B-Tech KVM1702 User manual

KVM1702
HDMI KVM 2*1 SWITCH
USER MANUAL
1. Description
HDMI KVM switch two groups of high-definition Audio and video source and USB interface
implementation free switch, Adaptive EDID , can adapt to a variety of complex application
environments.The equipment has excellent image processing and transmission capacity, make the
output signal is more smooth and steady, is a reliable, high performance and efficient way of HDMI
USB switch.
2. Features
⚫The two groups of HD audio ,video source and USB interface to free switching;
⚫Support video resolution max up to 3840x2160@30Hz；
⚫Compliance with HDMI 1.4 and HDCP 1.2 standard;
⚫Adaptive EDID , able to adapt to a variety of complex application environment;
⚫Hot key switch, convenient and quick(Scroll Lock + Scroll Lock+ 1、2);
⚫High compatibility, can auto-match source and display device;
⚫Built-in automatic adjustment system, make the image smooth, clear and stable;
⚫Built-in ESD protection system;
⚫Easy to install, plug and play;
3. Package list
⚫HDMI KVM2*1 Switcher host 1 pcs
⚫USB Cable 2 pcs
⚫HDMI Cable 4 pcs
⚫MicroUSB Cable 1 pcs
⚫User manual 1 pcs
⚫Warranty Card 1 pcs

1/ 4
4. Specifications
Parameter
Description
Video
Standards
HDMI 1.4
Maximum pixel clock
225MHz
Maximum data rate
10.2Gbps
Resolution range
Up to 3840x2160@30Hz, 1920*1080@60Hz
Connector
HDMI-A Interface
Impedance
100Ω
HDMI Cable Range
<5M( Resolution: 1920*1080@60Hz)
USB
Interface protocols
USB1.1, USB2.0
PC input interface
type
USB-B
Output interface type
USB-A
Other
Power supply
USB-B 5V power supply
Power dissipation
MAX 4W
Temperature
Operating: -5℃~ +70℃
Humidity
Operating: 5% ~ 90%
Dimension
130*75.8*35mm
The warranty
1 year free warranty

2/ 4
5. Panel
Port name
Description
1
5V power supply , for high power USB device
2
HDMI video output signal group
3
PC1 HDMI USB input
4
PC2 HDMI USB input
5
PC1 , PC2 switch buttons
6~7
PC1 , PC2 status indicators
8
Power indicators
9
USB keyboard mouse connectors
10
USB2.0 device connectors

3/ 4
6.Diagram
(Note: Please note that in the premise that the host computer supports multi-screen display, the extended mode can
output two different screens, and the copy mode can output two identical screens; if the computer only supports
single-screen display, even if there are many One output port, only one output port works when the wiring is
correct.)
7. Warranty
Thank you very much for using our products.
The warranty time is one year and life-long maintenance. During this period, any belongs to
under normal usage circumstance cause because of the product quality’s problem of breakdown,
our company will be responsible for giving free maintain.
Free maintain won’t be given under the following circumstance:
⚫The malfunction and damaged caused by incorrect use, the unauthorized repairs and alteration;
⚫The damage caused by fire, flood, abnormal voltage, other natural disasters and secondary
product damage;
⚫The product malfunction caused by not in accordance with the user manual operation;
⚫The malfunction and damaged caused by the other barriers(man-made factors or external
device).
