www . a v i ronactiv e . com
Impact Series Rower
Service Manual
2
CONTENTS
Parts Reference step
Shroud
Tension cable
Motor
Sensor
Magnec wheel w/fan
Belt
Return spring assembly
Slider assembly (w/ PU wheel)
Cable
1→2
1→2→4
1→2→4→9
1→2→7
1→2→4→5
1→2→4→5→6
11→12
1→2→3→5.1→6.1→7→8
1→2→10
Step 1
Remove shroud-1
N10
N10
N10
N10
N10
N8
N8
N8
N8
N8
3
INSTRUCTIONS
Step 2
Remove shroud-2
N7
N7
N7
N7
N7
N7
N7
4
INSTRUCTIONS
Step 3
Remove handlebar
12
35 41
37
17
5
INSTRUCTIONS
Step 4
Remove tension cable
E1
E1
Before removing the tension cable, adjust
the resistence to the heaviest level.
6
INSTRUCTIONS
Step 5.1
'13='1!+2'ধ$>,''£>c(!2
C1 C3
C1
C3
B1
Step 5.2
7
INSTRUCTIONS
Step 6.1
Remove belt
Step 6.2
F1
8
INSTRUCTIONS
Step 7
Remove sensor
Step 8
Remove return spring assembly
A0
A14
A14
D1
9
INSTRUCTIONS
Step 9
Remove motor
Step 10
Remove cable
84
66
67
K3
K6
K1
10
INSTRUCTIONS
