OWNER’S MANUAL
Table of Contents
Important Safeguards ...........................................................Page 2
Expanded View & Hardware .......................................................... 4
Assembly Instructions............................................................... 5
Installing LP Gas Tank.............................................................. 10
Installing Natural Gas Line .......................................................... 10
Operating Instructions.............................................................. 10
Cleaning and Care ................................................................ 12
Limited Warranty ................................................................. 13
Troubleshooting .................................................................. 14
The use and installation must conform with local codes or, in the absence of local codes, with either the
National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1,
or Propane Storage and Handling Code, B149.2, or the Standard for Recreational Vehicles, ANSI A 119.2/
NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP
FOR FUTURE REFERENCE.
If you are assembling this unit for someone else, give this manual to him or her to read and save for
future reference.
Manufactured in China for: RevoAce Inc. Limited
Hong Kong, China
Outdoor LP Gas Barbecue Grill
Model No. GBC1748WRSB-C, GBC1748WBSB-C
.
.
Never operate this appliance unattended.
.
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
.
FOR YOUR SAFETY:
1. Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage.
2. Read the installation, operation, and
maintenance instructions thoroughly
before installing or servicing this
equipment.
3. Failure to follow these instructions could
result in fire or explosion, which could
cause property damage, personal injury, or
death.
4. This instruction manual contains Important
information necessary for the proper
assembly and safe use of the appliance.
5. Read and follow all warnings and
instructions before assembling and using
the appliance.
6. Follow all warnings and instructions when
using the appliance.
7. Keep this manual for future reference.
.
FOR YOUR SAFETY:
1. Do NOT store or use gasoline or other
flammable liquids or vapors in the vicinity
of this or any other appliance.
2. An LP cylinder not connected for use shall
NOT be stored in the vicinity of this or any
other appliance.
If you smell gas -
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
If you have questions or need assistance during assembly,
please call 1-800-694-0013
GBC1748WRSB-WBSB-C-OM-EF-F105
Natural gas conversion kit
(model no. VFK1702W-C)
available at Walmart or
www.Walmart.ca

2
WThis grill is for outdoor use only, and should not be used in a building, garage or any other enclosed area.
WDo NOT operate, light or use this appliance within ten feet (3.05 m) of walls, structures or buildings.
WFor residential use only. This grill is NOT for commercial use.
WThis grill is not intended for and should never be used as a heater. TOXIC fumes can accumulate and cause asphyxiation.
WThis grill is safety certified for use in the United States and/or Canada only. Do NOT modify for use in any other location. Modification will result in a
safety hazard and will void your warranty.
WThis grill, from the factory, is for use with liquid propane (LP) gas only. The conversion to or attempted use of natural gas in this LP gas grill is
dangerous, may cause bodily harm and will void your warranty.
WThis grill, from the factory, is for use with LP gas. The natural gas conversion kit model number VFK1702W-C may be used to convert your grill to
natural gas. The use of any other conversion kit is dangerous, may cause bodily harm and will void your warranty.
WLP gas characteristics:
a. LP gas is flammable and hazardous if handled improperly. Become aware of the characteristics before using any LP gas product.
b. LP gas is explosive under pressure, heavier than air, and settles/pools in low areas.
c. LP gas in its natural state has no odor. For your safety, an odorant is added that smells like rotten cabbage.
d. Contact with LP gas can cause freeze burns to skin.
WNatural gas (NG) characteristics:
a. NG is flammable and hazardous if handled improperly. Become aware of the characteristics before using any NG product.
b. NG is explosive under pressure, heavier than air, and settles/pools in low areas.
c. NG in its natural state has no odor. For your safety, an odorant is added that smells like rotten cabbage.
d. Contact with NG can cause freeze burns to skin.
WApartment dwellers: Check with management to learn the requirements and fire codes for using a LP gas grill in your apartment complex. If allowed,
use outside on the ground floor with a ten foot (3.05 m) clearance from any structure. Do NOT use on or under balconies.
WLP gas cylinder needed to operate. Only cylinders marked “propane” may be used.
WThe LP gas cylinder must be constructed and marked in accordance with the Specifications for LP-gas Cylinders of the U.S. Department of
Transportation (D.O.T.) or the National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods;
and Commission.
WLP gas cylinder must be arranged for vapor withdrawal.
WThe LP gas cylinder must have a listed overfilling prevention device (OPD).
WOnly use LP gas cylinders equipped with a cylinder connection device compatible with the connection for outdoor cooking appliances.
WThe LP gas cylinder must have a cylinder collar to protect the cylinder valve.
WNever use a LP gas cylinder with a damaged body, valve, collar or footing.
WDented or rusted LP gas cylinders may be hazardous and should be checked by your LP gas supplier prior to use.
WThe LP gas cylinder should not be dropped or handled roughly.
WLP gas cylinders must be stored outdoors out of the reach of children and must not be stored in a building, garage or any other enclosed area. Your
cylinder must never be stored where temperatures can reach over 125°F.
WDo NOT insert any tool or foreign object into the valve outlet or safety relief valve. You may damage the valve and cause a leak. Leaking propane may
result in an explosion, fire, severe personal injury or death.
WDo NOT block holes in sides or back of grill.
WNever keep an LP gas cylinder in a hot car or trunk. Heat will cause the gas pressure to increase, which may open the relief valve and allow gas to
escape.
WPlace dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided
with the cylinder valve. Other types of caps or plugs may result in leakage of propane.
WIf grill is not in use, the gas must be turned off at the supply cylinder and disconnected.
WDo NOT store a spare LP gas cylinder under or near this appliance.
WNever fill the cylinder beyond 80 percent full.
WA fire causing serious injury or damage to property may occur if the above is not followed exactly.
WNever attempt to attach this grill to the self-contained LP gas system of a camper trailer, motor home or house.
WNever use charcoal, lighter fluid, lava rocks, gasoline, kerosene or alcohol with this product.
WYour grill has been checked at all factory connections for leaks. Recheck all connections as described in the “Operating Instructions” section, as
shipping can loosen connections.
WCheck for leaks even if your unit was assembled for you by someone else.
WDo NOT operate if a gas leak is present. Gas leaks may cause a fire or explosion.
WYou must follow all instructions in “Checking for Leaks” section before operating. To prevent fire or explosion hazard when testing for a leak:
a. Always perform a leak test before lighting the grill and each time the cylinder is connected for use.
b. No smoking. Do NOT use or permit sources of ignition in the area while conducting a leak test.
c. Conduct the leak test outdoors in a well-ventilated area.
d. Do NOT use matches, lighters, or a flame to check for leaks.
e. The use of alcohol, prescription or non-prescription drugs may impair the consumer’s ability to properly assemble or safely operate the appliance.
f. Strong odors, colds, sinus congestion, etc. may prevent the detection of propane. Use caution and common sense when testing for leaks.
g. Do NOT use grill until any and all leaks are corrected.
LP: If you are unable to stop a leak, disconnect the LP gas supply. Call a gas appliance serviceman or your local LP gas supplier.
NG: If you are unable to stop a leak, turn off the main valve on the NG supply line. Call a gas appliance serviceman or your local NG supplier.
Important Safeguards
Warning

3
WNG: The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system
at pressure in excess of ½ psig (3.5 kpa).
WNG: The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the
gas supply piping system at test pressures equal to or less than ½ psig (3.5 kpa).
WThis grill is designed to operate at an inlet pressure of: LP gas: 11 inches water column; NG: 7 inches water column.
WDo NOT store or use gasoline or other flammable liquids or vapors within 25 feet (7.62 m) of this appliance.
WDo NOT use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
WMinimum clearance from sides and back of unit to combustible construction is 36 inches (91.4 cm). Do NOT use this appliance under any type of
overhang or roof.
WIt is essential to keep the grill’s valve compartment, burners and circulating air passages clean.
WInspect grill before each use.
WDo NOT alter grill in any manner. Any alteration will void your warranty.
WDo NOT use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
WDo NOT build this model of grill in any built-in or slide-in construction. Ignoring this warning could cause a fire or an explosion that can damage
property and cause serious bodily injury or death.
WThis grill should be thoroughly cleaned and inspected on a regular basis.
WClean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts or leaks, the hose must be replaced prior to
operation.
WUse only the regulator and hose assembly provided. Use only the replacement regulator and hose assembly specified by RevoAce Inc. Limited.
WUse only RevoAce Inc. Limited factory-authorized parts. The use of any part that is not factory-authorized can be dangerous and will void your
warranty.
WDo NOT operate this appliance without reading “Operating Instructions” in this manual.
WDo NOT touch metal parts of grill until they have completely cooled (about 45 min.) to avoid burns, unless you are wearing protective gear (pot holders,
gloves, BBQ mittens, etc.).
WDo NOT install or use in or on boats or recreational vehicles.
WWhen cooking, fire extinguishing materials should be readily accessible. In the event of an oil/grease fire, do NOT attempt to extinguish with water.
Use type BC dry chemical fire extinguisher or smother with dirt, sand or baking soda.
WDo NOT use grill in high winds.
WNever lean over the grill when lighting.
WDo NOT leave a lit grill unattended. Keep children and pets away from grill at all times.
WDo NOT leave grill unattended while preheating or burning off food residue on high. If grill has not been cleaned, a grease fire can occur that may
damage the product.
WDo NOT place empty cooking vessels on the appliance while in operation.
WUse caution when placing anything on the grill while the appliance is in operation.
WDo NOT attempt to move grill when in use. Allow the grill to cool before moving or storing.
WLP gas cylinder must be properly disconnected and removed prior to moving this grill.
WStorage of grill indoors is permissible only if the cylinder is disconnected, removed from the grill and properly stored outdoors.
WAlways open grill lid carefully and slowly as heat and steam trapped within grill can cause severe burns.
WDo NOT attempt to disconnect the gas regulator from the cylinder or any gas fitting while the grill is in use.
WAlways place your grill on a hard, non-combustible, level surface. An asphalt or blacktop surface may not be acceptable for this purpose.
WMove gas hoses as far away as possible from hot surfaces and dripping hot grease.
WKeep all electrical cords away from a hot grill.
WAfter a period of storage and/or nonuse, check for leaks, burner obstructions and inspect for any abrasion, wear or cuts to the hose.
WFailure to open lid while igniting the grill’s burners, or not waiting 5 minutes to allow the gas to clear if the grill does not light, may result in an
explosive flame-up.
WNever operate grill without its heat plates installed.
WAlways use a meat thermometer to ensure food is cooked to a safe temperature.
WUse protective gloves when assembling this product.
WDo NOT force parts together as this can result in personal injury or damage to the product.
WNever cover entire cooking area with aluminum foil.
WDeath, serious injury or damage to property may occur if the above is not followed exactly.
Important Safeguards
Warning

4
Expanded View
Parts List
1Lid Handle G1646-010
2Temperature Gauge B0104-J70
3Warming Rack G1646-020
4Cooking Grid (3) G1646-030
5Lid* G1646-04R
6Heat Plate (4) B0212-005
7Burner (4)* G1646-050
8Grill Body Assembly* G1748-060
9Side Burner Grid B0404-D04
10 Side Burner G1646-070
11 Right Side Shelf G1646-080
12 Control Knob Bezel (5)* G1205-090
13 Control Knob (5) G0900-100
14 Regulator/Hose Assembly* B0308-A18
15 Side Burner Electrode* B0406-001
16 Grease Cup B0219-H08
17 Left Side Shelf G1646-110
18 Bottle Opener* G1349-120
19 Left Cart Frame G1646-130
20 Grease Tray G1646-140
21 Rear Cart Frame Support G1646-150
22 Right Cart Frame G1646-160
23 Foot (2) G1349-170
24 Cart Frame Support Wire (2) G1646-180
25 Lighting Rod* B0223-D04
26 Wheel (2) B0302-FA0
27 LP Gas Tank Retainer Wire G1349-190
28 Axle G1646-200
29 Upper Front Panel G1646-210
30 Lower Front Panel G1646-220
* Pre-assembled
AScrew ST4.8x10 Nickel Plated Phillips Truss Head 2 pcs
BScrew M4x10 Nickel Plated Phillips Truss Head 4 pcs
CScrew M6x20 Nickel Plated Phillips Truss Head 2 pcs
DBolt M6x16 Nickel Plated Phillips Hex Head 14 pcs
EWasher ø6.4 Nickel Plated 6 pcs
FLock Washer ø6.5 Nickel Plated 6 pcs
GPlug Black 1 pc
Tools Required for Assembly (Included)
#2 Phillips Head Screwdriver 1 pc
Parts List
1
16
27
28
17
20 14
3
9
4
4
4
5
10
11
21
22
24
8
29
2
18
15
19
23
7
12
12
13
13
6
30
26
26
25

5
DO NOT RETURN TO PLACE OF PURCHASE.
For assistance, call 1-800-694-0013 toll-free. Please have
your owner’s manual and model number available for
reference.
Note: The model number is printed on a label which can be found on
the inside door, back or side of the cart assembly.
Assembly Tips:
1. Select an area where you will assemble this product. To
protect components, choose a smooth surface that’s free of
cracks or openings.
2. Spread out all parts.
3. Tighten all hardware connections by hand first. Then, before
completing each step, go back and fully tighten all hardware.
Be careful not to over-tighten. That could damage surfaces or
strip threads.
4. For best results, complete each step in the order presented.
To complete assembly you will need:
• (1) Leak detection solution (instructions on how to make the
solution are included in the “Operating Instructions” section of
this manual).
• LP: (1) Precision-filled LP gas grill tank with Acme Type 1
external threaded valve connection (standard grill size).
• NG: (1) Natural gas conversion kit, model number VFK1002W-C
(not included).
Typical assembly is approximately one hour.
Assembly Instructions
DO NOT RETURN TO PLACE OF PURCHASE.
1
Assemble Left Cart Frame
2
Attach Upper Front Panel
4
Assemble Right Cart Frame
3

6
Attach Cart Frame Support Wires
6
Attach Rear Cart Frame Support
5
Attach LP Gas Tank Retainer Wire, Axle and Wheels
8
Attach Feet and Tighten all Screw from Steps 2-5
7
A
Gx 1
Ax 2

7
Attach Temperature Gauge
9
Attach Grill Body Assembly
10
Attach Right Side Shelf
12
Attach Left Side Shelf
11
Dx 4
Ex 4 Fx 4
Note: Leave 5 mm of bolt threads exposed.
Dx 5 Dx 5
Note: Leave 5 mm of bolt threads exposed.

8
Attach Side Burner Valve and Control Knob Bezel
13
Insert Side Burner, Side Burner Grid and Igniter Wire
14
Attach Lid Handle
16
Attach Control Knobs
15
Bx 2
Bx 2
Cx 2
Ex 2 Fx 2

9
Insert Heat Plates and Cooking Grids
17
Insert Warming Rack
18
Natural gas conversion kit (model no.
VFK1702W-C) available at Walmart or
www.Walmart.ca.
Insert Grease Tray and Grease Cup
19

10
To operate, you will need one precision-filled standard grill LP gas tank with external valve threads.
20 lb
9 Kg
17.9 in. / 45.5 cm
12.2 in. / 31 cm
Securing LP Gas Tank
Secure tank by sliding the tank retainer wire over shoulder of LP gas tank.
Inserting LP Gas Tank
Place precision-filled LP gas tank upright into the notches in the right cart frame so the tank
valve is facing the gas line connection.
Connecting LP Gas Tank
1. Before connecting, be sure there is no debris caught
in the head of the LP gas tank, head of the regulator
valve or in the head of the burner or burner ports.
2. Connect regulator/hose assembly to tank by turning
knob clockwise until it stops.
Disconnecting LP Gas Tank
1. Before disconnecting, make sure the LP
gas tank valve is “CLOSED.”
2. Disconnect regulator/hose assembly
from LP gas tank by turning knob
counterclockwise until it is loose.
WCAUTION: LP gas tank must
be properly disconnected and
removed prior to moving this
grill.
3. Place the protective cap cover on the
LP tank and store the tank outdoors
in a well ventilated area out of direct
sunlight.
Checking for Leaks
Burner Connections
1. Make sure the regulator hose and valve connections are securely fastened to the burner and the
tank.
2. Visually check the connection between the burner/venturi tube and orifice.
3. Make sure the burner/venturi tube fits over the orifice.
WWARNING: Failure to inspect this connection or follow these instructions
could cause a fire or an explosion which can cause death, serious bodily
injury or damage to property.
4. Please refer to diagram for proper installation (Figure 1 and 2).
5. If the burner/venturi tube does not rest flush to the orifice, as shown, please contact
1.800.694.0013 for assistance.
Tank/Gas Line Connection
1. Make 2-3 oz. of leak detection solution by mixing one part liquid dishwashing soap with three
parts water.
2. Make sure control knobs are in the “ OFF” position (Figure 3).
3. LP: Connect LP gas tank per “Installing LP Gas Tank” section.
NG: Connect NG main line per “Installing Natural Gas Line” section.
4. LP: Turn LP gas tank valve to “OPEN.”
NG: Turn “ON” natural gas main valve.
Operating Instructions
Figure 1：Main Burners
Burner/
Venturi Tube
LP Gas
Valve with
Orifice
LP Gas
Connection
Figure 3
OFF
ARRÊT
Figure 2: Side Burner
LP Gas
Connection
Valve Soft Pipe
Connection
LP Gas
Valve with
Orifice
Burner/
Venturi
Tube
Installing LP Gas Tank
.
WLP gas tank must be properly disconnected and
removed prior to moving this grill.
CAUTION
Getting More Propane
Need a tank of gas? One option is to try propane exchange. It’s easy, fast, safe, and available
at tens of thousands of conveniently located retail outlets nationwide, which are typically
open nights and weekends. You can purchase a fresh, precision-filled tank or exchange your
empty for a fresh, precision-filled tank. Another option is to have your tank refilled at a refill
station. Be sure to check the hours of operation for the refill station.
Installing Natural Gas Line
Installation should be done by a qualified service person.
WCAUTION: If young children are in the area, a locking valve should be considered.
Connecting Natural Gas Line
1. Before connecting, be sure there is no debris caught in the head of the natural gas line, head of the grill natural gas line or in the head of the
burner or burner ports.
2. Connect grill natural gas line to natural main gas line.
Disconnecting Natural Gas Line
1. Before disconnecting, make sure the natural gas main line valve is “OFF.”
2. Disconnect grill natural gas line from natural gas main line.
X
X

11
5. Spoon several drops of solution, or use a squirt bottle, at all “X” locations (Figures 1 and 3).
a. LP: If any bubbles appear, turn LP gas tank valve to “CLOSED,” reconnect and re-test.
NG: If any bubbles appear, turn natural gas main valve “OFF,” reconnect and re-test.
b. LP: If you continue to see bubbles after several attempts, turn LP gas tank valve to “CLOSED” and disconnect LP gas tank, per “Disconnect LP Gas
Tank” section. Contact 1.800.694.0013 for assistance.
NG: If you continue to see bubbles after several attempts, turn natural gas main valve to “OFF.” Disconnect natural gas line and contact
1.800.694.0013 for assistance.
c. LP: If no bubbles appear after one minute, turn LP gas tank valve to “CLOSED,” wipe away solution and proceed.
NG: If no bubbles appear after one minute, turn natural gas main valve to “OFF,” wipe away solution and proceed.
Operating Instructions (continued)
.
If burner flame goes out during operation,
immediately turn the control knobs to the “ OFF”
position
(a) LP gas tank valve “CLOSED” or
(b) NG main valve “OFF”
and open lid to let the gas clear for 5 minutes before
re-lighting.
CAUTION
.
When cooking, fire extinguishing materials should
be readily accessible. In the event of an oil/grease
fire, use type BC dry chemical fire extinguisher or
smother with dirt, sand or baking soda. Do NOT
attempt to extinguish with water.
Burner
Flame Slight
Yellow
Slight
Blue
Dark
Blue
Figure 6
Operating Main Burners
1. Open lid.
2. Check for obstructions of airflow to the burners. Spiders, insects and webs can clog the burner/venturi tube. A clogged
burner tube can lead to a fire.
3. All control knobs must be in the “ OFF” position (Figure 3).
4. LP: Connect LP gas tank per “Installing LP Gas Tank” section.
NG: Connect NG main line per “Installing Natural Gas Line” section.
5. LP: Turn LP gas tank valve to “OPEN.”
NG: Turn natural gas main valve to “ON.”
6. Push and turn any control knob to (HIGH). The burner should light. If it does not, repeat up to three times.
7. If ignition does not occur in 5 seconds, turn burner control knob “ OFF,” wait 5 minutes, and repeat lighting procedure.
8. If igniter does not light burner, use a lit match secured with the Lighting Rod (included with grill) to light burners. Access
the burners through the cooking grid and heat plates. Position lit match near side of burner (Figure 5).
Important: Always use the Lighting Rod (included) when lighting burners with a match.
9. After lighting, observe the burner flame. Make sure all burner ports are lit and flame height matches illustration (Figure 6).
Note: Each burner lights independently - repeat steps 5-9 for the other burners.
Turning Off
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the LP gas is burned.
3. LP: Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
NG: Keep NG main gas line connected.
Controlling Flare-ups
WCAUTION: Putting out grease fires by only closing the lid is not possible.
1. If a grease fire develops, turn control knobs to the “ OFF” position
(a) LP gas tank valve “CLOSED” or
(b) NG main valve “OFF”
Do NOT use water on a grease fire. This can cause the grease to splatter and could result in serious burns, bodily harm or other damage.
2. Do NOT leave grill unattended while preheating or burning off food residue on (HIGH). If grill has not been cleaned, a grease fire can occur.
Flare-ups are a part of cooking meats on a grill and add to the unique flavor of grilling.
Excessive flare-ups can over-cook your food and be dangerous.
Important: Excessive flare-ups result from the build-up of grease in the bottom of your grill.
If a grease fire occurs, close the lid AND turn the control knob(s) to “ OFF” until the grease burns out. Be careful when opening the lid as sudden flare-ups may occur.
If excessive flare-ups occur, do NOT pour water onto the flames.
Minimize Flare-ups:
1. Trim excess fat from meats prior to cooking.
2. Cook high fat content meats on (LOW) setting or indirectly.
3. Ensure that your grill is on a hard, level, non-combustible surface and the grease is allowed to drain into grease receptacle.
Lighting
WCAUTION: Keep outdoor gas cooking appliance area clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
WCAUTION: Do NOT obstruct the flow of combustion and ventilation air.
WCAUTION: Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire.
WCAUTION: Attempting to light the burner with the lid closed may cause an explosion.
First Use
1. Make sure all labels, packaging and protective films have been removed from the grill.
2. Remove manufacturing oils before cooking on this grill for the first time by operating the grill for at least 15 minutes on (HIGH) with the lid closed.
This will “heat clean” the internal parts and dissipate odors.
Figure 4
X
XX
XX
Operating Side Burner
Note: Side burner can be used while main burners are operating.
Never use side burner as a grill.
WCAUTION: Maximum weight for side burner and side shelf is 33 lbs.
WCAUTION: Using pots larger than 6 quarts in capacity could exceed weight limit of the side burner shelf,
resulting in failure of grill cart components.
WCAUTION: Do NOT lean on the side burner shelf.
WCAUTION: Attempting to light the burner with the lid closed may cause an explosion.
Lighting
1. Open lid.
2. Check for obstructions of airflow to the burners. Spiders, insects and webs can clog the burner/venturi tube. A clogged burner
tube can lead to a fire.
3. Control knob must be in the “ OFF” position
(Figure 3).
4. LP: Connect LP gas tank per “Installing LP Gas Tank” section.
NG: Connect NG main line per “Installing Natural Gas Line” section.
5. LP: Turn LP gas tank valve to “OPEN.”
NG: Turn natural gas main valve to “ON.”
Figure 7
Lighting
Rod
Match
WARNING
Figure 5
Lighting Hook
Match

12
Operating Instructions (continued)
1. Push and turn control knob to (HIGH). The burner should light. If not, repeat up to three times.
2. If ignition does not occur in 5 seconds, turn burner control knob “ OFF,” wait 5 minutes and repeat lighting procedure.
3. If igniter does not light burner, use a lit match secured with the Lighting Rod (included with grill) to light burners. Position the lit match near
side of the burner (Figure 7).
Important: Always use the Lighting Rod (included) when lighting burner with a match.
4. After lighting, observe the burner flame. Make sure all burner ports are lit and flame height matches illustration (Figure 8).
WCAUTION: If burner flame goes out during operation, immediately turn the control knob to the “ OFF” position
(a) LP gas tank valve “CLOSED” or
(b) NG main valve “OFF”
and open lid to let the gas clear for 5 minutes before re-lighting.
Turning Off
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF.”
2. Turn control knob clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the LP gas is burned.
3. LP: Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
NG: Keep NG main gas line connected.
Cooking
1. Open lid and ignite the side burner per “Lighting” instructions.
2. Adjust control knob to desired flame height.
3. Place pan on center of grid.
4. Cook and adjust temperature as needed.
5. Turn grill off per “Turning Off” instructions.
Cleaning Main Burner
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the gas is burned.
3. LP: Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
NG: Disconnect main gas line per “Disconnecting Natural Gas Line” section.
4. Remove cooking grids and heat plates.
5. Remove burners by removing the fasteners, which secure the burners to the grill bottom.
6. Lift burners up and away from gas valve orifice.
7. Disconnect wire from spark electrode.
8. Clean venturi of each burner with small bottle brush or compressed air.
9. Remove all food residue and dirt on burner surfaces.
10. Clean any clogged ports with a stiff wire (such as an opened paper clip).
11. Inspect burners for any damage (cracks or holes). If damage is found, replace with new
burner(s) from manufacturer.
12. Reinstall burners, checking to insure that gas valve orifice is correctly positioned inside
each burner venturi. Also, check position of spark electrode.
13. Replace heat plate(s) and cooking grid(s).
14. LP: Connect LP gas tank per “Installing LP Gas Tank” section.
NG: Connect NG main line per “Installing Natural Gas Line” section.
15. Perform leak test per “Checking for Leaks” section.
Cleaning Surfaces
1. Wipe surfaces clean with mild dishwashing detergent or baking soda mixed with water.
2. For stubborn surfaces, use a citrus-based degreaser and a nylon scrubbing brush.
3. Rinse clean with water.
4. Allow to air dry.
Cleaning Surfaces
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the gas is burned.
3. LP: Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
NG: Disconnect main gas line per “Disconnecting Natural Gas Line” section.
4. Clean all surfaces.
5. Lightly coat the burner(s) and cooking grid(s) with cooking oil to prevent excess rusting.
6. If storing the grill indoors, disconnect the LP tank per “Disconnecting LP Gas Tank” section.
7. Place the protective cap cover on the LP tank and store the tank outdoors in a well-ventilated area out of direct sunlight.
8. If storing the grill indoors, cover the grill and store in a cool dry place.
9. If storing the grill outdoors, cover the grill with a grill cover for protection from the weather.
Cleaning and Care
.
1. This grill should be thoroughly cleaned and
inspected on a regular basis.
2. Abrasive cleaners will damage this product.
3. Never use oven cleaner to clean any part of
grill.
NOTICE
WCAUTION:
1. All cleaning and maintenance should be done when grill is cool and with the fuel supply
disconnected.
2. Do NOT clean any grill part in a self-cleaning oven. The extreme heat will damage the
finish.
3. Do NOT enlarge valve orifices or burner ports when cleaning the valves or burners.
WCAUTION: Unplug rotisserie motor from the outlet when not in use and before cleaning. Allow
to cool before putting on or taking off parts.
Before Each Use:
1. Keep the grill area clean and free from any combustible materials, gasoline, and other flammable vapors and liquids.
2. Do NOT obstruct the flow of the combustion of LP gas and the ventilation of air.
3. Keep the ventilation opening(s) of the LP gas tank area free and clear from debris.
4. Visually check the burner flames to make sure your grill is working properly (Figure 6).
5. See below for proper cleaning instructions.
6. Check for obstructions of airflow to the burners. Spiders, insects and webs can clog the burner/venturi tube. A clogged burner tube can lead to a fire.
Figure 8
Burner Flame Conditions
Use this chart to see if your burners need to be
cleaned.
1-2 in. /
25.4 - 50.8 mm
Normal: Soft blue flames with yellow
tips between 1 in. - 2 in. height.
Needs cleaning: Noisy with hard
blue flames.
Has to be replaced: Wavy with
yellow flames.

13
Limited Warranty
RevoAce Inc. Limited (“RA”) warrants to the original retail purchaser of this product, and to no other person, that if this product is assembled, maintained, and
operated in accordance with the printed instructions accompanying it, then for a period of five (5) years for the burners and one (1) year for all remaining parts
from the date of purchase, all parts in such product shall be free from defects in material and workmanship. RA may require reasonable proof of your date
of purchase. Therefore, you should retain your sales slip or invoice. This Limited Warranty shall be limited to the repair or replacement of parts, which prove
defective under normal use and service and which RA shall determine in its reasonable discretion upon examination to be defective. Before returning any parts,
you should contact RA’s Customer Care Department using the contact information listed below. If RA conforms, after examination, a defect covered by this Limited
Warranty in any returned part, and if RA approves the claim, RA will replace such defective part without charge. If you return defective parts, transportation
charges must be prepaid by you. RA will return replacement parts to the original retail purchaser, freight or postage prepaid. This Limited Warranty does not cover
any failures or operating difficulties due to accident, abuse, misuse, alteration, misapplication, improper installation or improper maintenance or service by you or
any third party, or failure to perform normal and routine maintenance on the product as set out in this owner’s manual. In addition, the Limited Warranty does not
cover damage to the finish, such as scratches, dents, discoloration, rust or other weather damage, after purchase.
This Limited Warranty is in lieu of all other express warranties. RA disclaims all warranties for products that are purchased from sellers other than authorized
retailers or distributors, including the warranty of merchantability or the warranty of fitness for a particular purpose. RA ALSO DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. RA SHALL HAVE
NO LIABILITY TO PURCHASER OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES. RA further disclaims
any implied or express warranty of, and assumes no responsibility for, defects in workmanship caused by third parties. This Limited Warranty gives the purchaser
specific legal rights; a purchaser may have other rights depending upon where he or she lives. Some jurisdictions do not allow the exclusion or limitation of
special, incidental or consequential damages, or limitations on how long a warranty lasts, so the above exclusion and limitations may not apply to everyone.
RA does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or
replacement of its equipment, and no such representations are binding on RA.
RevoAce Inc. Limited
Hong Kong, China
1.800.694.0013

14
Troubleshooting
Problem Possible Cause Prevention/Cure
Burner will not light using ignitor
LP gas tank valve is closed
NG main valve is closed
LP: Make sure regulator is securely attached to the LP gas tank per “Installing
LP Gas Tank,” then turn LP gas tank valve to “OPEN”
NG: Make sure regulator and NG main line are securely attached per “Installing
Natural Gas Line,” then turn NG main valve to “ON”
LP gas tank is low or empty Exchange, refill or replace LP gas tank
LP gas / NG leak
1. LP: Turn LP gas tank valve to “CLOSED”
NG: Turn natural gas main valve to “OFF”
2. Wait 5 minutes for gas to clear
3. Follow “Checking for Leaks” section
Battery needs to be changed Replace the “AA” battery (follow assembly step for inserting battery)
Wires or electrode covered with cooking residue Clean wire and/or electrode with rubbing alcohol
Electrode and burners are wet Wipe dry with cloth
Electrode cracked/broken - sparks at crack Replace electrode
Wire loose or disconnected Reconnect wire or replace electrode/wire assembly
Wire is shorting (sparking) between ignitor and electrode Replace ignitor wire/electrode assembly
Bad ignitor Replace ignitor
Burner will not light with match
No gas flow
LP: Check if LP gas tank is empty
A. If empty, exchange, refill or replace LP gas tank
B. If LP gas tank is not empty, refer to “Sudden drop in gas flow or reduced
flame height” (see below)
NG: Check if NG main valve is connected
A. Make sure regulator and NG main line are securely attached, then turn NG
main valve to “OPEN”
B. If NG main valve is “ON,” then refer to “Sudden drop in gas flow or reduced
flame height” (see below)
LP gas tank is low or empty Exchange, refill or replace LP gas tank
LP gas / NG leak
1. LP: Turn LP gas tank valve to “CLOSED.”
NG: Turn natural gas main valve to “OFF”
2. Wait 5 minutes for gas to clear
3. Follow “Checking for Leaks” section
Coupling nut and regulator not fully connected Turn the coupling nut about one-half to three quarters additional turn until solid
stop. Tighten by hand only - do NOT use tools.
Obstruction of gas flow 1. Clear burner tubes
2. Check for bent or kinked hose
Disengagement of burner to valve Reengage burner and valve
Spider webs or insect nest in venturi Clean burner/venturi tube
Burner ports clogged or blocked Clean burner ports
Sudden drop in gas flow or reduced flame height
LP: Out of gas Exchange, refill or replace LP gas tank
NG: No main line pressure Call your natural gas provider to inspect natural gas line
LP: Overfilling prevention device may have been
activated
1. Turn control knobs to “ OFF”
2. Wait 30 seconds and light grill
3. If flames are still too low, reset the overfilling prevention device:
a. Turn control knob(s) “ OFF”
b. Turn LP gas tank valve to “CLOSED”
c. Disconnect regulator
d. Turn control knobs to (HIGH)
e. Wait 1 minute
f. Turn control knobs to “ OFF”
g. Reconnect regulator and leak check connections, being careful not to
fully open valve
h. Light grill per “Lighting” section
Irregular flame pattern, flame does not run the
full length of burner Burner ports are clogged or blocked Clean burner ports
Flame is yellow or orange
New burner may have residual manufacturing oils Burn grill for 15 minutes on (HIGH) with the lid closed
Spider webs or insect nest in venturi Clean venturi
Food residue, grease, etc. on burners Clean burner
Poor alignment of valve to burner/venturi tube Ensure burner/venturi tube is properly engaged with valve
Flame goes out
High or gusting winds Do not use grill in high winds
Low on LP Gas Exchange, refill or replace LP gas tank
Overfilling prevention device may have been activated Refer to “Sudden drop in gas flow or reduced flame height” (see above)
Flare-up
Grease buildup Remove and clean all grill parts per “Cleaning and Care” section
Excess fat in meat Trim fat from meat before grilling
Excessive cooking temperature Adjust to lower cooking temperature
Persistent grease fire Grease trapped by food buildup around burner system
1. Turn control knobs to “ OFF”
2. LP: Turn LP gas tank valve to “CLOSED”
NG: Turn natural gas main valve to “OFF”
3. Leave lid in closed position and let fire burn out
4. After grill cools, remove and clean all parts per “Cleaning and Care” section
Flashback (fire in burner tube(s)) Burner and/or burner/venturi tube are blocked Clean burners and/or burner/venturi tube(s)
Inside of lid is peeling (like paint peeling) The lid is coated/painted Grease buildup has turned to carbon and is flaking off – clean thoroughly per
“Cleaning and Care” section

15

16

16

15
Guide de dépannage (suite)
Problème Cause possible Prévention/mesure correctrice
La flamme s’éteint.
Vent fort ou bourrasques. Ne pas utiliser le barbecue les jours de vent fort.
La bouteille de propane est presque vide. Échangez, remplissez ou remplacez la bouteille de propane.
La soupape de limitation de débit s’est peut-être
déclenchée.
Reportez-vous aux instructions du paragraphe « Baisse soudaine du débit du
propane ou hauteur réduite de flamme » (voir ci-dessus).
Flambée soudaine.
Accumulation de graisse. Retirez et nettoyez toutes les pièces du barbecue en suivant les instructions
« Nettoyage et entretien » du manuel d’utilisation.
La viande est trop grasse. Éliminez la graisse de la viande avant de la griller.
La température de cuisson est trop élevée. Réglez à la baisse la température.
Feu de graisse persistant. Graisse piégée par accumulation de nourriture autour
des brûleurs.
1. Tournez les boutons de commande sur « ARRÊT ».
2. PROPANE (GPL) : Fermez le gaz en réglant le robinet de la bouteille de
propane sur « CLOSED » (fermé).
GAZ NATUREL (GN) : Fermez le gaz au niveau de la conduite principale
d’alimentation en gaz naturel en réglant le robinet sur « OFF » (fermé) .
3. Laissez le couvercle fermé et laissez le feu se consumer.
4. Une fois que le barbecue a refroidi, retirez et nettoyez toutes les pièces du
barbecue en suivant les instructions « Nettoyage et entretien » du manuel
d’utilisation.
Retour de flammes (feu dans le ou les tubes de
brûleurs). Le brûleur et/ou ses tubes sont bouchés. Nettoyez le brûleur et/ou les tubes du brûleur.
L’intérieur du couvercle s’écaille comme de la
peinture. Le couvercle est peint.
L’accumulation de graisse cuite s’est transformée en carbone et s’écaille.
Nettoyez rigoureusement le couvrecle en suivant les instructions « Nettoyage et
entretien » du manuel.

14
Guide de dépannage (suite)
Problème Cause possible Prévention/mesure correctrice
Le brûleur ne s’allume pas en utilisant l’allumeur
électrique.
Le robinet de la bouteille de propane est fermé.
Le robinet de la conduite principale d’alimentation en
gaz naturel est fermé.
PROPANE (GPL) : Assurez-vous que le régulateur est solidement fixé à la
bouteille de propane en suivant les instructions « Installer la bouteille de
propane » puis ouvrez le gaz en tournant le robinet de la bouteille de propane
sur « OPEN » (ouvert).
GAZ NATUREL (GN) : Assurez-vous que le régulateur est solidement fixé à la
conduite principale d’alimentation en gaz naturel en suivant les instructions
« Installation de la conduite principale d’alimentation en gaz » puis ouvrez le gaz
en tournant le robinet de la conduite principale sur « ON » (ouvert).
La bouteille de propane est vide ou presque vide. Échangez, remplissez ou remplacez la bouteille de propane.
Il y a une fuite de propane ou de gaz naturel.
1. PROPANE (GPL) : Fermez le gaz en tournant le robinet de la bouteille de
propane sur « CLOSED » (fermé).
GAZ NATUREL (GN) : Fermez le gaz en tournant le robinet de la conduite
principale d’alimentation en gaz naturel sur « OFF » (fermé).
2. Attendez 5 minutes pour que le gaz se dissipe.
3. Suivez les instructions du chapitre « Détecter une fuite » du manuel.
La pile doit être remplacée. Remplacez la pile « AA » (voir les instructions pour insérer la pile).
Les fils ou l’électrode sont recouverts de résidus de
cuisson.
Nettoyez le fil conducteur et/ou l’électrode avec de l’alcool isopropylique.
L’électrode et les brûleurs sont mouillés. Essuyez avec un chiffon sec.
L’électrode est fendue ou brisée, des étincelles
apparaîssent au niveau de la fente.
Remplacez l’électrode.
Le fil est desserré ou déconnecté. Reconnectez le conducteur ou remplacez l’ensemble électrode-fil conducteur.
Court-circuit (étincelles) du fil conducteur entre
l’allumeur et l’électrode.
Remplacez l’ensemble électrode-fil conducteur.
Allumeur défectueux. Remplacez l’allumeur.
Le brûleur ne s’allume pas avec une allumette.
Absence de gaz.
PROPANE (GPL) : Vérifiez si la bouteille de propane est vide.
A. Si elle est vide, échangez-la, remplissez-la ou remplacez-la.
B. Si la bouteille n’est pas vide, reportez-vous aux instructions “Baisse
soudaine du débit du propane ou hauteur réduite de flamme.” (voir ci-
dessous).
GAZ NATUREL (GN) : Vérifiez que le robinet de la conduite principale
d’alimentation en gaz naturel est raccordé.
A. Assurez-vous que le régulateur est solidement raccordé à la conduite
principale d’alimentation en gaz naturel, ouvrez le gaz en tournant le
robinet de la conduite sur « OPEN » (ouvert).
B. Si le robinet de la conduite principale d’alimentation en gaz naturel est
ouvert (ON), reportez-vous aux instructions « Baisse soudaine du débit du
propane ou hauteur réduite de flamme » (voir ci-dessous).
La bouteille de propane est vide ou presque vide. Échangez, remplissez ou remplacez la bouteille de propane.
Il y a une fuite de propane ou de gaz naturel.
1. PROPANE (GPL) : Tournez le robinet de la bouteille de propane sur
« CLOSED » (fermé).
GAZ NATUREL (GN) : Tournez le robinet de la conduite principale
d’alimentation en gaz naturel sur « OFF » (fermé).
2. Attendez 5 minutes pour que le gaz se dissipe.
3. Suivez les instructions du chapitre « Détecter une fuite » du manuel.
L’écrou de couplage et le régulateur ne sont pas
complètement raccordés.
Tournez l’écrou de couplage viron un demi ou trois quart de tour de plus jusqu’à
l’arrêt complet. Serrez manuellement sans utiliser d’outils.
Obstruction du débit de gaz. 1. Nettoyez les tubes des brûleurs.
2. Assurez-vous que le tuyau n’est pas plié ou déformé.
Le brûleur n’est plus raccordé à la valve. Raccordez à nouveau le brûleur et la valve.
Araignées ou insectes dans le venturi. Nettoyez le venturi et le tube du brûleur.
Les orifices du brûleur sont bouchés ou bloqués. Nettoyez les orifices du brûleur.
Baisse soudaine du débit de propane ou hauteur
réduite de flamme.
PROPANE (GPL) : Il n’y a plus de gaz. Échangez, remplissez ou remplacez la bouteille de propane.
GAZ NATUREL (GN) : Pas de pression au niveau de la
conduite.
Contactez votre fournisseur de gaz naturel afin qu’il vienne inspecte la conduite
de gaz naturel.
PROPANE (GPL) : La soupape de limitation de débit s’est
peut-être déclenchée.
1. Tournez les boutons de commande sur « ARRÊT ».
2. Attendez 30 secondes puis allumez le barbecue.
3. Si les flammes demeurent trop basses, réarmez le dispositif de sécurité de
limitation de débit:
a. Tournez le(s) bouton(s) de commande sur « ARRÊT ».
b. Tournez le robinet de la bouteille de propane sur « CLOSED » (fermé).
c. Débranchez le régulateur.
d. Tournez les boutons de commande sur (max).
e. Attendez 1 minute.
f. Tournez les boutons de commande sur « ARRÊT ».
g. Rebranchez le régulateur et assurez-vous que le raccord ne présente
pas de fuite en veillant à ne pas complètement ouvrir le robinet.
h. Allumez le barbecue en suivant les instructions d’allumage « Pour
allumer ».
Flamme irrégulière, flamme ne se répartissant
pas sur toute la longueur du brûleur. Les orifices du brûleur sont bouchés ou bloqués. Nettoyez les orifices du brûleur.
La flamme est jaune ou orange.
Le nouveau brûleur peut contenir des huiles résiduelles
de fabrication. Laissez le barbecue fonctionner pendant encore 15 minutes sur (max) avec le
couvercle fermé.
Toiles d’araignées ou nid d’insectes dans le venturi. Nettoyez le venturi.
Résidus de nourriture, de graisse, etc. Nettoyez le brûleur.
Mauvaise alignement de la valve sur le venturi du
brûleur.
Vérifiez que le venturi du brûleur est correctement raccordé à la valve.

13
Nettoyage et entretien (suite)
La société RevoAce Inc. Limited(« RA ») garantit cet article au premier acheteur au détail et à aucune autre personne, contre tout vice de matériau et de fabrication
pour une période de cinq (5) ans pour les brûleurs et d’un (1) an pour toutes les autres pièces à partir de la date d’achat si cet article est monté et utilisé
conformément aux instructions fournies. RA vous demandera sans doute une preuve raisonnable d’achat datée, veuillez donc conserver votre facture ou votre
reçu. Cette garantie limitée se limitera à la réparation ou au remplacement de pièces ayant été déterminées défectueuses par RA lors de conditions d’utilisation
et d’entretien normales. Avant de renvoyer une pièce, contactez le service à la clientèle de RA. Si RA conárme le défaut de fabrication et approuve la réclamation,
ce dernier remplacera gratuitement les dites pièces. Si vous devez renvoyer des pièces défectueuses, les pièces devront être expédiés port-payé. RA s’engage à
renvoyer les pièces à l’acheteur portpayé.Cette garantie limitée ne couvre pas les pannes et dysfonctionnements survenant suite à tout accident, mauvais usage,
entretien incorrect de cet article, ou toute modiácation, mauvaise installation ou négligence comme il a été établi dans ce manuel. De plus, cette garantie limitée ne
couvre pas les dommages au áni, à savoir les rayures, les bosses, les traces de décoloration, de rouille ou les dommages résultant des intempéries après achat de
l’article.
Cette garantie remplace toute autre garantie expresse et il n’existe aucune autre garantie expresse à l’exception de la couverture indiquée ici. RA désavoue
toute garantie couvrant des produits ayant été achetés auprès de revendeurs autres que les revendeurs et distributeurs agréés y compris toute garantie de
commerciabilité et d’adaptation à un usage particulier. RA DÉCLINE ÉGALEMENT TOUTE GARANTIE IMPLICITE Y COMPRIS TOUTE GARANTIE DE COMMERCIABILITÉ
ET D’ADAPTATION À UN USAGE PARTICULIER. RA NE POURRA ÊTRE TENU RESPONSABLE PAR L’ACHETEUR OU UN TIERS POUR TOUS DÉGÂTS ET DOMMAGES
PARTICULIERS, INDIRECTS, PUNITIFS OU CONSÉCUTIFS. De plus, RA désavoue toute garantie expresse ou implicite et décline toute responsabilité en cas de
défaut de fabrication causés par un tiers.Cette garantie limitée octroie des droits spéciáques à l’acheteur reconnus par la loi et il est possible que ce dernier en
possède d’autres selon sa localité. Certaines juridictions ne permettent pas l’exclusion ni la limitation de dommages consécutifs ou accessoires ni la limitation
en temps d’une garantie et ces limitations peuvent ne pas être applicables à tous. RA ne permet en aucun cas à une personne ou à une société de s’attribuer les
responsabilités et les obligations liées à la vente, l’installation, l’utilisation, la dépose ou le remplacement de cet article, et aucune de ces représentations n’engage
la responsabilité de RA.
RevoAce Inc. Limited
Hong Kong, China
1.800.694.0013
Nettoyage des brûleurs principaux
1. PROPANE (GPL) : Fermez le gaz en réglant le robinet de la bouteille de propane sur « CLOSED » (fermé).
GAZ NATUREL (GN) : Fermez le gaz au niveau de la conduite principale d’alimentation en gaz naturel en réglant le robinet sur « OFF » (fermé) .
2. Tournez tous les boutons de commande dans le sens des aiguilles d’une montre afin de les régler sur « ARRÊT ».
Remarque : Vous entendrez un son étouffé, ceci est normal, il s’agit du reste du gaz venant de se consumer.
3. PROPANE (GPL) : Débranchez la bouteille de propane en suivant les instructions
« Débrancher la bouteille de propane ».
GAZ NATUREL (GN) : Débranchez la conduite principale d’alimentation en gaz naturel en suivant les instructions « Débrancher le tuyau de gaz naturel ».
4. Retirez les grilles de cuisson et les diffuseurs de chaleur.
5. Retirez les brûleurs en retirant les dispositifs de fixation retenant le brûleur à la partie inférieure du barbecue.
6. Soulevez et éloignez les brûleurs de l’orifice de la valve de gaz.
7. Déconnectez le fil de l’électrode d’allumage.
8. Nettoyez le venturi de chaque brûleur avec un petit goupillon ou de l’air comprimé.
9. Nettoyez les restes de nourriture et la saleté de la surface du brûleur.
10. Nettoyez les orifices bouchés avec un fil métallique (un trombone ouvert, par exemple).
11. Vérifiez les brûleurs à la recherche de détériorations (fissures ou trous). En cas de détériorations, remplacez le brûleur endommagé par un brûleur neuf du même fabricant.
12. Réinstallez les brûleurs, vérifiez que les orifices de la valve de gaz sont correctement positionnés à l’intérieur du venturi de chaque brûleur. Vérifiez également la position de l’électrode
d’allumage.
13. Remettez en place les diffuseurs de chaleur et les grilles de cuisson.
14. PROPANE (GPL) : Branchez la bouteille de propane en suivant les instructions « Brancher la bouteille de propane ».
GAZ NATUREL (GN) : Branchez la conduite principale d’alimentation en gaz naturel en suivant les instructions « Installation de la conduite principale d’alimentation en gaz naturel ».
15. Reportez-vous au chapitre « Détecter une fuite ».
Nettoyage du brûleur latéral
1. PROPANE (GPL) : Fermez le gaz en réglant le robinet de la bouteille de propane sur
« CLOSED » (fermé).
GAZ NATUREL (GN) : Fermez le gaz au niveau de la conduite principale d’alimentation en
gaz naturel en réglant le robinet sur « OFF » (fermé) .
2. Tournez tous les boutons de commande dans le sens des aiguilles d’une montre afin de
les régler sur « ARRÊT ».
Remarque : Vous entendrez un son étouffé, ceci est normal, il s’agit du reste du gaz venant
de se consumer.
3. PROPANE (GPL) : Débranchez la bouteille de propane en suivant les instructions
« Débrancher la bouteille de propane ».
GAZ NATUREL (GN) : Débranchez la conduite principale d’alimentation en gaz naturel en
suivant les instructions « Débrancher le tuyau de gaz naturel ».
4. Retirez les grilles de cuisson et les diffuseurs de chaleur.
5. Retirez le brûleur en retirant les vis retenant le brûleur à la tablette latérale.
6. Soulevez et éloignez les brûleurs de l’orifice de la valve de gaz.
7. Nettoyez le venturi de chaque brûleur avec un petit goupillon ou de l’air comprimé.
8. Nettoyez les restes de nourriture et la saleté de la surface du brûleur.
9. Nettoyez les orifices bouchés avec un fil métallique (un trombone ouvert, par exemple).
10. Vérifiez les brûleurs à la recherche de détériorations (fissures ou trous). En cas de
détériorations, remplacez le brûleur endommagé par un brûleur neuf du même fabricant.
11. Réinstallez le brûleur, vérifiez que les orifices de la valve de gaz sont correctement
positionnés à l’intérieur du venturi de chaque brûleur. Vérifiez également la position de
l’électrode d’allumage.
12. Remettez en place la (les) grille(s) de cuisson.
13. PROPANE (GPL) : Branchez la bouteille de propane en suivant les instructions « Brancher
la bouteille de propane ».
GAZ NATUREL (GN) : Branchez la conduite principale d’alimentation en gaz naturel en
suivant les instructions « Installation de la conduite principale d’alimentation en gaz
naturel ».
14. Effectuez le test d’étanchéité afin de vous assurer que le raccord ne présente pas de fuite.
Reportez-vous au chapitre « Détecter une fuite ».
Avant le remisage
1. PROPANE (GPL) : Fermez le gaz en réglant le robinet de la bouteille de propane sur
« CLOSED » (fermé).
GAZ NATUREL (GN) : Fermez le gaz au niveau de la conduite principale d’alimentation en
gaz naturel en réglant le robinet sur « OFF » (fermé) .
2. Tournez tous les boutons de commande dans le sens des aiguilles d’une montre afin de
les régler sur « ARRÊT ».
Remarque : Vous entendrez un son étouffé, ceci est normal, il s’agit du reste du gaz venant
de se consumer.
3. PROPANE (GPL) : Débranchez la bouteille de propane en suivant les instructions
« Débrancher la bouteille de propane ».
GAZ NATUREL (GN) : Débranchez la conduite principale d’alimentation en gaz naturel en
suivant les instructions « Débrancher le tuyau de gaz naturel ».
4. Nettoyez toutes les surfaces du barbecue.
5. Pour aider à lutter contre la rouille, appliquez une légère couche d’huile de cuisson sur les
brûleurs.
6. Si vous comptez remiser le barbecue à l’intérieur, débranchez la bouteille de propane et
reportez-vous au chapitre « Débrancher la bouteille de propane ».
7. Placez le capuchon protecteur sur la bouteille de propane et entreposez la bouteille à
l’extérieur dans un endroit largement aéré et à l’abri des rayons direct du soleil.
8. Si vous comptez entreposer le barbecue à l’intérieur, recouvrez le barbecue avec une
housse et rangez-le dans un endroit frais et sec.
9. Si vous remisez le barbecue à l’extérieur, couvrez le barbecue avec une housse de
barbecue pour la protéger des intempéries.
Garantie limitée
