Avtex SB195BT User manual

SB195BT
Mini Soundbar Instruction Manual

Some Dos and Don'ts On The Safe Use Of Equipment
1
This equipment has been designed and manufactured to meet international safety standards
but, like any electrical equipment, care must be taken if you are to obtain the best results and
safety is to be assured.
***********************************
DO read the operating instructions before you attempt to use the equipment.
DO ensure that all electrical connections (including the mains plug, extension leads and
interconnections between the pieces of equipment) are properly made and in accordance
with the manufacturer’s instructions. Switch off and withdraw the mains plug before making
or changing connections.
DO consult your dealer if you are ever in doubt about the installation, operation or safety of
yourequipment.
DO be careful with glass panels or doors on the equipment.
DO route the mains lead so that it is not likely to be walked on, crushed, chafed, or subject to
excessive wear and tear or heat.
***********************************
DON’T remove any fixed cover as this may expose dangerous voltages.
DON’T obstruct the ventilation openings of the equipment with items such as newspaper,
tablecloths, curtains, etc. Overheating will cause damage and shorten the life of the
equipment.
DON’T allow electrical equipment to be exposed to dripping or splashing, or objects filled
with liquids, such as vases.
DON’T place hot object or naked fame sources such as lighted candles or night-lights on, or
close to equipment. High temperatures can melt plastic and lead to fires.
DON’T use makeshift stands and NEVER fix legs with wood screws-to ensure complete safety
always fit the manufacturer’s approved stand or legs with the fixings provided according to
the instructions.
DON’T use equipment such as personal stereos or radios so that you are distracted from the
requirements of traffic safety.
DON’T leave equipment switched on when it is unattended unless it is specifically stated that
it is designed for unattended operation or has a stand-by mode. Switch off by unplugging the
equipment and make sure that your family know how to do this. Special arrangements may
need to be made for infirm or handi-capped people.
DON’T continue to operate the equipment if you are in any doubt about it working normally,
or if it is damaged in any way-switch off, withdraw the mains plug and consult your dealer.
ABOVE ALL,
- NEVER let anyone especially children push anything into holes, slots or any other opening in
the equipment - this could result in a fatal electrical shock;
- NEVER guess or take chances with electrical equipment of any kind. It is better to be safe
than sorry!
***********************************

BATTERY
SAFETY Take care to fit
your batteries correctly,
observing the plus and minus marks on
the battery and appliance. Incorrect
fitting can cause leakage or, in extreme
case, fire or even an explosion.
Store unused batteries in their
packaging and away from metal objects
which may cause a short-circuit
resulting in leakage or, in extreme
cases, fire or even an explosion.
Never attempt to recharge ordinary
batteries, either in a charger or by
applying heat to them. They may leak,
cause fire or even explode. There are
special rechargeable batteries which
are clearly marked as such.
Keep loose button cells away from
young children.
Make sure battery compartments
are secure.
Seek medical advice if you believe a
cell has been swallowed.
Supervise children if they are replacing
batteries themselves in order to ensure
these guidelines are followed.
Remember that small button cell
batteries such as used in some hearing
aids, toys, games and other appliances,
are easily swallowed by young children
and this can be dangerous.
Remove dead batteries from the unit
and all batteries from the unit you know
you are not going to use for a long time.
Otherwise the batteries may leak and
cause damage.
Replace the whole set of batteries at
one time, taking care not to mix old and
new batteries or different types, since
this can result in leakage or, in extreme
cases,fire or even an explosion.
Never dispose of batteries in fire as this
can cause them to explode. Please
recycle dead batteries; do not put with
the normal household waste.
Battery Safety Guidelines
GUIDELINES
2
Used correctly, domestic batteries are a safe and dependable source of portable
power. Problems can occur if they are misused or abused - resulting in leakage
or, in fire or explosion.
Here are some simple guidelines to safe battery use designed to eliminate any
such problems.

Safety Warnings
Read all the instructions carefully before using the unit and keep them for future
reference.
Retain the manual. If you pass the unit onto a third party make sure to include this
manual. Check that the voltage marked on the rating label matches your mains voltage.
Damage
Please inspect the unit for damage after unpacking.
Do not continue to operate the unit if you are in any doubt about it working normally, or if
it is damaged in any way - switch off, withdraw the mains plug and consult your dealer.
Location of Unit
The unit must be placed on a flat stable surface and should not be subjected to vibrations.
Do not place the unit on sloped or unstable surfaces as the unit may fall off or tip over.
The mains socket must be located near the unit and should be easily accessible.
Temperature
Avoid extreme degrees of temperature, either hot or cold. Place the unit well away from
heat sources
such as radiators or gas/electric fires.
Avoid exposure to direct sunlight and other sources of heat.
Naked Flames
Never place any type of candle or naked flame on the top of or near the unit.
Moisture
To reduce the risk of fire, electric shock or product damage, do not expose this unit to rain,
moisture, dripping or splashing. No objects filled with liquids, such as vases, should be
placed on the unit.
If you spill any liquid into the unit, it can cause serious damages. Switch it off at the mains
immediately. Withdraw the mains plug and consult your dealer.
Ventilation
To prevent the risk of electric shock or fire hazard due to overheating, ensure that curtains
and other materials do not obstruct the ventilation vents.
Do not install or place this unit in a bookcase, built-in cabinet or in another confined
space. Ensure the unit is well ventilated.
Safety
Always disconnect the unit from the mains supply before connecting/disconnecting
other devices or moving the unit.
Unplug the unit from the mains socket before a lightning storm.
3

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Mains Cable
Make sure the unit or the unit stand is not resting on top of the mains cable, as the weight
of the unit may damage the cable and create a safety hazard.
Interference
Do not place the unit on or near appliances which may cause electromagnetic
interference. If you do, it may adversely affect the operating performance of the unit, and
cause a distorted picture or sound.
Batteries
Batteries used in the remote control for this unit are easily swallowed by young children
and this is dangerous.
Keep loose batteries away from young children and make sure that the battery holder tray
is secure in the remote control. Seek medical advice if you believe a cell has been
swallowed.
Please dispose of batteries correctly by following the guidance in this manual.
Supervision
Children should be supervised to ensure that they do not play with the unit and the
remote control.
Never let anyone especially children push anything into the holes, slots or any other
openings in the case - this could result in a fatal electric shock.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the unit’s
enclosure that may be sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
manual accompanying the unit.
Service
To reduce the risk of electric shock, do not remove screws. The unit does not contain any
user-serviceable parts. Please leave all maintenance work to qualified personnel.
Do not open any fixed covers as this may expose dangerous voltages.
Maintenance
Ensure the unit is fully unplugged from the power supply before cleaning.
Do not use any type of abrasive pad or abrasive cleaning solutions as these may damage
the unit’s surface.
Do not use liquids to clean the unit.
4

Table of Contents
5
Some Dos and Don'ts On The Safe Use Of Equipment......................................................................
Battery Safety Guidelines......................................................................................................................
Safety Warnings......................................................................................................................................
Product Overview...................................................................................................................................
Front view.....................................................................................................................................
Back view.......................................................................................................................................
Remote Control.......................................................................................................................................
Remote Control Battery Replacement................................................................................................
Battery Installation.....................................................................................................................
Remote Control Operation Range............................................................................................
Standard Accessories.............................................................................................................................
Normal installation................................................................................................................................
Power Connections................................................................................................................................
Connect Power.............................................................................................................................
HDMI connection.........................................................................................................................
USB connection............................................................................................................................
Analogue Input Connection.......................................................................................................
General Operation..................................................................................................................................
Standby/ON..................................................................................................................................
Select the Play Mode...................................................................................................................
Adjust the Volume.......................................................................................................................
Select the Sound Effect...............................................................................................................
AUX IN/COAXIAL OPERATION....................................................................................................
Operation.................................................................................................................................................
Bluetooth Operation...................................................................................................................
USB Charging................................................................................................................................
Trouble shooting.....................................................................................................................................
Specifications..........................................................................................................................................
Care and maintenance...........................................................................................................................
1
2
3
6
6
6
7
8
8
8
9
10
11
11
12
14
15
16
16
16
16
16
16
17
17
17
18
19
20

Back view
Product Overview
1.
2.
3. LED Display
4.
Power indicator(Standby & on)
Remote Control sensor
• Press and hold for power on/off.
• Press to change source.
5.VOL+/ VOL-
• Press to increase/decrease the
volume level.
/
Front view
6. DC IN socket
7. AUX IN socket
8.
9. USB
• To connect to a USB storage device.
• To recharge for mobile devices.
10. COAXIAL socket
11. Power switch
HDMI ARC socket
123
678 9 10
6
45
12V/2 4V AUX IN HD MI AR C USB C OA XIA L
12V/24V AU X IN HDMI AR C USB COAXIAL
11

1.
• To switch the unit between ON and
STANDBY mode.
2. EQ
• Press to select a preset sound effect.
Default EQ is MUSIC, press to switch to
NEWS, NORMAL and MUSIC as recycle.
3.
• Press to mute or resume the sound.
4. VOL+/VOL-
• Press to increase/decrease the volume
level.
5.
• Press to play/pause in Bluetooth and
USB.
6.
• Press to select previous/next track in
Bluetooth and USB.
7.
• Press to switch audio source to bluetooth.
• Press and hold to activate the pairing
function in blueooth and/or disconnect
the existing paired bluetooth deivce.
8. USB/AUX
• Toggle button to switch between audio USB and
AUX
9. COAX
• Press to switch audio source to COAXIAL.
10. HDMI ARC
• Press to switch audio source to HDMI ARC.
• To allow the TV remote control to power on/off
the soundbar press and hold HDMI ARC button
until display shows “ON”. (Default setting is OFF)
/
10
1
2
6
7
8
Remote Control
3
4
9
7
5

Remote Control Operation Range
• The remote-control sensor on the front of the unit is sensitive to the remote control’s
commands up to a maximum of 5 metres away and within a maximum of a 60º arc.
• Note that the operating distance may vary depending on the brightness of the room.
8
Remote Control Battery Replacement
1. Unclip and remove back cover to open battery
compartment of the remote control
2. Insert two AAA size batteries.
Make sure the (+) and (-)ends of the
batteries match the (+)and (-)ends
indicated in the battery compartment.
3. Close the battery compartment cover.
Battery Installation

Standard Accessories
Standard Accessories
Remote Control x 1 pc
AAA batteries x 2 pcs
Instruction Manual x 1 pc
Power adaptor x 1 pc
Car adaptor x 1 pc
AC cord x 1 pc
AUX cable x 1 pc
HDMI cable x 1 pc
Coaxial cable x 1 pc
Bracket x 1 pc
Screws A x 2 pcs
9

Installation
1. Disassemble the TV stand from the TV
2. Using the bracket to assembly the mini soundbar with TV.
step 1:
step 2:
Screws A x 2
Parts
Existing TV stand screws
Existing TV stand screws Screws A x 2
Normal installation
Bracket x 1
Mini soundbar x 1 TV x 1
Bracket x 1
10

Power Connection
Caution:
- Risk of product damage! Ensure that the power supply voltage corresponds to the voltage
printed on the rating label on the back or on the underside of the unit.
- Before connecting the power cable , ensure that you have completed all the other connections.
- Connect the small end of power socket at the back of unit and insert the plug of power adaptor into
- Be sure to unplug the power adaptor from the outlet when the system is not in use for an extended
standard AC wall outlet.
period of time.
12V/2 4V AU X IN HD MI AR C USB COA XIAL
Insert the Mini soundbar plug into a wall socket and turn the wall socket on/or connect the
12V-24V volt lead to your battery source.
11

HDMI Connection
With compatible TVs HDMI-CEC and ARC
If you connect your sound bar to a compatible TV HDMI-CEC and ARC (Audio Return Channel), you can
play the sound from your TV through your sound bar without using additional audio cable.
HDMI2 (ARC)
- Use a High-Speed HDMI cable that supports the ARC function to connect the HDMI ARC connector
- On your TV, turn on HDMI-CEC and ARC functions. For this, refer to its instructions.
on your sound bar in the HDMI ARC connector on the TV. For more details about the location of this
connector, see the TV user manual.
- Repeatedly press the SOURCE on the unit or HDMI on remote control to select the input source to
HDMI. Once connected, use the TV remote control to adjust the volume.
If your TV is not HDMI-CEC and ARC, you must connect an audio cable to play sound from your TV
through the speakers of your sound bar.
12V /24V AUX I N HDMI ARC U SB CO AXIAL
12

To enjoy the sound and image.
You can enjoy both sound and image for a device connected to your sound bar.
HDMI OUT
Blu-Ray player,
a games console…
DVD player,
- To do so, plug HDMI cable (not supplied) to the HDMI 1 or HDMI 2 jack on the back of the TV and the
other end into the HDMI OUT jack on your audio device, such as DVD player, Blu-Ray player, games
- Then plug one end of a second HDMI cable to the HDMI ARC of the TV and the other end into the
soundbar's HDMI ARC.
- Repeatedly press the SOURCE on the unit or HDMI on RC to select the input source to HDMI.
- Start playing on your device. The sound of your device is broadcast on speakers of the sound bar and
the image appears on the TV screen.
console.
HDMI 1
HDMI 2
(ARC)
12V/24V AU X IN HDMI AR C USB COAXIAL
13

Digital Input Connection
Connecting DVD player/T V outputs to digital input from the soundbar .
- Use the COAXIAL cable t o connect the COAXIAL output socket from the DVD player /TV with the
input socket from the soundbar .
soundbar input
DVD player / TV outputs
If there is no sound coming out of the soundbar and the indicator lights up make sure that the
audio setting of your source player(e.g.DVD player, game player, TV) is set to PCM with COAXIAL
input.
Tip
12V/24V AU X IN HDMI AR C USB COAXIAL
14
Connecting a USB mass storage device (including USB flash memory, USB flash players or
memory cards) to this unit to enjoy the device’s stored music through the powerful speakers of
this unit.
1. Insert the USB device into the port at the rear of the unit.
2. Press the button repeatedly on the side of the unit or press the USB button on the
remote control to select the USB function.
3. The device’s stored music will be played automatically.
USB Connection
/
12V/2 4V AUX IN HD MI AR C USB C OA XIA L

Analogue Input Connection
Connecting DVD player/T V outpus to analogue input from the soundbar .
socket from the soundbar .
sound board input
DVD player / T V output
Connecting DVD player/T V output to analogue input from the soundbar .
- Use a to connect the DVD player/TV output with the AUDIO 3.5mm line-in cable input socket from
the soundbar .
sound board input
DVD player / T V output
- Use a 3.5mm line in to RCA audio cable to connect the DVD player/TV output with the AUX input
12V/24V AU X IN HDMI AR C USB COAXIAL
12V/24V AU X IN HDMI AR C USB COAXIAL
15

General Operation
Standby/ON
Selecting the Play Mode
Press the button repeatedly on the unit to switch between BLUETOOTH, USB, AUX IN, HDMI
ARC. Alternatively press the , USB, COAX, AUX and HDMI ARC button on the remote control to
select the desired source.
Note:
If there is no signal, the unit will automatically switch off within 19 minutes to save energy.
Adjust the Volume
- Press the VOL +/– buttons to adjust the volume.
- If you want to turn off the sound, press the MUTE button on the remote control. Press the
MUTE button again or press the VOL+/- button to resume normal listening.
Note :
If you adjust the volume to above 26 then power off, when you power on again, the volume will
automatically be restored to the factory setting.
Selecting the Sound Effect
The default Sound Effect is MUSIC. While playing, press EQ button on the remote control to
switch sound effect. The options are NEWS, NORMAL and MUSIC.
AUDIO IN/COAXIAL OPERATION
1. Press the button repeatedly on the unit or alternatively press the AUX/COAX buttons on
the remote control to select your desired source.
2. Operate your audio device directly for playback features.
3. Press the VOL +/– button to adjust the volume to your desired level.
When you connect the unit for the first time to the power supply, the unit will automatically
switch on.
- Press the button on the remote control or press and hold the on the unit to switch the
main unit to STANDBY mode, the POWER indicator will illuminate red.
- Press the button on the remote control or press the on the unit again to switch the unit
back to ON mode.
- Disconnect the power supply if you want to switch OFF the unit completely.
/
/
16

You can listen to tracks from a media device if it is connected to the unit via Bluetooth.
Pair Bluetooth-enabled Devices
You need to pair your Bluetooth device with this unit before you connect them for the first time.
Note:
- The operational range between this unit and a Bluetooth device is approximately 8 metres
(without any object between the Bluetooth device and the unit).
- Before you connect a Bluetooth device to this unit, ensure that you know the device’s capabilities.
- Any obstacle between this unit and the Bluetooth device can reduce the operational range.
- If the signal strength is weak, your Bluetooth device may disconnect, but it will re-enter
automatically into pairing mode.
1. During ON mode, press the
If the unit is not paired to any
mode; or you need to press and hold the button to start pairing.
2. Activate the Bluetooth function on your device and select the search mode.
“ Avtex SB195BT ” will appear on your Bluetooth device.
Tips:
• If there is already an existing connection, press and hold button on the remote control to
re -activate the pairing mode.
• The unit will also be disconnected when your device is moved beyond the operational range.
• If you want to reconnect your device to this unit, place it within the operational range.
• If the device is moved beyond the operational range, when it is brought back, please check if the
device is still connected to the unit.
• If the connection is lost, follow the above instructions to pair your device again to this unit.
button on the remote control to select the Bluetooth mode
The existing connection will be interrupted.
3. Select “Avtex SB195BT" in the pairing list. After successful pairing, LED display will display bT.
Bluetooth Operation
Bluetooth device, the system enters automatically into pairing
Operation
USB Charging
Important note:
This device is equipped with an energy saving mode: if no signal is given during 19 device will
(ERP 2 standard). Please note
recognized as “no audio signal”: this will
device and can also originate an automatic
please reactivate the audio signal transmission or
audio source player (MP3 player, etc.), to resume playback.
You can plug a USB cable (not supplied) in USB socket to charge the mobile device. Output
voltage and current is 5V/500mA. (Note: All devices for USB charging are not guaranteed)
switch automatically into standby mode in order to save energy
that low volume setting in the audio source may be
affect the capability of signal detection from the
switch into standby mode. If this happens
increase the volume setting on the
Please contact the local service centre if the problem remains .
17

To keep the warranty valid, never try to repair the system by yourself. If you encounter
problems when using this unit, check the following points before requesting service.
No power
• Ensure that the mains cable is connected securely.
• Make sure that the unit is switched on.
The remote control does not function
• Use the remote control near to the unit.
• Point the remote control at the remote-control sensor on the unit.
• Replace the batteries in the remote control with new ones.
• Remove any obstacles between the remote control and the unit.
Loud hum or noise is heard
• The plugs and sockets are dirty. Wipe them with a cloth slightly moistened with an appropriate
non-abrasive cleaning solution.
The unit does not respond when pressing any buttons
• The unit may freeze up during use. Switch off and then switch on the unit again at the
mains socket to reset it.
I can't find the Bluetooth name of this unit on my Bluetooth device for Bluetooth pairing
• Ensure that the unit is switched on.
• Ensure that the Bluetooth function is activated on your Bluetooth device.
• The unit has a Bluetooth function that can receive a signal within 10 metres. Keep a distance
The unit switches off automatically during playing
• Please increase the volume level on your input source player like DVD player/T V ect.
within 10 metres both devices.
Trouble shooting
No Sound
• Make sure that the unit is not muted. Press or VOL + to resume normal listening.
• Ensure that the audio setting of the input source (e.g. TV, game console, DVD player, etc.) is set to
PCM mode while using Coaxial and HDMI(ARC) connection.
Trouble shooting
18
