AVIRON Tough Series User manual

www.avironactive.com
Tough Series Rower
User Manual

2

3
WELCOME
to AVIRON INTERACTIVE
Connected. Competitive. Exhilarating.
This guide will help you safely setup the equipment and get you started.
You can nd addional help and tutorials in the Aviron applicaon help menu
or our website www.avironacve.com
TOUCHSCREEN
TRANSPORT WHEELS
POWER PLUG
RAIL
STABILITY FEET
DRIVE BELT
HANDLEBAR
HANDLE HOOK
FOOT CARRIAGE
SEAT
We are excited to get you started!

4
SLEEP BUTTON
CAMERA AND MICROPHONE
VOLUME CONTROL
HEADPHONE JACK
INCREASE RESISTANCE
DECREASE RESISTANCE
BACK BUTTON
CAUTION: Any changes or modicaons to this equipment could void the equipment warranty.
Any service other than cleaning or user maintenance must be performed by an authorized
service representave. There are no user-serviceable parts.
ETHERNET PORT LOCATED AT REAR

5
RESISTANCE 15
14 1613 1200 METERS 5:25 MIN/200M 21 SPM 365 CALORIES 15 16 RESISTANCE 1314
10:23 AM
1
2
3
4
5
PLAYER 1
PLAYER 2
PLAYER 3
PLAYER 4
PLAYER 5
114
112
WATTS
OUTPUT ( KJ )
0 240
160
150
142
111
102
POSITION OUTPUT ( KJ )
LEADERBOARD 05:11
1
2
3
4
5
2
1
3
4
WORKOUT SCREEN
2.
3.
6.
8.
9.
10.
11.
12.
13.
7.
RESISTANCE LEVEL
TIME REMAINING/ELAPSED
CHECKPOINT
METERS TRAVELED
EXIT
BACK
Go back to the previous menu
SPLIT TIME
Projected minutes to travel 500 meters
4.
5.
1. LEADERBOARD
PLAYERS
See other players and their posion
WATTS
Was per stroke
CALORIES BURNED

STROKE RATE
Strokes per minute
Your posion highlighted in red in
relaon to other players
8 85 6
9
10
2
7
3
1
4
12
11
13

6
FRAME
High strength aluminum
RESISTANCE
16 level dual air & magnec system
BELT
Industrial poly-v belt
SEAT
Ergonomic seat with extra rear support
DIMENSIONS
249.5 x 53 x 111 cm
WEIGHT
125LBS / 56.5KG
MAX USER WEIGHT
507LBS / 230KG
ROWER
SPECIFICATIONS

7
SCREEN
21.5” 1080P touchscreen
PROCESSORS
ARM 2.0Ghz dual core & 1.5Ghz quad core
GRAPHICS
ARM Mali-T864 GPU
MEMORY
4GB RAM
STORAGE
32GB eMMC ash
OS
Android 7.0
WIFI
802.11 b/g/n/ac
ETHERNET
10/100Mbps
BLUETOOTH
4.1
CAMERA
2 megapixel front-facing
SPEAKERS
2x2 wa stereo
CERTIFICATIONS
FCC & IC
TOUCHSCREEN
SPECIFICATIONS

8
Read all instrucons before assembling and using the equipment.
These instrucons are for your safety and to protect the equipment.
Periodically consult your physician before using the equipment. If at any me
you feel faint, dizzy or are experiencing pain, stop and consult your physician
immediately. It is recommended that you consult a tness professional on the
correct use of this equipment.
The equipment is not recommended for children under the age of 10 years.
Safety Instructions
Assemble and operate the equipment on a solid, level surface. A clear space of at
least 100cm (39in) should be maintained on all sides. Do not use this equipment
outdoors, near swimming pools, or in areas of high humidity.
The transmier must not be collocated or operaon in conjuncon with any other
antenna or transmier. This equipment complies with the FCC RF radiaon exposure
limits set forth for an uncontrolled environment. This equipment should be installed
and operated with a minimum distance of 20cm between the radiator and any part
of the body.
Location
FCC Radiation Exposure Statement
The maximum recommended weight capacity for the equipment is 507lbs (230kg).
Weight Capacity
To reduce the risk of burns, re, electric shock, or injury, it is imperave to connect
the equipment to a properly grounded electrical outlet. Always disconnect the
equipment from the electrical outlet immediately before cleaning or aempng
any maintenance acvity.
Electrical Shock
Inspect your equipment prior to exercising to ensure that all nuts and bolts are fully
ghtened. Do not use the equipment if it is unsafe.
Inspection

9
Stretch for 5 to 10 minutes prior to exercising.
Warm-up for 5 to 10 minutes prior to exercising.
The warm-up should gently prepare the body for exercises by gradually increasing
the heart rate and circulaon; this will loosen the joints and increase blood ow
to the muscles. Stretching the muscles prepares them for physical acvity and
prevents injuries.
Warm-up
Remove all jewelry, including rings, chains and pins before exercising. Always wear
suitable clothing and footwear while exercising. Do not wear loose ng clothing
that could become caught in the moving parts of your equipment.
Tie back long hair.
For safety, and to save me and eort, read these instrucons completely before
beginning assembly.
Do not plug the power supply to the outlet before the equipment is fully assembled.
Input power supply specicaon depends on local electricity supply, and a proper
transformer may be needed.
Assembly
DC transformer spec.: Input: 100-240V ~1.5A (50-60Hz)
Output: 19V 3.42A
Tools required for assembly
Screw driver Wrench Allen wrench
4mm 6mm 8mm

10
ASSEMBLY INSTRUCTIONS
Step 1
Step 2
47
40
4
33
47
48
48

11
ASSEMBLY INSTRUCTIONS
Step 3
Step 4
33
33
33
33
40
40

12
ASSEMBLY INSTRUCTIONS
31
31
Step 5

13
ASSEMBLY INSTRUCTIONS
74
75
Step 6

14
N3
N11
N11
N11
N4
N1 N2
Step 7
Step 8
ASSEMBLY INSTRUCTIONS

15
ASSEMBLY INSTRUCTIONS
Step 9
PEDAL ADJUSTMENT

16
Step 10
ASSEMBLY INSTRUCTIONS

17
15
27 92
15
Step 11
ASSEMBLY INSTRUCTIONS
ATTENTION:
Washers go in between the bracket arm and
the bracket, not on the outside of the bracket.

18
15
27
92
33
40
91
78
91
66
67
23
24
26
52
53
25
7
42
42
42
42
43
43
43
43
44
6
8
8
56
57
68
54
71
76
76
76
76
18
11
11
9
60
40
61
33
33
40
N12
N13
31
31
45
46
62 58
59
64
28
28
6059
58 61
59
63
33
72
3
49 50
20
49
51 21
19
51 21
48
47
48
47
4
51
19 21
10
65
22
2
40
38
32
32
73
93
38
33
39
33
38
73
38
53
23
24
26
52
53
25
7
55
68
54
53
15
13
98
100
94
95
99
97
96
101
N2
N3
N1
N5 5
30
33
40
1
69
74
75
77
N11
N11
5
N1
1
ASSEMBLY INSTRUCTIONS

19
PART LIST
NO. DESCRIPTION QTY
1MAIN FRAME 1
2CENTRAL BEAM 1
3FRONT STABILIZER 1
4REAR STABILIZER 1
5HAND GRIP HOLDER 2
6HANDLE 1
7 PEDAL BASE 2
8 PEDAL SUPPORT TUBE 2
9SLIDING SUPPORT SIDE PLATE 2
10 REAR STABILIZER HOLDING BRACKET 1
11 SLIDING SUPPORT BAFFLE PLATE 2
15 TOUCHSCREEN WASHER 2
18 SADDLE 1
19 FOOT CAP 4
20 TRANSPORTATION WHEEL 2
21 FOOT PAD 4
22 END CAP FOR CENTRAL BEAM 1
23 PEDAL (A) 2
24 PEDAL ADJUSTMENT BOTTOM 2
25 PEDAL STRAP 2
26 PEDAL (B) 2
27 SOCKET HEAD BOLT M8 X 85MM 1
28 NYLON NUT M8 6
30 ROUND HEAD SCREW M6 X 10MM 4
31 ROUND HEAD SCREW M5 X 12MM 4
32 ROUND HEAD SCREW M5 X 6MM 4
33 SOCKET HEAD BOLT M8 X 16MM 16
38 STOPPER 4
39 ROUND HEAD SELF-TAPPING SCREW M3 X 6MM 2
40 WASHER Φ8 X Φ16 X 2.0T 12
42 LOCK NUT 4
43 PAN HEAD SCREW M6 X 20MM 4
44 NYLON NUT M12 1
45 ADJUSTMENT BOLT 2
46 SADDLE BASE 1
47 WASHER Φ10 X Φ23 X 2.0T 2
48 SOCKET HEAD BOLT M10 X 16MM 2
49 ROUND HEAD BOLT M8 X 40MM 2
50 CAP NUT M8 2
51 ROUND HEAD SCREW 5/32" X 1/2" 8
52 ROUND HEAD SELF-TAPPING SCREW M4 X 8MM 8
53 PAN HEAD SCREW M5 X 15MM 8

20
PART LIST
NO. DESCRIPTION QTY
54 PEDAL ADJUSTMENT BOTTOM HOLDER 2
55 PEDAL NUT (R) 1
56 PEDAL BOLT 1
57 PEDAL NUT (L) 1
58 ROLLER (A) 4
59 BEARING 608ZZ 10
60 POWDER METAL SPACER (12 X 8 X 2MM) 4
61 ROUND HEAD BOLT M8 X 25MM 4
62 PAN HEAD BOLT M8 X 25MM 2
63 ROLLER (B) 2
64 POWDER METAL SPACER (12 X 8 X 5MM) 2
65 SOCKET HEAD SCREW M6 X 10MM 1
66 WIRE UPPER 1
68 PEDAL SLEEVE 8
69 LOGO L 1
70 LOGO R 1
71 PEDAL BASE 1
72 WASHER Φ12 X Φ20 X 5T 2
73 STOPPER BOLT 2
74 SOCKET HEAD BOLT M8 X 40MM 4
75 WASHER Φ8 X Φ23 X 2T 4
76 WASHER Φ6 X Φ32 X 6T 4
77 STRAP PROTECTED PAD 1
78 CONSOLE TUBE 1
91 ROUND HEAD SCREW M6 X 10MM 3
92 NYLON NUT M8 1
93 PROTECTIVE PLATE OF CENTRAL BEAM 2
94 HANDLE BAR PIPE 1
95 HANDLE BAR CENTER 1
96 U BOLT M6 1
97 T-NUT M6 2
98 HEX SOCKET NUT M6 2
99 HANDLE BAR END CAP 2
100 FORM GRIP 2
101 NYLON WEBBING 1
N1 CHAIN COVER-MAIN L 1
N2 CHAIN COVER-MAIN R 1
N3 CHAIN COVER-MESH L 1
N4 CHAIN COVER-MESH R 1
N5 CHAIN COVER-BOTTOM L 1
N6 CHAIN COVER-BOTTOM R 1
N11 SCREW 1/8” X 1/2” 18
N12 SADDLE BASE COVER (L) 1
N13 SADDLE BASE COVER (R) 1
