Pressure Relief Valve
Up to 200PSI.
Product number 30277633
Read this instruction manual before use.
Using this device without understanding this product’s operation
and care may lead to injury. If you do not understand how to use
this device and do not receive proper training, do not use this
product.

www.awg-fire.com
43 Summer St.
South Walpole, MA 02071
Tel [phone]
Fax [phone]
2Mar-11
1.0 WARRANTY
• AWG Fittings LLC warrants to the original purchaser and all subsequent purchasers
of the AWG Fittings LLC products that the product is free from defects in material
and workmanship during a one (1) year period from the date of its sale by AWG
Fittings LLC.
• AWG Fittings LLC’s obligation under this warranty is specifically limited to replacing
or repairing any product which is determined by AWG Fittings LLC’s inspection to
be in a defective condition attributed to AWG Fittings LLC’s manufacture or design.
If AWG Fittings LLC determines the product is defective, then AWG Fittings LLC will
repair or replace the product during the warranty period. The purchaser or
beneficiary must notify AWG Fittings LLC of any alleged defect within a reasonable
time period.
• If AWG Fittings LLC determines that the product is defective, then it will replace the
product, repair the product or refund the purchase price, at AWG Fittings LLC’s
election.
• This warranty is a LIMITED WARRANTY. The original purchaser of the product
and any subsequent purchaser of the product and any person who is an intended or
unintended beneficiary of the product shall not be entitled to recover from AWG
Fittings LLC and consequential or incidental damages for injury to person and/or
property resulting from any defective product manufactured or assembled by AWG
Fittings LLC. It is agreed that the price stated and paid for the product is in part
consideration for limiting AWG Fittings LLC’s liability.
• This is a limited Expressed Warranty Only. AWG Fittings LLC
EXPRESSLY DISCLAIMS WITH RESPECT TO THE PRODUCT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED
WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.
• There are NO WARRANTIES of any nature made by AWG Fittings LLC beyond that
stated in this Warranty

www.awg-fire.com
43 Summer St.
South Walpole, MA 02071
Tel [phone]
Fax [phone]
3Mar-11
Safety and Cautions
This equipment is to be used by trained firefighting personnel only. Failure to
obtain proper training may result in severe injury or death.
Do not exceed maximum operating pressure. Exceeding the maximum rated
pressure for this appliance may cause malfunction, or failure resulting in severe
injury or death.
Failure of fittings and hoses can result in injury. Use caution not to exceed hose
pressures as stated in NFPA 1961 for the type of hose being used.
Make sure all connections are secure and complete. Failure to ensure proper
connection may result in leaks or cause the devices to become disconnected
under pressure resulting in injury or death.
Open and close all valves slowly. Failure to operate valves slowly may cause
water hammer, which may result in damage or failure of hose, coupling devices,
and appliances leading to injury or death.
Do not use if damaged. Damage to product may cause malfunction or failure.
Remove from service until unit can be repaired.
Check for damage or worn coupling connections. Damaged or worn connections
may become disconnected under pressure. Remove from service to be repaired
by an AWG certified repair facility.
For use with fresh or salt water, with or without firefighting foam.
Altering of this device may reduce its operating effectiveness, or safety. Do not
alter or change in any way from its intended design.
2.0 Safety and Cautions
Meaning of safety words

www.awg-fire.com
43 Summer St.
South Walpole, MA 02071
Tel [phone]
Fax [phone]
4Mar-11
Dimensions:
Height: 4.3 in (110 mm)
Length: 6.29 in (160 mm)
Depth: 4.25 in (108 mm)
Weight: 3.5 lbs (1.6 kg)
Construction:
Aluminum body and
anodized aluminum piston.
Operating pressures:
Adjustable from 100, 150, 200 PSI (7, 10, 14 bar)
Friction loss:
Not calculated for this
device.
3.0 Overview

www.awg-fire.com
43 Summer St.
South Walpole, MA 02071
Tel [phone]
Fax [phone]
5Mar-11
Setting the PRV.
Incorrectly setting the pressure relief valve may result in the valve
opening to soon and creating inadequate water flow or to late resulting
in over pressurizing the hose line or appliance. Be sure to test your
setting before placing the unit in service.
If the relief valve operates continually, fails to operate or water leaks
slowly through the relief valve during use, remove from service until
valve can be cleaned, repaired, and the pressure reset.
Inspect for damage or malfunctioning parts. If appliance is damaged
or not functioning remove from service until repairs can be made.
Altering of this device may reduce its operating effectiveness or safety.
Do not alter or change in any way from its intended design
4.0 Operation

www.awg-fire.com
43 Summer St.
South Walpole, MA 02071
Tel [phone]
Fax [phone]
6Mar-11
This relief valve has one (1) center adjustment screw for
setting the pressure for the relief valve.
The relief valve has 3 settings, 100 PSI, 150 PSI, and 200
PSI.
When the adjustment screw is set flush with the top cover,
the highest vertical setting, the relief valve is set to open at
100 PSI.
When the adjustment screw is set in its middle position, the
top of the screw will be flush with the height of the slot cut in
the top cover. The relief valve will be set to open at 150
PSI.
When the adjustment screw is set all the way down to its
lowest vertical position, where the screw will not go any
lower, the relief valve will be set to 200 PSI
4.0 Operation

www.awg-fire.com
43 Summer St.
South Walpole, MA 02071
Tel [phone]
Fax [phone]
7Mar-11
Keep pressure relief valve clear of obstructions. This may cause
the relief valve to operate prematurely or fail to operate.
If relief valve appears to be damaged remove the appliance it is
installed to from service until the relief valve can be repaired or
replaced.
The relief valve has no field serviceable parts. Never try to repair
this valve unless you are a certified repair person. Improper repair
could result in serious injury and or death.
All working parts are contained inside the body of the relief valve.
The port opening on the relief valve body should be kept clear of
dirt and debris.
The relief valve should be exercised every six months to keep the
internal components clean and to make sure all parts are working
properly.
Adjust the set screw to the lowest available setting, 100 PSI.
Attach a water supply line to the appliance the valve is attached to
and slowly fill the supply line with water and bleed off any trapped
air.
Keep personnel clear of the valve and slowly increase the pressure
to 100 PSI. The relief valve should open and discharge water from
the PRV when set pressure is reached.
If water is not flowing from the relief valve, slowly increase the
pressure to 110 PSI. Check for water flow from the relief valve.
The relief valve should open and discharge water from the PRV.
Allow water to flow freely from the valve to remove dirt and debris.
If no water is flowing from the relief valve, the relief valve will need
service at an AWG Fittings, LLC facility.
5.0 Care and Maintenance

www.awg-fire.com
43 Summer St.
South Walpole, MA 02071
Tel [phone]
Fax [phone]
8Mar-11
If the relief valve operated properly at the low pressure setting, test
again to the high pressure setting.
Adjust the set screw to the highest available setting, 200 PSI.
Attach a water supply line to the appliance the valve is attached to
and slowly fill the supply line with water and bleed off any trapped
air.
Keep personnel clear of the valve and slowly increase the pressure
to 200 PSI. Check for water flow from the relief valve. The relief
valve should open and discharge water from the PRV.
If water is not flowing from the relief valve, slowly increase the
pressure to 210 PSI. Check for water flow from the relief valve The
relief valve should open and discharge water from the PRV.
Allow water to flow freely from the valve to remove dirt and debris.
If no water is flowing from the relief valve, the relief valve will need
service at an AWG Fittings, LLC facility.
After exercising the relief valve, shut down the water supply. Reset
the relief valve to the desired setting and test the setting to make
sure it was reset correctly.
If the relief valve fails to open when pressure rises above the set
level the relief valve should be returned to AWG Fittings, LLC for
service.
5.0 Care and Maintenance
