Baby Relax Miles DA7319-1BLS User manual

Model No:
UPC CODE:
0-65857-13018-8 (BLACK)
NOTE:
Lot number:
(TAKEN FROM CARTON)
_____________________________________
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
Date of purchase:
_______ / _______ / _______
KEEP FOR FUTURE REFERENCE.
THIS INSTRUCTION BOOKLET
0-65857-17220-1 (BLUE)
0-65857-17224-9 (WHITE)
INSTRUCTION MANUAL
DA7319-1BLS (BLUE)
DA7319-1WS (WHITE)
DA7319-B (BLACK)
DA7319-1G (GREY)
6-Drawer Dresser
DO NOT RETURN PRODUCT TO THE RETAILER.
If a part is missing or damaged, contact our customer
service department. We will replace the part FREE of
charge.
Tel #: [phone]
E-Mail: [e-mail]
0-65857-20603-6 (GREY)

*
*
*
*
*
*
*
*
*
WARNING: Should this product become damaged, and/or components are
broken or missing, DO NOT USE.
CAUTION: Adult assembly required.
Assembly will require two people.
To avoid unnecessary damage, when levelers have been extended, DO NOT drag across surface when
Estimated assembly time: 60 minutes.
CARE, CLEANING AND MAINTENANCE
Dust regularly with a soft, lint-free cloth to prevent soil build-up. A damp cloth may be used occasionally to clean
surface. Dry immediately. Do not use any abrasives that may damage finish. Excessive exposure to sunlight and
extreme changes in temperature and moisture can damage wood furniture.
Check all bolts, screws and fasteners periodically and tighten them if necessary.
1-YEAR LIMITED WARRANTY
Dorel warrants its product to be free from defects in material and workmanship and agrees to remedy any such
defect. This warranty covers 1 year from the date of original purchase from authorized retailers. This warranty is
valid only upon presentation of proof of purchase. This is solely limited to the repair or replacement of defective
furniture components and no assembly labor is included. This warranty does not apply to any product which has
been improperly assembled, subjected to misuse or abuse or which has been altered or repaired in any way. The
warranty does not cover wearing, tearing, fading or splitting of the fabric (where applicable). This warranty gives you
specific legal rights and you may also have other rights which vary from State to State or Province to Province.
DO NOT use power tools.
CUSTOMER SERVICE
You can also contact us by writing to the address listed below. Please include the product model number, color and
a detailed description of your enquiry.
DHP Consumer Services
12345 Albert-Hudon Boulevard, Suite 100
Montreal, Quebec
Canada, H1G 3L1
NOTES AND INSTALLATION
Ensure all parts and components are present before beginning assembly.
Assemble on a soft, smooth surface to prevent damage to the product finish.
Use the wall safety strap provided to secure the unit to the wall.
A Phillips head screw driver is not included.

HARDWARE LIST
123
456
789
10 11 12
13
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G
Ø4 X 25mm
Ø8 X 30mm
LARGE CAM LOCK
26 PCS
LARGE WOOD DOWEL
26 PCS
1/4" x 35mm
LARGE CAM BOLT
26 PCS
SAFETY STRAP
1 KIT
ALLEN KEY
1 PC
BOLT
1 PC
SCREW
26 PCS
Ø6 X 20mm
SMALL WOOD DOWEL
24 PCS
Ø3 X 15mm
SCREW
14 PCS
SMALL CAM BOLT
24 PCS
SMALL CAM LOCK
24 PCS
Ø5/32" x 15mm
BOLT
12 PCS
HANDLE
6 PCS

PARTS LIST
A B C D
E F G H
I J K L
M N O
1 PC
BACK TOP RAIL
1 PC 1 PC
FRONT BOTTOM RAIL
1 PC
1 PC
MIDDLE PANEL FRONT MIDDLE RAIL
2 PCS
BACK BOTTOM PANEL
6 PCS 6 PCS 6 PCS
DRAWER RIGHT SIDE
RIGHT SIDE PANELLEFT SIDE PANEL
DRAWER LEFT SIDE
TOP PANEL
1 PC
DRAWER FRONT
1 PC
DRAWER BOTTOM
1 PC
SUPPORT LEG BACK TOP PANEL
1 PC
DRAWER BACK
6 PCS6 PCS
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 1
Insert large cam bolts (1) into the back top rail (A) and back bottom panel (B) as shown.
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 2
Insert large cam locks (3) and large wood dowels (2) into the middle panel (C).
Attach back top rail (A) and back bottom panel (B) to the middle panel (C) and secure by rotating
the large cam lock (3) 1/2 turn clockwise using a Phillips head screwdriver (not included).
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 3
Insert large cam bolts (1) into the front middle rails (D) and front bottom rail (E) as shown.
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 4
Insert large cam locks (3) and large wood dowels (2) into the middle panel (C) as shown below.
Attach front rails (D & E) to the middle panel (C) and secure by rotating the large cam locks (3) 1/2
turn clockwise using a Phillips head screwdriver (not included).
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 5
Insert large cam bolts (1) into the top panel (F) as shown
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 6
Insert large cam locks (3) and wood dowels (2) into the middle panel (C).
Place the top panel (F) on the assembled unit.
Secure the top panel (F) by rotating large cam locks (3) 1/2-turn clockwise using a Phillips head
screwdriver (not included).
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 7
Insert large cam bolts (1) into the right & left side panels (G & H) as shown.
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 8
Insert large wood dowels (2) and large cam locks (3) into the rails (A, D & E), top panel (F) and
back bottom panel (B).
Attach side panels (G & H) to the assembled unit by rotating the large cam locks (3) 1/2 turn
clockwise using a Phillips head screwdriver (not included).
D
A
E
F
D
B
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 9
Attach support leg (I) to the middle panel (C) with bolt (4) and large wood dowels (2) as shown.
Use Allen key (5) to tighten the bolts.
NOTE- The support leg (I) and side frames (H & G) are equipped with adjustable levelers. Once
assembly is complete and the unit is in the desired location, rotate the adjustable levelers clockwise
or counterclockwise until it rests evenly on the floor.
H
G
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 10
Secure top panel (F) to the back top rail (A) with screws (6) as shown.
Use a Phillips head screwdriver (not included) to tighten the screws.
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 11
Attach back top panel (J) to the assembled frame with round head screws (7).
Use a Phillips head screwdriver (not included) to tighten screws.
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 12
Insert small cam locks (10) into the drawer left side (L) and drawer right side (M).
Insert small cam bolts (8) and small wood dowels (9) into the drawer front (K).
Attach drawer sides (L & M) to the drawer front (K). Secure the drawer sides by rotating small cam
locks (10) 1/2-turn clockwise using a Phillips head screwdriver (not included).
Slide the drawer bottom (N) into the grooves of drawer sides (L & M) and drawer front (K).
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 13
Use a Phillips head screwdriver (not included) to tighten the screws.
Attach drawer back (O) to the drawer sides (L & M) with screws (6).
Attach handle (12) to drawer front (K) with bolts (11).
Use a Phillips head screwdriver (not included) to tighten the bolt.
Repeat steps 12 and 13 to assemble the other drawers.
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

STEP 14
Insert all drawers into the assembled unit.
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

That's it! You've finished assembling your Miles 6-Drawer Dresser!
CAUTION: This unit is intended for use only with the
products and/or maximum weights indicated. Use with
other products and/or products heavier than the
maximum weights indicated may result in instability or
cause possible injury.
Maximum
weight on top
of the dresser
Maximum
weight per
drawer 15
lbs.
DO NOT RETURN PRODUCT TO THE
RETAILER.
If a part is missing or damaged, contact our
customer service department. We will replace
the part FREE of charge.
Tel #: [phone]
E-Mail: [e-mail]
6-Drawer Dresser
DA7319-1BLS / DA7319-1WS / DA7319-B / DA7319-1G

Furniture Wall Safety Strap
A B C D
TOOLS NECESSARY: RUBBER MALLET AND PHILLIPS SCREW DRIVER ARE NOT INCLUDED.
NOTE: 3/8" DRILL BIT AND ELECTRIC DRILL ARE NOT PROVIDED.
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE
USING THIS PRODUCT AND KEEP THESE INSTRUCTIONS FOR
FUTURE REFERENCE. IF YOU HAVE ANY QUESTIONS, PLEASE
CALL OUR CUSTOMER SERVICE NUMBER: 1-800-267-1739
Step 4: CONFIRM THAT THE STRAP IS SECURELY LACED AND LOCKED.
TO MOVE THE FURNITURE AFTER THE SAFETY WALL STRAP HAS BEEN INSTALLED, SIMPLY
REMOVE THE SCREW FROM THE WALL TO LOOSEN THE SAFETY WALL STRAP.
Step 1: ATTACH A MOUNTING BRACKET (A) SECURELY TO THE BACK EDGE OF THE FURNITURE USING THE
SHORT SCREW (D), THROUGH THE SMALLER HOLE.
Step 2: LOCATE THE OTHER MOUNTING BRACKET (A) ON THE WALL OVER A WALL STUD AND 2 INCHES
BELOW THE MOUNTING BRACKET SECURED TO THE BACK OF YOUR UNIT. ATTACH TO THE WALL
STUD USING THE LONG SCREW (C) PROVIDED, THROUGH THE SMALLER HOLE.
Step 3: PLACE THE FURNITURE INTO POSITION SO BOTH MOUNTING BRACKETS ARE VERTICALLY IN LINE.
LACE THE END OF THE SAFETY WALL STRAP (B) THROUGH THE LARGER HOLE IN EACH MOUNTING
BRACKET (A). BRING BOTH ENDS TOGETHER AND SLIDE THE FLAT END THROUGH THE LOCKING
END AND DRAW IT THROUGH UNTIL ALL SLACK IS REMOVED.
MOUNTING BRACKET
4 PCS
SAFETY WALL STRAP
2 PCS
LONG SCREW
2 PCS
SHORT SCREW
2 PCS
WARNING: WHEN UPRIGHT, IT IS POSSIBLE THAT THE FURNITURE
MAY TIP OVER. PLEASE INSTALL THE SAFETY WALL STRAP BEHIND
THE FURNITURE TO ENSURE SAFETY.
