AvMap EKP-IV PRO User manual

Via Caboto, 9
54036 Marina di Carrara - MS - ITALIA
E-mail: [email protected]
USER MANUAL
updated to software version 1.11.50 R

2
WARRANTY
AvMap warrants their GPS receiver and accessories to be free of defects in material and work-
manship for a period of two years from the date of original purchase. This warranty applies only
to the original purchaser of this product. In the event of a defect, AvMap, at its option, will
repair or replace the product with no charge to the purchaser for parts or labor. The repaired
or replaced product will be warranted for ninety (90) days from the date of return shipment, or
for the balance of the original warranty, whichever is longer.
PURCHASER’S REMEDY - Purchaser’s Exclusive Remedy under this written warranty or any
implied warranty shall be limited to the repair or replacement, at AvMap’s option, of any
defective part of the receiver or accessories which are covered by this warranty. Repairs under
this warranty shall only be made by an authorized AvMap dealer.
PURCHASER’S DUTIES - To obtain warranty service, the purchaser must return the receiver
or accessories post paid, with proof of the date of original purchase and purchaser’s return
address to AvMap, or an authorized AvMap representative. AvMap will not be responsible for
any losses or damage to the product incurred while the product is in transit or is being shipped
for repair. Insurance is recommended.
LIMITATION OF IMPLIED WARRANTIES - Except as set forth above, all other expressed or implied
warranties, including those of fitness for any particular purpose and merchantability, are hereby
disclaimed. Some states do not allow limitations on warranties, so the above limitation may
not apply to you.
EXCLUSIONS - This warranty does not cover the following: Installation, Finishes, Defects resulting
from installation. Any damage due to accident, resulting from inaccurate satellite transmissions.
Inaccurate transmissions can occur due to changes in the position, health, or geometry of a
satellite. Any damage due to shipping, misuse, negligence, tampering or improper use. Servicing
performed or attempted by anyone other than an authorized AvMap representative.
Attenzione! L’esposizione del display ai raggi ultravioletti può accorciare la vita dei
cristalli liquidi usati nel vostro plotter cartografico. Questo limite è dovuto alla tecnologia costruttiva
degli attuali display. Evitare inoltre che il display si surriscaldi per non causare una diminuzione di
contrasto che, in casi estremi, può rendere lo schermo completamente nero. Tale condizione è
comunque reversibile durante il raffreddamento.
Warning! Exposure of display to UV rays may shorten life of the liquid crystals used in
your plotter. This limitation is due to the current technology of the LCD displays. Avoid overheating
which may cause loss of contrast and, in extreme cases, a darkening of the screen. Problems which
occur from overheating are reversible when temperature decreases.
Achtung! Ultraviolette Strahlen können die Lebensdauer vom Flüssigkristalldisplay
verkürzen. Die derzeitige LCD-Technologie bedingt diese verkürzte Lebensdauer.
Überhitzung des Displays durch Sonneneinstrahlung führt zu einem Kontrastverlust und in extremen
Fällen sogar in eine Schwär zung des Bildschirmes. Bei sinkenden Temperaturen normalisiert sich
der Kontrast wieder und die Bildschirminformation wird wieder ablesbar.
Attention! L’exposition de votre écran LCD aux ultra-violets lors de soleil intense
réduira la durée de vie de l’afficheur de votre lecteur. Cette contrainte est liée à la technologie des
écrans LCD. Une augmentation trop importante de température peut obscurer des zones de votre
écran et le rendre ainsi inutilisable (non couvert par la garantie).
Aviso! La exposición de la pantalla a los rayos UV puede acortar la vida del cristal líquido
usado en su ploter. Esta limitación se debe a la tecnología actual de las pantallas LCD. Evitar que
la pantalla se caliente en exceso pues puede causar pérdida de contraste y, en caso extremo, la
pantalla puede quedar totalmente negra. Este problema revierte al enfriarse la pantalla

3
Warning!!!
A measure of knowledge by the user is required for proper and safe use of the chart plotter.
Read the User Manual and the Warranty completely.
Use Good Judgement
This product is an excellent navigation aid, but it does not replace the need for careful
pilotage and good judgement. Never rely solely on one means of naviga-tion.
Use Care to Avoid Inaccuracies
The Global Positioning System (GPS) is operated by the U.S. Government, which is solely
responsible for the accuracy and the maintenance of GPS. Certain conditions can make the
system less accurate.
Accuracy can also be affected by poor satellite geometry.
The accuracy of position fixes is subject to changes in accordance with the Department of
Defense civil GPS user policy and the Federal Radionavigation Plan.
Cleaning Procedure for the Chartplotter Screen
Cleaning of the chartplotter screen is a very important operation and must be done carefully.
Since the surface is covered by a antireflective coating, the procedure for cleaning all the
surfaces can be performed using the following procedure: You need a tissue or lens tissue
and a cleaning spray containing Isopropanol (a normal spray cleaner sold for the PC screen,
for example PolaClear by Polaroid). Fold the tissue or lens tissue into a triangular shape,
moisten the tip and use the index finger behind a corner to move the tissue across the
surface, in overlapping side to side strokes. If the tissue is too wet, a noticeable wet film will
be left in its path and you will need to repeat the process. If too dry, the tissue won’t glide
easily, and may damage the surface.
Copyright 2005 AvMap Italy - All rights reserved
No part of this User Manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying and recording , for any purpose other than the
purchaser’s personal use without the written permission of AvMap.

4

5
INDEX
1 INTRODUCTION
1.1 FEATURES 10
1.1.1 Specifications 10
1.2 BASIC 12
1.3 FLYING START 13
1.3.1 The Moving Map 14
1.3.2 The Main Menu 14
1.3.3 Moving Map Functions 14
1.3.4 Moving Map Icons 15
1.3.5 Course Predictor 15
1.3.6 GoTo 15
1.3.7 Database 16
1.3.8 Battery Compartment and Batteries 16
2 THE BASICS
2.1 THE KEYBOARD 17
2.2 TURNING THE EKP-IV ON/OFF 18
2.2.1 Turning On 18
2.2.2 Turning Off 19
2.3 CHANGING BRIGHTNESS & CONTRAST 19
2.4 SELECTING THE LANGUAGE 19
2.5 EXTERNAL CONNECTIONS 19
2.5.1 Internal/external GPS Source 19
2.5.2 NMEA Outputs 20
2.5.3 Down Or Up-load Flight Plans & Tracks 20
2.5.3.1 Download/Upload Waypoints 21
2.5.3.2 Download/Upload Flight Plan 21
2.5.3.3 Download Track 21
2.6 SYSTEM SETUP OPTIONS 21
2.7 DATA ENTRY 21
3 THE MOVING MAPS
3.1 OPERATING MODES 23
3.1.1 Cursor Mode 23
3.1.2 Home Mode 23
3.1.3 Auto Zoom Mode 23
3.2 DATA WINDOW 24
3.3 AUTOMATIC INFO 24
3.4 CURSOR OR POSITION MODE 24
3.4.1 Airspace Information 25
3.4.2 Full Information 25
3.4.3 Project Radial 25
3.4.4 A - B Function 26
3.4.5 Waypoint Handling 26
3.4.6 Flight Plan 27
3.5 MOVING MAP MENU 27
3.5.1 Viewed FP 28
3.5.2 Auto Position Mode 28
3.5.3 Data Window Mode 29
3.5.4 Setup Data Fields 29

6
3.5.5 Default Data Fields 30
3.5.6 Map Orientation 30
3.5.7 Map Presentation Settings 31
3.5.8 Automatic Information 31
3.5.9 Rangerings 31
3.5.10 Vfr, Airspace, Land, Marine Andothersettings 31
3.5.10.1 VFR Settings 32
3.5.10.2 Airspace Settings 32
3.5.10.3 Land Settings 33
3.5.10.4 Marine Settings 33
3.5.10.5 Other Settings 34
3.5.11 Terrains 34
3.5.11.1 Terrain “ON” 34
3.5.11.2 TAWS 34
3.5.12 Selective Display Settings 36
3.5.13 POI Settings 37
4 NAVIGATION & LOCATION
4.1 NAVIGATION & LOCATION DATA 38
4.2 SAVE CURRENT FIX AS USER WAYPOINT 39
5 THE HSI SCREEN
5.1 HSI DESCRIPTION 40
5.2 HSI MENU 40
5.2.1 Add Mark Under Fix 41
5.2.2 Setup Data Fields 41
5.2.3 Default Data Fields 41
5.2.4 Compass Orientation 41
6 FLIGHT PLAN
6.1 VIEWED FLIGHT PLAN 42
6.2 CREATING A FLIGHT PLAN FROM THE DATABASE 43
6.3 ACTIVATE & DEACTIVATE A FLIGHT PLAN 43
6.4 NAMING A FLIGHT PLAN 44
6.5 CLEAR A FLIGHT PLAN 44
6.6 REVERSE A FLIGHT PLAN 44
6.7 GOTO FLIGHT PLANS 44
6.7.1 GoTo - Database Mode 44
6.7.2 GoTo - Moving Map Mode 45
6.7.3 GoTo - Quick Info 45
6.8 NEAREST SEARCH FOR GOTO FLIGHT PLAN ACTIVATION 45
7 THE GLOBAL POSITIONING SYSTEM
7.1 GPS PAGE 47
7.2 GPS RECEIVER SPECIFICATIONS 48
7.3 HOW GPS WORKS 48
7.2.1 Accuracy 48
7.2.2 WAAS 48
7.2.3 Differential GPS 48
7.2.4 Monitoring & Controlling the GPS 49
7.2.5 GPS Information Sources 49
8 WAYPOINT & DATABASE
8.1 USER WAYPOINTS – MOVING MAP 50

7
8.1.1 Creating User Waypoints – Moving Map 50
8.1.2 Saving Present Position – Moving Map Methods 50
8.1.3 Editing User Waypoints – Moving Map Methods 50
8.1.4 Deleting User Waypoints – Moving Map Methods 51
8.2 USER WAYPOINTS – DATABASE METHODS 51
8.2.1 Creating User Waypoints – Database Methods 51
8.2.2 Editing User Waypoints – Database Methods 51
8.2.3 Deleting User Waypoints– Database Methods 51
8.3 DATABASE 51
8.3.1 Database Menu 52
8.3.1.1 Selecting Database Search Fields 52
8.3.1.2 Displaying Sunrise and Sunset Information 53
8.3.2 File Manager 53
9 APPROACH DATA PROCEDURES
9.1 APPROACH FROM THE MOVING MAP 54
9.2 APPROACH FROM FLIGHT PLAN DATABASE 54
9.3 SELECT APPROACH FOR GOTO 55
10 CALCULATOR
10.1 COUNTDOWN TIMER 56
10.2 ELAPSED TIMER 56
10.3 TRIP COMPUTER 57
10.4 VERTICAL NAVIGATION 58
10.5 WIND CALCULATION 59
10.6 FUEL CONSUMPTION 60
11 THE CHECKLISTS
11.1 ENGINE START 62
11.2 GROUND CHECK 63
11.3 PRE TAKE-OFF 63
11.4 CRUISE IN FLIGHT 63
11.5 LANDING 63
12 SIMULATOR
12.1 SIMULATING STRAIGHT MODE 64
12.2 SIMULATING ROUTE MODE 64
12.3 TURNING THE SIMULATOR OFF 65
13 THE COMMUNICATION
13.1 NMEA OUTPUT 66
13.2 WAYPOINTS UPLOAD/DOWNLOADS 66
13.3 FLIGHT PLAN UPLOAD/DOWNLOAD 67
13.4 TRACK DOWNLOAD 67
14 THE SYSTEM SET-UP MENU
14.1 GENERAL SET-UP 68
14.1.1 Beeper 68
14.1.2 Scale format 69
14.1.3 Language 69
14.1.4 Military Frequency 69
14.1.5 Airspaces Level 69
14.1.6 Terrain Legend 69

8
14.1.7 Power Save 69
14.1.8 Layout 70
14.2 FIX SET-UP 70
14.2.1 Fix Source 70
14.2.2 Differential Correction Source 70
14.2.3 Fix Symbol 70
14.2.4 Static Navigation 70
14.2.5 Course Predictor 71
14.2.6 Head Up Response 71
14.3 ALARM SET-UP 71
14.3.1 Arrival Alarm Radius 71
14.3.2 XTE Alarm Range 71
14.3.3 Waypoint Alarm Radius 71
14.3.4 TAWS Alarm 72
14.3.5 Airspace Ahead Alarm 72
14.3.6 Event Log 72
14.3.7 Clear Event Log 73
14.4 TRACK SET-UP 73
14.4.1 Track Display 73
14.1.2 Track Line 73
14.1.3 Track Width 73
14.1.4 Track Color 73
14.4.5 Track Recording Step 73
14.4.6 Clear Track 73
14.4.7 Remaining Track 74
14.5 UNITS SET-UP 74
14.5.1 Distance Unit 74
14.5.2 Speed Units 74
14.5.3 Altitude Unit 74
14.5.4 Depth Unit 74
14.5.5 Fuel Unit 74
14.5.6 Vertical Speed 75
14.5.7 Temperature 75
14.5.8 North Reference 75
14.5.9 Coordinate System 75
14.6 DATE & TIME SET-UP 75
14.6.1 Time Format 75
14.6.2 Local Time Difference 76
14.6.3 Data Format 76
14.7 COLORS SET-UP 76
14.7.1 Data Window Colors 76
14.8 CLEAR USER DATA 76
14.9 CLEAR ALL RADIALS 76
14.10 FACTORY DEFAULTS 77
15 OPERATING REQUIREMENTS
15.1 ANTENNA ASSEMBLY & PLACEMENT 78
15.2 SECURING THE EKP-IV 78
15.3 DIMENSIONS 79
15.4 INSERT / CHANGE BATTERIES 80
15.5 TROUBLESHOOTING 80
15.5.1 Power 80
15.5.2 GPS Fix 80
15.5.3 When Nothing else Works 81
15.5.4 Customer Support 81

9
15.6 SYSTEM TEST 82
15.6.1 RAM Menu 82
15.6.2 C-card Menu 83
15.6.3 Serial Ports 83
16 EKP IV PRO
16.1 FUNCTIONS FOR THE AU TOMATIC CREATION OF SEARCH AND RESCUE
(S.A.R) FLIGHT PA TTERN 84
16.2 CUSTOMIZED REGIONAL COVERAGE AREA 84
16.3 PLACE AND STREET RESEARCH 84
16.3.1 Place Research 84
16.3.2 Street Research 84
16.4 CONNECTION TO THE RADIO LOCALIZ. SYSTEM TELEFIX AND/OR
KENWOOD APRS, AUTOMATIC POSITION REPORTING SYSTEM 84
APPENDIX A - TERMS 85
APPENDIX B - MAP DATUM 88
APPENDIX C - ICAO CODES 89
APPENDIX D - C-MAP AVIATION CARTRIDGE OPTIONS 95
APPENDIX E - C-MAP DATA TRANSFER 96

10
1 INTRODUCTION
If you have not used a GPS Charting System before and intend to use your EKP-IV for navigating, we
suggest that you read this User Manual and make sure you are familiar with its contents. Throughout
this User Manual, the keys are shown in capital letters enclosed between single inverted commas,
for example ‘MENU’. Menu operations are in bold characters listed by keys sequence with the
menu names enclosed between quotes, for example ‘MENU’ 1 sec. + “SYSTEM SETUP” + ‘ENTER’
+ “FIX SETUP” + ‘ENTER’ means: press and hold down the ‘MENU’ key for 1 second, using the
cursor key selects the System Setup menu, press ‘ENTER’, using the cursor key selects the Fix Setup
menu and then press ‘ENTER’.
1.1 FEATURES
This electronic charting system integrates the remarkable accuracy of a GPS receiver with a detailed
moving map into a single, easy-to-use, computerized electronic map system. The EKP-IV contains a
built-in base map with coast/shorelines, names of states, major cities, highways, lakes and rivers.
When the EKP-IV is first opened, please check it for the following contents:
• C-MAP Navdata Compact Flash (inserted in the slot at the base of the unit)
• Antenna and 5 meter cable with SMB connector
• Power Cable (with cigarette lighter adapter)
• Velcro Leg Strap
• User Manual
Optional Accessories:
• PC/Data cable
1.1.1 Specifications
Main Characteristics
Recordable Individual points
• Waypoints :1000
• Type of User Waypoint Icons :16
Flight Plans
• Flight Plans : 10
• Max Waypoints per Flight Plan : 100
Tracking
• Tracks: 1
• Track Colors : 7
• Points per Track : many thousand of points
• Step by Distance : Auto, 20, 100, 500 Mt, 1Km; 5, 30 Sec, 1 Min
Cartographic Functions
• Worldwide Background
• Built-in Continental Cartography
• Coordinates System (DDD MM SS, DDD MM.mm, DDD MM.mmm, UTM, OSGB, MGRS)
• North Reference

11
• Auto Zoom
• Map Presentation (Aero+Terrestrial, Aeronautical, Marine)
• POI Settings
• Selective and cycled Display
• VFR (Airports, VOR, NDB, Intersections, Vertical Obstructions, Aero Objects Id, Enroute
Communications)
• Airspace (Controlled Areas, Restricted Areas, FIR & UIR, MORA)
• Land (Roads, Road Labels, Railroads, City Names, Rives and Lakes, Cultural Features, Natural
Features, Landmarks, POI Objects)
• Marine (Lights, Chart Boundaries, Bathymetric & Soundings, Bathymetric & Soundings Range,
Depth Area Limit, Navigational Aids, Attention Areas, Tracks & Routes)
• Other Settings (User Points, Objects Overlap, Lat/Lon Grid)
Fix Functions
• DGPS
• WAAS
• Fix Symbol user selectable (Standard, Plane, Helicopter, Car)
• Static Navigation
• Course Predictor
• Map Orientation (Track-up, Course-up, North-up)
• Projected Radial
• A-B measurement
Data Page Options
• Nav/Location
• HSI Page
• Flight Plan
• GPS Page
• About Page
Special Functions
• Automatic Info (Aero+Terrestrial, Aeronautical, Terrestrial, Marine)
• Nearest search
• Direct-To navigation
• Date and Time Format
• Astronomic Data Calculation (Sun/Moon Info)
• Distance Unit selection (KM, NM, SM)
• Speed Unit selection (MPH, KTS, KMH)
• Altitude Unit selection (FT, FL, MT)
• Depth Unit selection (FT, FM, MT)
• Fuel Unit selection (GAL, LIT, LB, KG, BGAL)
• Descent Rate selection (FT/MIN, M/S, DEG)
• Temperature Unit (C/F)
• Alarms handling (Arrival, XTE, Waypoint Alarm Radius, Airspace)
• Database(Airports, VOR, NDB, Intersections, POI objects, User Waypoints, File Manager)
• Calculator (Countdown Timer, Elapsed Timer, Trip Computer, Vertical Navigation, Wind
Calculation, Fuel Consumption)
• Simulation mode (Speed, Heading)
• Checklists (Engine Start, Ground Check, Pre Take-Off, Landing)
• Communications (Waypoints Upload/Download, Flight Plan Upload/Download, Track Upload/
Download)
Interface
• Serial I/O port

12
Physical Characteristics
Size
• 7.1” x 4,8” x 1,8” (2.3”)
Weight
• 670 g
LCD display
• color TFT 7” (16:9)
• resolution 800 x 480 pixels
Antenna dimensions
• 3” diameter, 0.625” height (76.2 mm diameter, 15.9 mm height) (Antenna includes a 5 mt
cable)
Power consumption
• Color 10 Watt, 10–35 Volt DC
• Operating Temperature Range 32°F to 131°F (0°C to 55°C)
Storage Temperature
• -13°F to 158°F (-25°C to 70°C)
Memory
• Non volatile with battery back-up
Keyboard
• Backlighted, silicon rubber
1.2 BASIC
The EKP-IV is controlled by using 10 keys and the cursor key. As you press a key, a single audio beep
confirms the key action; three rapid beeps indicates that no response is available.
POWER Key - For quick access to the GPS status tap the ‘POWER’ key. The Brightness and contrast
will appear; the GPS status and current time are displayed at the bottom of this box.
Removal of Knee Mount. The knee mount is secured to the back of the EKP-IV with Velcro and snap
guides. To remove the knee mount place a few fingers under the top of the knee mount and apply
constant backpressure until the mount disengages from the Velcro. To reinstall the knee mount,
align the mount to the back of the unit and apply pressure until mount locks in place.

13
Fig. 1.2 - The EKP-IV
Fig. 1.2a - How to insert the Compact Flash
1.3 FLYING START
These pages provide a very brief overview of several of the EKP-IV’s important features, the Main
Menu, the Moving Map, GoTo flights and locating a Waypoint in the Database. It does not replace
the User Manual, which should be read to get the fullest possible use from your EKP-IV.
Note
The EKP-IV is an aid to navigation. It does not replace paper charts and good judgement.

14
1.3.1 The Moving Map
Before starting, connect the EKP-IV to power and place the antenna with a clear view of the sky.
Turn On the unit pressing ‘POWER’. Press ‘ENTER’ to exit from the Warning page and enter the
Moving Map mode. The Moving Map is the default state displaying the Moving Map screen and the
Data Window. The Data Window contains navigation information boxes (See Chapter 3 for details
on Moving Map mode).
Note: If no Fix is available, red dashed cross is displayed over the map for increased Pilot
Awareness.
To Change the Scale of the Moving Map
Use ‘ZOOM IN’ and ‘ZOOM OUT’ to change the map display scale.
To Select Position
Use the cursor key to scroll to the location you want.
1.3.2 The Main Menu
From Moving Map press ‘MENU’ for 1 second to display the Main Menu:
Fig. 1.3.2 - Main Menu
1.3.3 Moving Map Functions
The Moving Map operates in Auto Home, Auto Zoom, and Cursor Mode. The screen will behave
differently based on the mode of operation selected. The Auto Home mode will allow the user to
pan away from his present position to view other parts of the map, and return to present position
automatically when no buttons are pushed for a pre-determined amount of seconds. Auto Zoom
mode will keep your present position, and your destination in the screen at all times. The screen
will automatically zoom in as you get closer. To shut off this function, simply select OFF.
The Cursor Mode (OFF Selected) will allow you to move the map to any position to view data or
details. To return to your present position, just press ‘CLEAR’ while in moving map.
The control for these functions is found in the Moving Map Menu, under Auto Position Mode.

15
1.3.4 Moving Map Icons
The following icons are displayed on the Moving Map to represent Waypoints, navigation aids and
airports.
Fig. 1.3.4 - Moving Map Icons
1.3.5 Course Predictor
Indicates the projected position at the set time interval if the current speed and heading are kept.
This allows the pilot to correct for wind drift, in real time, right from the moving map. To select
course predictor:
> ‘MENU’ 1 sec. + “SYSTEM SETUP” + ‘ENTER’ + “FIX SETUP” + ‘ENTER’ + “COURSE
PREDICTOR” + ‘ENTER’
1.3.6 GoTo
GoTo sets a 1-leg course from the present position to any location or selected Waypoint. To activate
a GoTo Flight Plan move the cursor to the desired location or Waypoint and press ‘GOTO’. The
GoTo menu box will open enabling you to activate the current cursor position or search the
Database for a specific object to fly to. To activate the current cursor position, highlight “CURSOR”
and press ‘ENTER’. To activate a GoTo Flight Plan to a specific Database item, select the category
and press ‘ENTER’. Select the database item and press ‘GOTO’ again to activate.

16
To deactivate, press ‘GOTO’ and select “DEACTIVATE”.
1.3.7 Database
The Database function allows the user to access information stored in the data cartridges on
Airports, VOR’s, NDB’s, Intersections and User Waypoints. Searching the Database allows the user
to activate GoTo Flight Plans and locate the item on the map. There are two methods of accessing
the Database information. The first is through the Database function within the Main Menu and the
second is directly from the Moving Map display (see Chapter 3).
1.3.8 Battery Compartment and Batteries
The EKP-IV is designed with a battery compartment for 6 rechargeable AA batteries. It is located
in the rear of the unit underneath the removable knee mount. The unit provides a ‘trickle’ charge
to the batteries when the unit is plugged into external power and powered ON. Rechargeable AA
batteries are required. Install them only after the batteries are fully charged. With fully-charged
batteries, the normal discharge time will be close to two hours, depending upon the condition of
the batteries, as well as the brightness and contrast of the screen settings. AvMap highly recommends
that NiMH AA batteries be used (available from AvMap/Navigation, or from any electronics shop).
DO NOT USE ALKALINE BATTERIES, as they may damage the unit and void the warranty.

17
2 THE BASICS
This chapter provides general information about the functions of the keys and entering data
(connecting the EKP-IV to power and using the antenna are described in Chapter 15).
2.1 THE KEYBOARD
The EKP-IV has 10 keys, which access and control features. Some keys perform different tasks
based on the operation mode. A quick key guide is displayed at the bottom of many menus for
easy reference.
Below we indicate the keys in capital letters enclosed between single inverted commas, for example
‘MENU’. When a key, for example ‘MENU’, must be pressed and held down for more than 1
second it is shown as ‘MENU’ 1 sec.
The POWER key
‘POWER’: press and hold to turn the EKP-IV On.
‘POWER’ 3 seconds: once the EKP-IV has been turned On turns the EKP-IV Off.
‘POWER’: (immediately release!) once the EKP-IV has been turned On displays the Brightness and
the Contrast Menu.
The PAGE key
Displays a list of the 20 nearest objects, including private airports which contain runways of at least
500 ft. in lenght, relative to fix position or cursor position if no fix is available. Press and hold to
access the NavData Page.
The GOTO key
Activates a Flight Plan to the cursor position (in Moving Map) or to selected object (in other
modes).
The ZOOM-OUT key
Shows less detail of a larger area by changing the chart scale and zooming out on the map display.
The CURSOR key
Moves the cursor on the Moving Map, quickly and accurately. Also scrolls to the desired options
in menu page(s).
The ZOOM-IN key
Shows more detail of a smaller area by changing the chart scale and zooming in on the map
display.
The MENU key
‘MENU’: selects the Moving Map Menu.
‘MENU’ 1 sec.: opens Main Menu (equivalent to press ‘MENU’ twice).
The ENTER key
Selects the desired option or confirms selection. Also opens the Cursor/Position Menu.
The CLEAR key
Rejects an action, closes a window or activates Home or Auto Zoom mode.
The CYCLE key
The EKP-IV is equipped with a Cycle Key that allows the user to quickly filter mapping information
on the display. There are three Cycle modes and hitting the Cycle Key one to three times activates

18
them. The Cycle Key is defaulted in the Cycle 1 position that normally activates all features to be
visible on the display. By hitting the Cycle Key once, Cycle 2 is activated and hitting it a secnd time
activates Cycle 3, one last Cycle key activation and the display is back to Cycle 1.
To set user preferences for the Cycle Key:
‘MENU’ + “SELECTIVE DISPLAY” + ‘ENTER’
The Cycles appear in the first three columns and are labeled 1, 2 and 3. In order to adjust at which
Cycle features appear, use the Cursor Control key to highlight an item and hit ‘ENTER’ to remove
the item from appearing. Hit ENTER again to check the item so that it will appear on the display
when that Cycle is activated. Continue to use this procedure to activate features in Cycles 1 - 3 as
desired.
2.2 TURNING THE EKP-IV ON/OFF
Before powering On the EKP-IV, check for the correct voltage (10-35 Volt DC).
2.2.1 Turning On
Press and hold ‘POWER’ for 1 second. The EKP-IV emits one rapid beep sound and a Title page
containing information about the Product name, Software version, library version and cartridges
installed is displayed. This data can also be viewed in the “About” page in the “Main Menu”.
Fig. 2.2.1 - Title page

19
After a few seconds the Warning page is displayed, reminding you that the EKP-IV is an aid to
navigation and should be used with appropriate prudence. The electronic charts are not intended
to substitute for the official charts. Press ‘ENTER’ to open the Moving Map screen.
2.2.2 Turning Off
‘POWER’ 3 sec.: a countdown timer appears on the screen, if you release the key before the
countdown timer reaches zero, the EKP-IV will remain On.
2.3 CHANGING BRIGHTNESS & CONTRAST
Press and immediately release ‘POWER’ to adjust the brightness and the contrast of the display and
keyboard (do not press and hold the key or the “power-off ” message will be displayed!).
To increase/decrease the brightness use respectively up/down cursor key. Similarly, to increase/
decrease the contrast use left/right cursor key. In addition the Time and the GPS State are shown.
2.4 SELECTING THE LANGUAGE
It is possible to select the language in which the information is displayed (for screen labels, menus
and options, but it does not affect the map information). The default setting is English.
> ‘MENU’ 1 sec. + “SYSTEM SETUP” + ‘ENTER’ + “GENERAL SETUP” + ‘ENTER’ +
“LANGUAGE” + ‘ENTER’
Choose the language you want and press ‘ENTER’ again to confirm.
2.5 EXTERNAL CONNECTIONS
2.5.1 Internal/external GPS Source
The EKP-IV has an internal GPS Receiver. Be sure the Fix Source is set to Internal GPS to receive
data from this internal receiver.
> ‘MENU’ 1 sec. + “SYSTEM SETUP” + ‘ENTER’ + “FIX SETUP” + ‘ENTER’ + “FIX SOURCE” +
‘ENTER’
Choose Internal GPS and press ‘ENTER’ to confirm.
Otherwise if the EKP-IV is using an external NMEA0183 positioning source, set the Fix Source as
External NMEA0183. The recognized Input NMEA0183 messages are the following: GGA, GLL,
GSA, GSV, HDG, HDM, HDT, PCMPA, RMC, VHW, VTG (see Appendix E for more details on
NMEA sentences).
> ‘MENU’ 1 sec. + “SYSTEM SETUP” + ‘ENTER’ + “FIX SETUP” + ‘ENTER’ + “FIX
SOURCE” + ‘ENTER’
Choose External NMEA0183 and press ‘ENTER’ to confirm.
Fig. 2.5.1 - External Input

20
2.5.2 NMEA Outputs
The EKP-IV can be connected to external equipment that accepts NMEA0183 data input.
Once attached, the output of NMEA formatted position information can be enabled in the following
manner:
> ‘MENU’ 1 sec. + “COMMUNICATIONS” + ‘ENTER’ + “NMEA OUTPUT” + ‘ENTER’
The default setting is Off. The Output NMEA0183 messages are the following: APA, APB, BOD,
BWC, GGA, GSA, GSV, GLL, HSC, RMA, RMB, RMC, VTG, WCV, XTE (see Appendix F for more
details on NMEA sentences) BOD, BWC, GGA, GLL, HSC, RMA, RMB, RMC, VTG, WCV, XTE (see
Appendix F for more details on NMEA sentences).
Fig. 2.5.2 - NMEA Connections
2.5.3 Down Or Up-load Flight Plans & Tracks
The EKP-IV can also send and receive Flight Plans from the AvMap Flight
Planner or another device compatible with it through the serial port (the USB port is for factory
use only). This requires an optional data cable that can be purchased from your avionics dealer or
AvMap/Navigation for a proper connection to the device (see following figures).
Fig. 2.5.3 - Optional Data Cable
Fig. 2.5.3a - directional Communicatons
