Axi Milan A030.047.00 User manual
Milan
A030.047.00
A030.057.00
A030.058.00
A030.059.00
A030.110.00
Have Fun!
USER MANUAL
Keep instructions for later use
WARNING
Read these instructions carefully before use.
WARNING
Choking hazard - Small parts.
Not suitable for children under 36 months.
WARNING
The toy is to be assembled by an adult.
WARNING
Potential hazard description, e.g. In unassembled state
contain potentially hazardous sharp points, so please
keep out of baby’s reach.
www.axi.com
The assembly must be done by an adult!
Milan
s5
6s2
789 s1
s2
8
s2
s5 9
s5 s2
s2
8
9s1
6
s1
s2
s2
7
5 x 90
4 x 60
2x
3,5 x 50
2x 4x 8x 2x
A030.057.00 + A030.110.00
Milan
A030.047.00 + A030.057.00
4 x 60
16x
14x
4 x 55
7x
2x s2
12
t1 Detail A
A
A
A
A
t1
11
10 12
s2
s2
s2
s2
s2
s2
11 s2s2
10
10
Milan
16 18 s2
17 s1
s118
s2 s2
17
s2
16
s1 s2
s2
s1
s1
s1
A030.058.00
4 x 60
12x
17x
3,5 x 50
English
WWW.AXI.COM [email protected]
Milan
Introduction
Congratulations on your purchase of a AXI playhouse.
AXI makes every effort to design and manufacture a robust, safe product. In choosing this product, you have bought a
product you will enjoy for many years.
1. Safety
AXI playhouses are tested and approved in accordance with the EN71 toy standard and carry the CE mark and EN71 logo.
1.1 Safety Instructions:
•Do not allow children to play without (parental) supervision.
•Climbing or playing on the roof of a AXI playhouse is not permitted.
•AXI playhouses are suitable for up to two children and one adult (maximum weight - 150 Kg.).
2. Assembly
•The assembly of the playhouse must only be done by an adult.
•It is strongly recommended that a AXI playhouse with a raised base framework should be anchored with an anchoring
set (can be purchased separately). This increases the stability and therefore the safety of the playhouse.
•Do not place the AXI playhouse on a hard surface, such as concrete or asphalt. A fall from the playhouse onto a hard
surface can cause serious injury. A shock-absorbent surface, for at least 1.50 meters around the AXI playhouse, like
grass, wood chips or sand is required for playhouses higher than 60.0 cm.
• PlacetheAXIplayhouseonaatsurfaceandatleast2.00metresawayfromotherstructuresandotherobstaclessuch
as house walls, garage, fence, overhanging branches or clotheslines.
•Do not place the AXI playhouse on a surface that will remain damp. This can be achieved by using the anchoring set or
for AXI playhouses without a raised base framework by placing a paving stone between each corner of the playhouse
and the ground.
•For the AXI playhouses with a slide, it is recommended the house should be sited so that the slide does not face south.
The temperature of the slide can be increased considerably simply by the heat of the sun.
3. Material
AXI playhouses are made of Cunninghamia lanceolata with FSC quality mark. This wood has a natural resistance to wood
rotandpests.Togivethewoodanextraprotectivelayerandtonishoffthewood,ithasbeentreatedwithawater-based
stain. This stain, which is based on natural components, is not harmful to humans or the environment.
4. Maintenance
•Check whether all the nuts are on the bolts and whether there are any sharp edges, replace part as necessary.
•It is necessary to check regularly for splinters, loose screws and the tightness of joints and/or fastenings. If necessary,
nuts and bolts must be tightened. ‘Regularly means: when you put it up and twice a month during the outdoor play
season.
•Once a year check the state of the protective stain layer. To ensure the optimum durability, the AXI playhouse needs
to be given a new coat of stain every two years. Use a water-based paint / stain based on natural components for this.
WARNING!
•A fall from a playhouse onto a hard surface can cause serious injury. AXI.com cannot be held responsible if this occurs.
Always place the house on a soft surface.
•AXI playhouses are designed for private use. These playhouses must not be rented or placed in public places like
schools and day-care nurseries. In the case of rental or use in public places, any guarantee or warranty becomes
invalidate and other liabilities claims lapse.
•Wood is a natural product that is subject to the effect of the weather that may cause the wood to warp and split. No
guarantee is provided for the consequences of weather conditions on the construction that do not cause any damage,
such as splits in the wood and warping of the panels.
English
WWW.AXI.COM [email protected]
Milan
5. GUARANTEE CERTIFICATE
AXI.COM provides a 2-year guarantee on its AXI wooden playhouses when properly used in respect of the joints and
accessoriesandaguaranteeofveyearsonthewood.
AXI.COM reserves the right not to provide a guarantee if:
•no original sales receipt can be presented;
•natural effects of weather conditions on the wood have caused warping and splitting of wood that do not have a
negative impact on the construction of the AXI playhouse;
•the AXI playhouse is used for purposes other than those for which it was designed;
•a method of assembly is used other than the method indicated;
•technical repairs have been carried out unprofessionally;
•the AXI playhouse is used in public places like schools and day-care nurseries;
•the AXI playhouse is rented to third parties;
•the regular monitoring and where appropriate replacement of parts, screws and joints has been omitted.
•there is a failure to re-stain or paint the AXI playhouse once every two years.
This manual suits for next models
