Reader VAKA A66 SOLO (offline)
Manual
Updated 11/20/2020

A66 SOLO (Off line)
Introduction A66 SOLO 3
Screw terminals 4
Commissioning A66 4
Commissioning of a SOLO-system 5
Maintenance/ administration of a SOLO-system 6
Synchronisation of all readers. 6
Programming 7
To be programmed in the master reader 7
To be programmed in each slave reader 7
Initialization of a new slave reader 8
Convert a slave reader to a master reader 8
Replacement of a slave reader 9
About MIFARE DESFire EV2 tags 9
2 (9) ManualA66 SOLO

Introduction A66 SOLO
Reader VAKA A66 and operation mode SOLO is available from version 3.00.
With Axema SOLO, an off-line system consisting of 20 doors can be deployed, fully without phys-
ical interconnecting cabling. One of the readers are set as Master and the other readers are set as
Slaves. The configuration of the master reader is distributed to the slave readers by MIFARE
DESFire EV2 credentials. Axema radio keys (RN18), MIFAREClassic, and EM credentials can
be used in a SOLO system, but not to distribute data.
In a SOLO system, access rights and time schedules (incl. daily open
and exit button) are identical for all readers. Codes can be con-
figured to be distributed in the slave readers or only work in the mas-
ter reader.
3 (9) ManualA66 SOLO

Screw terminals
Connector Function
1-2 AUX relay (NO/NC)
3-4 Supply voltage (12-35 VDC)
8-9 Exit button
8, 10 Door monitoring sensor
The 100 Ω resistor is only used in VAKA applications.
Door monitoring deactivates the unlocking as soon as the door is opened, even if the unlocking
time is longer. A closed door is to be indicated by a closed contact between the terminals.
Commissioning A66
1. Connect the power supply to the A66. (The display will not turn on automatically).
2. Press A and B simultaneously.
3. When the text Enter Programming Code appears, enter the code 112233.
4. Select language and press OK . (Default language is Swedish)
5. Set time and date
4 (9) ManualA66 SOLO

Commissioning of a SOLO-system
Commissioning of a SOLO-system requires a MIFARE DESFire EV2 card or tag. If data in the sys-
tem should be spread by the cards/tags of the users, the Master reader should be the reader
where most users passes.
1. Select the master reader.
2. If not already done, connect and commission the reader
3. Enter the programming mode of the selected master reader.
The programming mode is entered by pressing the programming button (the rightmost
round button) and entering of the programming code. (Default set to 112233).
4. Navigate to menu Options > Operating mode and select Master .
5. Return to main menu and navigate to tags menu. Select New tag and present a
MIFAREDESFire EV2 tag, from now referred to as programming tag. Select Yes if the
question to erase tag appears.
6. Perform configuration of tags, codes time schedules and so on.
7. Exit the programming mode
8. Present the Programming tag to the master reader until Hold tag disappears.
9. For all slave readers,
i. If not already done, connect and commission the reader
ii. Enter programming mode
iii. Navigate to menu Options > Operating mode and select Slave .
iv. Select Pair system .
v. Present the Programming tag to the reader until Hold tag disappears.
vi. Set time/date and active buttons for radio keys.
vii. Exit the programming mode
5 (9) ManualA66 SOLO

10. Until a plus (+) sign is shown in the right corner in the display of the master reader
i. Present the programming credential to the master reader.
ii. Present the programming credential to all slave readers
A plus sign (+) is shown in the upper right corner of the display when the master reader is
synchronized with every slave reader.
A plus sign (+) is shown in the upper right corner of the display when the master reader is syn-
chronized with every slave reader.
Maintenance/ administration of a SOLO-sys-
tem
If the system's users have DESFire EV2 fobs or cards, they will spread data from tha master
reader to the slave reader(s). To ensure that the database is quickly synchronized in all readers,
the slave readers can be updated manually. If the system has readers whose users do not also
pass the master reader, these readers must be updated manually.
If the system users do not have DESFire EV2 chips, all slave readers must be updated manually.
Synchronisation of all readers.
A programming tag is referred to the DESFIRE EV2 tag that was added to the system after initially
setting the master reader as master.
Until a plus (+) sign is shown in the right corner in the display of the master reader
i. Present the programming credential to the master reader.
ii. Present the programming credential to all slave readers
A plus sign (+) is shown in the upper right corner of the display when the master reader is syn-
chronized with every slave reader.
6 (9) ManualA66 SOLO

Programming
To be programmed in the master reader
lTime schedules
lUnlocking time (always 7 sec. in slave readers)
lCodes (distribution of codes can be inactivated, witch means that codes only works in the
master reader).
lDaily unlocked function
lExit button
lEM (on/off)
lProgramming code
lLanguage
lAutomatic daylight saving time adjustments
To be programmed in each slave reader
lTime/ date
lStandard/ reversed lock function
lPostal IR codes (Sweden only)
lActive buttons on radio keys
lback light
lSound
7 (9) ManualA66 SOLO

Initialization of a new slave reader
A programming tag is referred to the DESFIRE EV2 tag that was added to the system after initially
setting the master reader as master.
1. Connect and commission the reader.
2. If not already done, connect and commission the reader
3. Enter programming mode
4. Navigate to menu Options > Operating mode and select Slave .
5. Select Pair system .
6. Present the Programming tag to the reader until Hold tag disappears.
7. Set time/date and active buttons for radio keys.
8. Exit the programming mode
9. Follow the instructions in Maintenance/ administration of a SOLO-system
Convert a slave reader to a master reader
If the master reader needs to be replaced, any slave reader can be set as the new master reader.
1. Replace the master reader with a slave reader from the system.
2. Enter programming mode
The programming mode is entered by pressing the programming button (the rightmost
round button) and entering of the programming code. (Default set to 112233).
3. Navigate to Options menu -> System -> Operating mode and select Master .
4. Verify that the settings in the new master reader are correct.
5. Exit the programming mode
6. To replace a slave reader, see Driftsättning av ny slavenhet.
8 (9) ManualA66 SOLO

Replacement of a slave reader
1. Enter the programming mode of the slave reader to be replaced.
The programming mode is entered by pressing the programming button (the rightmost
round button) and entering of the programming code. (Default set to 112233).
2. Navigate to menu Options > System and select Show reader ID .
3. Exit the programming mode
4. Enter programming mode of the master reader.
5. Navigate to menu Options > System and select Uninstall reader .
6. Select the ID of the slave reader to be replaced.
7. Exit the programming mode
8. Follow the instructions in Initialization of a new slave reader
About MIFARE DESFire EV2 tags
A MIFARE DESFire EV2 tag can only exist in one SOLO system at a time. If a tag is added to
another system, the tag will stop working in the previous system. DESFire EV2-tags can also be
used in systems where information not is spread by the tag, even if the tags are active in a SOLO
system.
The table below shows capabilities for carrying information for different memory capacities of the
DESFire cards/tags.
Memory Capacity
2kB 9 tags
4kB 89 tags
8kB 210 tags
