SSV Works RG4-F65 User manual

RG4-F65
Polaris Ranger
6.5” Speaker Front Kick Panels
SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: [phone] | Fax: [phone]
!
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material
or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against
defects in material or workmanship. All SSV Works Speakers are covered by a limited 1 year
warranty against defects in material or workmanship. Labor for replacement of defective
components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
PARTS LIST IMAGES
2. Enclosure Brackets x 41. RG4-F65 Enclosures
(1 pair)
3. M6 x 16mm Screws
x 10
- T-30 Torx Driver - Panel Removal Tool
4. M6 Washers x 8 (small) 4. M6 Washers x 2 (large)
A. Remove hood by turning locking pins and lifting up.
A
B. Use a panel tool to extract push pins circled in pink.
B
C. With push pins extracted, lift to remove the cup holder and gauge cluster.
C
- Phillips Screwdriver

K. Using the supplied M6 screws and small washers, install the
brackets to kick pods.
L. Remove factory T40 torx screws located from the front of the
dash next to the cup holders.
K L
F. Extract push pins that are now exposed from removing the
upper glove box.
H. Extract push pins exposed from gauge cluster removal.
I. Extract push pins located above driver and passenger side cup
holders.
F
H
I
E. Unscrew (4) torx screws located in upper glove box and
remove box.
G. Extract push pins exposed from cup holder removal.
E
G
J. Lift to remove the dash.
J

Connecting the RG4-F65 using the
pre-installed, two-pin connector will
require an optional SSV Works plug-
&-play harness (WP-H1149 - sold
separately). If you are not using the
WP-H1149 harness, simply cut off
the two-pin connector and follow the
wiring instruction.
Repeat for the other side.
RG4-F65 © 2018 SSV Works, Oxnard, CA 93030 RG4-F65 Rev. B 7-23-18
WIRING INSTRUCTIONS
For proper sound, ensure the speaker
polarity is correct connect the “+” to
the “+” and the “-“to the “-“from the
speaker wire to the amplier. If using
with an SSV Works complete system
refer to the amplier wiring instructions
for more detailed wiring information.
“+”
“+”
“ - ”
“ - ”
M. Remove factory T25 torx screws located underneath the dash. N. Located on the inside top of the pocket you will have two
holes, route speaker wire though the larger hole. The smaller
hole will be used to mount the pod in Step P.
O. Place the speaker pod in location and resecure the factory screws through the pod brackets on the front and underneath the dash.
P. From the inside-top of the dash, secure the top mounting M6 screw and large washer to the pod through the smaller hole next to
the routed speaker wire.
M N
O
P P
O

SSVWORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks . com I Phone: [phone] I Fax: [phone]
WARRANTY INFORMATION:
All SSV Works enclosures are covered by alimited lifetime warranty against defects in
material or workmanship. All SSVWorks Electronics are covered bya li mited 1 year warranty
against defects in materia l or workmanship. All SSV Works Spea k ers are co vere dbya
limited 1 yearwarranty against defects in material or workmanship. Labor for replacemen tof
defective components is not covered. Contact SSV Works for further warranty infonnation.
RG4-DM3
Polaris Ranger
MRB3 Dash Kit
A
Please read and understand these
instructions completely before
. installation to avoid possible injury, or
damage to the accessory or vehicle.
-9/16" Bit -Phillips
Screwdriver
-Scribe
PARTS LIST IMAGES
1. MRB3 Dash Kit 2. MRB3 Dash Screws x6
A. Use a panel tool to extract push pins on the top of the center
cup holders.
INSTALLATION NOTES
Please refer to the MRB3 User Guide for
instructions for wiring and operation.
B. With push pins extracted, lift to remove the cup holder.

C. Place MRB3 dash mount onto the center cup holder panel,
and scribe the 4 comer mounting points.
E. Drill out the center of the cup holder for the controller cable to
be routed through with a9/16" drill bit
NOTE: Control drill bit depth to avoid puncturing through other
side of cup holder.
_ II
G. Route MRB3 controller cable through cup holder
D. Make pilot holes using a 3/32" drill bit
F. Place MRB3 controller in controller mount and fasten down
with provided screws.
H. Fasten the dash mount to cup holder with provided screws.
Refer to the MRB3 User Guide for instructions on how to complete wiring for the controller. Replace the cup holder panel.
UJCIRKS
• RG4-DM3
© 2018 SSVWorks, Oxnard ,CA93030 RG4-DM3 Rev. A 8-2-18

User Guide
MRB3
Bluetooth®Media Controller
Corporate: SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
Web: www.SSVworks.com | Phone: [phone] | Fax: [phone]
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG,Inc. and any use of such
marks by SSV Works is under license. © 2018 SSV Works, Oxnard, CA 93030 MRB3 Rev. C 11/16/18
Do not attempt to disassemble or repair the MRB3 yourself. Please call SSV Works for
technical assistance or repair information. Changes or modications to the MRB3 not
authorized by SSV Works will void the warranty.
SSV Works recommends disconnecting the negative battery terminal before
beginning any installation.
SAFETY INFORMATION
!
RADIO FUNCTIONS
CONNECTING AN EXTERNAL AUDIO DEVICE (OPTIONAL)
BLUETOOTH AUDIO STREAMING
MRB3
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or workmanship. All
SSV Works Electronics are covered by a limited 1 year warranty against defects in material or workmanship. Labor for
replacement of defective components is not covered. All SSV Works Speakers are covered by a limited 1 year warranty
against defects in material or workmanship. Contact SSV Works for further warranty information.
Selecting FM/AM Band: Press MODE until the FM or AM band shows on the display.
Automatic Station Search: Press or to start automatic station search. The search
stops when a station is found.
Manual Station Search: Press and hold or until M - SEEK. Press the or
briey to change the frequency until the desired frequency is set. Change to Automatic
search (A - SEEK) mode after a station is found.
- Press MODE until AUX shows on the display.
Add 3.5mm AUX-in
and USB Charging with
SSV Works 3PUSB35A
(sold separately)
1. Open the Bluetooth setup program on the mobile device and activate the Bluetooth feature
2. The device will show up as “SSV”. Select this device and enter passkey: OOOO
3. After successfully pairing, a Bluetooth logo will appear on the phone menu screen and
show “CONNECT” “BT MUSIC” on the device LCD display.
Stop Playback: Press briey to pause music. Press button again to continue playback.
Skip Track: Press or to play previous/next song.
Line in

MRB3
1. Play/Pause
Power On/Off
Mute
2. Volume Up/Down
3. Mode
4. Track Forward/Back
Station Forward/Back
Menu Settings Up/Down
5. LCD Display
BUTTON LOCATIONS AND FUNCTIONS
GENERAL OPERATIONS
1
5
34
2
AMPLIFIER WIRING DIAGRAM
USB charge
Line out/Ext. amp trigger
Wire control panel
Antenna
Line in
Rear speaker
Front speaker
Right (Red)Signal ground
AMP turn on Left (White)
Signal ground (Black)
Left (White)Right (Red)
Rear left(-) Green/Black
Rear left(+) Green
Rear left(-) Green/Black
Rear right(-) Purple/Black
Rear right(+) Purple
Front left(+) White
Front left(-) White/Black
Front right(+) Grey
Front right(-) Grey/Black
Rear left(+) Green
Rear right(-) Purple/BlackRear right(+) Purple
Power connector
Yellow
12A
Black
Black
Backup yellow
Front left(-) White/BlackFront left(+) White
Front right(-) Grey/BlackFront right(+) Grey
can’t read USB data
charge only
12v+ Yellow
does not read
USB data
USB 1A charge input
Signal ground
(Black)
AMP turn on
(Blue)
Power On/Off: Press to power on. Press and hold to power off.
Volume: Press the VOL(+) or (-) button to increase or decrease the volume.
Mute On/Off: Press briey to mute the sound. Press again to un-mute the sound.
Mode Sources: Press the MODE button to switch between AUX, FM, AM, Bluetooth (BT MUSIC).
Mode Settings (Bass/Treble/Balance/Fader/EQ/Loudness): Press the MODE button for
2 seconds and then press the button until the function you want is shown on the display.
Press VOL(+) (-) to change the settings of the menu item displayed.
Bass (BAS)/Treble (TRE): Press the VOL(+) or (-) button to adjust Bass & Treble.
Balance (BAL): Press VOL(+) or (-) to adjust balance (sound distribution between the right and
left speakers).
Fader (FAD): Press VOL(+) or (-) to adjust sound distribution between the front and rear speakers.
Equalizer (EQ): Press VOL(+) or (-) to select one of the EQ options: OFF, FLAT, CLASS, POP,
ROCK, JAZZ, METAL. The equalizer will be disabled if EQ OFF is set. The equalizer setting is shown
at the bottom of the display.
Loudness (LOUD): Press VOL(+) or (-) (LOUD ON) or to disable the function (LOUD OFF). When
the loudness function is on, LOUD is shown on the right of the display.
Select USA/Europe Area Frequencies (AREA): Press VOL(+) or (-) to select Radio Region
(USA / Europe Frequencies).
2 sec.
MODE BASS TRE BAL FAD EQ LOUD
