B2 Audio RAGE SERIES User manual

rage series
amplifiers
rage 2500.1 rage 1200.6 rage 600.4
product id: Rage25001D19
rage12006df19
rage6004df19

rage
Don’t blow a fuse, keep calm. The next era comes with our redened levels. The Rage series is “The increased Desire for B2 audio”. Starting out with 3
amplifers at the same time, the Rage should cover any need for near any type of user. Mono, 4ch or even 6 ch amplication, no problem, Rage covers it
all. Enough power and authority rened with the keystones of B2 audio will provide you with numerous hours of joy and sweetness.
The added bonus is that these amplifers not only are ecient, but they are compact as well.
To obtain the full potential of any amplier & to minimize failure, it is adviced to upgrade your stock electrical system. Don’t take any shortcuts, a better
electrical equals enhanced performance and stability.
4-9
10
strapped control panel setting 11
strapped speaker connection 12
accu8 crossover settings 13
troubleshooting 14
audio precision chart (RAGE2500.1) 15
warranty info 16

Design features
Circuit Configuration: HI-EF Class D Hi-ef Class D fr hi-ef Class D fr
Frequency Response: 15 ~ 200 Hz 10 Hz ~ 25 Khz 10 Hz ~ 27 khz
Signal to Noise Ratio: > 85 dB > 90 db > 90 db
Input Sensitivity: 4 V ~ 0.1 V 6 v ~ 0.2 v 6 v ~ 0.2 v
Crossover Circuit:
high pass crossover: 50 hz - 5 Khz (ch 1~4) 20 Hz - 5 khz
high pass crossover : 20 ~ 200 hz (ch 5-6)
24 dB / Oct 24 db / oct 24 db / oct
Low Pass Crossover:
band pass crossover: 20 ~250 hz (ch 5~6) 50 hz ~ 5 khz
20 ~ 200 Hz 50hz~5khz (ch 1-4)/20 - 200hz (ch 5~6) 50 hz ~ 5 khz
Subsonic Crossover: 10 ~50 Hz
Damping Factor: > 300 > 250 > 250
Bass Boost Frequency: 45 Hz
Remote Control w/clip & low volt: Included
Power Terminal Gauge: 0 GA 4 ga 4 ga
Fuse Rating: 250 A 120 a 60 a
Dimensions: 45 x 18.5 x 5.4 cm 35 x 14.2 x 4.9 cm 23 x 14.2 x 4.9 cm
17.7 x 7.3 x 2.1” 13.7 x 5.6 x 1.9” 9 x 5.6 x 1.9”
Continious output power (RMS)
rage 2500.1 rage 1200.6 bridge @4 ohm rage 600.4 bridge @4 ohm
4 ohm 750w (Ch 1-4) 110w x 4 / (ch 5-6) 200w x 2 (Ch 1-4) 320w x 2 / (ch 5-6) 640w x 1 100w x 4 300w x 2
2 ohm 1500w (ch 1-4) 160w x 4 / (ch 5-6) 320w x 2 NA NA 150w x 4 NA
1 ohm 2500w Na Na
Description of specifications
* Speaker overload
* Short circuit
* Input Voltage - RCA & Power Supply
3
Operational voltage 9V ~16V.
rage 2500.1 rage 1200.6 rage600.4

4
Panel layout
rage2500.1
INPUT REMOTE LEVEL CONTROL PORT
RCA signal input for left & right channel. Connection of external signal level control.
A minimum of 0.1V input signal is required for correct CAUTION, the amplier needs to be gained in accordance
operation. Using only 1 input will minimize input signal with the remote to avoid excessive signal boost.
and amplier will need to be gained as such.
POWER & PROTECTION INDICATOR LPF (LOW PASS FILTER 20 Hz ~200 Hz, 24 dB/oct)
Power LED, blue light shows correct operation, Adjusts the cut o point for the low pass crossover
Protect LED, red light shows general malfunction, faulty at the frequency chosen.
connection or thermal protection.
output master / input slave
GAIN (4V~0.1v) Used for linking / strapping the amplier to another unit
Adjusts signal input voltage from the input source to achieve twice the amount of power.
to match the ampliers input stage. When set in output master, this unit will be sending the
0.1 V ~ 4 V is the operational voltage. signal to the slave unit, that will have the switch set to
Voltages beyond may cause errors or damage to the input slave with the rca connected to the input.
input section.
SUBSONIC
Variable subsonic setting from 10 Hz to 50 Hz.
It is highly recommended to set it according to the tuning
of your subwoofer enclosure to avoid unnecessary strain to
your sound system.

5
Power & speaker terminal
rage2500.1
power terminal
GND (Ground connection) +12v (Power connection)
Connects to the vehicle’s chassis. Keep as short as Connects to the positivie terminal of the battery.
possible (< 20” / 50 cm). Use minimum 0AWG cable For specied performance 0AWG cable is required.
for optimal operation. Fuses shall be placed within 8” / 20 cm of the battery.
rem speaker terminal
Connects to +12V switched remote from the headunit. Connects to the speakers negative and positive terminal.
It can also use switched +12V source for external units. Use minimum 12 AWG speaker cable. The terminals are
If several units are installed in the car, it can be wise with bridged internally. The dual terminals are there to make
a relay to ensure sucient voltage is present. connections easier.
GND REM 12V
POWER SPEAKER
Keep ground as short as possible and as use the
adequate AWG to achieve optimal performance.
The minimum ohm load is 1 ohm. In strapped mode,
the ohm load is 2 ohm.

6
Panel layout
rage1200.6
INPUT CH1~CH6 Gain (6v~0.2v) CH3/4
RCA signal input for left & right on channel specied. Adjusts signal input voltage from the input source
A minimum of 0.2V input signal is required for correct to match the ampliers input stage. 0.2V ~ 6V is the
operation. operational voltage. Voltages beyond may cause errors
or damage to the input section. All adjustments apply to
rem channel 3 & 4.
Connects to +12V switched remote from the headunit.
Push the tab to insert the wire and release after. hPF
See the description on the left side of the page.
Gain (6v~0.2v) CH1/2
Adjusts signal input voltage from the input source Full
to match the ampliers input stage. 0.2V ~ 6V is the No crossovers are applied.
operational voltage. Voltages beyond may cause errors
or damage to the input section. All adjustments apply to lpf
channel 1 & 2. See the description on the left side of the page.
hpf Gain (6v~0.2v) CH5/6
Adjusts the high pass crossover point to lter out audio Adjusts signal input voltage from the input source
with a 24 dB slope from the given selection on ch 1 & 2. to match the ampliers input stage. 0.2V ~ 6V is the
The switch selection sets the HPF in active or fullrange. operational voltage. Voltages beyond may cause errors
If in HPF mode frequencies below the setting will be cut or damage to the input section. All adjustments apply to
with 24 dB per octave. Full setting is fullrange signal. channel 5 & 6.
Full hPF
No crossovers are applied. Adjusts the high pass crossover with 24 dB/oct at the set
frequency. Will works as a band pass if LPF switch is set
lpf at 80 Hz or 250 Hz.
Adjusts the low pass crossover point to lter out audio
with a 24 dB slope from the given selection on ch 1 & 2. LPF switch
If in LPF mode frequencies above the setting will be cut Sets up a band pass crossover on ch 5 & 6 if set at 80 Hz
with 24 dB per octave. Full setting is fullrange signal. (typically subwoofer applications) or 250 Hz for midbass
drivers. The band pass setting is dependant on the HPF
setting.

7
P0wer & speaker terminal
rage1200.6
GND 12V
POWER PWR
PRO
CH1
CH3
CH2
CH4
CH5
CH6
BRIDGED
BRIDGED
BRIDGED
SPEAKER
gnd pro led
onnects to the vehicle’s chassis. Keep as short as Amplier has gone into protect mode.
possible (< 20” / 50 cm). Use minimum 4AWG cable The malfunction could be caused by speaker short,
optimal operation. thermal protect, faulty connection or general errors.
rem
Connects to +12V switched remote from the headunit. speaker output terminals
It can also use switched +12V source for external units. Connects to the speakers pos & neg terminals.
If several units are installed in the car, it can be wise with Use a 12AWG cable for optimal performance.
a relay to ensure sucient voltage is present. The RAGE 1200.6 is stable to 4 ohm bridge or 2 ohm stereo.
Bridge mode is enabled by connecting the speaker cables
+12 (power connection) to the terminals indicated on the illustration above.
Connects to the positivie terminal of the battery.
For specied performance 4AWG cable is required.
Fuses shall be placed within 8” / 20 cm of the battery.
pwr led
Shows the amplifer is connected to both +12V power and
is grounded at the same time.

8
Panel layout
rage600.4
INPUT CH1~CH4 Gain (6v~0.2v) CH3/4
RCA signal input for left & right on channel specied. Adjusts signal input voltage from the input source
A minimum of 0.2V input signal is required for correct to match the ampliers input stage. 0.2V ~ 6V is the
operation. operational voltage. Voltages beyond may cause errors
or damage to the input section. All adjustments apply to
channel 3 & 4.
Gain (6v~0.2v) CH1/2 hPF
Adjusts signal input voltage from the input source See the description on the left side of the page.
to match the ampliers input stage. 0.2V ~ 6V is the
operational voltage. Voltages beyond may cause errors LPF
or damage to the input section. All adjustments apply to See the description on the left side of the page.
channel 1 & 2.
bpf
hpf See the description on the left side of the page.
Adjusts the high pass crossover point to lter out audio
with a 24 dB slope from the given selection on ch 1 & 2.
The switch selection sets the HPF in active or inactive.
If in ON mode frequencies below the setting will be cut
with 24 dB per octave. OFF setting is full range signal.
lpf
Adjusts the low pass crossover point to lter out audio
with a 24 dB slope from the given selection on ch 1 & 2.
If in ON mode frequencies above the setting will be cut
with 24 dB per octave. OFF setting is full range signal.
bpf
Adjusts the band pass crossover point to lter out audio
with a 24 dB slope from the given selection on ch 1 & 2.
If in ON mode frequencies above & below the setting will
be cut with 24 dB per octave. To use the BPF both HPF
ON and LPF ON needs to be selected.

9
Power & speaker terminal
rage600.4
gnd pro led
onnects to the vehicle’s chassis. Keep as short as Amplier has gone into protect mode.
possible (< 20” / 50 cm). Use minimum 4AWG cable The malfunction could be caused by speaker short,
optimal operation. thermal protect, faulty connection or general errors.
rem clip led (active on ch 3/4)
Connects to +12V switched remote from the headunit. Flashing led indicates signal is clipped on ch 3 and ch 4.
It can also use switched +12V source for external units. Set gains in accordance, so clip indicator is only ashing
If several units are installed in the car, it can be wise with at absolute peak levels.
a relay to ensure sucient voltage is present.
speaker output terminals
+12 (power connection) Connects to the speakers pos & neg terminals.
Connects to the positivie terminal of the battery. Use a 12AWG cable for optimal performance.
For specied performance 4AWG cable is required. The RAGE 600.4 is stable to 4 ohm bridge or 2 ohm stereo.
Fuses shall be placed within 8” / 20 cm of the battery. Bridge mode is enabled by connecting the speaker cables
to the terminals indicated on the illustration above.
volt led indicator
Flashing led indicates power supply voltage is below
recommended to achieve the ampliers rated performance.
Continious negligence of the indicator can cause damage to
your sound system & reduced performance.
pwr led
Shows the amplifer is connected to both +12V power and
is grounded at the same time.
SPEAKER
BRIDGED
BRIDGED

Strapped control panel setting
11
master amplifier
Bass remote
slave amplifier
output power. Follow the instructions carefully as it can cause harm to your system if done incorrect.
Speaker impedance 2 Ohm ~ 16 Ohm
will reach thermal at a faster rate & will eventually go into protect.
Strapped impedance load under 2 ohm is not warranted!

Strapped control panel setting
11
master amplifier
Bass remote
slave amplifier
output power. Follow the instructions carefully as it can cause harm to your system if done incorrect.
Speaker impedance 2 Ohm ~ 16 Ohm
will reach thermal at a faster rate & will eventually go into protect.
Strapped impedance load under 2 ohm is not warranted!

12
Strapped speaker connection
rage2500.1
GND REM 12V
POWER SPEAKER
GND REM 12V
POWER SPEAKER
master amplifier
slave amplifier
Speaker impedance 2 Ohm ~ 16 Ohm
will reach thermal at a faster rate & will eventually go into protect.
Strapped impedance load under 2 ohm is not warranted!
step 1.
Run the positive (+) speaker cable from the master
positive terminal (+) of the subwoofer.
step 2.
Run the positive (+) speaker cable from the slave
negative terminal (-) of the subwoofer.
Step 3.
negative speaker output on master
to negative speaker output on slave

13
accu8 crossovers
rage1200.6
rage600.4
rage2500.1
CLick settings for LPF - hpf - subsonic
rage2500.1 rage1200.6 rage600.4
LPF subsonic hpf ch1-4 ch5-6 lpf hpf lpf
1. 20 Hz 10 Hz 1. 50 Hz 20 Hz 50 Hz 1. 20 Hz 50 Hz
5. 21 Hz 13 Hz 5. 65 Hz 25 Hz 55 Hz 5. 25 Hz 53 Hz
10 33 Hz 16 Hz 10. 95 Hz 35 Hz 80 Hz 10. 35 Hz 68 Hz
15. 56 Hz 23 Hz 15. 160 Hz 60 Hz 135 Hz 15. 65 Hz 125 Hz
20. 90 Hz 35 Hz 20. 350 Hz 110 Hz 310 Hz 20. 150 Hz 270 Hz
25. 111 Hz 41 Hz 25. 500 Hz 130 Hz 450 Hz 25. 240 Hz 400 Hz
30. 155 Hz 48 Hz 30. 1000 Hz 165 Hz 900 Hz 30. 600 Hz 900 Hz
35. 179 Hz 54 Hz 35. 2200 Hz 192 Hz 2000 Hz 35. 1500 Hz 2000 Hz
41. 200 Hz 54 Hz 41. 5000 Hz 200 Hz 5000 Hz 41. 5000 Hz 5000 Hz

9
14

15
audio precision charts
rage2500.1
Color
Sweep Trace Line Style Thick Data Axis Comment Cursor1 Cursor2
1 1 Magenta Solid 25 Anlr.THD+N Ratio Left .. ..
MODEL-------------RAGE2500.1
LOAD-----------------1 Ohms FITER=20K% GAIN TO MAX
VOLTAGE-----------14.4 ±0.2V Current: 225A
0.01
10
0.02
0.05
0.1
0.2
0.5
1
2
5
%
1 4k
2 5 10 20 50 100 200 500 1k 2k 2.596k
W
ColorSweep Trace Line Style Thick Data Axis Comment Cursor1 Cursor2
1 1 Magenta Solid 25 Anlr.THD+N Ratio Left .. ..
MODEL-------------RAGE2500.1
VOLTAGE-----------14.4 ±0.2V Current: 126A
0.01
10
0.02
0.05
0.1
0.2
0.5
1
2
5
2 3k
5 10 20 50 100 200 500 1k 2k
1.565k
