Avpro edge Ac-da210-hdbt User manual

AC-DA210-HDBT

HDBaseT 2-8-2 splitter with Audio De-Embedding, EDID

Management, and switchable inputs.

Operation Manual

AC-DA210-HDBT

Page 1

The AC-DA210-HDBT is designed for massive distributions over extreme distances. Using tried and true HDBaseT

Technology, this distribution amplifier has simplified long distance distribution while giving the end points

undisturbed HD and UHD images.

Simplicity and "Plug & Play" are focal points of this unit. With RS-232 and IR you can manage your end points as well

for things like "Power On" or "Power Off". Additionally, these have two switchable inputs making for more robust

systems. The dual HDMI inputs allow you to expand the switching virtually forever.

The AC-DA210-HDBT is ideal for Retail Spaces, Bars, Restaurants, Showrooms and Public Spaces where you want to

have consistent messaging, images or signage across large spaces. Having two inputs allows you to option between

sources like custom signage, computers and any HDCP protected content.

Features:

•Advanced Equalization and amplification of

outputs for smooth switching

•2 HDMI inputs, In2 supports HDCP2.2.

•Advanced EDID Management

•Support HDMI 2.0 4K60 4:2:0

•IR, RS-232 Control Options

•IR, RS232 routed to HDBaseT output

•Digital Toslink Out

•L/R Analog Out

•Digital S/PDIF Out

•Good little clear circuit ensure the cascading

capability

Easy to use:

•

Install in seconds

•

Feature rich

•

Powerful EDID management

•

Front Panel Control

•

RS-232 Control

In The Box:

•

AC-DA210-HDBT

•

48V Power Supply

•

2x Phoenix Connectors

(RS-232 and 2CH Audio)

•

Mounting Ears

Quick Installation:

1.

Connect the HDMI input sources (Blu-ray, Set Top Box, etc...) to the AC-DA210-HDBT.

2.

Connect the HDBT/HDMI output devices (AVR, Display, Distribution Amplifier, Extender) to the AC-

DA210-HDBT.

3.

Power on the sources.

4.

Connect the power supply into the AC-DA210-HDBT.

5.

Turn on output devices/displays.

6.

Use the front panel controls to control the DA.

AC-DA210-HDBT

Page 2

AC-DA210-HDBT

Page 3

AC-DA210-HDBT

Page 4

Device Overview:

These devices are perfect for distributing any one/two sources to an unlimited amount of

displays. (One source at a time)

Think:

•Retail signal distribution – Big Box Stores & Local Retail for Advertising; School's & Office's

for Infoboards – 1000's of new accounts just opened up to you!

•Bars & Restaurants – a very simple way to “split” the signal to show in multiple locations.

•Digital Signage – low cost method for airports, rail, subway and more to distribute high

value 4K signals

•A word on Cascading – need more displays? Just connect an output to the next devices

input and keep stringing the displays together – now you have a 1 x 500 DA that can

switch two sources!

AC-DA210-HDBT

Page 5

AC-DA210-HDBT

Page 6

Switching:

The AC-DA210-HDBT can be switched from the front panel by pressing the

“Select” button. This switches back and forth from Input 1 and Input 2

EDID management:

1. Pressing and holding the button for more than 3 seconds will enter an

EDID management mode.

2. When in EDID management mode the HDMI out LED’s 1&2 will be

flickering.

3. HDBT out LED’s 1 through 5 are used to identify the EDID setting.

4. Press the button to cycle through the available EDID’s

5. Press and hold for 3 seconds again to set the selected EDID

a) If all LED’s light up it is successful, and press the button once more to

return to normal operating mode.

b) If all LED’s are flickering, the setting failed. Press the button to resume

normal operating mode and try again.

6. The table below (Page 8) shows the different EDID options.

AC-DA210-HDBT

Page 7

AC-DA210-HDBT

Page 8

AC-DA210-HDBT

Page 9

Audio:

The extracted audio is always active by default, you may simply plug into any/all

of the ports (Toslink, SPDIF, 2CH) and the audio will be output based on the active

source. Additional audio commands can be sent by RS-232.

IR Routing:

IR can be routed in three ways

1. To the remote (HDBaseT Receiver) end by inserting an IR Receiving Eye

into the IR In port on the AC-DA210-HDBT.

2. Back out of the IR Out port on the AC-DA210-HDBT by placing an

IR Receiving Eye in the AC-EX70-UHD Receiver’s IR In port

3. Directly from a control system using a cable as designed below.

AC-DA210-HDBT

Page 10

RS-232 Control:

You may also control or configure the AC-DA210-HDBT with

RS232. RS232 setting:

Baudrate: 57600 Parity: None DataBit: 8 StopBit: 1

The available commands are as follows:

AC-DA210-HDBT

Page 11

Troubleshooting

•Verify Power - The LCD screen on the front of the matrix should be lit up when power is

applied. Check that both power supplies are connected to the matrix and powered

•Verify Connections - Check that all cables are properly connected

•Issues with one INPUT/OUTPUT - Swap ports/cables/etc to help narrow down if the issue

stays with the input/output/etc

oFollows the device, then it may be an EDID issue. Default out of the box is a 1080p

2ch. Try another canned EDID or use the COPY FROM OUTx command to copy the

connected displays EDID - Pg. 7, 8, 11, and 21

•Issues with 4k but 1080p or less is working

oVerify all connected devices are capable of the signal you are sending

AC-DA210-HDBT

Page 12

After Sale Service:

Safety Instructions:

To ensure reliable operation of these products as well as protecting the safety of any person using or handling

these devices while powered, please observer the following instructions.

1. Use the power supplies provided. If an alternate supply is required, check Voltage, polarity, and that it

has sufficient power to supply the device it is connected to.

2. Do not operate these products outside the specified temperature and humidity range given in the above

specifications.

3. Ensure there is adequate ventilation to allow this product to operate efficiently.

4. Repair of the equipment should only be carried out by qualified professionals as these products contain

sensitive devices that may be damaged by any mistreatment.

5. Only use these products in a dry environment. Do not allow any liquids or harmful chemicals to come

into contact with these products.

6. Due to the weight and physical size of some of these matrix switchers, correct Manual Handling and

Lifting procedures should be observed at all times while handling these products in order to minimize the

risk of injury.

1. Should you experience any problems while using this product, firstly refer to the Troubleshooting section in this

manual before contacting Technical Support.

2. When calling Technical Support, the following information should be provided:

•Product name and model number

•Product serial number

•Details of the fault and any conditions under which the fault occurs

3. This product has a ten year standard warranty, beginning from the date of purchase as stated on the sales invoice.

Online registration of this product is required to activate the full ten year extended warranty. For full details

please refer to our Terms and Conditions.

4. Product warranty is automatically void under any of the following conditions:

•The product is already outside of its warranty period

•Damage to the product due to incorrect usage or storage

•Damage caused by unauthorized repairs

•Damage caused by mistreatment of the product

5. Please direct any questions or problems you may have to your local dealer before contacting AVProEdge

AC-DA210-HDBT

Page 13

•Use the power supplies provided. If an alternate supply is required, check voltage,

polarity and that it has sufficient power to supply the device it is connected to.

•Do not operate these products outside the specified temperature and humidity range

given in the above specifications.

•Ensure there is adequate ventilation to allow this product to operate efficiently.

•Repair of the equipment should only be carried out by qualified professionals as these

products contain sensitive components that may be damaged by any mistreatment.

•Only use this product in a dry environment. Do not allow any liquids or harmful

chemicals to come into contact with these products.

•Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean

this unit.

Maintenance

To ensure reliable operation of this product as well as protecting the safety of any person

using or handling this device while powered, please observe the following instructions.

Damage Requiring Service

•The DC power supply cord or AC adaptor has been damaged

•Objects or liquids have gotten into the unit

•The unit has been exposed to rain

•The unit does not operate normally or exhibits a marked change in performance

•The unit has been dropped or the housing damaged

The unit should be serviced by qualified service personnel if:

AC-DA210-HDBT

Page 14

Support

Should you experience any problems while using this product, first, refer to the

Troubleshooting section of this manual before contacting Technical Support. When

calling, the following information should be provided:

•Product name and model number

•Product serial number

•Details of the issue and any conditions under which the issue is occurring

Warranty

If your product does not work properly because of a defect in materials or

workmanship, AVProEdge (referred to as “the warrantor”) will, for the length of the

period indicated as below, (Parts/Labor (10) Years), which starts with the date of original

purchase (“Limited Warranty period”), at its option either (a) repair your product with

new or refurbished parts, or (b) replace it with a new or a refurbished product. The

decision to repair or replace will be made by the warrantor. During the “Labor” Limited

Warranty period there will be no charge for labor. During the “Parts” warranty period,

there will be no charge for parts. You must mail-in your product during the warranty

period. This Limited Warranty is extended only to the original purchaser and only covers

product purchased as new. A purchase receipt or other proof of original purchase date is

required for Limited Warranty service.

This warranty extends to products purchased directly from AVPro or an authorized

dealer. AVPro is not liable to honor this warranty if the product has been used in any

application other than that for which it was intended, has been subjected to misuse,

accidental damage, modification or improper installation procedures, unauthorized

repairs or is outside of the warranty period. Please direct any questions or issues you may

have to your local dealer before contacting AVPro.

AC-DA210-HDBT

Page 15

_____________________________________________

AC-DA210-HDBT

Page 16

_____________________________________________

AC-DA210-HDBT

Page 17

AVProEdge

2222 E 52nd St N ~ Sioux Falls, SD 57104

1-877-886-5112 ~ 605-274-6055

[email protected]

Thank you for choosing AVProEdge!

Please contact us with any questions, we are happily at

your service!

AC-DA210-HDBT

Page 18
