Super-RFID SP-S100 User manual

SUPER-RFID 11/28/2006
Shanghai Super Electronic Technology Co. Ltd Phone: [phone]
Fax: [phone] E-Mail: [e-mail] website：http://www.superrfid.net
Page 1 of 6
SUPER-RFID
SP-S100 Hand held CF reader
User manual

SUPER-RFID 11/28/2006
Shanghai Super Electronic Technology Co. Ltd Phone: [phone]
Fax: [phone] E-Mail: [e-mail] website：http://www.superrfid.net
Page 2 of 6
1. SP-S100 Hand held CF reader brief
description
SP-S100 hand held reader/writer is the product of Shanghai Super electronic
technology Co. Ltd, the first RFID hand held PDA reader/writer communicating
with PC through CF interface in the whole world. It is microminiaturized, super light,
portable, extremely convenient and flexible. SP-S100 offers simple application
software to help customers get familiar with our products and do further
windows-based customized application development. Commonly, it is carried by
operator, finishing data collection for tags in certain area and simultaneously storing
collected data in PDA or transmitting to back-end via 802.11b/GPRS, or
automatically finishing data writing for tags in certain area under safety control. It is
capable of bidirectional and long distance communications with tags, able to
supervise hundreds of articles tag attached within range of 10 meters.
As important part of our systematic solution for RF identification, SP-S100 hand held
reader/writer fully demonstrated several advanced technologies of our unique
i-CollectedTM patent package, and integrated many other advanced technologies,
such as micro controller, RF technology, high speed data transmission, high capacity
data storage and imbedded real time system. Cooperating with other types of RFID
products in our company, it provides high quality solution for cases demanding
automatic identification, such as supply chain, storage, animal tracking, product line
management (working-in-progress) and electric power equipments routine check.

SUPER-RFID 11/28/2006
Shanghai Super Electronic Technology Co. Ltd Phone: [phone]
Fax: [phone] E-Mail: [e-mail] website：http://www.superrfid.net
Page 3 of 6
Performance
1) Identification range is within 10 meters
2) Advanced anti-collision techniques, simultaneously identifying up to 200 tags
3) Applied channel isolation technology, no interferences between equipments
4) Capability of high speed bi-directional data transmission between tag , reader and
PC
5) Communicate with computer through RS232/483/weigand 26 or wirelessly
6) Encrypted and certified to assure data safety, preventive of eavesdropping and
intentional decoding
7) Work at globally free 2.45GHz ISM band
8) Ultra low RF transmission power consumption, healthier and safer
9) Applied 0.18uM technology to reduce cost
10) Meet harsh industrial environment requirements
11) Stable, work temperature range from -10℃to 60℃, anti-impact design
12) Anti-jamming capability, tolerance of interfering sources at the scene
13) Applied design techniques of anti-interferences and thunders

SUPER-RFID 11/28/2006
Shanghai Super Electronic Technology Co. Ltd Phone: [phone]
Fax: [phone] E-Mail: [e-mail] website：http://www.superrfid.net
Page 4 of 6
Specifications
Mechanical characteristics
parameters specifications
size 64mm×43mm×11mm
weight 20g
Shell material ABS、stainless steel
Color black
Installation manner Portable, handheld
Microwave link characteristics:
specifications
parameters uplink downlink
modulation GFSK GFSK
frequency 2.4 - 2.4835 GHz
Working volage 3.3V±10%
Transmission power ≤0dBm(software adjustable)
Antenna polarization linear polarization
Microwave communication range Within 10 meters
Microwave communication error check Cyclic redundancy check(CRC16)
Communication encryption Temporarily confidential
Bit error ratio/B.E.R 10-7
Electric characteristics:
parameters specifications
power Supplied by PDA
CF interface Communication
interface baud rate：19200
Environment characteristics:

SUPER-RFID 11/28/2006
Shanghai Super Electronic Technology Co. Ltd Phone: [phone]
Fax: [phone] E-Mail: [e-mail] website：http://www.superrfid.net
Page 5 of 6
Parameters Specifications
temperature -40℃ — +80℃
Storage temperature -60℃ — +80℃
Anti-electromagnetism interferences 10V/m 0.1-1000MHz AM waves
reliability MTBF≥70000 hours
Work life 15 years
2. CF reader parameter setup for
testing software
CF reader testing software is named as “Cardreader”, open it, run Cardreader.exe, the
application interface is as follows:

SUPER-RFID 11/28/2006
Shanghai Super Electronic Technology Co. Ltd Phone: [phone]
Fax: [phone] E-Mail: [e-mail] website：http://www.superrfid.net
Page 6 of 6
“reader” bar can be optionally blank, “count” display the number of tags having been detected,
“interval ” means the time interval of data renew, usually 1 to 2 seconds. “autosave ” is usually set
to 1, means one execution produce 1 data backup file.
Once setup is done, click “read”. ID numbers and corresponding read time of tags being detected
can be displayed on the PDA screen.
Warning:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
The equipment compliance with FCC radiation exposure limit set forth for
uncontrolled environment
Changes or modifications to this unit not expressly approved by the party
responsible for compliance will void the user’s authority to operate the equipment.
Any change to the equipment will void FCC grant.
