PORTABLE MIXERS
FMX-42
Having 4 Balanced XLR line/mic inputs with individual level and pan
controls, the FMX-42 provides switchable (per channel) 48V phantom
power and limiting, professional quality VU meters for accurate level
setting, master level control, 1k tone generator, 2 Balanced XLR out-
puts (line/mic switchable), stereo mini jack output for DV cams, and
a headphone monitor with level control.
It can be powered by either six internal "AA" batteries or a
12V external supply (optional). The pictured ballistic nylon
case is included.
INPUTS
OUTPUTS
Alow-noise 3-channel portable mixer designed
for use by professional videographers, the
FMX-32 connects easily to the video
camera's "MIC" input via the mixer's
balanced XLR outputs or its 3.5mm
unbalanced stereo output. Each mic input
has switchable phantom power (48V DC).
FMX-32 FEATURES:
•3Balanced XLR inputs w/individual level controls
•Phantom Power with On/Off switch
for each input (48V)
• 2 Balanced XLR outputs
•5-Step LED output level indicator
•Selectable output configurations
•Stereo mini-jack output for DV cameras
•Headphone Output (stereo or mono) w/level control
•3-position Power Switch with Power On/Low Battery LED
•Operates for 15 hours on 6 “AA” batteries (not supplied)
•DC Input for optional external power supply
•Built-in Limiter with On/Off switch to prevent overload
• Dimensions: 6.69"(L)x4.33"(D)x1.96"(H)
Aportable 2-channel mixer designed for use by the professional
videographer, the small (3.75" x 1.625" X 5"), all metal, battery
operated (9V) mixer can be attached directly to the camera
withsupplied hook-and-loop fastener or belt-worn using the
3-position belt clip. The FMX-20 has the following features:
enhanced circuitry for an improved signal-to-noise ratio,
a3-step LED array for easy signal monitoring, a 12V DC input
for external power, a switchable input limiter to reduce the
possibility of overload distortion, and a channel-addressable
1/4" monitor headphone jackwithlevel control, 2 balanced
XLR mic inputs, 2 channel-addressable XLR line-level outputs
with level controls, a stereo mini-jack (3.5mm) line-level output
and a POWER On/Off/LowBattery LED indicator.
FMX-20

FMX-32
Frequency Response
Main and Unbalanced Output: 40-17,000Hz (-3dB)
Monitor Output: 50-17,000Hz (-3dB)
Noise Level
Left & Right Channel: -114dBu (A weighted, Input Equivilent Level)
T.H.D.: less than 0.05% @ 1KHz (+10dBu output)
MIC Input Level: -50dBu Electronic Balanced
Balanced Output Level
Electronic Balanced: -0dBu (100K ohm load)
-6.5dBu (600 ohm load)
Unbalanced: -50dBu (100K ohm load) 3.5mm Stereo
Monitor Output: -4dBu (32 ohm load) 3.5mm Stereo
Maximum Output Level
Balanced Output: +14dBu (100K ohm load
+6.5dBu (600 ohm load)
Unbalanced Output: -36dBu (100K ohm load)
Battery Type/Duration: 6-"AA"Alkaline - 15 hours
Current Drain: 47mAnominal (Phantom Power Off)
100mA maximum (Phamtom Power On)
Phantom Power Voltage: 48VDC (+/- 4VDC)
Size: 50H x 170W x 110D mm (1.96 x 6.69 x 4.33 inches)
Weight w/o Battery: 27.9 ounces (791 grams)
Azden Corp., P.O. Box 10, Franklin Square, NY 11010
tel: [phone] • fax: [phone]
email: [email protected] • web: www.azdencorp.com
FMX-20
Frequency Response
Main and Unbalanced Output: 40-17,000Hz (-3dB)
Monitor Output: 50-17,000Hz (-3dB)
Noise Level
Mic (-50): -55dB
Line (+0): -57dB
T.H.D.: 0.15% @ 1KHz
MIC Input Level: -50dBu Electronic Balanced
MIC Output Level: 50dBu Switchable Balanced
Unbalanced Output: -50dBu 3.5mm Stereo
Monitor Output (3.5mm Stereo)
(Max Load 16 ohm): -18dBu
Main Output 0.5dBu - 600 ohm load 0dBu ref @ 0.775Vrms
0.5dBu - 1k ohm load 0dBu ref @ 0.775Vrms
Unbalanced Output -32dBu - 600-1k ohm load 0dBu ref @ 0.775Vrms
Battery Type/Duration: 9-Volt Alkaline (006p type): 6 Hours
Current Draw: 38mA nominal - 50mA maximum
Size: 42H x 130W x 103D mm (1.65 x 5.1 x 4.05 inches)
Specifications*
FMX 42
Frequency Response
Balanced and Unbalanced Output: 20 Hz - 30 kHz (± 1.5 dB)
Monitor Output: 30 Hz - 30 kHz (± 2 dB)
Signal-To-Noise
Balanced Output: -120 dBu (A weighted, Input Equivalent Level)
T.H.D. Balanced Output: <0.005% @ 1 kHz (@ LINE position +19 dBu output)
Phantom Power Voltage: 48V (± 4V)
Power
Battery Requirement: 6Alkaline “AA”
Battery Runtime: Approx. 10 hours (Meter Illum. OFF/Phantom OFF)
External Power: 12VDC @ 200 mA
Current Drain: 155 mA (Meter Illum. OFF/Phantom OFF - @ 9V)
195 mA (Meter Illum. OFF/Phantom ON w/2-SGM-1000 - @ 9V)
Dimensions: 56H x 220W x 150.5D mm (without protrusions)
1.968H x 8.6614W x 5.9055D inches (without protrusions)
Weight: 1400 g (without batteries) 49.3835 oz (without batteries)
Balanced Input: XLR 3-pin x 4 (CH1, 2, 3 and 4)
Level
Line Input
Standard: +4 dBu (electronically balanced)
Maximum: > +26 dBu
Mic (-30 position)
Standard: -30 dBu (electronically balanced)
Maximum: +4 dBu
Mic (-50 position)
Standard: -50 dBu (electronically balanced)
Maximum: -11 dBu
Impedance
Line: 20 k ohm
Mic: 2 k ohm
High Pass Filter (HPF): 100 Hz – 6 dB/oct
Balanced Output: XLR 3-pin x 2 (Output L and R)
Unbalanced Output: 3.5 mm (1/8") Stereo mini-jack
Monitor Output: 6.5 mm (1/4") Stereo jack
Level
Balanced Output
Standard: +4 dBu (> 10 k ohm load)
-2 dBu (600 ohm load)
Maximum: +20 dBu (>10 k ohm load)
+13 dBu (600 ohm load)
Unbalanced Output
Standard: -36 dBu (> 10 k ohm load)
Maximum: -20 dBu (> 10 k ohm load)
Tone Generator: 1 kHz @ +4 dBu
Max Monitor Out: +1 dBu (32 ohm load
16-100 ohm load recommended)
Output Impedance
Balanced: 600 ohm
Unbalanced: 120 ohm
Meters
Standard Output Level: 0 VU (+4 dBu)
* Due to constant improvements, specifications are subject to change without notice.
