AXITEC AXIstorage Li SH User manual

V2002 1 3 E N S e i t e 1 | 27
Installation Instruction
AXIstorage Li SH
AXITEC Energy GmbH & Co. KG
Otto-Lilienthal-Str.5
DE-71034 Böblingen
Tel.: [phone]
Fax: [phone]
Web: http://www.axitecsolar.com

V2002 1 3 E N S e i t e 2 | 27
Inhalt
1 Safety ....................................................................................................................................4
1.1 Important notes on this manual.......................................................................................4
1.1.1 Purpose...................................................................................................................4
1.1.2 Target group............................................................................................................4
1.1.3 Storage ...................................................................................................................4
1.2 Symbol explanations .......................................................................................................5
1.2.1 Explanations regarding safety instructions and warnings............................................5
1.2.2 Explanation of pictograms and symbols.....................................................................6
1.3 Battery application area ..................................................................................................7
1.3.1 Appropriate use.......................................................................................................7
1.3.2 Perilous misuse........................................................................................................7
1.4 Main hazards..................................................................................................................8
1.5 Qualification of the users.................................................................................................8
1.6 Personal protective equipment (PPE) ...............................................................................9
1.7 Emergency instructions...................................................................................................9
1.7.1 Measures in case of fire ...........................................................................................9
1.7.2 Measures after gases or liquids have escaped............................................................9
1.7.3 Measures afterelectrical shock ................................................................................9
2 Product description ..............................................................................................................10
2.1 Important information about the product ......................................................................10
2.1.1 Conformity............................................................................................................10
2.2 Scope of delivery...........................................................................................................11
2.3 Technical data...............................................................................................................12
2.3.1 Performance features ............................................................................................12
2.3.2 Dimensions and weight of the Energypack ..............................................................12
2.3.3 Compatible inverters..............................................................................................12
2.3.4 Supply, interfaces, connections...............................................................................12
2.3.5 Ambient conditions................................................................................................13
3 Commissioning.....................................................................................................................14
3.1 Safety Instructions ........................................................................................................14
3.2 Installation ...................................................................................................................14
3.2.1 Transport ..............................................................................................................14
3.2.2 Choice of intallation site.........................................................................................14
3.2.3 Mounting..............................................................................................................15

V2002 1 3 E N S e i t e 3 | 27
3.3 Assembly......................................................................................................................15
3.3.1 Installing AXIstorage Li SH - Energypack einbauen....................................................15
3.3.2 Connect Energypack next to each other in series.....................................................18
3.3.3 Closing the housing of the battery system...............................................................19
3.3.4 Disposal measures.................................................................................................20
3.4 Connecting the inverter.................................................................................................20
3.4.1 SMA Sunny Boy Storage 3.7 / 5.0 / 6.0 ....................................................................20
3.4.2 Kostal PLENTICORE plus..........................................................................................21
3.5 Putting the AXIstorage Li SH systeminto operation.........................................................23
4 Repair..................................................................................................................................23
5 Decommissioning, storage ....................................................................................................23
5.1 Introduction .................................................................................................................23
5.1.1 Safety regulations..................................................................................................23
5.2 Storage connections......................................................................................................24
5.2.1 Storage period.......................................................................................................24
5.2.2 Physikcal conditions...............................................................................................24
5.2.3 Cleaning................................................................................................................24
6 Packing and transport...........................................................................................................24
7 Disposal...............................................................................................................................25
8 Further directories................................................................................................................26
8.1 Glossary .......................................................................................................................26
8.2 List of abbreviations......................................................................................................26
8.3 List of tables .................................................................................................................26
8.4 List of figures................................................................................................................26
9 Addresses, identification and notes .......................................................................................27

V2002 1 3 E N S e i t e 4 | 27
1Safety
Before installing the battery system, read these instructions carefully.
Please follow the safety and warning instructions carefully toavoid damage topersons, objects and
the environment.
1.1 Important notes on this manual
1.1.1 Purpose
This document describes the installation of an AXIstorage Li SH battery system in combination with
SMA Sunny Boy Storage 3.7/5.0/6.0 or Kostal PLENTICOREplus.
1.1.2 Target group
The installation instructions are intended exclusively for qualified electricians.
1.1.3 Storage
Thismanual is part of the battery. For a safe installation, the manual must be accessible to the
installers.
Keep this manual near the battery.
Pass this manual on to the next owner of the battery.
CAUTION
Risk of burns if you fail to adhere to the safety instructions.
During operation, heat can be generated by live parts, overload,
arc or short circuit. Touching hot surfaces can cause minor burns.
Read the operating instructions carefully before
usingthe Energypack.

V2002 1 3 E N S e i t e 5 | 27
1.2 Symbol explanations
1.2.1 Explanations regarding safety instructions and warnings
Safety Instructions are universally valid and can be found in a safety chapter orat the beginning of a
chapter.
Warnings are placed directly before behavioral guidelines. They help you to avoid dangers during an
upcoming operation. They consist of the following elements:
Table 1: Warnings.
Warning
triangle
indicates all hazards with regard to death or injury along with a signal
word.
Signal word
DANGER
denotes a hazard with a high degree of risk. Failureto avoid exposure
to it will result in death or serious injury.
WARNING
denotes a hazard with a medium degree of risk. Failure to avoid
exposure to it will resultin death or serious injury.
CAUTION
denotes a hazard with a low degree of risk.Failureto avoid exposure
to it will result in a minor injury.
ATTENTION
indicates hazard concerning objects. Failureto avoid exposure to it will
result in damage to property.
Type and
source of the
danger
states the nature of the danger and what causes it
Consequence
indicates what can happen if you do not follow the warning
Call for action
describes what you must do to protect yourself
from the danger
Additional
symboles,
pictograms
can be used in addition to the warning triangle.Warning signs (yellow)
indicatethe danger. Prohibition signs (red) and mandatory signs (blue)
represent remedial measures.

V2002 1 3 E N S e i t e 6 | 27
1.2.2 Explanation of pictograms and symbols
Table 2: Expla nation of the symbols used
Symbols
Declarationg
General warning sign.
Note additional information.
Warning of electrical voltage.
Warning of dangers from batteries that are being charged.
Warning of flammable substances.
Hot surfacewarning.
Warning of hand injuries.
No access for persons who have pacemakers or implanted defibrillators.
Manual lifting prohibited.
General commandment sign
Note additional information.
Adhere to instructions.
Use foot protection.
Use hand protection.
Do not disposeof batteries with household garbage.

V2002 1 3 E N S e i t e 7 | 27
1.3 Battery application area
1.3.1 Appropriate use
The AXIstorage Li SH is a battery system. It serves asan energy storage device withinanelectricity
storage system forprivate households and small businesses. It enables you to temporarily store self -
produced electricity, e.g. from photovoltaic - or CHP (cogeneration of heatand power) plants. The
electricity can later be used when needed.
In a battery system, 3 to 6 Energypack can be connected to one anotherin series.
AxitecEnergy GmbH& Co.KGis not liable forpersonal injury and/or material damage due to
improperuse of the energystorage system.
The battery system is a self-contained unit which is only functional after properinstallation with an
approved inverter.
A maximum of 6 Energypack can be connected serially in the AXIstorageLi SHbattery system.
In orderto avoid dangers such as water pipe bursting, the Energypack must be stored at least 15 cm
above the floor.Proper installation of the AXIstorage Li SH fire pump ensures that the active
electrical componentsare at least 15 cm above the floor.
The AXIstorage Li SH battery system may:
only be used with Energypack.
only be used with compatible inverters.
only be used in closed rooms.
only be used in an undamaged condition and in accordance with the operating
instructions.
Any other usage is not intended.
1.3.2 Perilous misuse
Do not use the battery systemwith other Energypack.
Do not use the battery systemoutside its performance limits.
Do not install the battery system in rooms at risk of flooding.
Do not connect the battery system to devices not approved for this purpose.
Do not open Energypack. The Energypack may only be opened by trained service
personnel.

V2002 1 3 E N S e i t e 8 | 27
1.4 Main hazards
You can expect zero danger from the battery under normal conditions. The battery corresponds to
the state of the art inscience andtechnology. However,it is obviously impossible to completely
exclude risks if the battery ismisused orin the event of technical failure. In case of lithium-ion
batteries, these generally includefire, explosion, chemical burns and electricshock.
The product-specificrisk of hazards is elevated by
Water (e.g. flooding)
Heat exposure (>70 °C)
Failure ormalfunction of the control system due to electromagneticradiation
Touching live components may cause an electric shock when Energypack are connected in series. The
electric shock can have thermal or muscle paralyzing effects. The latter can lead to ventricular
fibrillation, cardiac arrest or respiratory paralysis, ordeath.
Overload, short circuit or arcing can cause a lithium-ion firewith thermal runaway. People can be hit
by electrolyteor molten material. In the event of fire, there is a risk of suffocation due to lack of
oxygen and a risk of poisoning due to toxic fumes.
1.5 Qualification of the users
Only the electricians qualified by the AxitecEnergy orthe AxitecEnergy itselfmay work with the
battery system.
Do not leave the children unattendedorallow them tobe nearthe battery system.
High currents have effects on medical implants.
People with implants must be careful not to be in the directvicinity of the battery during
operation.
Electric shock
Fire
People with
implants

V2002 1 3 E N S e i t e 9 | 27
1.6 Personal protective equipment (PPE)
Use foot protection and hand protection during assembly.
1.7 Emergency instructions
1.7.1 Measures in case of fire
Do not inhale smoke and vapors.
Reporta lithium-ion fire tothe fire department.
If possible: Close the doors.
If possible: Cool the Energypack with water. Avoid contact with the extinguishing
water!
1.7.2 Measures after gases or liquids have escaped
Escaping gases can cause respiratory problems.
Ventilate immediatelyorgo out into the fresh air, in more extreme cases, call a doctor
immediately.
Skin contact may cause skin irritation.
Wash skin thoroughly with soap and water.
Eye contact may cause irritation to the eyes.
Immediately rinse eyes thoroughly with water for 15 minutes, then consulta doctor.
1.7.3 Measures after electrical shock
Ensure that the system is at zero voltage.
For unconscious patients: Ensure respiration and cardiovascularfunction. If necessary,
initiate cardiopulmonary resuscitation immediately.
For responsive patients: Cool burn injuries and coverthem by dressing the wound.

V2002 1 3 E N S e i t e 10 | 27
2Product description
2.1 Important information about the product
Overall view
Figure 1
Overall viewof batterysystem.
2.1.1 Conformity
The following standards, laws and guidelines were taken into account during the development of the
Energypack:
EU directive with CE labelling obligation
Low Voltage Directive2014/35/EU
EMC Directive 2014/30/ EU
Legal requirements
UN transport test (lithium systems)
Standards and userguidelines
DIN EN 60730
DIN EN 62619

V2002 1 3 E N S e i t e 11 | 27
Installation kit:
A B C D E F G
2.2 Scope of delivery
AXIstorage Li SH system housing
Installation kit (in systemhousing) is included:
6 RJ45 patch cables A
1 RJ45 Terminator B
12 screws M6x10 C
3 Dummy sockets, power plugs D
2 PG connections E
1 Three-hole cable bushing F
1 Single-hole cable bushing G
ATTENTION
Not included withthe systemhousing
Installation instructions
This can be downloaded at www.axitecsolar.com in the download area.
3 to 6 Energypack
The numberof Energypack must be ordered separately dependingon the selected
performance and may only be installed / put into operation by qualified electricians.

V2002 1 3 E N S e i t e 12 | 27
2.3 Technical data
2.3.1 Performance features
Modules in series
3
4
5
6
Energy content
(nom./usable)
9 kWh /
7,5 kWh
12 kWh /
10 kWh
15 kWh /
12,5 kWh
18 kWh /
15 kWh
Nominal voltage
155 V
207 V
258 V
310 V
End-of-charge voltage
172,5 V
230,0 V
287,5 V
345,0 V
Final discharge voltage
126 V
168 V
210 V
252 V
Capacity (nom.)
57 Ah
57 Ah
57 Ah
57 Ah
Charging current
(continuous.)
30 A
30 A
30 A
30 A
Disscharge current
Peak
40 A
40 A
40 A
40 A
Discharge power Peak
6,2 kW
8,3 kW
10,3 kW
12,4 kW
Discharge capacity
(max.)
4,6 kW
6,2 kW
7,7 kW
9,3 kW
Dimensions (B x H x T)
751 mm
x 870 mm
x 423 mm
751 mm
x 870 mm
x 423 mm
751 mm
x 870 mm
x 423 mm
751 mm
x 870 mm
x 423 mm
Weight
107 kg
129 kg
151 kg
173 kg
Discharge operating
temperature
-20 to 55 °C
-20 to 55 °C
-20 to 55 °C
-20 to 55 °C
Load operating
temperature
0 to 45 °C
0 to 45 °C
0 to 45 °C
0 to 45 °C
Storage temperature
-20 to 50 °C
-20 to 50 °C
-20 to 50 °C
-20 to 50 °C
Battery chemistry
Li-Ion NMC
Discharge depth
83 % DOD [in relation to nom. ca pacity]
Full Cycles
5 000 or3 000 (for residual capacityof 60 % or80 %)
Table 3: Structure of warnings
2.3.2 Dimensions and weight of Energypack
Dimensions (Wx H x D): 545.2 mm x 214 mm x 155.4 mm
Weight: 22 kg
2.3.3 Compatible inverters
SMA Sunny Boy Storage 3.7 / 5.0 / 6.0 (CAN)
KOSTALPLENTICOREplus (RS-485)
2.3.4 Supply, interfaces, connections
The AXIstorage Li SH is supplied with the followingconnections:
+ DC cable: AWG8 red (American standard for wire cross section)
- DC cable: AWG8 black
Cable for grounding: AWG8 yellow-green
Communication cable, either CAN or RS-485
All cables have a length of about 40 cm.

V2002 1 3 E N S e i t e 13 | 27
The Energypack has one socket whichcontains(+) and (-) as powercontacts and two RJ45 sockets
which contain CAN bus and status and signal lines:
1 socket with power contacts (+) and (-)
1 RJ45 sockets with CAN bus connection for monitoring and control of the Energypack
by the higher-level controller
1 RJ45 socketforconnecting a further Energypack
2 M6 threads for connectingthe grounding
2.3.5 Ambient conditions
Operation exclusively inside buildings (air-conditioned and non air-conditioned interiors):
Temperature: 0 … 50 °C
Relative humidity: 5 ... 85 %
Height: 0 ... 2000 m above sea level.
Temperature Storage: -20 … 60 °C

V2002 1 3 E N S e i t e 14 | 27
3Commissioning
3.1 Safety Instructions
The installation may only be carried out by qualified electricians according toIEC 60204
(InternationalElectrotechnical Commission)-1.
The housing including electronics weighs 41kg. One Energypack weighs 22 kg. Heavy lifting can cause
a disturbance of the musculoskeletal system.
Lifting the AXIstorage Li SH cover (11 kg) andbase (30 kg) separately
If and as necessary, donot lift the AXIstorage Li SHbase alone or be sure to use
transport aids.
Risk of crushing and abrasions when lifting and inserting the Energypack.
Use foot and hand protection.
3.2 Installation
3.2.1 Transport
If the installation site is difficult to access, it is recommended that the base and the hood of the
system housing be carried to the installation siteseparately:
1. Open the packaging of the AXIstorage Li SH system housing.
2. Unscrew 2 screws (hexagon socket, SW4) at the front of the bottom of the system
housing
3. Remove the hood from the system housingbase.
4. Carry the hood and base to the installation site individually.
The Energypack should be transported to the installation site in their original packaging.
3.2.2 Choice of intallation site
The battery system can be mounted uprighton the floor.
It is recommended thatthe inverterbe installedon the flooragainst a wall, where itcan be mounted
centrally above the battery system. The invertershouldbe mounted at least 20 cm above the battery
system. Ata distance of up to 30 cm, the cables already attached to the AXIstorage Li SH can be used.
Leave space of at least 30 cm free to the left and right of the battery system to get to the DC
disconnect switch to ensure sufficient air circulation.
To prevent the battery system from tipping over, it can be secured to the installation wall with two
screws (not supplied). Two fixing points are provided in the system housing for this purpose .
Four fixing points are providedin the systemhousing forwall mounting. Since the battery systemcan
weigh up to 173 kg, it must be checked in advance whether the wall and fastening material are
suitable to support the loadin the long term.

V2002 1 3 E N S e i t e 15 | 27
3.2.3 Mounting
The installation location forthe battery system and the inverterhave been determined.
Recommended mounting:
1. Install the wall bracketof the inverter.
2. Hook the inverterinto its bracket.
3. Unscrew the cover of the connectionarea.
4. If not already done, remove the coverfromthe
battery system housing:
Unscrew 2 screws (hexagon socket, SW4) on the
front underside.
Remove the coverfromthe base.
Position the base of the battery housing atthe intended installation location (and screw it on if
necessary).
3.3 Assembly
3.3.1 Installing AXIstorage Li SH - Energypack einbauen
Safety Instructions
CAUTION
Risk of crushing due to improper installation.
Falling orimproperinsertion of the module can cause slight bruising and
abrasions to hands and feet.
Wear protective clothing.
Screws M5 (SW4)

V2002 1 3 E N S e i t e 16 | 27
CAUTION
Ergonomic hazards due to heavy lifting.
Lifting the Energypack can cause a disturbance of the musculoskeletal system.
Should it be necessary, be sure not to lift the module alone.
Use a lifting aid, when necessary.
ATTENTION
Incorrect installation due to damaged or contaminated Energypack.
Only faultless modules may be mounted. The housingmust be undamaged. The contact points
must be undamaged and clean.
Perform a visual inspection.
Clean the contact points with adry cloth if necessary.
The Energypack may only be inserted into the AXIstorage Li SHbattery system provided forthis
purpose.
The power storage system is securely installed.
The main switchof the powerstorage system isoff.
The Energypack should have a similarvoltage
1. Make sure that the DC disconnectorof the AXIstorage Li SH isset to "off".
2. Loosen the two screws H and I, with which the hold-down is fixed on the left and right,
and lift up the hold-down.
Unpack and insert the Energypack.
H
I

V2002 1 3 E N S e i t e 17 | 27
To ensure the best possible cooling, we recommend that the Energypack are inserted asfollows:
Figure 2: Insert 3 to 6 Energypack
3. Screw the downholderto the right and left of the base of the systemhousing.
4. Screw each Energypack with two screws (M6) to the downholder/grounding support.
For example, referto Figure 3.
Figure 3: Energypack fixed to the grounding support
with 3 Energypack with 4 Energypack
with 5 Energypack with 6 Energypack

V2002 1 3 E N S e i t e 18 | 27
5. Use the patch cables to connectthe BMS master (left of the two RJ45 sockets) with the
installed Energypack.
6. For example, referto
7.
8.
Figure 4.
Figure 4: Connect the Energypack to the BMS master usingthe patch cables
9. Plugthe terminatorinto X2 of the last Energypack.
3.3.2 Connect Energypack next to each other in series
WARNING
Electricshock from live parts.
Touching live components may cause electrical shock, which may create intense
heat or paralyze muscles. The latter can lead to ventricularfibrillation, cardiac
arrest or respiratory paralysis, or death.
Never touch the contacts.

V2002 1 3 E N S e i t e 19 | 27
1. Remove the safety coverof the "Power"sockets.
2. Insert the power plug for the respective Energypack until it clicks into place. For
example, referto Figure 5.
Figure 5: Power path with s witching devicesa nd BMS
3. Checkby pullingthe powerplugs tomake sure that the latchingis engaged.
4. If there are less than 6 Energypack: Fit the power plugs not required with the dummy
sockets Dsupplied.
5. Feed the power cables (red and black) as well as PE (yellow-green)through the left
hole in the basic housing and fix them with the supplied PG screw connection.
6. Lead the communication cable through the right hole and fix it with the supplied cable
gland.
3.3.3 Closing the housing of the battery system
1. Position the housing hood (with display) in front of the
housing base and plugthe cable for the display on the
board into the hood.
2. Insertthe hood intothe guide atthe top and close it at
the bottom with the two M5x10 hexagon socket
screws (SW4) which were unscrewed in
Screws M5 (SW4)

V2002 1 3 E N S e i t e 20 | 27
3.3.4 Disposal measures
Dispose of transportpackaging forrecyclingin accordance with the statutory provisions.
It is recommended to keep not required parts (patch cables, dummy plugs, screws) together with the
installation instructions nearthe battery system.
Before removing defective Energypack, the powersocket must be taped with insulatingtape after
removing the powerplug.
3.4 Connecting the inverter
3.4.1 SMA Sunny Boy Storage 3.7 / 5.0 / 6.0
1. Feed the DC power cable, PEas well as the communication cable(s)through the
respective PGscrew glands into the connection compartment of the inverter.
Figure 6: Connecting the SMA SB Storage to the AXIstorage Li SH
2. Connectthe cables in the inverteraccording tothe Sunny Boy Storage 3.7 / 5.0 / 6.0
operatinginstructions.
Chapter 6.5: Connecting battery communication cable:
yellow: CAN H (E)
white: CAN L (D)
red: Enable (B)
black: GND (C)
Chapter 6.1.2: Interior View
Yellow-green Grounding point for grounding the battery (L)
Chap. 6.8 DC connection
Red (+) (A+)
Black (-) (A-)
It is recommended to use all bridges (30A)
