Axis AX1805BT User manual

INSTRUCTION MANUAL
AX1805BT
12/24V 3” LCD MULTIMEDIA RECEIVER
GENERAL
- 3 Inch LCD
- Fixed Face Panel
- Illuminated Controls
- 12/24 Volt DC (10.8 - 32V)
- Ultra Memory
- Digital Clock
- Dimensions:
178W x 50H x 88D mm (Chassis)
188W x 58H x 20D mm (Front Panel)
AUDIO
- 4 x 45W Max Power
- EQ Presets
- Loud/Mute
- Telemute
- 4-8 Ohm Speaker Impedance
- 2CH RCA Pre-Out
INCLUDED
- ISO Wiring Harness
MULTIMEDIA
- 1 x USB Input (2A Charging) (Front)
MPEG5 Audio/Video Playback
Up to 64GB Support
- 1 x 3.5mm Aux-In (Front)
- 1 x A/V Input
- 1 x Camera Input
- 2 Video Output
BLUETOOTH
- Hands Free
- A2DP Audio Streaming
- Internal Hands Free Microphone
TUNER
- PLL Synthesized AM/FM Stereo
- ELITE Tuner (FM 87.5-108 MHz; AM 522-1620 Khz)
- Interference Absorption Circuit
- 30 Station Presets (18 FM, 12 AM)
- Mono/Stereo
SPECIFICATIONS
2YEAR WARRANTY

Installation
Please read these instructions carefully before operating the unit
ATTENTIONS OF INSTALLATION
1. This player should be installed by a professional technician.
2. Please read instructions carefully before installing.
3. Please ensure all wires are connected before powering unit on.
4. To avoid short circuit, please ensure all exposed wiresare insulated.
5. Please secure all wires after installation.
6. Please ensure connections made are as per directions in this instruction manual.
Wrong connection may cause damage tothe unit.
7. Please connect the wires correctly. Wrong connection will cause malfunction or
damage the electrical system.
INSTALLING THE UNIT
REMOVE THE UNIT
1. Detach the front panel.
REMOVING THE UNIT
Insert the keys supplied into both sides of the unit until they click. Pull the keys to
remove the unit from the dashboard.
2

Installation
WIRING CONNECTION
1. Do not connect the terminals ofthe batteryuntil the player is installed.
2. Please connect the yellow wire tothe positive of the battery (+).
3. When changing the fuse, ensure the new fuse specification is the same as the current.
Name Colour Description
Back Sight Grey Displays reverse camera.
Connect to reverse lamp positive.
Brake Orange Displays movies.
Connect to hand brake negative.
Tele-Mute Brown Mutes audio input.
Connect to Tele-Mute on UHF/VHF CB.
V-OUT- 1
ANTENNA SOCKET
BRAKEORANGE
TEL-MUTE BROWN
BACK-SIGHTGREY
V-OUT- 2V-IN
R-IN
L-INCAMERAL-OUT
B1
B2
B3
B4
B5
B6
B7
B8
A1
A2
A3
A4
A5
A6
A7
A8
R-OUT NC
ISO
FUSE
RCA BLOCK
NO NO
A1 B1 REAR-R SPEAKER +
A2 B2 REAR-R SPEAKER -
A3 B3 FRONT-R SPEAKER +
A4 POWER+ B4 FRONT-R SPEAKER -
A5 ANTENNA B5 FRONT-L SPEAKER +
A6 B6 FRONT-L SPEAKER -
A7 ACC B7 REAR-L SPEAKER +
A8 GROUND B8 REAR-L SPEAKER -
*
*Optional
*
*
*
3

OPERATION
LOCATION OF KEYS
11. AUX IN
12. MIC
13. Seek upbutton
14. MODE
15. 6/10+ Seconds
16. 5/10- Seconds
17. 4/RANDOM
18. RESET
1. 1
2. MUTE/POWER ON/OFF
3. MENU
4. 2 INTRO
5. 3 REPEAT
6. Seek Down Button
7. VOL/PUSH/ENT/SEL
8. BAND/Video Out On/Off
9. TFT SCREEN
10. USB
4

OPERATION
Key functions
KEYS
ACTION
RADIO
USB/SD
AUX
BT
POWER/
MUTE
Short Power on /
Mute on/off
Power on /
Mute on/off
Power on /
Mute on/off
Power on /
Mute on/off
Long Power off Power off Power off Power off
MENU
Short Main menu Main menu Main menu Main menu
Long file search
MODE
Short source change source change source change source change
Long BT off/link BT off/link BT off/link BT off/link
BAND
Short band change Music/Photo/Video
switch
Long Auto store Video Out/3 inch display
I<<
Short Seek down previous file previous file
Long Manual turn down FR
>>I
Short Seek up next file next file
Long Manual turn up FF
1/ Short Preset 1 recall /
Answer call
Answer call /
Play/Pause Answer call Answer call / Transfer Play/Pause
Long Save station to P1
2/INT
Short Preset 2 recall / Reject call / INT on/off Reject call
Long Save station to P2
3/RPT
Short Recall preset 3 Repeat on/off
Long Save station to P3
4/RDM Short Preset 4 recall /
Reject call
Random on/off / Reject
call Reject call Reject call / finish call
Long Save station to P4
5/10-
Short Preset 5 recall -10 skip
Long Save station to P5
6/10+
Short Preset 6 recall +10 skip
Long Save station to P6
VOL Rotary Volume +/- Volume +/- Volume +/- Volume +/-
SEL
(push
VOL)
Short BAS/TRE/BAL/FAD/EQ
/LOUD
BAS/TRE/BAL/FAD/EQ
/LOUD
BAS/TRE/BAL/FAD/EQ
/LOUD
BAS/TRE/BAL/FAD/EQ
/LOUD
Long
P-VOL/CT/ST/LOC P-VOL/CT P-VOL/CT P-VOL/CT
5

OPERATION
Basic Operation
Turn on/off the unit and MUTE function
Press /MUT button to turn on the unit. When the unit is on. Shortly press this button for mute
on/off. Press and hold it for 2 seconds to turn off the unit.
Audio setting menu adjustment
Repeatedly press VOL knob for the audio menu:
BAS(Bass)-TRE(Treble)-BAL(Balance)-FAD(Fader)-EQ-LOUD
Press and hold VOL knob for the setting menu: P_VOL-CT(INDEP/SYNC)-ST/MONO-DX/LOC
In each item rotating VOL knob to set them.
Switch source
Shortly press MODE button to change source. Also shortly press MENU button and rotating the
VOL knob to select other source or settings then press VOL knob.
Main menu adjustment
Shortly press MENU button and rotating the VOL knob to select SETTINGS then press VOL knob.
There are below items:
Language-Radio Area-Time-Time mode-Date-PAL/NTSC-Led Color-Video Warning-Factory
default -Version
In each item rotating VOL knob to set them.
Reset the unit
Press RESET button to reset the unit. It is activated for the following reasons:
a) Some buttons do not operate.
b) Error symbol shows on the display.
Note: if the RESET function is activated. All the memory will be lost.
There is a “Factory default” item in settings menu. To active it. You also can make all data back to
the factory setting.
Radio Operation
Receive a radio station
In RADIO source press BAND button to select desired band. Shortly press /button to
receive the desired radio station. Press and hold /button for manual tuning the
frequency.
Auto Store:
Press BAND button for 2 seconds to auto store stations to band 1~3.
Manually store station & recall preset station
Tuning to a station with or button. Press and hold one of the 1- 6 preset button for 2
seconds. The current station is stored into the number button. Shortly press the preset button (1~6)
to directly listen the station that saved in the corresponding preset button.
USB Operation
When an USB driver inserted to the unit, the unit will play the MP3/WMA file automatically. If an
USB drive is already inserted in the unit. Keep pressing MODE button shortly until the USB mode
6

OPERATION
display appears.
Select file
Press /button to skip to next/previous file. Hold /button to fast forward or
fast reverse.
Play/Pause
Press button to pause/playing the file.
INT function
Press INT button to play the first 10 seconds each file. Press it again to cancel this function.
RPT function
Press RPT button to select repeat mode: RPT ONE / RPT ALL (default).
Random function
Press RDM button, all files will be played randomly. Press it again to cancel this function.
+10/-10 file skip
Press 5/-10 button to skip back 10 file playing. Press 6/+10 button to skip forward 10 file playing.
Search song
Press and hold MENU button for 2 seconds. It will list all the songs on the display. Press and hold
MENU button for 2 seconds again. It will return to the parent directory. Using VOL+/-button to
select the desired folder/song then press VOL knob to enter/play.
Video/Photo/Music changing
Way 1: Shortly press BAND button to change Video/Photo/Music mode.
Way 2: Press and hold MENU button for 2 seconds. It shows the file search screen. Press I<< button.
One of the MUSIC/VIDEO/PHOTO symbol will be active. Rotating VOL knob to desired symbol.
Press >>I button switch to the right side. Rotating VOL knob to select folder /file then press VOL
knob to play.
AV IN operation
Connecting the Audio and Video signal to the RCA connecters (L-IN/R-IN/V-IN) behind the unit.
Then press MODE button to switch to AV IN mode. (Note: BRAKE wire needs to be connected to
ground.)
AUX operation
Connecting a audio signal (from a player) to the 3.5mm jack of front panel. Then press MODE
button to switch to AUX mode.
Camera in operation
Connecting the camera signal to RCA “CAMERA” connecter behind the unit. When “BACK SIGHT”
wire is connected to ground. It will switch to Camera mode.
Tele-mute operation
When “TEL-MUTE” wire is connected to ground. The sound of speakers will be muted. When
“TEL-MUTE” wire is disconnected to ground. The sound of speakers resumes.
7

OPERATION
Bluetooth Operation
Pairing
On your mobile phone, turn on Bluetooth and search for Bluetooth devices. “AX1805BT” should
appear inthe list and select “AX1805BT”. Enter password “0000” if needed.
When successfully paired, the BT icon will be shown on the display.
Bluetooth Audio
Press MODE button to switch toBTmode. Music on your mobile phone will automatically play.
Press key topause/play the song. Press /button to select the next/previous song.
Answering / rejecting an incoming call
When there is an incoming phone call, Press key to answer the call.
Press key to reject the call. To end a conversation, press key to hang up.
Transfer the call between mobile phone and source unit
During a phone call, press MENU button to transfer the phone call between the mobile phone and
the unit.
Disconnect the Bluetooth
When the mobile phone is paired with the unit and you wish to disconnect the Bluetooth, press
and hold MODE button for 2 seconds to disconnect/re-connect the Bluetooth.
For other operations, please refer to the Key functions table on page 5.
8
Bluetooth Operation
PAIRING
On your mobile phone, turn, no Bluetooth and search for Bluetooth devices. “CAR-BT” should appear in the
list and select.
Enter the password “0000” if needed.
When successfully paired, the BT icon will be on the display.
BLUETOOTH AUDIO
Press MODE button to switch to BT mode. Music on your mobile phone will automatically play.
Press >II key to pause/Play the song. Press >>I or I<< button to select the next of previous song.
BT CALLING
When there is an incoming call, press the Phone answer icon to answer the call.
Press the phone hang-up icon to reject or end the call.
DISCONNECT BLUETOOTH
To disconnect the bluetooth, press and hold the MODE button for 2 seconds. Repeat to re-connect.

TROUBLE SHOOTING
GENERAL
Power Supply Requirements
Chassis Dimensions
Tone Controls
:DC 10-32 Volts, Negative
Ground : 178 (W) x 97 (D) x 50 (H)
: ±10 dB
-Bass (at100 Hz)
-Treble (at 10kHz)
Maximum Output Power @32V
Current Drain
: ±10 dB
: 4 x 45watts
: 5Ampere (max.)
RADIO
Frequency Coverage
IF
Sensitivity
FM
87.5 to 108MHz
10.7 MHz
4dBμV(S/N=30dB)
AM
522 to 1620 kHz
450 KHz
36dBuV(S/N=20dB)
Stereo Separation >25dB /
TROUBLE SHOOTING
Before going through the checklist below, check the wiring connection. If any of the problems
persist after checklist has been made, consult your nearest service dealer.
Symptom
Cause
Solution
No power. The car ignition switch is
not on.
If the power supply is connected
to the car accessory circuits, but
the engine is not moving, switch
the ignition key to “ACC”.
The fuse is blown. Replace the fuse.
No sound.
Volume is minimum/mute. Adjust volume to a desired level.
Speaker or speaker wiring
are short circuited.
Remove short circuit.
The buttons do
not work.
Unit is frozen. Press the reset button.
The radio does
not work. The
radio station
automatic
scan does
not work.
The antenna cable is not
connected.
Insert the antenna cable firmly.
The signals are too weak. Select a station manually.
The antenna amplifier
has no power. Connect to 12 volts.
9

NOTES
10

NOTES
11

AX1805BT
