Avital Diablo User manual

1
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99
Downloaded from: http://www.guardianalarms.net

Table of Contents
Required Installation Tools.......................2
Important Information..........................2
Wiring Diagram..............................3
14 Pin Connector..............................4
Starter Disable Relay............................4
Installation Procedures..........................5
Control Unit................................5
Antenna..................................5
Wireloom..................................5
Zone
1Impact Sensor...........................5
Valet Switch................................6
LED Indicator...............................6
Ignition Input................................6
Channel 2 Accessory Output........................6
Parking Lights...............................6
Interior Light Trigger...........................7
Optional Interior Light Illumination Output................7
Starter Disable...............................7
Two Pulse Unlock.............................8
Door Lock/Unlock Outputs........................8
Hood/Trunk Pin Switch..........................8
Siren....................................8
Power and Ground Connections.....................8, 9
Door Lock Diagrams..........................9-11
Programming Alarm System Features.................12
Programming Table for Alarm Features.................12
Programming Your Remote Controls.................13
Programming Table for Remote Controls................13
2
Diablo
2
/AMX 68/AT-58 Installation Manual 3/31/99

Required Installation Tools
Voltmeter
Wire Strippers
Electric Drill & Bits
Phillips Screw Driver
Convoluted Tubing *
Solder Gun *
Wire Crimpers
Shrink Tube or Electrical Tape * Optional
Important Information
1.Test all circuits with a voltmeter.
2.Make all wiring connections with butt connectors. DO NOT twist wires
or use “scotch-lok” connectors.
3. Route RED, RED/WHITE and BLACK wires from the control unit
directly to the battery.
4. Keep extensions as short as possible. Use same gauge wires.
5.Before installing, discuss the placement of the LED indicator and valet
switch with the vehicle owner. DO NOT disconnect the battery cables.
6.Make all connections by removing the lug from the cable clamp
without detaching clamp.
7. Turn off dome light or remove dome light fuse to prevent battery drain.
This device complies with Part 15 of the FCC rules. Any changes or
modifications made to the system without the express approval of Avital
Technologies, Inc. could void the user's authority to operate this
equipment.
3
Diablo
2
/AMX 68/AT-58 Installation Manual 3/31/99

Wiring Diagram
4
Diablo
2
/AMX 68/AT-58 Installation Manual 3/31/99

5
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99
14 Pin Connector
Wire colorDescription
Red/WhiteParking Light Polarity Select (+) or (-)
Red/Black Parking Light Output
RedBattery (+)
Gray(-) Armed Output for Starter Disable Relay
BlackBattery (-)
Violet Siren (-) Output
TanHood/Trunk (-) Input
White/BlackInterior Light Illumination (-) Output/Requires Optional Relay
Dark BlueChannel 2 (-) Accessory Output
White Door Trigger Input (+) or (-)
PinkIgnition Switched +12 Volt Input Pre-wired to Starter Disable Relay
Blue/White (-) Door Lock Output
Green/White (-) Door Unlock Output
Starter Disable Relay
Wire colorDescription
14 Ga Yellow Starter Disable Ignition Switch Side
14 Ga YellowStarter Disable Starter Solenoid Side

Installation Procedures
Control Unit
1.Select a location under the dash that will allow you to use the tie wraps
to securely fasten the control unit.
2.Mount the control unit as high as possible to ensure maximum range.
3.Do not mount the control unit near moving parts.
4.Avoid areas that are in the direct path of air blowing from the vents.
5.Route wires from this point, leaving slack for ease of service.
Antenna
1.Do not shorten or lengthen the antenna.
2.Route the antenna away from the control unit.
3.Keep the antenna as far away from metal and wire harnesses as possible
to optimize range.
Wireloom
1. Plug the wireloom securely into the control unit.
2. Route wires from the control unit directly to each connection point.
3.Separate the RED, RED/WHITE, BLACK, VIOLET and TAN wires.
4.Sleeve the wires with vinyl tubing or electrical tape and route them
through an existing rubber grommet into the engine compartment.
5.If an existing grommet is not available, drill a hole and install a snap
grommet.
Zone
1  Impact Sensor
The sensor must be firmly mounted on a solid metal surface inside the
vehicle. We recommend tie wrapping the sensor to the steering column
housing or steering column support bracket. DO NOT mount the sensor near
moving parts or in the direct path of an air duct opening.
1.Plug the impact sensor BLUE 4 pin connector into the control unit
BLUE 4 pin connector.
2.Route the impact sensor to the chosen mounting location.
3.Using the supplied long tie wraps, securely fasten the impact sensor
allowing access to the adjustment screw.
6
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99

Valet Switch
1.Discuss placement with the owner.
2. Choose a location for the valet switch that is hidden, but convenient for
the owner to access.
3.Drill a ¼" hole and mount the switch.
4. Route the valet switch wires to the control unit.
5.Plug the valet switch WHITE connector into the control unit WHITE
plug.
LED Indicator
1.Discuss placement with the owner.
2. Choose a location that is visible from both sides of the vehicle.
3.Drill a ¼" hole.
4. Route the LED wires through the hole and press LED into place.
5.Route the LED wires to the control unit.
6.Plug the RED LED connector into the control unit RED plug.
Ignition Input
1.Use a voltmeter to locate the one wire that shows +12 volts when the
ignition key is in the "ON," "CRANK" and "RUN" position, and 0 volts
when the ignition key is in the "OFF" position.
2.Connect the control unit PINK wire to the vehicle’s ignition wire.
Channel 2 Accessory Output
The DARK BLUE wire provides a 0.75 second ground (-) output when the
remote control button #2 is activated for 1-2 seconds. If the remote control
button #2 is continuously pressed, the signal will stay at ground as long as the
button is held. Most trunk releases are positive and require an optional relay.
Parking Lights
1.If the parking lights are positive trigger, connect the RED/WHITE wire
to the battery positive (+) terminal through the 20 amp fuse.
NOTE: Do not connect the RED/WHITE wire to the control unit RED wire.
2.If the parking lights are negative (-) trigger, connect the RED/WHITE
wire to control unit BLACK wire.
3. Connect the RED/BLACK wire to the vehicle parking light wire.
7
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99

Interior Light Trigger
The Diablo2
interior light trigger wire is programmable to accept a positive
(+) or negative (-) input. The module is factory preset for negative (-) door
trigger.
1. Connect the alarm WHITE wire to the vehicle door trigger wire(s).
2.If the vehicle door trigger is positive (+) trigger, follow the "Door
Trigger Input Polarity" section in the "Programming Table for Alarm
Features"to program the module for positive (+) door trigger.
Optional Interior Light Illumination Output
The WHITE/BLACK wire provides a current limited (-) output for 30
seconds upon remote disarm. Interior light illumnination requires an
optional relay.
1.Connect the alarm WHITE/BLACK wire to relay terminal 85.
2.Connect relay terminal 86 to a fused constant +12 volt source.
3.Connect relay terminal 30 to the vehicle door trigger wire(s).
4.If the vehicle door trigger is positive (+) trigger, connect relay terminal
87 to a fused +12 volt source.
5.If the vehicle door trigger is negative (-) trigger, connect relay terminal
87 to ground (-).
Starter Disable
Make sure the YELLOW relay wires are solidly connected. The starter
circuit may draw very high current. We recommend that all connections be
soldered.
1.Locate the ignition switch wireloom under the dashboard.
2.Use a voltmeter to find the one wire that will show +12 volts while the
ignition key is in the "CRANKING " cycle only. This should be the
starter solenoid wire.
3. Cut the starter solenoid wire. Test by trying to crank the starter with the
ignition key. If it does not crank, you have the correct wire.
4.Connect one YELLOW wire to the key side.
5.Connect the other YELLOW wire to the starter side.
8
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99

Two Pulse Unlock
Some vehicles require two pulses to unlock the doors. The alarm can be
programmed to pulse the unlock wire two times when the alarm is remotely
disarmed. (See "Programming Alarm System Features" on page 12.)
Door Lock/Unlock Outputs
The alarm provides a .75 second 300 MA (-) output for lock and unlock.
Follow the door lock diagrams on pages 9 - 11.
Hood/Trunk Pin Switch
1.Locate the vehicle hood or trunk pin switch that shows ground when
the hood or trunk is open only.
2.Connect the alarm module TAN wire to the vehicle hood or trunk
switch wire.
3.If the vehicle does not have a hood or trunk switch, install a pin switch
and connect it to the alarm module TAN wire.
Siren
1. Choose a location in the engine compartment away from high heat
engine components, moving parts and direct exposure to water.
2.Make sure the siren and siren wires cannot be seen or reached from
below the vehicle.
3.Mount the siren with the two self tapping screws to a solid metal
surface.
4.Connect the siren BLACK wire to the alarm module VIOLET wire.
5.Connect the siren RED wire to the alarm module RED wire.
Power and Ground Connections
Caution: Do not plug in the system fuses until the final step below.
1.Connect the alarm RED wire to one of the supplied fuse assemblies.
2.Connect the alarm RED/WHITE wire to the other fuse assembly (if the
vehicle parking lights are (+) positive).
3.Connect the fuse assembly(s) to one of the supplied 10mm ring
terminals.
Continued . . .
9
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99

4. Connect the alarm BLACK wire to the other 10mm ring terminal.
5.Remove the (+) and (-) battery bolts. Do not disconnect the battery
clamps.
6. Connect the empty fuse assembly(s) to the positive battery post.
7.Connect the alarm BLACK wire to the battery negative post.
8.Inspect all alarm wiring. Make sure all wires are connected.
9.Install the 5 amp fuse in the alarm module RED wire fuse assembly.
10.Install the 20 amp fuse in the alarm module RED/WHITE fuse
assembly (if the vehicle parking lights are positive).
10
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99
Negative Trigger Door Locks

11
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99

12
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99

Programming Alarm System Features
All programmable alarm features are accomplished by turning the ignition
key on (or starting the vehicle) and flicking the valet switch on and off a
preset number of times.
1. Remove the alarm from valet. Programming cannot be accessed while
the alarm is in the valet mode indicated by the LED on solid red.
2.Select the feature you wish to program from the "Programming Table
for Alarm Features." Note the number of chirps.
3.Turn the ignition key to the "ON" position.
4.Within 10 seconds, begin flicking the valet switch on and off. The siren
will chirp one time each time you flick the switch on then off.
5. Continue flicking the switch on and off until you reach the number of
chirps associated with your chosen feature.
NOTE: Stop on the chirp.
6.After a 3 second pause, you will hear 1 or 2 chirps noted to confirm
that you have changed the setting of that feature.
7.Turn the ignition key off.
8.Repeat steps 1-7 for any other feature you wish to program.
Programming Table for Alarm Features
FeatureFactory
Setting# of ChirpsSecondary Action
Passive/Active
Arming Passive ON4Wait 3 seconds, the siren chirps once for active or
twice for passive.
Passive Door
Locking OFF 5Wait 3 seconds, the siren chirps once for OFF or
twice for ON.
Remote Arming
Siren Chirps ON6Wait 3 seconds, the siren chirps once for OFF or
twice for ON.
Door Trigger
Polarity Select (-) Trigger7Wait 3 seconds, the siren chirps once for (+) trigger
or twice for (-) trigger.
Two Pulse Unlock1 Pulse8Wait 3 seconds, the siren will chirp once for 2 pulse
or twice for 1 pulse.
13
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99
Programming Alarm System Features
All programmable alarm features are accomplished by turning the ignition
key on (or starting the vehicle) and flicking the valet switch on and off a
preset number of times.
1. Remove the alarm from valet. Programming cannot be accessed while
the alarm is in the valet mode indicated by the LED on solid red.
2.Select the feature you wish to program from the "Programming Table
for Alarm Features." Note the number of chirps.
3.Turn the ignition key to the "ON" position.
4.Within 10 seconds, begin flicking the valet switch on and off. The siren
will chirp one time each time you flick the switch on then off.
5. Continue flicking the switch on and off until you reach the number of
chirps associated with your chosen feature.
NOTE: Stop on the chirp.
6.After a 3 second pause, you will hear 1 or 2 chirps noted to confirm
that you have changed the setting of that feature.
7.Turn the ignition key off.
8.Repeat steps 1-7 for any other feature you wish to program.
Programming Table for Alarm Features
FeatureFactory
Setting# of ChirpsSecondary Action
Passive/Active
Arming Passive ON4Wait 3 seconds, the siren chirps once for active or
twice for passive.
Passive Door
Locking OFF 5Wait 3 seconds, the siren chirps once for OFF or
twice for ON.
Remote Arming
Siren Chirps ON6Wait 3 seconds, the siren chirps once for OFF or
twice for ON.
Door Trigger
Polarity Select (-) Trigger7Wait 3 seconds, the siren chirps once for (+) trigger
or twice for (-) trigger.
Two Pulse Unlock1 Pulse8Wait 3 seconds, the siren will chirp once for 2 pulse
or twice for 1 pulse.

Programming Your Remote Controls
The alarm allows the user to add new remote controls in one step, delete lost or
stolenremotecontrolsorrearrangethefactorypresetremotecontrolfunctions.
All remote control programming features are accomplished by turning the
ignition key on (or starting the vehicle) and flicking the valet switch on and
off a preset number of times.
1. Remove the alarm from valet. Programming cannot be accessed while
the alarm is in the valet mode, indicated by the alarm LED on solid red.
2.Select the feature from the "Programming Table for Remote Controls."
Note the number of chirps.
3.Turn the ignition key to the "ON" position.
4.Within 10 seconds, begin flicking the valet switch on and off. The siren
will chirp one time each time you flick the switch on then off.
5. Continue flicking the valet switch on and off until you reach the
number of chirps associated with your chosen feature.
NOTE: Stop on the chirp.
6.Follow the "Secondary Action."
7.Turn the ignition key off.
8.Repeat steps 1-7 for any other feature you wish to program.
Programming Table for Remote Controls
FeatureFactory
Setting # of ChirpsSecondary Action
Arm/Disarm/Remote
PanicChannel 19Press any remote control button you choose to operate
this feature. Siren will chirp once for confirmation.
Accessory (-) Output Channel 2 10 Press any remote control button you choose to operate
this feature. Siren will chirp twice for confirmation.
Silent Arm/DisarmChannel 311 Press any remote control button you choose to operate
this feature. Siren will chirp 3 times for confirmation.
All Channel Learn—12Press button #1. The siren will chirp 1 time. Remote
control will operate at factory preset order.
Instant Code
Deletion—13 Wait 3 seconds. The siren will chirp twice. All Remote
Controls are erased from memory.
14
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99

15
Diablo2
/AMX 68/AT-58 Installation Manual 3/31/99
© Copyright 1998 Avital Technologies, Inc. 32-1241/98
