AVPro Edge AC-CXWP-KVM-KIT User manual

ac-CXWP-KVM-kit
Quick Start Guide
AVPro Edge’s ConferX Dual Gang Wall Plate presents a Full 4k60 444 KVM solution
for anything from the home oce to the classroom. Fully integrate with today’s
interactive displays using bidirectional USB and ARC up to 40 meters over a single
category cable.
This guide will walk you through the following topics:
• Installation
• EDID Management
• Scaling
• Test Pattern Generator
• IR Control Signals
• RS232 Control Signals
• Audio Extraction
• ARC
• USB Extension
• Troubleshooting
installation
1. Install a CAT5e (or better) cable between the display and the source (be sure
to follow local low voltage code. This varies state to state).
2. The Tx has an HDMI input. Connect this to the output of the source with an
18Gbps HDMI cable
3. The Rx has an HDMI output. Connect this to the input of the display with an
18Gbps HDMI cable.
4. Both the Tx and Rx have an RJ45 HDBT connector. Connect each end of the
installed Category cable to these ports.
5. Install the TX Wall Plate into the dual gang box
6. Connect the orange 2 Pin Phoenix power supply to the RX, setting the RX POE
Switch to the “RX” Position
*NOTE - Only use the included power supply
EDID management/Scaling
The EDID Management Pin Wheel allows
you to manage the input device (typically the
display) to request specific video resolutions
and/or audio codecs from a source. EDID Pin
Wheel also allows for downscaling for use with newer sources and legacy displays.
HDMI & Bi-Directional USB Extension Kit with HDBas eT technology

Using a small, flathead screwdriver adjust the EDID Pin Wheel to the desired EDID
*”E” Copies EDID from Display and downscales incoming signal to 1080p
Test Pattern Generator (Tx only):
The Test Pattern Generator can be used for testing and troubleshooting
infrastructure, cables, and signal path. This test pattern will be generated at
1080p.
1. Toggle Test Pattern by turning EDID Wheel to “F”
RS 232 Control
RS232 control signals can be sent 2 dierent ways:
1. From the rack using a control system (Control4, Crestron, etc) to the display
2. From the display back to the rack
Audio Extraction (TX Only)
This feature will allow you to extract 2ch audio from the source or ARC in order to
send audio signals to an amplifier or AVR.

You can make a cable, or a premade cable can be purchased separately (AC-
CABLE-3PIN-2CH).
Follow the diagram below if you are making your own cable.
1. Plug the 3 pin connector into either the Tx or Rx (the audio port on both the Tx
and the Rx are always active). The port is labeled “L/R Audio Extraction”.
2. Plug the L/R stereo cables into the audio input of an amplifier or AVR.
3. Set the audio output of the source/display to 2CH PCM
ARC
ARC can return audio from a display upstream to an audio device. ARC on the
KVM Wall Plate is enabled simply by flipping the Audio Extraction Switch to “ARC”.
ARC audio input can be selected using the “Audio IN” switch on the RX device. ARC
audio can be extracted from the TX 2 ways:
1. HDMI Input (ARC): Up to DD+ Atmos*
2. L/R: 2CH PCM Only
Remember, ARC must be enabled in source/display to use over HDMI
*Must be supported by both devices
USB Extension
The AC-CXWP-KVM-Kit can extend USB 2.0 bidirectionally up to 40 meters. USB
Direction is selected by the “USB DIR. SELECT” switch on the RX. Use the USB Type
A ports to extend USB devices to the PC on the opposite USB type B port.
Troubleshooting
1. Try dierent HDMI cables. A defective HDMI cable can bring the entire system
down.
2. If using short HDMI cables (.5m, 1m) try a longer cable. Some short HDMI
cables do not sync well.
3. Use the built in Test Pattern generator to confirm that the infrastructure is
passing a signal
4. Re-terminate the Category cable (even if a cable tester indicates that the
cable is passing signal).
4K Display
Pan tilt
zoom Camera
Table top
conference control
hdmi
cat 6a
usb
bi-directional usb extension
ac-cxwp-kvm-kit

5. Avoid RJ45EZ connectors
6. Check the Category cable length. It may be too long.
7. Remove any excess Category cable and be sure that it is not twisted or
damaged.
8. Bypass any patch panels or punch-down blocks
9. If you are powering the Rx with the power supply and the Tx is not getting
power, try plugging the power supply into the Tx instead. Be sure to double
check the POE switch on the extender
10. If you are still having issues after troubleshooting, feel free to contact our Tech
Support department.
Have a question or need assistance?
Don’t hesitate to contact us!
SUPPORT: [phone]
USA TOLL FREE: 877-886-5112
EMAIL: [e-mail]
Drivers are available at www.avproedge.com/drivers
