Avidsen 127043 User manual

WIFI MOTION
DETECTOR
HomeSensor IR-Wall
Ref.127043
www.avidsen.com
V1

EN3
TABLE
OF CONTENTS
A - SAFETY
INSTRUCTIONS
1 - OPERATING PRECAUTIONS 04
2 - WARNING 04
3 - MAINTENANCE AND CLEANING 04
4 - RECYCLING 04
B - PRODUCT
DESCRIPTION
1 - KIT CONTENTS 05
2 - CONNECTED MOTION SENSOR 05
3 - DETECTION ZONE 05
C - INSTALLATION
1 - INSTALLING THE SENSOR
ON THE WALL OR CEILING 06
2 - CHARGING THE BATTERY 06
D - WORKING WITH
THE APPLICATION
1 - CONNECTION 7
1.1 - Installing the mobile application and
creating an account 7
1.2 - Connecting the IRWALL 8
E - OPERATION
1 - USING THE PRODUCT VIA THE
APPLICATION 10
F - TECHNICAL AND
LEGAL INFORMATION
1 - TECHNICAL CHARACTERISTICS 10
2 - WARRANTY 11
3 - HELP AND ADVICE 11
4 - DECLARATION OF CONFORMITY 11

EN 4
A - SAFETY INSTRUCTIONS
1 - OPERATING PRECAUTIONS
• Read this entire manual before starting the
installation.
• Do not allow children to operate the product.
• This product is designed exclusively for indoor
use.
• This product is designed to work with a
smartphone with WiFi.
2 - WARNING
This product has been designed to detect motion
at a distance of less than 6 metres and with a 115°
angle; it must be used with the Avidsen Home app.
Any other use of the device shall not be covered by
the warranty or technical support. Avidsen cannot
be held liable for any use that does not comply
with the instructions in this manual and causes
damage. Children should be supervised to make
sure that they do not play with the device.
3 - MAINTENANCE AND CLEANING
The outside of the housing may have to be cleaned
from time to time.
• Switch off the circuit breaker before working on
the product.
• Do not use abrasive substances, substances
containing alcohol, thinners or other ammable
substances.
• Do not spray any products directly onto the unit.
4 - RECYCLING
This logo denotes that devices no longer
in use should not be disposed of as
household waste. They are likely to
contain hazardous substances that are
dangerous to both health and the
environment. Return the equipment to your local
distributor or use the recycling collection service
provided by your local council.
Pour en savoir plus :
www.quefairedemesdechets.fr

EN5
B - PRODUCT DESCRIPTION
The main component of the smart sensor is the infrared sensor, which can detect motion at a distance of
less than 6m and a maximum angle of 115°. The sensor is equipped with a WiFi connection to communicate
with the Avidsen Home app, allowing you for example to:
• Automatically switch an Avidsen Home HomeLight bulb on or off
• Turn the HomePlug smart plug on or off
• Turn on the heating or air conditioning…
1 - KIT CONTENTS
11 WiFi motion detector
21 micro USB cable
1Reset button
2Micro USB port to charge
the product
3ON/OFF switch
31 self-adhesive double sided tape mount
41 tool to reset the detector
ON OFF
DC5V
RESET
1x1 2x1 3x1 4x1
2 - CONNECTED MOTION SENSOR
3 - DETECTION ZONE
ON OFF
DC5V
RESET
3
2
1
6m
2,5m
3,6m
4m

EN 6
C - INSTALLATION
1 - INSTALLING THE SENSOR ON THE WALL
OR CEILING
2 - CHARGING THE BATTERY

EN7
D - WORKING WITH THE APPLICATION
1 - CONNECTION
1.1 - INSTALLING THE MOBILE APP AND
CREATING AN ACCOUNT
This product only works with a 2.4Ghz frequency.
During pairing, make sure your smartphone is
connected on that specic frequency. If you are
not sure, check with your Internet service provider.
Once the IRWall has been mounted, set the switch
to ON and follow the instructions below to pair it.
Download the Avidsen Home app from the Android
Play Store or Apple App Store.
Launch the app and log in if you already have
an account. If not, press CREER UN NOUVEAU
COMPTE (CREATE A NEW ACCOUNT) and let
the application guide you.
After accepting the privacy policy, create an
account with an email address.
In both cases, choose your country and then, after
entering your email address, select Obtenir le
code de vérication (Get verication code).
In a few seconds, you will receive a validation
code in your email inbox. Enter this code to nalise
registration.
Note that this email may go into your spam folder.
If you do not receive a code before the countdown
has ended, press renvoyer (return) and check the
email address entered.

EN 8
To complete your registration, set a password
between 6 and 20 characters long with letters and
numbers only, Then press Terminé (Finished).
1.2 - CONNECTING THE IRWALL
As soon as it is powered, the device is in pairing
mode by default. The indicator light will then ash
until the pairing procedure is completed. Otherwise
follow the reset procedure on your phone
To start pairing, press AJOUTER (ADD). Make
sure your phone is connected to your router’s 2.4
GHz WiFi network. If you already have a device
installed on the application (e.g. IP camera, smart
plug, etc.) click on + in the top right corner of the
application.
Select the product you wish to pair and select
IRWall.
Make sure the IRWall is switched on and the red
indicator light is ashing. Otherwise, press the
reset button for 5s so that the red indicator light
starts ashing.
Select your 2.4 GHz WiFi network (note: your
smartphone must be connected to the WiFi
network to which the plug will be connected), enter
your network password and press Suivant (Next).
IMPORTANT: if a location authorisation request
message appears, you need to accept it for your
Android or iOS device to receive your WiFi.
D - WORKING WITH THE APPLICATION

EN9
D - WORKING WITH THE APPLICATION
IMPORTANT: This device is compatible with 2.4
GHz - WPA/WPA2 networks. Not compatible
with 5 GHz WiFi or with WEP encryption. Please
check the WiFi settings of your router or contact
your Internet service provider if you experience
connection difculties.
If the following message comes up:
Click on change, or connect your smartphone to a
2.4GHz frequency then click on Continue.
Please wait while the pairing procedure takes
place. This stage can last several minutes.
Your HomeSensor is now operational and will
appear in your app.
You can now use your Avidsen sensor from your
smartphone.
You can rename it by clicking on the small pencil to
the right of the device name.

EN 10
1 - USE VIA THE APPLICATION
The sensor is used to detect motion in the room.
You can receive notications on your smartphone
and use this sensor with other products to create
automations (see scenario tab). For example, you
can switch on the HomeLight bulb automatically
for a few minutes when you walk in front of the
sensor.
You can also check motion detection details in the
app.
E - OPERATION
F - TECHNICAL AND LEGAL INFORMATION
1 - TECHNICAL CHARACTERISTICS
Features Movement detector
Connection Wireless - Wi-Fi
Use Indoor
Angle of detection 115°
Detection range 3.5m x 6m
Operating T° -10°C/+50°C
Storage T° -10°C/+50°C
Power supply 5V - 1A during charge
Battery Lithium 3.7V 500mA
Installation On a wall or on the ceiling
Colour White
Protection rating IP20
Radio protocol WiFi
Radio frequency 2.4 GHz
Protocol 802.11 b/g/n
Radio range
- Unobstructed range: 50m
- Masonry: 25m, through 3 walls max.
- Reinforced concrete: 10m, through 1 wall/oor
max.
- Plasterboard/Wood: 30m, through 5 walls
max.

EN11
F - TECHNICAL AND LEGAL INFORMATION
2 - WARRANTY
This product is guaranteed for parts and labour
for 2 years from the date of purchase. Proof of
purchase must be retained for the duration of the
warranty period.
The warranty does not cover damage caused by
knocks or accidents.
3 - HELP AND SUGGESTIONS
• If, despite the care we have taken in designing
our products and drafting these instructions, you
do encounter difculties when installing your
product or you have any questions, we urge you
to contact one of our specialists who will be glad
to help.
• If you encounter operating problems during
the installation or a few days afterwards, it is
essential that you are in front of your installation
when contacting us, so that one of our technicians
can diagnose the source of the problem, as it will
probably be the result of a setting that is incorrect
or an installation that is not to specication. If
the problem is caused by the product itself, the
technician will give you an RMA number so that
you can return the unit to the shop.
Without this RMA number, the shop may refuse to
exchange your product.
Need advice for the installation or start-up of your
product?
Contact our after sales service team technicians:
0,35 € / min
0 892 701 369
Monday to Friday, 9pm to 12pm, and 2pm to
6pm.
Avidsen undertakes to keep a stock of spare
parts for this product throughout the contractual
warranty period.
4 - DECLARATION OF CONFORMITY
with the RED directive
Avidsen declares that the equipment complies
with the RED 2014/53/EU directive and that its
conformity has been assessed pursuant to the
applicable standards in force:
EN 300 328 V2.1.1 (2016-11)
EN 301 489-1 V2.2.1
EN 301 489-17 V3.2.0
EN 50130-4:2011
EN 62311:2008
EN 60730-1:2011
Tours, 24/08/2020
Alexandre Chaverot, CEO

Avidsen
19 avenue Marcel Dassault - ZAC des Deux Lions
37200 Tours - France
