Axxera AVM1000Ui Operating instructions

1
INSTALLATION/OWNER’S MANUAL
Media Receiver with Bluetooth , USBMirror and SiriusXM-Ready
featuring a 10.1" Touch Screen Display
AVM1000Ui
RTM TM

1
Copyright Notes
SiriusXM and all related marks and logos are trademarks of Sirius XM Radio, Inc. All rights reserved.
MicroSD logo is a trademark of SD-3C, LLC.
Operating system updates from Apple and Android may cause your receiver not to function properly. This can usually be fixed
by doing a software/firmware update to the receiver itself. To see if your receiver has the latest firmware, contact customer
service at 1-866-382-5476 to see if your radio needs an update.
Other trademarks and trade names are those of their respective owners.

2
AVM1000Ui PREPARATION
Safety Information
Please read all instructions carefully before attempting to install or operate.
Due to its technical nature, it is highly recommended that your Axxera AVM1000Ui is installed by a professional
installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.
To prevent damage or injury:
• Make sure to ground the unit securely to the vehicle chassis ground.
• Do not remove the top or bottom covers of the unit.
• Do not install the unit in a spot exposed to direct sunlight or excessive heat or the possibility of water splashing.
• Do not subject the unit to excessive shock.
• When replacing a fuse, only use a new one with the prescribed rating. Using a fuse with the wrong rating may
cause the unit to malfunction.
• To prevent short circuits when replacing a fuse, disconnect the wiring harness first.
• Use only the provided hardware and wire harness.
• You cannot view video while the vehicle is moving. Find a safe place to park and engage the parking brake.
• If you experience problems during installation, consult your nearest Axxera dealer.
• If the unit malfunctions, reset the unit as described on page 10 first. If the problem still persists, consult your
nearest Axxera dealer or call tech assistance @ 1-866-382-5476.
• To clean the monitor, wipe only with a dry silicone cloth or soft cloth. Do not use a stiff cloth, or volatile solvents
such as paint thinner and alcohol. They can scratch the surface of the panel and/or remove the printing.
• When the temperature of the unit falls (as in winter), the liquid crystal inside the screen will become darker than
usual. Normal brightness will return after using the monitor for a while.
• When extending the ignition, battery or ground cables, make sure to use automotive-grade cables or other cables
with an area of 0.75mm (AWG 18) or more to prevent voltage drops.
• Do not touch the liquid crystal fluid if the LCD is damaged or broken. The liquid crystal fluid may be hazardous to
your health or fatal. If the liquid crystal fluid from the LCD contacts your body or clothing, wash it off with soap
immediately.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

3
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Insert the supplied keys into the slots as shown.
• Connect wiring harness as shown on page 4. Consult a qualified technician if you are
unsure.
• Certain vehicles may require an installation kit and/or wiring harness adapter (sold
separately).
• Reconnect negative battery terminal, and test for correct operation.
• Snap trim ring into place (if required).
AVM1000Ui INSTALLATION
Preparation
TYPICAL FRONT-LOAD DIN MOUNTING METHOD

4
Wiring Diagram - Inputs/Outputs
AVM1000Ui INSTALLATION
Note:
When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause
damage. The unit uses (1) 10 amp blade-type fuse located on the back of the unit.
Wiring Notes:
Rear camera input
A rear view camera (not included) can be used with the Camera input.
Connecting a device
DualMirror technology allows you to mirror the screen of select Android smartphones as well as iPhone, iPod and
iPad devices.
SiriusXM
For more information on how to install the SiriusXM Connect Vehicle tuner, consult the installation guide included
with the tuner (SiriusXM connect tuner and subscription sold separately).
CAMERA AUDIO INPUT
BT
ANTENNA
SiriusXM Tuner Connection
(SiriusXM Connect Tuner and
subscriptions sold separately)
USB CHARGE
PARKING BRAKE (-)
FOR SIM INTERFACE
TFT

DIMMER
IGNITION / ACC 12V(+)

5
Control Locations
Mode
Volume Up
Power
Tune / Track Up
Select
Band/Enter
Volume Down
Preset3/Play/Pause
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Preset 2 / Random
Preset 6
Preset 5
Mute
Menu
Preset 4
Preset 1 / Repeat
Bluetooth Talk
Tune / Track Down
Microphone
Power/Mute Button
Voice/Camera Button
Volume Down
Volume Up Button
1
2
3
Reset
microSD Card Slot
USB Port
3.5mm AUX Input Jack
5
6
7
8
9
4
AVM1000Ui OPERATION
17
2345
167
8
9
10
1 2 3
4
5
7
8
9
10
11
12
6
13
14
15
16
17

6
Notes:
• The remote control uses one 3 volt
Lithium CR2025 battery. Remove the
battery if the remote will not be used
for a month or longer.
• Remove and dispose of battery
properly.
• Do not store battery with metallic
objects or materials.
Remove battery insulation tape .
To insert or replace the battery,
remove the battery holder.
Remove the battery from the
battery holder.
Install the new battery.
Make sure to keep the (+) side
up.
Insert the battery holder.
Remote Control Preparation
AVM1000Ui OPERATION

7
Power On/Off
Mode
Volume
Mute
Auxiliary Input
USB Port
MicroSD Slot
Main Menu
Speaker Zone 1
Speaker Zone 2
Press to turn the unit on. Press and hold to turn the unit off.
Press MODE to access available input modes: Radio, SiriusXM,
USB Mirror, USB, SD Card, Bluetooth Phone, Bluetooth Music, Rear
Camera, Auxiliary Input. Modes of operation are indicated on the display
and/or the monitor. USB device or SD card must be connected/
inserted to appear in the mode selection string.
Press the Volume + or Volume - on the top of the front panel, the
Volume Pop up window will show up on the screen. Press the Volume
Button on the top of the front panel or swipe left and right the volume
on the pop up window directly to adjust the volume level lower or
higher(0~42).
Press the volume + or volume – on the top of the front panel. The
volume Pop up window will show up on the screen. Press the speaker
icon in the volume pop up window to turn mute on or off. When the
volume pop up window disappears on the screen and the unit is in
mute state, press the screen to cancel the mute.
Connect external audio devices to the 3.5mm auxiliary input on the
front panel.
Connect a USB device to the USB port on the front panel to play MP3
files or JPG photos.
Insert a MicroSD card into the MicroSD slot on the front panel to play
MP3 files or JPG photos.
From any operational mode, press the house icon in the top left corner
to access the Main Menu screen.
1. Adjust screen brightness or put the monitor into standby mode.
2. Access audio setting such as EQ, Surround Sound Settings and Field
Settings (Balance).
Press the Zone 1 button to turn on/off the sound from this zone
Press the Zone 2 button to turn on/off the sound from this zone.
General Operation
AVM1000Ui OPERATION
1 2

8
From the Main Menu screen, press Settings in the bottom right corner to
access the Setup Menu and select from the following categories: General,
Audio, Video and Bluetooth.
General:
• OSD Language - Select English as the language for the on-screen display.
• Wallpaper - Select between three available wallpaper options.
• Panel Adust - Select to calibrate the touch screen.
• Radio Area - Select your current geographic area: Europe, USA, South
America, Russia and Asia.
• Time Setting - Adjust the current time (hours and minutes) and choose
between a 12-hour and 24-hour clock.
• Beep - Select to turn the audible beep On or Off.
• Camera - Select to turn the rear camera On or Off.
• Version- Select to view information about the unit.
• Restore Default- Select to restore the unit to default setting
(Including SiriusXM data reset)
Audio:
• Sound Effect - Select to access the three sound effect sub-menus.
- EQ - Select from any preset equalization curve (Classic, Rock, Pop,
Jazz, Beat, Flat) or use custom settings (User).
Video:
• Aspect Ratio - Select the desired aspect ratio: 4:3PS, 4:3LB or 16:9.
• Adjust - Select to adjust levels of Brghtness, Contrast, Hue, Saturation
and Sharpness.
• Panel - Select to choose backlight settings: 10s, 20s, 30s or Off.
Bluetooth:
• Auto Connect - Turn auto connect feature On or Off.
• Auto Answer - Turn auto answer feature On or Off.
General Operation
Setup Menu
AVM1000Ui OPERATION
TM

9
Select the Radio icon from the Main Menu screen.
Press to return to Main Menu screen.
Displays current mode of operation.
Press momentarily to tune the unit down one step at a time. Press
and hold to tune down by seeking the next strong station.
To store a preset station, tune unit to desired station, then press
and hold the desired preset button to store the current station in
that preset spot. Up to 18 FM and 12 AM stations can be stored in
memory. Momentarily press any preset station to play it instantly.
Press to adjust screen brightness or put the monitor into standby
mode.
Press to select between three FM and two AM bands.
Press to toggle between LOCAL and DX (distance) tuning.
Press to access audio setting such as EQ, Surround Sound Settings
and Field Settings (Balance).
Press to toggle between Stereo and Mono tuning.
Radio Operation
Main Menu 1
Current Mode Indicator 2
Tune Frequency Down 3
Preset Stations 4
Screen 5
Band 6
Local / Distance 7
Audio 8
Stereo / Mono 9
AM/FM Tuner Operation
AVM1000Ui OPERATION
1
4
3
2
5 6 87 9

10
AVM1000Ui OPERATION
Press and hold to automatically store the six strongest stations in the
current band as presets. Press briefly for a preset scan, which will
scan all preset stations and play 10 seconds of each. Press again to
cancel the scan and continue playing the current station.
Press to access the Settings Menu.
Press momentarily to tune the unit up one step at a time. Press and
hold to tune up by seeking the next strong station.
Press to utilize Voice Activation feature.
Press to directly access Navigation app.
AS/PS 10
Settings 11
Tune Frequency Up 12
Navigation 13
Voice Activation 14
AM/FM Tuner Operation
1113
12
14 10

11
USB/SD Operation
MP3 or JPG Operation
Main Menu 1
Current Mode Indicator 2
File Information 3
Screen 4
Tune / Track Down 5
Play / Pause 6
Audio 7
Tune / Track Up 8
To play MP3 files from a USB device or SD card, insert device and
playback will begin automatically. To return to USB or SD playback
from another mode of operation, select the corresponding icon from
the Main Menu.
• USB Playback - Insert a USB device into the USB slot on the
front of the unit.
• SD Playback - Insert MicroSD card into the MicroSD slot on the
front of the unit.
Press to return to Main Menu screen.
Displays current mode of operation.
Displays information about the current file.
Press to adjust screen brightness or put the monitor into standby
mode.
Press momentarily to tune the unit down one step at a time. Press
and hold to tune down by seeking the next strong station.
Press to play or pause playback.
Press to access audio setting such as EQ, Surround Sound Settings
and Field Settings (Balance).
Press momentarily to tune the unit up one step at a time. Press and
hold to tune up by seeking the next strong station.
AVM1000Ui OPERATION
12
3
65 84 7

12
USB/SD Operation
Folder Search 9
Settings 10
Repeat 11
Random 12
Press to access the directory of folders and files. Use the up/down
arrows to scroll through the folder list, then press on the name of the
desired folder to access it. Use the up/down arrows to scroll through
the file list, then press on the name of the desired file to access it.
Press to access the Setting Menu.
Press to turn Repeat feature on.
Press to turn Random feature on.
AVM1000Ui OPERATION
12
11
910

13
AVM1000Ui OPERATION
Media Compatibility - USB/SD Card
File Type MP3
File System FAT FAT 12 X
FAT 16/FAT 32 
File
Extension
. m p 3 /. M P 3/.M p 3 /. m P 3 
. r m p /. m 4 a X
MPEG
Format
MPEG 1 
MPEG 2 
MPEG 2.5 
Sampling
Frequency
MPEG 1 32/4 4.1/4 8k Hz
MPEG 2 12/16/22.05/24kHz
MPEG 2.5 8/11.025/12k Hz
Bitrate
MPEG 1 32 ~ 320kbps
MPEG 2 8 ~ 160kbps
MPEG 2.5 8 ~ 160kbps
Other
Information
Directory Depth Unlimited
File Name Length 32 bytes
Total File Number 2000 files
Total Folder Number 200 folders
File Number via Folder 2000 files
MP3 ID3 TAG
ver.1.x 
ver.2.x 
Title, Artist, Album 
Notes:
• For USB mode, it is not possible to view JPG files on the in-dash monitor while the vehicle is
moving. This is a safety feature to prevent driver distraction.
• The JPG image viewer function will only operate when vehicle is in park and the parking
brake is engaged.
• Due to ongoing technological advancement, some USB flash drives and/or SD cards may
be incompatible with this unit.

14
AVM1000Ui OPERATION
Media Compatibility
The following types of discs/files are compatible:
• AVI - Max video resolution: 720x480, Max video bit rate: 5000 kbps
• Mpeg4: Max video resolution: 720x480, Max video bit rate: 5000 kbps
• SD/USB format type: FAT32/FAT
The following types of discs/files are not compatible:
• MP3 PRO format, MP3 playlists
• RMP format
• WAV format
• WMV format
• WMA format
• AAC, protected AAC, M4A format
MP3 playback sequence begins in the root folder of the USB flash drive or
SD card. Any empty folders or folders that do not include MP3/JPG files are
skipped.
ISO9660 standards:
• Maximum nested folder depth is 8 (including the root folder).
• Valid characters for folder/file names are letters A-Z (all caps), numbers
0-9, and “_” (underscore). Some characters may not be displayed correctly,
depending on the character type.
• This device can play back files in Joliet and other standards that conform
to ISO9660. MP3 written in the formats other than the above may not play
and/or their file names or folder names may not be displayed properly.
Some files may not play or be displayed correctly, depending on sampling
rates and bit rates.
For best results, use the following settings when ripping MP3 files:
128kbps or higher constant bit rate
44.1kHz or higher sampling frequency
Media Compatibility
Playback Order
Compatible Recording Formats
Notes

15
Before you can use a Bluetooth device, it must be paired and
connected. Make sure that Bluetooth is activated on your device
before you begin the pairing process.
The unit broadcasts the pairing signal constantly when no
devices are currently connected. Complete the pairing sequence
from your Bluetooth device. Refer to the owner's manual for
your device for more details. The device name is "Axxera
AVM1000Ui". The Bluetooth passcode "0000". The unit can
be in any mode of operation when pairing is performed.
Note: On certain phones, pairing may need to be done more than
once if there are connectivity issues.
Most Bluetooth devices support the auto-connect feature and
will connect automatically if the device is in range when the unit
is powered-on. If your device was previously paired but does not
connect, enter the Bluetooth setup menu and ensure that Auto
Connect is On.
To access the phone, select Bluetooth Phone from the Main
Menu.
Press to return to the Main Menu screen.
Displays current mode of operation.
Use the phone keypad to dial the desired phone number.
Alternately, numbers can be dialed directly from the phone.
Press to display keypad and dial a number.
Press to play music using the Bluetooth connection.
Preparation
Pairing a New Device
Connecting a
Paired Device
Bluetooth Phone
Main Menu 1
Current Mode Indicator 2
Phone Keypad 3
Phone 4
Music 5
AVM1000Ui OPERATION
Bluetooth Operation
12
4
5
3

16
Screen 6
Audio 7
Settings 8
End Call 9
Make a Call 10
Bluetooth Music 11
Previous File/Track 12
Play / Pause 13
Next File/Track 14
Press to adjust screen brightness or put the monitor into standby
mode.
Press to access audio setting such as EQ, Surround Sound Settings
and Field Settings (Balance).
Press to access the Settings Menu.
Press the end the current call.
Press to connect or answer a call.
To use your Bluetooth connection to play music from your device,
press #5 or select Bluetooth Music from the Main Menu.
Press to go back to the previous file or track.
Press to pause or resume playback.
Press to advance to the next file or track.
AVM1000Ui OPERATION
Bluetooth Operation
68
7
9
11
10
1312 14

17
Only SiriusXM Satellite Radio brings you more of what you love
to listen to, all in one place. Get over 140 channels, including
commercial-free music plus the best sports, news, talk, comedy and
entertainment. Welcome to the world of satellite radio. A SiriusXM
Vehicle Tuner and Subscription are required. For more information,
visit www.siriusxm.com.
After installing your SiriusXM Connect Vehicle Tuner and antenna,
power on your radio and select SiriusXM mode. You should be able
to hear the SiriusXM preview channel on Channel 1. After you can
hear the Preview channel, tune to Channel 0 to find the Radio ID of
your tuner. The In addition. Radio ID is located on the bottom of the
SiriusXM Connect Vehicle Tuner and its packaging.
Note: SiriusXM Radio ID does not include the letters I, O, S or F.
In the USA, activate online or by calling SiriusXM Listener care:
• Visit www.siriusxm.com/activatenow
• Call SiriusXM Listener Care at 1-866-635-2349
For Canadian Subscriptions, please contact:
• Visit www.siriusxm.ca/activatexm
• Call XM customer Care at 1-877-438-9677
Activation typically takes 10-15 minutes, but may take up to one hour.
It is recommended to leave your vehicle on until the “Subscription
Updated” message appears. Your radio will need to be powered on
and receiving the SiriusXM signal to receive the activation message.
Once activated, you can tune to channels in your subscription plan.
From the Main Menu, touch the SiriusXM icon to access SiriusXM
mode and begin operation.
SiriusXM Radio
Activating
SiriusXM Radio
Accessing
SiriusXM Radio
AVM1000Ui OPERATION
SiriusXM Satellite Radio Operation
®
®
®
®
®
®
®
®
®
®
®
®
®
®
®
®

18
Main Menu 1
Band 2
Current Mode Indicator 3
Program Information 4
Search 5
Preset Channel List 6
Press to return to the Main Menu screen.
Touch to select a band of preset channels. Three bands are available:
SXM1, SXM2, and SXM3. Each band can store up to six preset
channels. (Preset channels are accessed from the List icon.)
Displays current mode of operation.
Displays program information such as channel name, artist name
and song title.
Press to enter search mode, then press Channel to choose between
the following search options: Channel, Artist, Song Title or Info. Use
the up/down arrows on the left side to navigate categories, and use
the up/down arrows on the right side to navigate channels, artists,
song titles or info.
Press to display a list of preset channels in the current band.
AVM1000Ui OPERATION
SiriusXM Satellite Radio Operation
1 3 42 5 6
Category & Channel
Preset Channel List
®

19
AVM1000Ui OPERATION
Additional Options 7Press to display/adjust the options Mode, Tune Scan and Go to Live:
Mode - Press to access and adjust the following options:
• Parental Code - When enabled, the Parental Control feature
requires you to enter a passcode to tune to the locked channels.
Press "Change" to change the parental code. Follow the prompts to
enter the current code, then enter and confirm the new code. The
default code for the unit is "0000".
• Parental Control - The Parental Control feature allows you to limit
access to any SiriusXM channels, including those with mature
content. Select a Parental Control option: Off (turns Parental Control
off) Mature (locks all mature channels) or User (allows the user to
lock specific channels using the Parental Lock Channel feature).
Enter the Parental Code when prompted to confirm the change.
• Parental Lock Channel - Press "SET" to select specific specific
channels to lock. Press "All Clear" to clear all locked channels.
• Channel Skipping - Press "SET" to select channels to skip.
• TuneStart™ - Press "ON" or "OFF" to enable or disable TuneStart.
With the TuneStart feature turned ON, you will hear the beginning
of the song when you tune to one of your Preset channels. It may
take a minute or two for the feature to work after power up or after
changing preset bands.
TuneScan™
Press TuneScan button to initiate the TuneScan function. The unit
plays samples from the start of multiple buffered songs from each of
the Preset Channels that predominantly play music selections,. This
gives the user easy access to a large sampling of music content, and
they can enjoy hearing a full song when stopping the scan on a song
of interest. Pressing TuneScan again will stop the TuneScan function
and continue playing the song currently being scanned.
Pressing and holding the TuneScan button cancels the TuneScan
and returns the user to the original channel that was tuned when
TuneScan was first initiated.
Go to Live - Press to resume play of live broadcast while in Replay
mode. See page 22 for information on Replay mode.
Additional Options
7
SiriusXM Satellite Radio Operation
®
