Babyby BBM 7020 User manual

1
Digital Video Baby Monitor EN
Table of Contents
Introduction ......................................................................................................................................................2
Safety instructions and important notes............................................................................................................ 3
Description of the accessories .......................................................................................................................... 5
Description of the baby unit ..............................................................................................................................6
Description of the parent unit............................................................................................................................7
Installation location of the baby unit and parent unit..........................................................................................8
Power source ...................................................................................................................................................8
Using the baby monitor and its functions ..........................................................................................................9
Pairing the baby and parent units ...................................................................................................................18
General information about using the baby monitor..........................................................................................19
Troubleshooting.............................................................................................................................................. 19
Cleaning and maintenance .............................................................................................................................20
Technical specifications .................................................................................................................................. 20
Explanation of symbols used on the product, its accessories and packaging.................................................. 20
Instructions and information about the handling of used packaging ............................................................... 21

Digital Video Baby Monitor
EN
2
Introduction
■ Thank you for selecting the Bayby BBM 7020 Digital Video Baby Monitor. This baby monitor is agreat
child care accessory that enables you to hear your baby when you are not in the same room.
Nevertheless, it is important to understand that it cannot serve as asubstitute for responsible adult
supervision.
■ This baby monitor transmits not only audio but also avideo image thanks to a2.4" colour LCD screen
so that you can more reliably monitor your child.
■ 2.4 GHz wireless technology is utilised for transmitting the audio signal. This ensures quality
transmission up to adistance of 250 m in an open environment. You will be informed about an
exceeded signal range, loss of signal or interference by an alert signal.
■ The encrypted wireless transmission and automatic available channel selection features guarantee
privacy and the peace of mind that you will hear only your child.
■ On the parent unit screen, you may monitor the signal intensity, the battery power level, recharging
status, the volume setting and air temperature in the room in which the baby unit is located.
■ The baby monitor is also equipped with awarning signal indicating low battery power, or that the
minimum or maximum set air temperature has been exceeded.
■ The VOX function enables avoice-activated transmission mode to be set. In this mode, the baby
monitor will always start transmitting when it detects any voice or noise. When no sound is being
transmitted, the baby monitor will automatically switch to the ECO mode. This reduces the transmission
power to ensure power efficient operation and minimisation of radiation.
■ The parent unit may be connected to up to 4 cameras. The camera on the baby unit has anight-vision
function and aswivel joint enables the required camera angle to be set easily.
■ In the event that you need to calm down your baby, you may use the return communication function
and talk back to your child or play a lullaby.
■ Both the parent and baby units are powered using apower adapter or rechargeable Li-Ion batteries.
■ The parent unit is equipped with astable stand and abelt clip for easy carrying.

3
Digital Video Baby Monitor EN
Safety instructions and important notes
■ Before first use, thoroughly read the user'smanual. Keep this user'smanual for future use.
Attention:
This baby monitor meets all relevant standards and its use is safe when all the instructions contained
in this manual are followed.
■ The baby monitor serves to monitor your child when you are not in the same room and cannot
supervise it directly. Nevertheless, it is important to keep in mind that your child'ssafety comes first
and therefore the baby monitor cannot serve as asubstitute for supervision by aresponsible adult.
■ This baby monitor is intended for home (private) use only. It is not intended for commercial purposes.
■ After unpacking the baby monitor and its accessories from the packaging material, place the plastic
bags in asafe location out of the reach of children. In the presence of children, plastic bags may
present asuffocation hazard.
■ Only use the baby monitor with the original adapters that came with it.
■ Never use the baby monitor with accessories that are not approved by the manufacturer.
■ Before connecting the power adapter to apower socket, make sure the voltage stated on its rating
label corresponds to the voltage in the power socket. Position the power cord of the power adapter
so that it will not be tripped over.
■ The baby monitor may only be operated by adults.
■ Children must not play with the baby monitor. Keep the baby monitor, power adapters and rechargeable
batteries out of the reach of children.
■ Before first using the baby monitor, acquaint yourself with its functions and before every use, make
sure that both the baby and parent unit are in working order and that the rechargeable batteries are
not flat when they are used as apower source.
■ Ensure that the baby monitor and the power adapter do not come into contact with hot surfaces or
sharp objects.
■ Do not place the baby monitor in the vicinity of water containers or appliances that are sources of
heat.
■ Do not cover the baby monitor and do not place any items on it.
■ Do not use the baby monitor in an excessively dusty or humid environment. Do not subject it to
extreme temperature changes and electromagnetic fields.
■ Do not submerge the baby monitor and its accessories in water or rinse under running water.
■ Always disconnect the baby monitor from the power socket when not using it, after the batteries have
been recharged and before cleaning it.
■ Do not disconnect the power adapter from the power socket by pulling on the power cord. This could
damage the power cord or the socket. Disconnect the power adapter from the power socket by
pulling on the plug.
■ To power the baby monitor from an internal power source, use rechargeable Li-Ion batteries with the
following specifications: 3.7 V/ 800 mAh / 3.3 Wh.
■ When not using the baby monitor for an extended period of time, remove the batteries.

Digital Video Baby Monitor
EN
4
■ Keep the batteries out of the reach of children as they may present ahazard to achild.
■ Do not attempt to short circuit or break the battery or throw it into afire. Do subject the battery to
direct sunlight, fire, etc.
■ Do not make any alterations to the baby monitor that would change its electrical or mechanical
properties.
■ The baby monitor must not be operated with auxiliary amplifiers of high-frequency power or directional
antennas.
■ Do not use the baby monitor if it is in any way damaged or if the power adapters are damaged.
■ Do not attempt to repair the baby monitor yourself. Have all repairs or adjustments performed at an
authorised service centre. By tampering with the product you risk voiding your legal rights arising from
unsatisfactory performance or quality warranty.
■ We recommend saving the original box, packaging material, receipt and responsibility statement of
the vendor or warranty card for the duration of warranty. It is appropriate to transport the baby monitor
in its original box.

5
Digital Video Baby Monitor EN
Description of the accessories
1
2
3
A
1Parent unit*
2Baby unit*
3Power adapter (2 pcs)
The adapters are identical.
Note*:
Both the parent and baby unit A1andA2come with rechargeable Li-Ion batteries (3.7 V/ 800 mAh /
3.3 Wh).

Digital Video Baby Monitor
EN
6
Description of the baby unit
B
18
9
0
qa
qs
qd
qf
qg
2
3
4
5
6
7
1Antenna
2Infrared LED diodes
3Camera
4Jack for connecting the power adapter
connector
5Night-time LED light
6LED indicator showing that the baby unit is
on and the battery is being charged
7Microphone
8Button for turning the baby unit on and off
9Light sensor
0Loudspeaker (not shown)
it is located at the rear of the baby unit.
qa Battery compartment (not shown)
it is located at the rear of the baby unit.
qs Temperature sensor
qd LED signal indicator
qf Weak battery LED indicator
qg Pairing button (not shown)
it is located at the rear of the baby unit.

7
Digital Video Baby Monitor EN
Description of the parent unit
C
1Antenna
2LED indicator showing that the parent unit is
on and the battery is being charged
32.4" LCD screen
4LED volume level indicators
5MENU/OK button
serves to display Menu items and to
confirm the selection of items in the Menu
or Submenu.
6Power adapter connection socket
7Button for lowering volume or for scrolling
down through Submenu items
8Button for increasing volume or for scrolling
up through Submenu items
9Microphone
0Button for turning the parent unit on and off
qa Button for switching between cameras
qs Button for setting the timer in the range
from 0:30 to 4:00 h
qd BACK button
When selecting items in the main Menu and
Submenu, this button will move you back
one level.
qf Talk back to child button
qg Button for moving left between main Menu
items
qh Button for moving right between main Menu
items
qj Loudspeaker
qk Stand
ql Belt clip
w; Battery compartment
wa Pairing button
MENU
1
0
qj
qk
ql
w;
wa
qa
qs
qd
qf
qg
qh
2
3
4
5
6
7
8
9

Digital Video Baby Monitor
EN
8
Installation location of the baby unit and parent unit
1. Baby unit
■ Locate the baby unit A2on an even, dry and stable surface in the room where you want to monitor
your child. We recommend an elevated location (e.g. chest of drawers or ashelf) at asufficient distance
away from equipment and devices that could cause signal interference.
■ When the baby unit A2is to be powered from the grid, locate it within reach of apower socket. In
order to minimise electro-smog, the baby unit A2should be located at least 1 m away from your child.
■ Turn the camera panel B3so that the camera lens B3covers the area that you wish to monitor.
Attention:
Never locate the baby unit A2or the power adapter A3in the baby'sbed or within the reach of
your child.
2. Parent unit
■ Place the parent unit A1in the room where you will be located. When the parent unit A1is to be
powered from the grid, locate it within reach of apower socket.
Power source
1. External power source and its use
■ To power the baby and parent units A2andA1from an external power source, use only the original
power adapters A3type JF005WR-0500100VH (output 5 V , 1 A).
■ Insert the plug of one of the power adapters A3into the socket B4that is located at the side of the
baby unit A2. Insert the plug of the power adapter A3into apower socket.
■ Insert the plug of the second power adapter A3into the socket C6that is located at the side of the
parent unit A1. Insert the plug of the power adapter A3into apower socket.
Attention:
Before connecting the power adapter A3to apower socket, make sure the voltage stated on its
rating label corresponds to the voltage in the power socket.
2. Internal power source and its use
■ To power the baby and parent units A2andA1using an internal power source, use the supplied
rechargeable Li-Ion batteries (3.7 V/ 800 mAh / 3.3 Wh).
■ Inserting and removing the battery
– For safety reasons, the battery compartment cover Bqa on the baby unit A2is secured by
ascrew. Remove the screw. Take off the cover. Insert the Li-Ion battery into the compartment
Bqa so that the contacts point towards the bottom right corner of the compartment Bqa. Put
the cover back on and secure in place with the screw. To remove the battery from the baby unit
A2, proceed in the reverse sequence.

9
Digital Video Baby Monitor EN
– On the parent unit A1, slide the battery compartment cover Cw; downwards. Insert the Li-Ion
battery into the compartment Cw; so that the contacts point towards the top left corner of the
compartment Cw;. Close the cover. To remove the battery from the parent unit A1, proceed
in the reverse sequence.
■ Charging the battery
– Before first using the baby and parent units A2and A1independently of an external power
source, allow the batteries to fully recharge. Afull charge takes approximately 8 hours. When
the baby and parent units A2andA1are connected to an external power source, the battery
will start charging if correctly placed in the respective compartment. The LED indicator light B6
on the baby unit A2and the LED indicator light C2on the parent unit A1will be lit red.
– You may use the baby and parent units A2and A1while they are charging. When the parent
unit A1is running, you may watch the charging progress on the screen C3.
– When the battery is fully charged, the LED indicator B6andC2will be lit green, when the
respective unit is running, or it will turn off when the respective unit is turned off. When you
disconnect the baby and parent units A2and A1from the power socket after charging them,
you may use them independently of an external power source.
– We do not recommend discharging the battery too much, or otherwise to recharge it when it is
almost fully charged. The optimal temperature for operation and storage of the battery is around
20 °C.
– Battery operation minimises electro-smog which arises due to the effect of alternating electric
and magnetic fields.
– Both units are equipped with asignal indicating an almost flat battery. When the battery inside
the baby unit A2is almost flat, the LED indicator Bqf will start flashing red. The almost flat
status of the parent unit A1is signalled by agreen flashing LED indicator C2and by the symbol
being shown together with amessage "Low Battery" on screen C3. If you do not connect
the baby unit A2and/or the parent unit A1to an external power source for the battery to
recharge, it will turn itself off automatically after acertain time. The LED power indicator B6
and/or C2will turn off.
– If you are planning on not using the baby monitor for an extended period of time, we recommend
that you allow the batteries to discharge to half their capacity, then take them out of the baby
monitor and store them out of the reach of children.
Using the baby monitor and its functions
1. Baby unit
■ Turning on and off
– To turn on the baby unit A2, press and hold button B8for approximately 3 seconds. When it
is turned on, the LED indicator B6will be lit green. If abattery is being charged, the LED
indicator B6will be lit red.
– To turn off the baby unit A2, press button B8and hold it down for approximately 3 seconds.
The turned off state of the baby unit A2is signalled by the LED indicator B6turning off. If
abattery is being charged, the LED indicator B6will be constantly lit red.
– When you have finished using it, always turn off the baby unit A2and disconnect the power
adapter A3from the power socket. When it is charging, disconnect the power adapter A3
from the power socket only when it has finished charging.

Digital Video Baby Monitor
EN
10
■ LED indicator showing that the baby unit is on and the battery is being charged.
– When the LED indicator B6is lit green, it signalises that the baby unit A2is turned on.
– When the battery is being charged, the LED indicator B6will be lit red irregardless of whether
the baby unit A2is on or off.
– When the baby unit A2is turned off and the charging process is complete, the LED indicator
B6will be off.
■ LED signal indicator
– When the baby A2connects with the parent unit A1, the LED indicator Bqd will be lit green.
– The LED indicator Bqd will not be lit when no connection is made or it will turn off when the
connection is interrupted.
– The LED signal indicator Bqd will flash green when the baby unit A2is switched to the pairing
mode.
■ Weak battery LED indicator
– When the battery inside the baby unit A2is almost flat, the indicator Bqf will start flashing red.
■ Night-vision mode
– The baby unit is equipped with eight infrared LED diodes B2, thanks to which it is possible to
see apicture even in complete darkness. The infrared light of the diodes B2is invisible to the
human eye.
– When the light sensor B9detects alow level of ambient light, the LED diodes B2will activate
themselves automatically. In this mode, the screen C3on the parent unit A1will show ablack
and white picture.
■ Night-time LED light
– The night-time LED light B5will turn on automatically when the light sensor B9detects alow
level of ambient light. In the user MENU of the parent unit A1, the automatic lighting function
of the night-time LED light B5can be turned off or the light B5may be turned on permanently.
Amore detailed procedure for setting the night-time LED light B5is described in subchapter
2. Parent unit / night-time light mode
■ Loudspeaker
– Thanks to the integrated loudspeaker B0, you can talk back to your child or play it alullaby.
■ Temperature sensor
– Temperature sensor Bqs senses the temperature in the room in which the baby unit A2is
located. The measured temperature is shown on the screen C3of the parent unit A1.
■ Pairing button
– The baby unit A2is paired with the parent unit A1in advance. Under normal circumstances,
it is not necessary to pair the units. However, in the event that the connection is lost, then it is
necessary to pair the units again in order for the baby monitor to function. Detailed instructions
for pairing the units are provided in chapter Pairing the baby and parent units.

11
Digital Video Baby Monitor EN
2. Parent unit
■ Turning on and off
– To turn on the parent unit A1, press and hold button C0for approximately 3 seconds. When
it is turned on, the LED indicator C2will be lit green. When the battery is almost flat and the
parent unit A1is not connected to an external power source, the LED indicator C2will flash
green. If abattery is being charged, the LED indicator C2will be lit red.
– When the parent unit A1is turned on, the following information and symbols will be shown in
the upper part of the screen C3.
Symbol/
information
Explanation
Signal intensity
Number of lit segments indicates the signal intensity. When no
segment is lit, it means that the baby monitor has no signal.
0:30, 1:00, 1:30,
2:00, 2:30, 3:00,
3:30 or 4:00
Timer, if it is set.
Temperature detected by the baby unit A2, when it is turned on
and when there is aconnection.
Camera number (1 to 4)
Battery power level or charging progress indicator
– When the baby unit A2is turned on and located within signal range, the connection will be
made automatically and the baby monitor will start transmitting audio and video.
– When the baby unit A2is turned off or located outside the signal range, no connection will be
made. The screen C3will show aflashing message "No connect" (no connection) and the
message "Waiting for Connecting..." (waiting for aconnection).
– To turn off the parent unit A1, press button C0and hold it down for approximately 3 seconds.
The turned off state of the parent unit A1is signalled by the LED indicator C2turning off. If
abattery is being charged, the LED indicator C2will be constantly lit red.
– When you have finished using it, always turn off the parent unit A1and disconnect the power
adapter A3from the power socket. When it is charging, disconnect the power adapter A3
from the power socket only when it has finished charging.
■ LED indicator showing that the parent unit is on and the battery is being charged.
– When the LED indicator C2is lit green, it signalises that the parent unit unit A1is turned on
with sufficient battery capacity.
– When the parent unit A1is turned on and the battery is almost flat, the LED indicator C2will
flash green.

Digital Video Baby Monitor
EN
12
– When the battery is being charged, the LED indicator C2will be lit red irregardless of whether
the parent unit A1is on or off.
– When the parent unit A1is turned off and the charging process is complete, the LED indicator
B2will not be lit.
■ LED volume level indicators
– Depending on the volume detected by the baby unit A2, the corresponding number of LED
indicators C4will be lit.
– When all LED indicators C4are turned off, the baby unit A2is not detecting any sound.
■ Setting the volume and turning off audio
– Buttons C7and C8can be used to decrease or increase the volume on the parent unit A1.
When button C7or C8is pressed, the symbol will be shown in the top bar. The number
of segments shown indicates the set volume level that can be set at 5 levels. The symbol will
turn off shortly after the volume is set.
– To turn off the volume on the parent unit A1, repeatedly press button C7until the symbol
appears in the top bar of the screen C3. This symbol will remain in the top bar on the screen
C3while volume is turned off. The volume of the transmitted audio is shown by the LED
indicators C4.
■ Sound alert settings (almost flat batteries or lost connection)
– To set the sound alert that will inform you about the battery being almost flat, proceed as follows.
Press the button Menu/OK C5. The main MENU panel will appear in the bottom part of the
LCD screen C3. Use buttons Cqg and Cqh to scroll through the main Menu items. Select the
item "Alert Ringtone" (sound alert signal).
The Submenu items will appear in the middle of the screen. Use buttons C7and C8to scroll
through the Submenu items. Select the item "Low Battery Alarm" (alarm for almost flat battery)
and confirm the selection by pressing the button Menu/OK C5. The items "On" (activate) and
"Off" (deactivate) will appear on the screen. To activate the alarm, select the item "On" (activate)
and confirm the selection by pressing the button Menu/OK C5. After ashort while, the screen
C3will automatically switch back to the mode for displaying the picture registered by the
camera B3. Now the alarm will be triggered when the battery power level is low. At the same
time, the message "Low Battery" will start flashing and the symbol will appear. To deactivate
the acoustic alarm, proceed in the same way, only select the item "Off" (deactivate).
– To set the acoustic alarm that will inform you about there being no signal between the baby and
parent unit A2and A1, or about the loss of connection between the two, proceed as follows.
Press the button Menu/OK C5. The main MENU panel will appear in the bottom part of the
screen C3. Use buttons Aqg and Aqh to scroll through the main Menu items. Select the item
"Alert Ringtone" (sound alert signal).

13
Digital Video Baby Monitor EN
The Submenu items will appear in the middle of the screen. Use buttons C7and C8to scroll
through the Submenu items. Select the item "No Connect Alert" (alarm for loss of signal) and
confirm the selection by pressing the button Menu/OK C5. The items "On" (activate) and "Off"
(deactivate) will appear on the screen. To activate the alarm, select the item "On" (activate) and
confirm the selection by pressing the button Menu/OK C5. After ashort while, the screen C3
will automatically switch to the mode for displaying the video registered by the camera B3.
Now the acoustic alarm is activated and will be triggered when no connection is made between
the baby and parent units A2and A1or when it is lost. At the same time, the screen C3will
show a flashing message "No connect" (no connection) and the message "Waiting for
Connecting..." (waiting for aconnection). To deactivate the acoustic alarm, proceed in the same
way, only select the item "Off" (deactivate).
Note:
In the event that the acoustic alarm is triggered, you may temporarily pause it by pressing any
button on the front control panel or press button Cqs. The alarm will start again after approximately
3 minutes.
■ Screen brightness settings
– To set the brightness of the screen C3, press the button Menu/OK C5. The main MENU panel
will appear in the bottom part of the screen C3. Use buttons Aqg and Aqh to scroll through
the main Menu items. Select the item "Screen Display" (screen).
The item "Brightness" (brightness) will appear in the middle of the screen. Press the button
Menu/OK C5to enter the screen brightness settings menu. Use buttons C7andC8to select
abrightness level from the menu "Level 1–5" (level 1 to 5). Confirm the selection by pressing
the button Menu/OK C5. After ashort while, the screen C3will automatically switch to the
mode for displaying the video registered by the camera B3.
■ Playback of alullaby
– The loudspeaker on the baby unit A2makes it possible to play alullaby to your child. Press
the button Menu/OK C5. The main MENU panel will appear in the bottom part of the LCD
screen C3. Use buttons Cqg and Cqh to scroll through the main Menu items. Select the item
"Lullabies" (lullabies).

Digital Video Baby Monitor
EN
14
Aselection of 8 lullabies (Lullaby 1–8) and the option "Play All" (play all lullabies) will appear in
the middle of the screen. Use the buttons C7and C8to select asequence number of alullaby
or the option to play all lullabies. Confirm the selection by pressing the button Menu/OK C5.
The options "Play Once" (play once), "Play Repeat" (play repeatedly) and "Stop" (stop playback)
will appear on the screen. Select one of these options and confirm it by pressing the button
Menu/OK C5. After ashort while, the screen C3will automatically switch to the mode for
displaying the video registered by the camera B3. While the lullaby is being played, the symbol
and the sequence number of the lullaby that is being played will appear in the top bar of the
screen C3. To immediately stop playback of the lullaby, select the option "Stop" (stop playback).
■ Setting the VOX function
– The VOX function enables avoice-activated transmission mode to be set. In this mode, the
baby monitor will always start transmitting the picture when it detects any voice or noise. When
no sound is being transmitted, the baby monitor will automatically switch to the ECO mode and
the screen C3will turn off. This reduces the transmission power to ensure power efficient
operation and minimisation of radiation.
– There are 3 sensitivity levels that can may be set or the VOX function may be deactivated. To
set the sensitivity or to turn off the VOX mode, proceed as follows. Press the button Menu/OK
C5. The main Menu panel will appear in the bottom part of the screen C3. Use buttons Cqg
and Cqh to scroll through the main Menu items. Select the item "Voice Sensor" (voice sensor).
– The items "Low" (low sensitivity), "Medium" (medium sensitivity), "High" (high sensitivity) and
"Off" (deactivate the VOX function) will appear in the middle of the screen. To select an item,
use buttons C7and C8and then confirm the selection by pressing button Menu/OK C5.
– When the baby monitor is switched to ECO mode, the screen C3is turned off. Nevertheless,
you may turn on the screen C3for acertain time by pressing any control button on the front
panel of the parent unit A1. The message "ECO mode activated“ (ECO mode activated) will
appear on the screen C3. In the top bar, it will be indicated that the baby monitor has no signal.
The signal will be restored once the baby monitor starts sending and transmitting the picture.
■ Setting air temperature units, the warning signal and the alarm signalling that the minimum or
maximum set temperature is exceeded
– The baby unit A2continuously monitors the air temperature in the room in which it is located.
In the section "Temperature" (temperature) in the main Menu, you may select the unit in which
the air temperature will be shown on screen C3. In this section, you may also set the warning
signal and alarm function, that is triggered when the minimum and maximum temperature that
you set is exceeded.

15
Digital Video Baby Monitor EN
– To set the air temperature units, press the button Menu/OK C5. The main Menu items will
appear on the screen C3. Use the buttons Cqg andCqh to select the item "Temperature"
(temperature).
The items "Scale" (unit), "Minimum" (minimum temperature), "Maximum" (maximum temperature)
and "Alert" (warning signal) will appear in the middle of the screen C3. Use buttons C7and
C8to select the item "Scale" (unit). Confirm the selection by pressing the button Menu/OK
C5. The unit "Celsius" and "Fahrenheit" will appear on the screen C3. Select your preferred
unit and confirm the selection by pressing button Menu/Ok C5. After ashort while, the screen
C3will automatically switch to the mode for displaying the video registered by the camera B3.
Air temperature will be displayed in the top bar in the measuring unit that you set.
– To set an alert for aminimum and/or maximum air temperature level, press the button Menu/
OK C5. The main Menu items will appear on the screen C3. Use the buttons Cqg andCqh
to select the item "Temperature" (temperature).
The Submenu items will appear in the middle of the screen C3. Use buttons C7and C8to
select the item "Minimum" (minimum temperature) or "Maximum" (maximum temperature). Confirm
the selection by pressing the button Menu/OK C5. The minimum temperature can be set in the
range from 0 to 17 °C (32 to 63 °F) and the maximum temperature can be set in the range from
18 to 35 °C (64 to 95 °F). Confirm the minimum or maximum temperature setting by pressing the
button Menu/OK C5. If the temperature in the room falls below the set minimum temperature or
otherwise exceeds the maximum temperature, the message "Temperature too low" (temperature
too low) or "Temperature too high" (temperature too high) will appear on the screen C3.
– To set the acoustic alarm that will be triggered when the temperature exceeds the set level,
proceed in the same way as in the preceding paragraph, only with the difference that in the
section "Temperature" (temperature) select the item "Alert" (alert). Confirm the selection by
pressing the button Menu/OK C5. The items "On" (activate) and "Off" (deactivate) will appear
on the screen. Select the item "On" (activate) and confirm the selection by pressing the button
Menu/OK C5. If prior to this you set the minimum and/or the maximum temperature temperature
and it is exceeded, the message "Temperature too low" (temperature too low) or "Temperature
too high" (temperature too high) will appear on the screen C3and at the same time the acoustic
alarm will be triggered. To deactivate the alert, select the item "Off" (deactivate).
Note:
In the event that the acoustic alarm is triggered, you may temporarily pause it by pressing any
button on the front control panel or press button Cqs. The alarm will start again after approximately
3 minutes.

Digital Video Baby Monitor
EN
16
■ Night-light mode
– In the user MENU it is possible to activate the automatic start night-time LED light function B5.
The night-light B5can be turned off entirely or it ma also be permanently on. When the automatic
light activation function is activated, the night-time LED light B5will turn on automatically when
the light sensor B9detects alow level of ambient light.
– The user setting for the night-time LED light B5is performed as follows. To show the main
MENU items, press the button Menu/OK C5. Use the buttons Cqg andCqh to select the item
"Night Light" (night light).
The items "Off" (deactivate), "On" (activate) and "Auto" (automatic light) will appear in the middle
of the screen C3. Use buttons C7and C8to select your preferred item and confirm the
selection by pressing button Menu/Ok C5. After ashort while, the screen C3will automatically
switch to the mode for displaying the video registered by the camera B3.
■ Language settings
– Alanguage can be set in the user MENU for displaying information on the screen C3.
– Available languages are as follows: English, French, German, Dutch, Spanish, Portuguese,
Italian, Turkish, Russian and Hungarian.
– To show the main MENU items, press the button Menu/OK C5. The main MENU items will
appear on the screen C3. Use the buttons Cqg andCqh to select the item "Language"
(language).
The language menu will appear in the middle of the screen C3. Use buttons C7and C8to
select alanguage and confirm the selection by pressing button Menu/Ok C5. After ashort
while, the screen C3will automatically switch to the mode for displaying the video registered
by the camera B3.
■ Exiting the main MENU
– The last item in the main MENU is Exit (exit the menu). To show the main MENU items, press
the button Menu/OK C5. The main Menu items will appear on the screen C3. Use the buttons
Cqg andCqh to select the item "Exit" (exit the menu).

17
Digital Video Baby Monitor EN
The options "Yes" (yes) and "No" (no) will appear in the middle of the screen C3. Use buttons
C7and C8to select whether you wish to exit the main Menu or not. Confirm the selection by
pressing the button Menu/OK C5.
Note:
To exit the main MENU, you may also use the button BACK Cqd or if you do not press any
button for approximately 7 seconds the screen C3will automatically switch to the mode
displaying video from camera B3.
■ Talk back (talk to the child)
– Press button Cqf and hold it down for as long as you wish to talk to your child. You voice will
be heard from the loudspeaker on the baby unit A2.
■ Digital zoom
– When the baby monitor is turned on, the digital zoom will enable you to zoom into the video
from camera B3.
– To activate the digital zoom mode, hold down button Cqs. The video will zoom in and the symbol
will appear on the top bar of the screen C3. You can use buttons C7and C8to move
the picture up and down and buttons Cqg and Cqh to move it left and right.
– To deactivate the digital zoom mode, hold down button Cqs again.
■ Switching between individual cameras
– If you have multiple cameras (max. 4 cameras) connected to the the parent unit A1, you may
use button Cqa to switch the picture coming from the individual cameras.
■ Setting the timer
– Use button C0to set the timer in the range from 0:30 to 4:00 h. Each time button C0is
pressed, the set time will increase by 30 minutes. The timer may be used, for example, as
areminder of afeeding time, etc. The set time is shown in the top bar of the screen C3. After
the set time has elapsed, an alert will be sounded and the message "Feed time arrives" (feeding
time) will appear on the screen C3.
■ Pairing button
– The parent unit A1is paired with the baby unit A2in advance. Under normal circumstances,
it is not necessary to pair the units. However, in the event that the connection is lost, then it is
necessary to pair the units again in order for the baby monitor to function. Detailed instructions
for pairing the units are provided in chapter Pairing the baby and parent units.
Note:
If when performing user settings, you do not confirm the selection of an item by pressing button C5,
the setting will not be made and after ashort time the display C3will automatically switch to the
video from camera B3display mode.
User settings will remain saved in the memory of the parent unit A1even when it is disconnected
from apower socket or when the battery is removed.
For the purpose of explaining the items that appear on the display, the language of the default settings
was used.

Digital Video Baby Monitor
EN
18
Pairing the baby and parent units
■ The baby unit A2is paired with the parent unit A1in advance. Under normal circumstances, it is
not necessary to pair the units. However, in the event that the connection is lost, then it is necessary
to pair the units again in order for the baby monitor to function. When pairing the baby and parent
units A2and A1, proceed as follows.
■ Make sure that the baby unit A2is turned on and press the pair button Bqg. The LED signal indicator
Bqd will start flashing. This indicates that the baby unit A1has switched to pairing mode.
■ Make sure that the parent unit A1is turned on and press the pair button Cwa. The screen C3will
switch to the pairing menu display mode.
Press UP/Down button to select channel
Press LEFT/Right button to set
Press OK button to entry
Status
CH1 Pair Del NULL
CH2 Pair Del NULL
CH3 Pair Del NULL
CH4 Pair Del NULL
EXIT
■ Use buttons C7and C8to select your preferred channel (CH1 to CH4). Use buttons Cqg and Cqh
to select item "Pair" (pair). Confirm the selection by pressing the button Menu/OK C5. The message
"Pairing..." (pairing) will appear on the screen C3. If the pairing process is successful, the message
"Pairing succeed, CHx is selected. Press OK button to back Menu." will appear on the screen C3.
After amoment, the screen C3will automatically switch to the picture from camera B3display
mode.
Note:
Status "Paired" in the pairing menu display mode means that the camera is successful paired.
■ If the pairing takes longer than 20 seconds, it means that it has not been successful and the message
"Waiting for Connecting..." (waiting for connection) will appear on the screen. Then the parent unit
A1will automatically switch back to the preceding display mode.
■ If you wish to cancel the connection to the baby unit A2or one of the other connected cameras,
proceed in the same way as when pairing, only with the difference that for the camera that you wish
to cancel, select the item "Del" (delete) instead of "Pair" (pair).
Note:
In the same way, you may connect another camera to the parent unit A1or remove it.

19
Digital Video Baby Monitor EN
General information about using the baby monitor
■ Before using the baby monitor for monitoring your child, always check that both the baby and parent
unit A2andA1are in working order, that there is aconnection between the units and that audio
and video is being transmitted.
■ We recommend that you perform all user settings before using the baby monitor for monitoring your
child.
■ To increase the signal range, place the baby unit A2in an elevated location as close as possible to
the door or window.
■ Other radio waves may interfere with the signal transmission. For this reason, do not place the baby
monitor in the vicinity of appliances such as e.g. amicrowave oven or WLAN devices, etc.
■ The following factors may interfere with the signal, reduce its range or affect its quality:
– one of the units is covered,
– other wireless networks, ecological light bulbs,
– obstacles in the signal transmission direction such as furniture, interior and exterior walls of
buildings, trees, etc.,
– weather events such as fog, rain, etc.
Troubleshooting
Problem Solution
No picture Check that the parent unit A1is located within signal range.
Check that the parent unit and baby unit A1and A2are connected to
aworking power socket and that they are turned on. When using an internal
power source, check that the batteries are sufficiently charged.
The parent unit A1may be switched to ECO mode when the VOX function
is activated.
An alert is being
sounded.
The alert may indicated the following:
– loss of signal,
– almost flat battery,
– minimum or maximum set temperature is exceeded,
– time set on the timer has elapsed.
Black and white
The baby monitor is switched to night-vision mode. The light sensor B9
detected alow light intensity level.

Digital Video Baby Monitor
EN
20
Cleaning and maintenance
■ Before cleaning the baby monitor, disconnect it from the power socket. If they become soiled, wipe
the outer parts of the baby monitor and adapters A3with aclean, dry cloth.
■ For cleaning, do not use abrasive cleaning products, solvents, thinners, etc. Never submerge the
baby monitor or its power adapters A3in water or rinse under running water.
Technical specifications
Model number ........................................... BBM 7020
Frequency broadcast band........................ 2 400–2 483.5 MHz
Transmission power................................... 17 dBm
Sensitivity .................................................. –85 dBm
Modulation ................................................ FHSS (Frequency Hopping Spread Spectrum)
Range in open space................................. up to 250 m
Audio transmission ....................................two-way communication
Display type and size ................................. 2.4" LCD
Voltage and power input............................ 5 V , 1 A
Power source ............................................ power adapter, JF005WR-0500100VH
input: 100–240 V , 50/60 Hz, 0.18 A,
output: 5 V , 1 A
or
rechargeable Li-Ion batteries 3.7 V/ 800 mAh / 3.3 Wh
Protection class against injury
by electrical shock (power adapter)............ II
Operating temperature .............................. 0–50 °C
Explanation of symbols used on the product, its accessories
and packaging
This symbol indicates that this appliance meets all the basic requirements of EU directives
related to it.
This symbol indicates that the product has protection class II.
This symbol indicates the polarity of the power cord connectors.
This symbol indicates that it is aproduct that may be used indoors.
LOT. This abbreviation serves to designate the production lot number.
This symbol indicates that the requirements of directive 2011/65/EU (RoHS II) have been met
for limiting the use of certain hazardous substances in electrical and electronic equipment.
