A -3 Power Supply Specifications . . . . . . . . . . . . . . . . . . . . . 77
Tab le A -4 United States and Canada Power Cord
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Tab le A -5 European Power Cord Requirements . . . . . . . . . . . . . . 79

10
Using This Guide
Congratulations on your purchase of the Avid®MediaDock™2+. This
guide contains information about connecting MediaDock 2+
enclosures to an Avid editing system. The MediaDock 2+ enclosure is
used in conjunction with Avid LVD shuttles to store, play back, and
record media files. The MediaDock 2+ enclosure is qualified on
Avid editing systems running Macintosh®or Windows®operating
systems.
Who Should Use This Guide
This guide is intended for Avid editors who are connecting
MediaDock 2+ enclosures to an Avid editing system.

11
About This Guide
The information in this guide is a supplement to the media drive
installation instructions found in the setup guide that came with your
Avid editing system.
This guide contains the following information:
• Chapter 1, “Overview,” describes the controls and indicators on
the front and back panels of the MediaDock 2+ enclosure. It also
includes information on the rackmount option available for the
MediaDock 2+ enclosure, as well as information on LVD shuttles.
• Chapter 2, “Installation,” provides step-by-step instructions for
connecting a MediaDock 2+ enclosure to your Avid editing system
and setting the SCSI IDs.
• Chapter 3, “Preparing your Drives,” describes how to format your
drives on Windows and Macintosh operating systems. This
chapter also includes information about how to move LVD
shuttles from one system to another. See this chapter for
information on available diagnostic utilities.
• Chapter 4, “Installing an Optional DVD Writer,” explains how to
install a DVD writer in the optional device bay. Information on
IEEE 1394 interface configurations is provided.
• Appendix A, “Specifications,” lists the dimensions and weights,
and the environmental, power supply, and power cord
specifications for the MediaDock 2+ enclosure.
• Appendix B, “Regulatory and Safety Notices,” provides
regulatory and safety information for the system.

12
Symbols and Conventions
The MediaDock 2+ enclosure documentation uses the following
special symbols and conventions:
1. Numbered lists, when the order of the items is important.
a. Alphabetical lists, when the order of secondary items is
important.
• Bulleted lists, when the order of the items is unimportant.
- Indented dashed lists, when the order of secondary items is
unimportant.
tOne arrow indicates a single-step procedure. Multiple arrows in a
list indicate that you perform one of the actions listed.
Look here in the margin
for tips. In the margin, you will find tips that help you perform tasks more
easily and efficiently.
nA note provides important related information, reminders, recommendations,
and strong suggestions.
cA caution means that a specific action you take could cause harm to
your computer or cause you to lose data.
wA warning describes an action that could cause you physical harm.
Follow the guidelines in this guide or on the unit itself when
handling electrical equipment.
In this document, Avid editing system refers to the system where your
Avid application software is installed.
Avid application software refers to the editing or playback software you
have purchased from Avid, such as Media Composer®,
Film Composer®, Symphony™, Avid Media Station, Avid Xpress®,
Avid Xpress DV, Avid|DS, NewsCutter®XP, or NewsCutter software.

13
Shuttle refers to the removable drive unit. The shuttle allows you to
transport data and media files from one system to another without
connecting and disconnecting cables. LVD (low-voltage differential)
indicates the drive technology inside the shuttle.
Daisy-chained refers to a MediaDock 2+ enclosure connected in a series
by one or more cables to multiple SCSI devices (such as another
MediaDock 2+ or MediaDrive rS LVD enclosure). Transmitted signals
go to the first SCSI device, then to the second, and so on. It also refers
to connecting the optional DVD IEEE 1394 (FireWire®) interface panel
to another 1394 device, such as the MediaDrive rS IEEE 1394
enclosure.
HotPlug refers to the process of pulling out a component from a system
and plugging in a new one while the power is still on and the unit is
operating.
If You Need Help
If you are having trouble setting up and configuring the
MediaDock 2+ enclosure hardware, you should:
1. Retry the action, carefully following the instructions given for that
task in this guide.
2. Check the documentation that came with your hardware for
maintenance or hardware-related issues.
3. Check the release notes supplied with your Avid application for
information on accessing the Avid Web site and the Avid
Knowledge Center.
4. For support services, call Avid Customer Support:
- Broadcast products — call 800-NEWS-DNG (639-7364).
- Postproduction products — call 800-800-AVID (2843).

14
Related Information
The appropriate Avid Products Setup Guide provides additional
information that might be useful when configuring the MediaDock 2+
enclosure. This guide provides SCSI installation and configuration
instructions as well as suggestions for troubleshooting problems that
might arise with the Avid editing system hardware.
If You Have Documentation Comments
Avid Technology continuously seeks to improve its documentation.
We value your comments about this guide and other Avid-supplied
documentation.
Simply e-mail your documentation comments to Avid Technology at
T[email protected]
Please include the title of the document, its part number, revision, and
the specific section you are commenting on in all correspondence.
How to Order Documentation
To order additional copies of this documentation from within the
United States, call Avid Telesales at 800-949-AVID (2843). If you are
placing an order from outside the United States, contact your local
Avid representative.

15
CHAPTER 1
Overview
The Avid MediaDock 2+ houses two LVD shuttles and an optional
DVD writer. The shuttles make it easy to share media (or data files)
between systems without connecting or reconnecting cables. The
MediaDock 2+ shuttles communicate with the Avid editing system
through a small computer system interface (SCSI) bus. The LVD
shuttles contain an industry-standard SCSI drive that is optimized for
use with Avid’s video and audio applications. The optional DVD
writer communicates with the Avid editing system via IEEE 1394
(FireWire).
nAs drive size and performance improve, different LVD shuttles will be
available for use. Contact your local Avid Reseller or call the Avid Sales and
Product information line at 800-949-2843 for the latest information about
available drives.
The MediaDock 2+ enclosure is designed as a desktop unit as well as
for mounting in industry-standard, 19-inch racks. Multiple
MediaDock 2+ enclosures can be stacked on top of one another,
minimizing the amount of desk space required.
LVD shuttles can be formatted for Windows or Macintosh operating
systems. Windows operating systems use the Windows Disk
Management utilities in the Windows operating system. For details,
see Chapter 3 of this guide and your Windows operating system
documentation.

16
Macintosh operating systems use the AVIDdrive™Utility 2 software to
manage shuttle packs (LVD shuttles) within your Avid editing system.
nFor information on using AVIDdrive Utility 2, see the AVIDdrive Utility 2
User’s Guide and the release notes for Media Composer Release 8.0 or later.
This chapter provides the following sections:
•MediaDock 2+ Enclosure Features
•LVD Shuttle Features
•System Requirements
•SCSI Requirements
•SCSI LVD Cables
•Rack-Mount Options
MediaDock 2+ Enclosure Features
The MediaDock 2+ enclosure contains:
• Two shuttle slots that support:
-LVDSCSIoperation
- Wide bus data transfers over a 16-bit bus up to 160 MB/s
(depending on the type of hard disks configured on the SCSI
bus and the type of host bus adapter)
- One LVD shuttle per slot containing a single 1.0-inch- or
1.6-inch-high hard disk in a 3.5-inch form factor
• One slot available for an optional DVD writer
• Single power supply
• Front-mounted SCSI ID selection switches
• LEDs to monitor MediaDock 2+ enclosure’s power and
temperature as well as shuttle functions
• Variable-speed, temperature-sensing fan

17
MediaDock 2+ Enclosure Slots
The MediaDock 2+ enclosure has two slots for LVD shuttles (see
Figure 1-1). This guide illustrates the MediaDock 2+ enclosure
without any device in the optional device bay. For instructions on
installing a DVD writer in the optional device bay, see Chapter 4.
nThe LVD shuttles are sold separately, see “LVD Shuttle Features” on
page 20.
Figure 1-1 Slot Allocation
Slot 1
Slot 2
Optional Device Bay

18
Front Panel
The front of the Avid MediaDock 2+ has controls and indicators for
determining its operating status (see Figure 1-2).
The front panel power switch turns the drive’s internal power supply
on and off. Two light emitting diodes (LEDs) provide the status of the
unit. The SCSI ID switches provide the method for setting the drive
shuttle’s SCSI IDs. The label on the right side of the front panel is the
Avid product identification label.
Figure 1-2 MediaDock 2+ Front Panel
Detailed descriptions of the LEDs are provided in Tab le 1- 1 .
Power LED (green)
Power switch
SCSI ID switchesThermal LED (red) Product label
NOTE: The label on your front panel might differ from the one shown.
Table 1-1 MediaDock 2+ LEDs
LED Function
Power LED The LED (green) is on when the enclosure is turned
on.
nWhen the LVD shuttle bays are empty and the
power is on, the power LED might blink slowly.

19
Back Panel
The MediaDock 2+ back panel has two SCSI connectors and a power
connector (see Figure 1-3). The SCSI connectors are for attaching SCSI
cables or a SCSI terminator to the drives. An internal fan pushes air
through the enclosure, from front to back, to cool the drive. The power
connector is where you attach the power cord. The optional device
connector panel contains IEEE 1394 (FireWire) connectors when an
optional DVD writer is installed. See Chapter 4 for more information.
Figure 1-3 MediaDock 2+ Back Panel
Thermal LED
c
The LED (red) flashes when the thermal overload
circuitry senses that the temperature inside the
MediaDock 2+ is too high. The LED could light for
the following reasons:
• Airflow through the drive is blocked.
• The internal fan has failed.
• Room ambient temperature is too hot.
Operating the MediaDock 2+ for extended
periods of time with the thermal indicator
on reduces the life expectancy of the drives.
Table 1-1 MediaDock 2+ LEDs (Continued)
LED Function
Power connector
68-pin SCSI connectors
Variable speed fan opening
Optional device
connector panel

20
Power Supply
The power supply in the MediaDock 2+ enclosure supplies power to
both LVD shuttles and the optional device bay.
The power supply has two LEDs that are visible on the front of the
chassis beside the power switch. The green LED is On when power is
on and within specifications. The red LED is On when a thermal fault
is detected. Figure 1-2 shows the power switch and LED locations on
the MediaDock 2+ enclosure. Descriptions of the LEDs are provided in
Tab le 1 -1.
LVD Shuttle Features
The MediaDock 2+ enclosure uses only LVD shuttles. These shuttles
are not included with the MediaDock 2+ enclosure, and must be
purchased and installed separately. The LVD shuttles are available in a
variety of storage capacities.
The LVD shuttles use a lever for inserting or removing the LVD shuttle
from the MediaDock 2+ enclosure. The internal drives have a 3.5-inch
form factor and transfer data on a 16-bit data bus. The drive enclosure
provides the cooling, power, and cabling connections.
Each LVD shuttle contains two LEDs that provide information about
the LVD shuttle’s activity (see Figure 1-4). Tab le 1 -2 describes the
function of each LED. The third LED is not used in the MediaDock 2+.
