Azden FMX-32a User manual

FMX-32a
3-Channel Portable Audio Mixer
Thank you for purchasing an Azden product.
Please read this manual thoroughly before using this
product.

2
○
1 POWER INDICATOR: When the power switch (○
12 )Is on, the LED will light in green. When the baery level becomes too
low for proper operaon, the LED will turn red. When this happens, replace the baeries with fresh “AA” alkaline baer-
ies.
○
2 CHANNEL 1, 2 & 3 INPUT LEVEL CONTROLS: Each knob controls the input volume level of the microphone connected to
the corresponding input (○
9). Zero is the lowest (quietest) seng while 10 is the highest (loudest).
○
3 CHANNEL 1, 2 & 3 OUTPUT SELECTORS: Let you select the output of each channel between LEFT, CENTER and RIGHT.
○
4 MASTER LEVEL CONTROL: This knob controls the overall volume level of all connected sources (microphone and/or line
-level devices).
○
5 CHANNEL 1, 2 & 3 LIMITER SWITCHS: Each input channel has a switchable limiter. Aer seng the input volume level,
turn this switch on. The limiter circuit will be acvated and reduce the possibility of overload distoron from very loud
sounds without aecng normal sound volume. If you prefer the overall sound quality of the mixer without the limiter
circuit engaged, leave this switch o.
○
6 INPUT PEAK LEVEL INDICATOR: When the mixer detects signal overload and distoron, this LED will light in red. Lower
the input level by turning the corresponding input level control (○
2) counterclockwise.
○
7CHANNEL LEFT & RIGHT OUTPUT LEVEL INDICATORS: These indicators will show the output volume level of the CH L
and CH R outputs (○
13 &○ 14 ). When the indicators show red, reduce the volume level by turning the input level control
knobs (○
2) or the master level control knob (○ 4).
○
8BATTERY COMPARTMENT: Open the lid by liing it while pushing the tab.
● Safety Instrucons
* It is very important to read and understand this manual completely before use. Keep this manual for future refer -
ence.
* When connecng/disconnecng cables and/or changing the phantom power seng or input level sengs, turn the
input level control knobs to zero or power switch o.
* When the phantom DC48V power is not needed, make sure the phantom switch is in the o posion.
* Before turning the phantom DC48V switch on, make sure your condenser microphone is designed to handle 48V DC
or the microphone may be damaged. Check the microphone’s manual or with the manufacturer.
* Do not use other baeries than “AA” alkaline baeries. Do not mix fresh baeries with used ones.
* Remove the baeries if the mixer will not be used for a long period of me to prevent baery uid leak.
● Front Control Panel

3
● Side Panels
○
9CHANNEL 1, 2 & 3 XLER INPUTS: Connect the 3-pin XLR output of a microphone, wireless receiver or line level audio com-
ponent to CH 1 and/or CH 2 and/or CH 3. Push the XLR connector into the input jack unl it locks. To remove the XLR con-
nector, press the “PUSH” tab while pulling the connector out.
○
10 INPUT LEVEL SELECTOR: The following 2 sengs are available for each channel:
MIC HI: maximum +4dBu (2kΩ) MIC LO: maximum -15dBu (2kΩ)
○
11 PHANTOM DC 48V SWITCH: Each channel has its own phantom DC 48V power seng. When using a dynamic micro-
phone, make sure that the corresponding phantom DC 48V switch is in the OFF posion. When using the condenser micro-
phone that requires 48V DC external power, turn the corresponding phantom DC 48V switch ON. When you turn the phan-
tom DC 48V switch ON or OFF, make sure to turn the volume level control knobs ( ○
2
) zero or turn the power switch ( ○
12
)
OFF.
○
12 POWER SWITCH
○
13 & ○ 14 CHANNEL LEFT & RIGHT XLR OUTPUTS: Connect a cable from these outputs to the MIC or LINE input of your cam-
era or audio recorder. The outputs accept a standard 3-pin female XLR connector.
○
15 STEREO MIC OUTPUT: This mini-connector (3.5mm) output is designed for video cameras or audio recorders with mini-
connector mic-level inputs. This output is stereo (dual-channel) and unbalanced. It is recommended to use a stereo-to-
stereo mini cable (not included) to connect this output to the input of your video camera or audio recorder. Because the
FMX-32a is equipped with low-impedance XLR inputs and a mini-connector output, users of cameras/audio recorders with
mini-connector inputs can now use high-quality microphones with XLR outputs.
○
16 MONITOR PHONES OUTPUT JACK: A 1/4” (6.3mm) jack for headphones.
○
17 LEVEL VOLUME CONTROL: Controls the volume level of the monitor phones output (○
16 ). Zero is the lowest and 10 is the
highest seng.
○
18 EXTERNAL DC IN CONNECTOR: To power the mixer with external 12V DC power. An oponal AC adaptor, part number BC
-27, is available. For informaon, visit www.azdencorp.com

4
AZDEN CORPORATION
147 New Hyde Park Road, Franklin Square, NY 11010
Phone: [phone] Email: [email protected]m Web Site: www.azdencorp.com
Printed in USA
LIMITED TWO-YEAR WARRANTY
Azden Corporaon warrants, to the rst purchaser, that the Azden brand product purchased is free from defects
in material and workmanship. Azden’s sole obligaon under this warranty shall be to provide, without charge,
repair or replacement (at Azden’s sole discreon), within two years from the date of purchase. The cost to ship a
failed product to and from Azden or to its dealer shall not be covered by this warranty. A dated receipt acts to
establish the date of purchase and is all that is required for warranty service.
This warranty is the sole and exclusive express warranty given with respect to the product and all other warran-
es, expressed or implied, are hereby excluded. Neither Azden, nor the dealer who sells this product, is responsi-
ble for indirect, incidental or consequenal damages.
This warranty does not extend to any defect, malfuncon or failure caused by misuse, abuse, accident, Act of
God, faulty hookup, unauthorized modicaon, connecng this product to equipment for which this product is
not intended or defecve associated equipment. Please read your owner’s manual carefully.
● Specicaons
IINPUT LEVEL: Max Input Level Max Gain Input Impedance
MIC LO -20dBu +63dB 2kΩ
MIC HI -3dBu +45dB 2kΩ
MAX OUTPUT LEVEL:
CH L & CH R: +20dBu (5kΩ) UNBALANCED OUTPUT: -19dBu (2kΩ) MONITOR OUTPUT: +1dBu (32Ω)
FREQUENCY RESPONSE: 20 - 20,000Hz (+0/-0.5dB)
NOISE LEVEL: -120dBu
T.H.D.: Less than 0.005% (1kHz, +19dBu)
PHANTOM POWER: 48V ±2V
POWER SOURCE: 6 “AA” Alkaline baeries/DC 12V 200mA
BATTERY DURATION: Up to 15 hours in connuous use
DIMENSIONS: 170mmL x 120mmW x 53.5mmH / 6 11/16”L x 4 3/4”W x 2 3/16”H
WEIGHT: 750 g / 26.45 oz (without baeries)
Oponal canvas carrying case, part number FMX-32C, is available. Visit www.azdencorp.com for details.
