Awntech NT22 Original instructions

1
Nantucket Style Awning
OWNER’S MANUAL & INSTALLATION INSTRUCTIONS
WARNING: Adult Assembly Required
WARNING: Assembly Kit Contains Parts with Sharp Points, Sharp Edges, and Small Parts That Can Present Cho ing
Hazards to Children.
WARNING: Components Are Pac ed in Plastic Bags that are a Suffocation Hazard.
NOTE: Please inspect the parts for damage during shipping and/or for any missing items. If you suspect that there
may be damage or a shortage, contact us and we will send replacement parts if needed. At this time, visualize how
the components fit together and ma e sure that you have identified the various parts.
Models with Valance: NT22, NT33. NT44
Awning size Width in inches Awning Size Width to Inches
3 40.5 12 148.5
4 52.5 13 160.5
5 64.5 14 172.5
6 76.5 15 184.5
7 88.5 16 196.5
8 100.5 17 208.5
9 112.5 18 220.5
10 124.5 19 232.5
11 136.5 20 244.5
OUR AWNINGS ARE DESIGNED 4.5” WIDER THAN STANDARD WINDOW/DOOR OPENINGS SO THEY ANCHOR TO THE
STUDS AROUND THE WINDOW OR DOOR. EXAMPLE: RR22-5 IS FOR 5’-0” WIDE WINDOW. IT MEASURES 4.5”
WIDE, 31” TALL, (24” PLUS 7” VALANCE AND 24” DEEP (PROJECTION)
There is a variety of building wall surfaces; Awntech® does not supply the hardware to install your awning. You will
need to purchase installation hardware at your local hardware store. We have advised you on different surface
applications below:
CONCRETE BLOCK WALLS: 3/8” x 3” Masonry anchor bolts or Tapcon Screws plus Washers (1 per brac et)
WOO OR SI ING: 3/8” x 3” Lag Screws plus Washers (1 per brac et)
OTHER STRUCTURES: CONSULT A PROFESSIONAL

2
PARTS:
Awning Size in Ft. 3 4 5 6 7 8-10 11-12 13-18 Custom
(TB) Top Bar – C Channel 1 1 1 2 2 2 3 3
(FB) Front Bar 1 1 1 2 2 2 3 3
(NTC) Cover Support 2 2 3 3 3 5 4 7
(P) Projection 2 2 2 2 2 2 2 2
(B) Back Bar 2 2 2 2 2 2 2 2
(PM) Projection Bar Assembly 1 1 1 3 3 2 5
Other parts: Z-Brac ets, Self-tapping Screws
All awning sizes over 6’ wide come in to sections. Example: Size 6’ Top Bar (TB) consists of TB1 & TB2 and Front
Bar (FB) consist of FB1 & FB2
Tools Required: Electric Impact Drill, Installation Anchors (as per your wall type), Tape Measure, Safety Glasses, 4’
Level, a Safe Ladder and #2 pencils.
YOU MAY ALSO NEED AN ASSISTANT FOR LARGER AWNINGS. IT DEPENDS ON THE SIZE AND WEIGHT OF THE
AWNING.
NOTE: YOU WILL FIND THAT THE FITTINGS HAVE BEEN PRE-INSTALLED, AS WE HAVE PRE-ASSEMBLED AND
INSPECTED IT FOR YOU IN THE FACTORY.
Nantucket should be assembled on the ground
STEP 1: Separate all of the parts, so they will be easy to assemble. Please refer to Parts chart for quantities for each
part. (pg. 2)

3
Step 2: Connect Top Bar (TB) to the (2) two bac bars (B). Ma e sure the C-Channel is towards the bac . The
Velcro on the bac bars should be facing the rear. Use a rubber mallet to fully seat the tubing into the fitting.
Secure with self-tapping screws.
Step 3: Connect Both Projection Bars (P) in the other ends of the Bac Bars Velcro facing outwards (B).

4
Step 4: Connect the Front Bar (FB) to the projection Bars (P). Velcro will be facing out. Secure with Self tapping
screws.
Step 5: Install the Cover Supports (NTC) with arrows pointing upward. Attach both ends to the (TB) and (FB).
Larger awnings add Cover support (NTC) and Wall Support (PM). Secure with self-tapping screws. Please eep in
mind wall supports (PM) won't have pre-drilled holes. You'll need to use the self tapping screws to secure the bars
to the rear end of the front bar where space is available.

5
The frame for the Nantuc et is complete
INSTALLING THE COVER
STEP 6: Slide the tubing at the top of the fabric cover into the C-Channel on the top of (TB).

6
STEP 7: Pull the remainder of fabric over the fame with the valance hanging down below the
(NC) and (FB) bars.
Frame 2’-4’ Frame 5’-24’
STEP 8: Once you are satisfied with the position of the cover, Pull the tabs snugly and attach them to the pre-
installed Velcro tape on the bars.

7
MOUNTING THE AWNING
STEP 9: Place the awning on in desired location. From the inside of the awning ma e a mar on the wall where the
awning touches. (See the chart below for the height measurements)
the sizes are in inches
Model Space between
TB and P
Height incl
valance Projection
NT22 24 31 24
NT33 36 44 36
NT44 48 56 48
Step 10: install the Z-Brac ets, temporarily place the awning on the wall to ma e sure it fits prior to tightening
screws. Please eep in mind there won't be pre-drilled holes for the Z-Brac ets so you can place them where they
are needed.
Step 11: Remove the awning and tighten wall brac ets.
Step 12: Install weather Stripping on the awning outside parameter. Place the awning bac on the brac ets. Drill
two holes for self-tapping screws thru the (TP) use Z-Brac ets for guide. Secure with self-tapping screws.
NORMAL WEAR & TEAR:
The weather in certain regions of the country contributes to wear and tear of the awnings. If you live in these
areas (High maintenance areas: FL, TX, NM, AZ, NV or high-altitude areas) weather conditions (including sun) can
ta e a toll. Normal wear and tear is not covered in our warranty and should be expected. Damages caused by
improper anchoring, strong winds, snow or ice are not considered defects. We offer replacement fabric at
affordable prices
CLEANING & CARE:
Awnings should be cleaned at least once a year in low maintenance areas or twice a year in high maintenance
areas (see high maintenance areas above). Cleaning consists of brushing off debris with broom, brushing on a non-
detergent cleaning compound (such as a solution of 1-part vinegar to 1-part water), allowing the awnings to sit for
20 minutes, and then rinsing. Remember that your awning is an exterior product; You’ll need to clean your awning
to preserve and extend its beauty and life. Please refer to the cleaning and care chart below if you acquire a stain
from one of the ingredients on the list.

CLEANING CHART FOR TYPICAL AWNING STAINS
STAIN RECOMMENDED CLEANING SOLUTIONS
CHARCOAL Vacuum, then liquid detergent
CHEWING GUM Acetone
SODA Liquid detergent
CAR GREASE Acetone
IRON RUST Oxalic or citrus acids, water
MILDEW 1 cup of bleach and ¼ mild soap per gallon of water
OIL Acetone
PAINT (LATEX) WET Liquid detergent, water
PAINT (LATEX) DRIED Paint, oil or grease remover
PAINT (OIL OR LACQUER) Paint, oil or grease remover
SUNTAN LOTION Pine Power® or pine oil detergent
TREE SAP Turpentine, liquid detergent
