AXA JetTENDER 250 User manual

JetTENDER 250
User Manual
1

FOREWORD
Congratulations on choosing a JetTENDER boat!
This user manual will familiarise you with the features of your new boat and help with its care and maintenance. It has
been written to help you learn to handle your boat safely andavoid any problems. Make sure that you have received
manuals for all equipment fitted on your boat. Supplement this manual with the specifications and manuals of
equipment you purchase later for your boat. Space has been left for your own notes at the end of the manual. Please
read this manual carefully and familiarise yourself with the craft before using it.
If this is your first craft, or you are changing to a type of craft you are not familiar with, please ensure that you obtain
sufficient handling and operating experience before "assuming command" of the craft. This is highly important for your
own comfort and safety.
Your dealer or national sailing association or yacht club will be happy to advise you of local boating schools or
competent instructors.
This user manual is not a detailed maintenance or trouble shooting guide. In case of difficulty please contact the
dealer. Always use qualified and competent people for the maintenance, repair and modification of the boat.
Modifications that may affect the safety characteristics of the craft must be assessed, executed and documented by
Competent people. The manufacturer is not responsible for modifications he has not approved.
Always keep your boat in a good condition and be aware that the boat requires maintenance and servicing.
Any craft –no matter how strong it may be, can be severely damaged if not used properly. Always adjust the speed
and direction of the craft to prevailing weather conditions.
We wish You enjoyable and relaxing times on board your JetTENDER Boat.
AXA d.o.o.
Preradovićeva 4
47000 Karlovac
Croatia ( local name HRVATSKA )
Tel. [phone]
Fax.[phone]
www.jettender.eu
Please keep this user manual safe and hand it over to the next owner if you sell your boat.
Hull Identification Number (HIN):
The HIN is located on the right hand side of the transom face. Record it in the above box.
2

Table of contents
1. General 6
1.1 Declaration of conformity 6
2. Definitions 9
3. Warranty 9
4. Before use 10
4.1 Registration 10
4.2 Insurance 10
4.3 Training 10
5. Characteristics and use of your boat 11
5.1 General 11
5.2 Basic data 11
5.3 Maximum recommended number of passengers 12
5.4 Loading 12
5.5 Prevention of water incursion and stability 12
5.5.1 Hull and deck through fittings and closing valves 12
5.5.2 Stability and buoyancy 13
5.6 Avoiding the risk of fire or explosion 13
5.6.1 Refueling 13
5.7 General arrangement 14
6. Operating 15
6.1 Fuelling 16
6.2 Before use 16
6.3 Safety check 16
6.4 Starting 17
6.5 Safety lanyard 17
6.6 Oil level check 17
6.7 Engine coolant 17
6.8 Dry engine compartment 17
6.9 Engine bay arrangement 18
6.10 After use –Flushing procedure 18
6.11 Fuel System Check 19
6.12 Routine Maintenance 19
6.13 Servicing 19
7. Pre-operation Check List 20
8. Product Maintenance Chart 21
9. Winterising/Dry Storage 23
10. Trouble Shooting 24
3

BEFORE YOU SET OFF
Familiarise yourself with this user manual.
Always check at least the following items before leaving:
− Weather conditions and forecast
Take the wind, waves and visibility into account. Are the design category, size and
equipment of your boat, as well as the skills of the skipper and crew adequate for the
waters you are heading for? Hull windows and hatches must be battened down during
heavy wind and rough seas to prevent water incursion.
− Loading and stability
Do not overload the craft, and distribute loads appropriately. Heavy items are to be
placed in the storage compartments underneath the aft bench. Please consider that the
stability of the boat is reduced if people stand up when on board.
− Passengers
Ensure that there are personal flotation devices or lifejackets for all people on board.
Agree on the tasks each person will be responsible for during the voyage before setting
off.
− Fuel and fuel system
Make sure that the boat has enough fuel, including a 20 % reserve for heavy weather or
other unforeseen eventualities.
− Engine and maneuvering equipment
Check the function and condition of steering and the remote control, and carry out the
routine daily checks specified in the engine manual.
− Seaworthiness
Check the boat's seaworthiness in other respects as well: no fuel or water leaks, safety
equipment on board, etc. Check that there is no water in the bilge.
− Fastening of equipment
Check that all onboard items are positioned so that they are held in place also during
rough seas and high winds. Please note that the seat cushions may fly over board if they
are not fixed properly with press studs.
− Nautical charts
If you are not navigating in completely familiar waters, ensure you have nautical charts
on board that cover a large enough area! If your boat is equipped with a chart plotter,
learn to use it before setting off. Ensure that the plotter charts are of the latest edition.
− Leaving the berth
Agree with the crew who will unfasten which mooring line, etc. Make sure that the
mooring lines will not get entangled with the propeller during maneuvering.
− Obligatory equipment
What is considered obligatory equipment varies from country to country. Find out what
is required for your boat.
You will find additional instructions concerning the engine in the separate engine manual.
4

1 General
The user manual will help you familiarise yourself with the properties and features, as well as the care and
maintenance of your new boat. Separate manuals for installed equipment are attached and are referred to in many
sections of the user manual. You can supplement this owner’s manual by adding the manuals of devices which are
installed afterwards. Space has been left for your own notes at the end of the manual.
The craft has a running serial number, a CIN-code (Craft Identification Number). The CIN code
can be found on the starboard side of the transom. We recommend that you write down the CIN-code in the
declaration of conformity in this book.
When contacting the dealer, please provide the CIN-code and the type of craft. This helps in delivering the correct
spare parts.
1.1 Declaration of conformity
5

6

7

8

2 Definitions
The warnings and cautions in this manual are defined as follows:
DANGER! Denotes an extreme intrinsic hazard exists, which would result in a high probability of death or
irreparable injury if proper precautions are not taken.
WARNING! Denotes a hazard which can result in injury or death if proper precautions are not taken.
NOTE! Denotes a reminder of safety practices or directs attention to unsafe practices, which could result in personal
injury or damage to the craft, its components or the environment.
SI system units are used in this manual. In some cases other units have been added in brackets. An exception is
wind speed, for which the Beaufort scale is used in the recreational craft directive.
3 Warranty
AXA d.o.o. Limited Warranty Certificate
AXA d.o.o. undertake a PDI (pre-delivery inspection) on all new boats before shipment from factory. AXA will provide for repairs
to their inflatable boats during the specific warranty periods provided herein, in accordance with the following terms,conditions
and limitations.
Warranty coverage:
AXA warrants to the original private purchaser of a properly registered craft that: a) All seams of the tubes, inflation valves, and
the fabric used in the construction of the tube shall be free from defects in material and workmanship for a period of 3 years
from the date of the original registration; b) The fabric of the tube shall be free from deterioration affecting serviceability (i.e.
cracking, porosity, but not discoloration, fading or chaffing) for a period of 3 years from the date of the original registration; c
) the fiberglass hull shall be free from defects in material and workmanship for a period of 2 years from the date of the original
registration; d) all components fitted to the boat at the AXA factory or subsequently replaced under warranty shall be free from
defects in material and workmanship for a period of 2 years from the date of the original registration. The warranty period for
commercial use owners will be 4 months from the date of original registration. The obligation of AXA under this Limited
Warranty is limited to repairing or replacing, as AXA may elect at its sole discretion, any parts that prove, in AXA’ sole
judgement, to be defective in material or workmanship.
THIS LIMITED WARRANTY SHALL BE THE ORIGINAL PURCHASER’S SOLE AND EXCLUSIVE REMEDY.
What is not covered:
This Limited Warranty shall not apply to: a) normal wear and tear; b) any minor boat damage, including but not limited to, gel
coat crazing, fading or blistering; c) any damage to AXA boats due to negligence, accident, misuse, lteration, improper
operation, collision, fire, theft, vandalism, riot, explosion, objects striking the boat, improper maintenance and storage; d) any
damage caused by towing a AXAboat, any damage caused by lifting or recovering a AXA boat; e) tubes exposed to harsh or
corrosive chemicals; f) any parts installed by anyone other than AXA factory personnel; g) any damage caused by after-market
parts; h) AXA boats purchased for commercial/governmental use; i) any work carried out on a boat by an unauthorized
service center and/or without AXA’ prior approval; j) labor, freight, delivery, storage or other similar charges; k) defects caused
Or worsened by failure to adhere to the instructions concerning the treatment, maintenance and care of the boat; l) Damage
caused by water ingestion. AXA reserves the right to make warranty coverage contingent upon proof of proper maintenance.
How to obtain Warranty repair:
Prior to any work being commenced on a AXA boat, the warranty claim must be approved in writing by AXA d.o.o. In order to
obtain warranty repair approval, the original owner must send written notification, along with a copy of the bill of sale, and
photograph depicting the damage and/or defect sought to be repaired to AXA d.o.o., Preradoviceva 4, 47000 Karlovac, Croatia.
If AXA finds that the specific defect and/or damage is covered under this Limited Warranty, AXA will advise the owner in writing
where to send (via pre-paid freight) the boat or part(s) for repair or replacement. In many cases the local authorized Sales and
Service Centre may be utilized for repairs. In others the boat or parts must be repaired by AXA personnel only. AXA does not
assume any liability for any work performed on a AXA boat at an unauthorized Service Centre and/or without AXA’ prior
approval. All parts replaced under this Limited warranty become the property of AXA.
9

Miscellaneous:
AXA does not authorise any person to create for it any other obligation or liability in connection with its boats. THIS
LIMITED WARRANTY AND AXA’ OBLIGATION HEREUNDER IS IN LIEU OF ALL WARRANTIES EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. AXA will not be liable for any incidental or consequential damages resulting from breach of this limited
warranty, including without limitation, loss of inflatable boat use, storage, payment for loss of time, inconvenience
, boat rental expense, and local taxes required on warranty repairs. AXA reserves the right to alter models, change
colors, specifications, materials, equipment, component parts, prices or cease production of certain models at any
time without prior notice, and such changes, alterations, or cessation shall be made without AXA incurring any
obligations to equip or modify inflatable boats produced prior to the date of such changes or alterations. This
Limited Warranty shall be governed by and construed and enforced in accordance with Croatian Law.
4 Before use
4.1 Registration
Registration regulations vary from country to country.
4.2 Insurance
Boat insurance can compensate damage occurring on water or during transport and lifting.
Check who has insurance liability each time when having the boat lifted. Insurance also has
an indirect effect on safety at sea: In the event of a serious accident or damage, you must,
above all, concentrate on saving people. Insurance companies will be able to give more
information about different insurance alternatives. Check who has insurance liability each
time when having the boat lifted or transported!
4.3 Training
No one is a born sailor.
Navigation courses are arranged by local yacht clubs or national boating associations where
you can gain basic skills.
However, please remember that you only become confident in boat handling, navigation,
docking and anchoring after long practical experience.
10

5 Characteristics and use of your boat
5.1 General
This user manual is not meant to be a complete service or repair manual, but to guide the user in using his/her boat
in a proper way.
5.2 Basic data
Recreational crafts can be constructed according to 4 categories (A, B, C and D) according to recreational craft
directive 94/25/EC. This boat has been constructed according to design category C, which denotes the following:
The boat is built for conditions where the wind reaches a maximum of 6 Beaufort (approx. 14 m/s) and
corresponding seas (significant wave height at most 2 meters). Such conditions may be encountered on exposed
Inland waters, in estuaries, and in coastal waters in moderate weather conditions.
Significant wave height is the mean height of the highest third of the waves, which approximately corresponds to
the wave height as estimated by an experienced observer. Individual waves may reach up to twice this height. If
the significant wave height is 2.0 m, the mean height of all waves is roughly 1.2 m.
Maximum recommended load: See technical specification.
Please also refer to section 5.4, ”Loading”.
Main dimensions and capacities: See technical specification.
Craft length, width, draught, total weight etc., as well as tank capacities are shown in the technical specifications.
Builder's plate:
Part of the previously mentioned information is given on the builder's plate, which is affixed below seats.
Supplementary information is provided in the appropriate sections of this manual.
General Specifications
JETTENDER 250
LOA 2.49m
Beam 1.62m
Dry weight 98 Kg-Hypalon tubes, 93 kg PVC tubes
Height 0,62m
Max speed 20,5 mph/33 kmh
Power 9,5hp*
Fuel capacity 8 litars
Seating 3
Max. payload 240 kg
Design category (CE) C
11

Engine Specifications
Engine AQUANAMI
Maximum power 9,5hp @ 6300rpm
Fuel : Recommended fuel quality: Unleaded gasoline (super) with an octane rating of at least 95 ROZ or 85 MOZ.
USA: At least “Premium 91”, unleaded
Minimum requirement: Low-quality fuel can cause loss of power and/or increased fuel consumption.
Unleaded gasoline with an octane rating of at least 91 ROZ or 82.5 MOZ.
USA: At least “Regular 87”, unleaded
An increased share of ethanol can lead to premature abrasion and poor starting performance of the engine.
Oil grade 20W40 fully synthetic, four stroke
5.3 Maximum recommended number of passengers
The boat's maximum recommended number of passengers isthree persons.
WARNING! Do not exceed the maximum recommended number ofpassengers. Regardless of the number of
passengers, the total weight of people and equipment must never exceed the maximum recommended load (please
refer to “Loading”). All persons on board must remain seated while the boat is moving.
5.4 Loading
The boat's maximum permitted load is 240 kg. This load includes the following weights:
a) The total weight of passengers 225 kg (the default weight of an adult is assumed to be 75 kg and that of a child
37.5 kg).
c) And liquids (fuel) in fixed tanks and cargo is 15 kg.
NOTE! The maximum load only includes the above-mentioned weight components.
WARNING! Never exceed the maximum recommended load when loadingthe craft. Always load the craft carefully
and distribute loads appropriately so that the boat is on an even keel. Always avoid placing heavy items high up.
5.5 Prevention of water incursion and stability
5.5.1 Hull and deck through fittings
The boat has a rainwater draining system, which means that rainwater is drained from theundecked part of the
boat when the boat is on the water. The system also functions whenthe boat is out of water, provided that the bow
is higher than the stern.
NOTE! Make sure that water can flow unobstructed through thedrainpipe. Debris like autumn leaves may obstruct
the water flow, which can cause the boat to fill with water and sink.
NOTE! There is always some amount of condensed water in the bilge. Asmall amount of water may also come
through the hull bushings, especially as the boat ages. Always remember to check the bilge, before you leave the
boat at quay or buoy and always before setting off.
WARNING! The boat's handling properties may become extremely dangerousif there is water in the bilge.
12

5.5.2 Stability and buoyancy
Please note that the boat's stability is reduced by any weight added high up on the boat. Any change in the
distribution of weight on board may significantly affect the stability, trim andperformance of your craft. Please
remember that large breaking waves always present a serious danger to stability.
The amount of water in the bilge must be kept as low as possible.
The boat's stability may be impaired during towing, or when passengers are lifting heavy items.
The boat will carry its passengers also when filled with water.
5.6 Avoiding the risk of fire or explosion
5.6.1 Refuelling
Shut off the engine and extinguish any cigarettes before starting to refuel. During refuelling do not use switches or
appliances that can cause a spark.
Do not stow any loose items under the seat that, if moved, could prevent fuel flow to the engine. This is particularly
important for items that may press against hoses or the fuel filter.
Check annually that the fuel hoses are not worn, especially at lead-ins.
Please note that depending on the trim of the boat or the boat's heeling angle, it might not be possible to use the
full capacity of the tank.
WARNING! Gasified fuel is highly explosive. Observe these instructions and the utmost caution during refuelling.
The smell of fuel always means that there is gasified fuel on your boat
Remember:
Never make changes to any of the boat’s systems (especially the electricity or the fuel systems) or allow an
unqualified person to make changes to any of the boat’s systems.
Never smoke while handling petrol or gas.
NOTE! Always keep the bilge clean and regularly check for possible fuel leaks.
13

5.7 General Arrangement
1. Splash proof storage (below seat)
2. Mooring cleat
2. And 3 Lifting points
4. Fuel filler (under storage cover)
5. Throttle/shift control
6. Big splash proof storage
7. Certification plate
8. Drain plug
9. Tube inflation valves
10. Hull Identification Number (HIN)
11. Engine flushing attachment
12. Start switch
13. Stop switch
14.Throtle
15.Safety lanyard / switch
12
2
3
4
5
6
789
10
11
5
12
13
14
15
14

6. Operating Your Tender
This boat uses a water-jet propulsion system and has unique characteristics in steering. The throttle produces thrust
from the jet pump, the directional control is provided by opening the throttle and turning the joystick in the
direction of your turn. High thrust will turn the boat sharply; low thrust will produce less turning force. There is no
rudder, so while underway there is no steering without thrust.
If weed or debris gets caught in the jet unit during use cavitation can occur causing a decrease in forward thrust. If
this condition is allowed to continue the engine may overheat resulting in serious damage. If there is any sign of
debris or weeds etc. blocking the jet, remove the boat from the water.
Remouve kill switch and remove all debris from around the jet unit. DO NOT make repeated attempts to start a
blocked or jammed tender as engine damage may result. In case of difficulty consult your AXA authorized dealer.
Recovery
CAUTION. Do not attempt to lift or recover the tender by the transom. Any stern-up angle will cause water
to enter the engine from exhaust system and will result in serious engine damage.
Mooring
CAUTION. Do not leave the JetTENDER moored for extended periods as this may result in an accumulation
of marine growth and a loss of performance.
Beaching
CAUTION. DO NOT operate in less than 0.6m/2ft of water as debris may enter the jet unit. DO NOT drive
JetTENDER onto beach. Stop engine before beaching as damage to pump/engine cooling may occur.
After beaching, move boat into deeper water and rock from side to side several times to remove sand from intake
area –failure to do so could cause damage to jet unit.
Trim
CAUTION. Do not overload the boat. At all speeds be aware of trim and keep weight evenly distributed.
General
CAUTION. Operate the boat with due care and at a speed appropriate to the sea conditions. Be aware of
local laws and restrictions. Always carry out a visual check of the boat and its components prior to use.
Adhere to the maintenance schedule.
WARNING. Manoeuvrability is restricted while decelerating. Familiarize yourself with the boat’s handling.
New Engine Break-in Period
Aquanami recommends that during the first five hours of operation, you should not operate the engine over 5,000
RPM. This protective running-in has a positive effect on the engine‘s lifespan.
15

6.1 Fuelling
•As part of its pre-delivery inspection your new JetTENDER has been fully tested and drained of fuel.
•Ensure kill switch is remouved.
•Open back storage compartment to expose filler cap.
•Re-fuel in a ventilated area.
•Do not overfill the tank; be careful not to spill fuel.
•Tighten fuel cap securely after re-fuelling.
•Open engine hatch and inspect bilges after re-fuelling.
Do NOT hose around the fuel filler area as water may enter the fuel tank.
IMPORTANT! Do not use fuel from fuel pumps labeled E85.
Use of fuel labeled E15 is prohibited by U.S EPA Regulations.
Fuel containing Ethanol can result in problems in the fuel system and engine, resulting in:
•Starting and operating difficulties.
•Deterioration of rubber or plastic parts.
•Corrosion of metal parts.
•Damage to internal engine parts.
6.2 Before Use
Tube pressure will fluctuate with temperature. Inflate tubes in sequence to 250mB/3.6psi. Failure to observe this
will compromise the sea-keeping ability and watertight integrity of the boat. Inflation valves are fitted with quarter-
turn locks to enable rapid deflation.
CAUTION. Tubes must be inflated in the correct sequence to prevent over-inflation.
•Set valves to shut and inflate tubes evenly
•Check bilge for fuel or water contamination.
•Tighten drain plugs.
•Check engine cover latches are secure
6.3 Safety Check!
WARNING. ALWAYS attach yourself to the safety lanyard when engine is running. Before setting off as a
precautionary measure always test lanyard for its functionality by pulling away from its seating –engine
should always stop.
WARNING. NEVER investigate engine bay with engine running or ignition on.
16

6.4 Starting Your JetTENDER
Ensure boat is in a depth of at least 0.6m/2ft of water.
Secure any loose ropes that could get sucked into jet unit.
Connect safety lanyard to switch.
WARNING. Personal injury may result if not attached.
Press START button until engine starts.
Test safety lanyard for correct functionality (see Safety Check!).
6.5 SAFETY LANYARD:
Always disconnect safety lanyard when watercraft is not in operation in order to prevent accidental engine starting
or to avoid unauthorized use by children or others or theft.
NOTE: Leaving the safety lanyard on its post when engine is not running will slowly discharge the battery.
6.6 Oil Level Check
The engine must be at operating temperature before an accurate level is indicated on the dipstick.
The oil level should be between MIN and MAX on the dipstick. Do not screw in cap to check level. Use the correct
grade of oil –recommended 20W40 fully synthetic.
Do not overfill
•The engine has 2 liter oil reservoir. However, your engine may already have some oil left over from the
factory testing. Adds oil slowly and use the oil level stick to check the oil level. Use a tower to wipe the stick
for better reading.
•Air may be trapped inside the hose and engine chamber. Please run the engine for 15 seconds and stop
engine, check the engine oil level again. To make sure you engine has right amount oil.
•Check the engine oil level each time before you use your boat. The engine oil evaporates fast because the
engine is running at high RPM all the time
ATTENTION:
•The engine will be burned and permanently damaged if the right engine oil level is not maintained
6.7 ENGINE COOLANT :
•Check engine coolant each time before use. Make sure the engine coolant is full.
•The engine coolant evaporates fast because the engine is running at high RPM all the time.
ATTENTION:
•The engine will be burned and permanently damaged if the engine coolant is not filled fully.
6.8 DRY ENGINE COMPARTMENT:
•During over-night and storage time, leave engine compartment cover open to prevent moisture
condensation and keep engine compartment dry.
17

1
43
6
5
2
Engine bay Arrangement
1. Closed loop coolant reservoir
2 .Oil check dipstick
3. Fuel filter/separator
4. Battery
5. Cylinder
6. Electronic box
After Use: Flushing Procedure
To prolong engine life it is very important to flush engine of salt water after use and prior to storage. Failure to carry
out flushing will significantly reduce the life of engine components and may invalidate warranty. DO NOT operate
throttle out of water.
In addition it is advised to thoroughly wash with fresh water around the jet pump area to remove all salt deposits
after use.
CAUTION. Engine MUST be running before water is connected. Risk of engine flooding exists if water remains
on after engine is switched off.
1. Connect a fresh water hose fitted with the male connector supplied with the tender to the flushing attachment
coupling fitted to the tender. Press outer ring to engage and release adaptor.
2. Start engine and immediately turn on water supply.
3. Run engine at idle for approximately 1 minute to completely flush the open loop cooling system.
4. Turn off water supply.
5. Allow the engine to run for no longer than 10 seconds to allow water to exit from the cooling system, then turn off
the engine. Remove hose connector from flushing attachment.
6. Check bilge of boat and dry any residual water.
12
3
45
1. Flushing attachment
2. Bilge pump outlet
3. Open loop coolant overflow
4. Footwell drain
5. Engine compartment drain
6. Ride plate anode
6
18

6.11 Fuel System Check
WARNING. Pressurised fuel system. Inspect system for leaks at scheduled service intervals. All elements of
the fuel system function under pressure (4 bar). The system remains pressurised after engine is switched
off. Extreme care must be taken when removing connectors during filter change. Wear eye protection. No
naked flames.
6.12 Routine Maintenance
To ensure long service life and to maintain the tender in a safe and reliable condition please follow these routine
maintenance instructions. AXA cannot accept any responsibility for damage or injury resulting from incorrect
maintenance or improper adjustment carried out by the owner.
1.Wash tender regularly with fresh water to remove salt deposits.
2. Check engine oil level (refer to section Oil Level Check in this handbook).
3.Check coolant level.
4. Flush open loop cooling system.
5. Apply a good quality marine grease containing Teflon (e.g. Quicksilver 101) to all control cables both under the
helm and at the pump.
6. Check bilges for water ingress, oil or fuel contamination and clean if necessary.
7. Lightly grease the extending running light pole base using white grease or similar.
8. Check condition of the anodes.
9.Loss of tube pressure over 24 hours is not unusual. Temperature and atmospheric pressure will affect tube
pressures. Check pressures regularly.
10. For boats used in tropical environments, the frequency of the routine maintenance should be increased
accordingly.
6.13 Servicing
Refer to Product Maintenance Chart
For parts and accessories please contact your AXA authorized dealer
19

7 PRE-OPERATION CHECK LIST
ITEM TO DO
Start and Stop buttons Check operation.
Safety Lanyard Check operation.
Throttle Check operation.
Steering system Check operation.
Armpole Check operation.
Exhaust pipe cooling Check by-pass outlet. Water mist/drops should come
out exhaust by-pass outlet.
Bilge plugs Ensure plugs are secured.
Exhaust flush Check for steady flow when engine is running
Battery Inspect cables and retaining fasteners. Ensure good
condition and fully charged.
Fuel tank Check/refill.
Engine compartment
Check if any water exists.
Check if any signs of water leak.
Check fuel line connections for tightness.
Verify for any fuel leak/odoras well as oil and coolant
leaks.
Check any loosen parts.
Engine oil level Check/refill.
Engine coolant Check/refill.
Carburetor
Periodically drain water or contaminated fuel from the
carburetor bowl by loosening the carburetor drain
screw. Use a cup to collect the drained liquids. Ensure
the drain screw closed after cleaning.
Fuel water separator bottle Periodically drain water or contaminated fuel from the
bottle.
Engine breathing oil retainer Periodically drain the engine breathing oil retainer bottle
to clean oil/water residue.
Jet pump water intake Inspect/clean.
Jet pump water intake seal Inspect any damage or leak.
Hull Inspect.
Dry storage compartment covers Ensure they are closed and properly sealed.
20
