AXEM Technology AT-07 User manual

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
1/46
AT-07 tablet
User guide

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
2/46
Table des matières
1Introduction..............................................................................................................................4
2Summary and System Structure ..............................................................................................5
2.1 Summary..........................................................................................................................5
2.2 Checking the package ......................................................................................................5
2.3 Safety Warning and Attentions..........................................................................................7
2.4 General Operation Standards and Attentions....................................................................8
2.4.1 Operation Standards..................................................................................................8
2.4.2 Attentions...................................................................................................................8
2.5 Structure and functions.....................................................................................................9
2.6 Instructions of Fixed Icon Display Area......................................................................15
2.7 Charging Battery Icon.....................................................................................................16
2.8 Install TF Card and SIM Card .........................................................................................16
2.9 Battery Usage.................................................................................................................16
2.9.1 Charging..................................................................................................................17
2.9.2 Charging time..........................................................................................................17
2.10 Main specification of the equipment................................................................................18
3Specifications and functions...................................................................................................18
3.1 Technical Specifications..............................................................................................18
3.1.1 RFID High Frequency Index (Optional)....................................................................18
3.1.2 1D Infrared Scanner Index (Optional) ......................................................................18
3.1.3 1D Laser Scanner Index (Optional)..........................................................................19
3.1.4 2D Infrared Light Scanner Index (Optional)..............................................................19
3.1.5 RFID Low Frequency Index (Optional).....................................................................19
3.1.6 RFID Ultrahigh Frequency Index(Optional)..............................................................19
3.2 General Functions ..........................................................................................................19
3.2.1 On/Off......................................................................................................................19
3.2.2 Standby and Wake up..............................................................................................20
3.2.3 Table Management..................................................................................................20
3.2.4 Open / Close Net Card (Connect OTG Cable).........................................................23
3.2.5 PPPoE Dial(Connect OTG Cable) ...........................................................................24
3.2.6 Input Method............................................................................................................24
3.2.7 Flashlight.................................................................................................................25

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
3/46
3.2.8 Camera....................................................................................................................26
3.2.9 Breathing Indicator...................................................................................................26
3.2.10 Headset...................................................................................................................26
3.2.11 Vibration ..................................................................................................................27
3.2.12 WIFI Hotspot............................................................................................................27
3.2.13 USB-OTG Function (Connect OTG Cable) ..............................................................29
3.2.14 Compass Function...................................................................................................29
4Usage of Main functions.........................................................................................................30
4.1 RFID HF (High Frequency) Card identification ...........................................................30
4.2 Barcode Scan Helper......................................................................................................32
4.3 RFID LF Card Identification..........................................................................................33
4.4 RFID HF (High Frequency) Card Identification................................................................35
4.5 Infrared meter reading..................................................................................................42
4.6 Control of the Electric Quality and Wireless Dial .......................................................42
4.7 Web................................................................................................................................44
5Usage and maintenance........................................................................................................45
6Faults and Solutions ..............................................................................................................46

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
4/46
1Introduction
This user manual includes module introduction, maintenance, wiring and operation as well as the
solutions to module problems. In order to guarantee the proper operation of this tablet PC, please
read this manual in detail before using; keep the manual in a safe and convenient place for quick
response when problems appear.
Note:
Due to the continuous improvement and refinement of the industrial tablet PC, please kindly forgive
us not to inform you of the modified manual.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
5/46
2Summary and System Structure
2.1 Summary
This tablet PC is portable and digital data acquisition equipment with the functions of 1D /2D bar-
code scanning, RFID label, Infrared meter reading, GPS positioning and smart phone function. It can
be widely used in the area of fashion industrial, industrial manufacturing, logistics management,
assets management and routing inspection, etc.
This tablet PC has the wireless voice and communication module, which can log on the Internet
through wireless network, and help you finish the work more quickly. According to different module,
user can acquire theinformation of1D bar-code, 2D bar-code, and RFID information, and at the same
time, transfer the information through LAN, GPRS, 3G,4G, WIFI, Bluetooth, and such wireless more
quickly and efficiently. This portable, one hand operation terminal meets IP-67 protection grade; it
can be used under any environment; it can help simplify the working process, improve working
efficiency, and reduce the business operating cost.
This tablet PC adopts 1280*800 capacitance touch screen, and embeddedwith Android 4.4operating
system. With the features of user friendly, easy to operation, visual AT-07 Industrial Tablet PC
scanning and recognizing result, it can meet your different needs, and transfer the data at real time,
as well as improve your working efficiency. It is really your powerful working assist.
2.2 Checking the package
Please open the packing box to make sure the accessories are correct before operation. Once there
are some incorrect items or any need of optional accessories, please contact with us.
Essential Components:
According to the following table, please check the model name and suffix code of the name plate on
the back of the tablet.
Function modules of Tablet PC:

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
6/46
Please make sure all the following accessories are in good condition:

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
7/46
Other optional Accessories:
(Users can choose according to different modules.)
2.3 Safety Warning and Attentions
•Please use the provided charger
•In order to use the tester safely and efficiently, please read the following information before
using.
•Please use the tester according to the rules when you in the hospital.
•Please keep far away from the precision instrument
•Do not use chemical solvent to clean the equipment.
•Do not throw away the waste battery. Put it into the battery recycling bins.
•Please do not use or store the equipment as well as its accessories under the environment
of high temperature, low temperature, high humidity or dust.
•Please put the equipment and its battery in a safety place and avoid strong shake and impact.
•When use the equipment for the first time, please charge the battery completely.
•Don't disassemble the equipment by yourself. If you need, please go to the appointed
professional organization to mend it.
•Please put the equipment and its accessories in the place out of children’s reach.
•Please take care of the UIM card and avoid static, scratch, as well as bending.
•Please use the original accessories of the product.
•Please use the standard battery, charger and other accessories. We will not be responsible
for anything if you use the accessories from the third party.
•Same as other mobile equipment, with built-in antenna on the bottom of the product, there is
some radiation and interface of this product. If you want to operate the product in light-
hearted, as well as take of your personal safety, any part of your body do not too close to the
antenna.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
8/46
•Please use the equipment within network coverage range.
•The LCD display effect will change a little in the temperature severely
2.4 General Operation Standards and Attentions
2.4.1 Operation Standards
•USB port
Please do not short the port with metal; otherwise the internal circuit will be damaged.
•Cleaning
The shell of this instrument is mainly made of plastic, when AT-07 Industrial Tablet PC
•Protecting the case and operating panel
Do not pour volatile agents on the case or operation panel, and avoid prolonged contacting with
rubber and PVC; otherwise, it may result malfunctioning.
•When moving the instrument
Please make sure the power cord and connection cables are removed before shift the instrument.
And unplug all the connecting cables from socket after using.
•When the instrument is unused for a long time
If the instrument is unused for a long time, the battery characteristics may have deteriorated. And it
will also take a longer time to charger. If it takes a very short time to charger and the operating time
is extremely short, please replace the battery.
•Faults
If there is strange sound, smell, or smock coming from the instrument, please turn off the instrument
and unplug of the power, and then contact with us immediately.
2.4.2 Attentions
•Please charge the battery full when using it for the first time as well as each time.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
9/46
•Please use touch pen and click the screen gently to operate function keys, do not click it
roughly, otherwise, the LCD may be damaged.
•If there is any abnormal phenomenon during the process of operating, please turn off and restart
it.
•Please don’t put the instrument under the strong direct sunlight or put it near the origin of heat.
Or else, there will be bad effect to internal circuit as well as the shell.
•Condensation may occur if the instrument is moved to another place where the temperature is
higher or the room temperature change rapidly. In such situation, let the instrument adjust to the
new environment for at least one hour before using the instrument.
•Using the instrument near strong magnetic field sources will have adverse affects on the internal
circuit of the instrument. That because the electromagnetic wave from the mobile may effect the
normal identification. If you are using a portable phone to transmit measured data, move the
portable phone at least 1m away from the instrument.
2.5 Structure and functions

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
10/46

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
11/46

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
12/46
Name
Functions
1
Seal Cover
Protect the tablet from dust and water.
2
Screan
Display
3
Function Button
Set functions of the program.
4
Main Menu Button
Quickly go main page main page.
5
Return Button
Back to last operation
6
F2 Button
Scan test
7
MIC
MIC
8
Indicator
To indicate the device status
9
Front Camera
Take pictures
10
Motor
Motor
11
Loudspeaker
Loudspeaker
12
Jacket Connector
To connect with the jacket
13
HF RFID Scanning Area
HF RFID scanning area
14
Rear Camera
Take pictures and video
15
Flashlight
Flashlight
16
Fingerprint Reader
Fingerprint Reader
17
SIM Card Slot
To take SIM Card
18
TF Card Slot
To take TF Card
19
Charging Hole
For charging
20
USB Port
USB Port
21
Earphone Hole
To connect with earphone
22
Power Button
Power Button
23
Reset Button
Reset Button
24
Barcode Scanner
Barcode Scanner
25
Volume Button -
Volume Button -
26
Volume Button +
Volume Button +
27
Scan window of ultra-high
frequency scanning area
It is used for scanning ultra-high frequency card.
28
Stents
Fixed the tablet
29
2D Laser Barcode Scanner
Barcode Scanner
30
Infrared Window
Copy meter data
Buttons
Buttons
Name
Functions
Power button
Under power-on state, shortly pressing the button can close or
light the screen; long pressing the button can pop up an
operating menu of "Phone Options". Under power-on state, long
pressing the button can close the tester.
Return button
Return back to the previous page.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
13/46
Main screen button
Pressing this button to return back to the main screen window.
Reset button
Long press 5 seconds to reset the device
Volume adjust button
Can adjust the volume for calling and make the loud speaker
louder.
Volume adjust button
Can adjust the volume for calling and make the loudspeaker
lower.
Extension Button
Customized button
Attribute Button
Edit menu attribute
BarCodeScanButton
Shortly pressing the button can start to scan the bar code.
Indicator lights:
The meaning of the 2 indicator lights from left to right is as following:
Indicator light 1: Equipment light, indicating the equipment state, which have 3 glittering state.
1) Normal state: 0.5s on, 4.5s off
2) Incoming call state: 0.5s on, 0.5s off
3) Receive the message or missed call: 0.5s on, 1.5s
Indicator light 2: Unused

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
14/46
Standby shortcut icon is as following:
: Click to enter into main menu interface.
: Click to enter into dialing plate interface.
: Click to enter into message interface.
: Click to enter into browser interface.
: Click to enter into contacts

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
15/46
2.6 Instructions of Fixed Icon Display Area

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
16/46
2.7 Charging Battery Icon
: The battery is in low power and needs to charge.
: The battery is charging and displays in motion.
: The battery has already been full.
2.8 Install TF Card and SIM Card
Open the closures on the top of the device, find TF card slot and adjust the TF card gap to be at the
bottom left. Insert TF card into the slot, you hear a click sound, the other end of TF card will flush
with the slot.
Open the closures on the top of the device, find SIM card slot and adjust the SIM card gap to be at
the bottom left. Insert SIM card into the slot, you hear a click sound, the other end of SIM card will
flush with the slot.
Take TF card, open the closures on the top of the device, press the TF card slot direction, TF card pops
up, remove the TF card.
Take SIM card, open the closures on the top of the device, press the SIM card slot direction, SIM card
pops up, remove the SIM card.
2.9 Battery Usage
The standby time will be affected by system environment, system setting, service test, taking photos
and using data service.
Calling or opening a backlight will consume more power than standby and standby time will shorten.
The standby time of no service area will be short than the normal standby time.
The battery performance will change with the charging status, temperature, local network as well as
the background light status.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
17/46
More accurate time will depend on the local network status, using conditions and equipment card.
2.9.1 Charging
This equipment can only be charged by power adapter and the USB port can’t be used to charge
the equipment.
Insert the charger into the power socket with 100~240V, 50/60Hz. When it is charging, the battery
power icon on the screen will shine; after charging finished, the battery power icon on the screen will
stop shining.
After charging finished, pull the charger out of the equipment and then pull the charger out of the
power socket.
Please use the provided charger.
2.9.2 Charging time
If the AC voltage is very low, you should charge the battery in a long time.
The charging time is about 6hours. (More accurate time will depend on the battery condition.)
The environment temperature of normally charging should be 0℃~40℃. Charging under below 0℃
or above 40℃, the battery performance will descend and the battery life will shorten. When charging
under too high or too low temperature for a long time, it will cause damage to the battery. For
example, the battery can't charge fully and cause the battery inflation.
It will lengthen the charging time to use nonstandard charger.
It will also lengthen the charging time to operate the tester when charging.
Note:
•You should fully charge the tester before the first usage; please disconnect the charger in
time after charging finished because the long-time charging will damage the battery
performance.
•When it is not charging, please take the charger from the outlet.
•When it is charging in very low battery, the tester will not start immediately and will display
low battery prompt if you do booting operation. After charging for a while, the tester will start
normally.
•Charger is safety device, please use our specialized charger. Meanwhile, please be careful
during the usage.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
18/46
2.10 Main specification of the equipment
•It adopts 7’’ 1280×800 capacitance touch screen
•It adopts the built-in Android 4.4JB operation system.
•Rechargeable 3.7V 7200mAh polymer battery and the max power is 3W.
•Host supports to make a phone call in earphone and listen to music. (needs earphone)
•Host supports 1D Infrared bar code scan
•Jacket supports 1D laser bar code scan
•Jacket supports 2D bar code scan
•Host supports LF RFID 134KHz (FDX)/134KHz (FDX/HDX)/125KHz
•Host supports HF RFID 13.56MHz
•Jacket supports UHF RFID 900MHz
•Jacket supports Infrared meter reading
•Camera with 8 million pixels and front camera with 2 million pixels; support auto focus and
flash function.
•Support flash light function
•Dimension: 208*140*20mm
•Weight: 620g (only host)
3Specifications and functions
3.1 Technical Specifications
3.1.1 RFID High Frequency Index (Optional)
•Working frequency:13.56MHZ
•Profile: Support ISO/IEC 15693, ISO/IEC 14443A profile
•Support Cards: SR176, SRIX4K (TYPE-B), I-Code2, TI RFID tag-it HF-I, EM4034, Mifare
Classic ETC
•Identification distance: more than 3cm
3.1.2 1D Infrared Scanner Index (Optional)
•Scanning mode: CCD
•Optical resolution: 5mil
•Scanning speed: 50 times/second
•Scanning distance: 5.7cm-60.96cm
•Scanning angle: 53.3° ± 3°
•Turning Angle from right to left: ±30°
•Turning Angle from front to back: ±65°
•Horizontal Angle: ±25°

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
19/46
3.1.3 1D Laser Scanner Index (Optional)
•Light source: visible laser diode
•Identification ability: 1D
•Scanning speed: 104 times/second+12 times/second
(two way scanning)
•Scanning distance: 2.5cm-114.3cm
•Scanning angle: 47±3°(default) /35±3°(reduced code)
3.1.4 2D Infrared Light Scanner Index (Optional)
•Identification ability: 1D, 2D, OCR
•Image sensor: 752*480 CMOS
•Scanning precision: ≥5 mil
•Scanning angle: rotate 360°, incline±50°, deflection ±50°
•Field of View: Horizontal 36°, vertical 23°
•Depth of field: 4cm-23.5cm
•Exercise tolerance ability: horizontal speed 12.7cm/s
•Light intensity: LED 350LUX(13cm)
•Environmental luminance: 0~100,000 LUX
3.1.5 RFID Low Frequency Index (Optional)
•Working frequency: 134KHz or 125KHz
•Operation mode: 134KHz supports full-duplex (FDX) communication , half-duplex (HDX)
communication
•Profile: Support ISO11784/5
•Support Cards: EM, TEMID, TK and compatible card
•Identification distance: 3cm (FDX)/5cm (HDX)
3.1.6 RFID Ultrahigh Frequency Index(Optional)
•Working frequency: 865-868MHz/920-925MHz
•Support agreement: EPC C1 GEN2/ISO 18000-6C
•Output power: 10dBm-30dBm
•Identification distance:
•920-925MHz50cm/200cm/350cm
•865-868MHz 150cm/300cm
3.2 General Functions
3.2.1 On/Off
Open the tester
Under the "off "condition and there is electricity in the battery, long press the power key to start the
equipment.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Fichier : AT-07 tablet user guide20190423_AT-
07_user_guide AT-07 tablet
Version : V1.0
20/46
Close the tester
Under standby interface and there is electricity in the battery, long press the power key to pop up an
option menu and then choose "Power Off" to close the tester.
3.2.2 Standby and Wake up
Under the "on" condition, the system will enter into standby state or shortly press on/off key to enter
into standby state. Under standby condition, shortly press on/off key to wake up the system. (The
time entering into standby is relevant with the backlight time setting in setup options. If the setting is
"Light Forever", the system will not standby automatically. But you still can realize the standby by
pressing on/off key.)
After waking up, the system will restore to the interface before the standby and the program will
restore to the state before the standby.
3.2.3 Table Management
There are five default pages of the table screen and it can display different screens by sliding with
finger.
Lock or Unlock
If there is no equipment operation, after some time the keypad will automatically locked. Press the
power button to wake up the screen, click the lock icon, you can slide in different directions
respectively, into different functional, as shown below:
In main menu "Settings> Display> Sleep" can set time delay before the device sleep.
