AXA MX-100 User manual

®
®
STUDIO CONDENSER MICROPHONE
WITH DESKTOP TRIPOD STAND
MX-100
PACKAGE INCLUDES
1.75”
6.25”
3.25”
7.25”
5”
3.75”
• The MX-100 condenser microphone provides smooth, extended
frequency response and is excellent for studio quality vocals, speech
and acoustic instruments.
• The MX-100’s Uni-Directional, Cardioid Polar Pattern delivers
high-sensitivity, low-noise and a wide dynamic output.
• A Professional Suspension Shockmount isolates the studio condenser
mic reducing physical vibrations from the mic stand or desktop surface;
It also features an angle adjustment with locking knob.
• Portable, Foldable, Stable and Non-slip Tripod Stand
- Made of stainless steel with 3/8” threaded mount and 5/8” adapter;
non-slip rubberized feet and folding legs.
• The MX100 requires & is compatible with +48 Volt phantom powered
audio mixers & Audio interfaces for your computer.
Features
• Type: Condenser
• Pickup: Cardioid Uni-Directional
• Frequency Response: 30Hz ~ 20kHz
• Sensitivity: -38dB (±2dB)(0dB=1V/Pa
@1kHz)
• Output Impedance: 250 ohms,
(±30%)@1kHz
• Dynamic Range: 140dB
• ENL: 18dB A
• Max. Sound Pressure:
15dB (@1kHz ≥≤ 1% T.H.D.)
• S/N: 76dB
• Requires +48 Volt Phantom Power
• Power Consumption: 3Ma/hr
• Weight: 0.77Lbs (350g)
Specifications
CONDENSER MICROPHONE
SHOCKMOUNT BALL TYPE
TRIPOD DESKTOP
MIC STAND
(WITH HEIGHT ADJUSTMENT)
MICROPHONE
WIND SCREENXLR 3-PIN MICROPHONE CABLE (10FT)
Speak or sing
into the front of
the mic for the best
sound quality.
The frontside is the
AXA logo side.
*Requires +48 Volt Phantom Power

AXCESSABLES HEALTH, SAFETY, AND COMPLIANCE GUIDE
Safety Warnings and Instructions
Electrical information warning symbols for AxcessAbles products are located on the electrical panel of the unit
adjacent to the electrical plug or bottom of the unit along with other product compliance information.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) AS THERE
ARE NO USER-SERVICABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
The exclamation point with arrowhead symbol within an equilateral triangle is intended to alert the user to
the presence of non-insulated “dangerous volatage” within the product’s enclosure that may be sufficient
magnitude to constitute and electric shock.
CAUTION: To reduce the risk of electrical shock, do not expose this device to rain and
moisture. Do not expose this device to dripping or splashing liquids, such as vases, should be
placed on the device.
CAUTION: This service instructions are for use by qualified personnel only. To reduce the risk
of electric shock, do not perform any servicing other than that contained in the operating
instructions. Qualified service personnel must perform repairs.
Radio and Television Interference
If these symbols are marked on the product, the device complies as follows:
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
USA: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not
installed in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Thisequipment should be installed and operated with minimum distance 20cm between the radiator& your
body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
CAUTION: Changes or modifications to this device not expressly approved by AxcessAbles Electronics could
void the user’s authority to operate the equipment under FCC rules.
CALIFORNIA PROP65 WARNING:
Warning: This product contains chemicals, including lead, known to the State of California to cause cancer
and birth defects or other reproductive harm. Wash hands after handling.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous volatage” within the product’s enclosure that may be sufficient
magnitude to constitute and electric shock.
EASY TO ASSEMBLE
ANY QUESTIONS? VISIT US AT AXCESSABLES.COM
®
®
STUDIO CONDENSER MICROPHONE
WITH DESKTOP TRIPOD STAND
PINCH CLAMPS
TO INSERT MIC
C
LA
SCREW SHOCKMOUNT
INTO THE TRIPOD STAND
INSERT MICROPHONE HALFWAY
INTO THE SHOCKMOUNT
AUDIO MIXER
AUDIO
INTERFACE
3-PIN TIP
XLR TIP
CONNECT TO
AUDIO INTERFACE
OR AUDIO MIXER
*Requires +48 Volt Phantom Power
