USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 2
$
$$
$
This USB2.0 to IDE 3.5” hard disk enclosure provides an easy to carry and
flexible interface solution for people to add more storage space to PC.
This device supports both USB 2.0 standard compliance interface, enables people
to easily connect to Desktop PC or Notebook or Mac computer without opening
cover.
%&
%& %&
%&
Hardware:
USB2.0 to IDE 3.5” hard disk enclosure
Power adaptor (DC-12V)
USB 2.0 A-B cable
Warranty Card
Screws
Software:
Driver software CD
User’s Manual
%
%%
%
USB specification revision 2.0 compliant
Fully backward-compatible with USB 1.1 devices
USB Mass Storage Class Bulk-Only Specification (Version 1.0)
Plug and Play Hot-swapping capability
Portable 3.5” hard disk, easy way to backup files
'
''
' () *+)
() *+) () *+)
() *+)
PC
IBM PC 486DX4-100 MHz or higher or compatible system
Available USB port
CD-ROM drive
Windows
®
98SE, Windows
®
ME, Windows
®
2000 or Windows
®
XP
MAC
Power PC G3, G4, or i-Mac
Available USB port
CD-ROM drive
Mac OS 8.6 or higher
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 3
%")
%") %")
%")
USB 1.1/2.0
Connect LED
Power Jack
Power/
DATA Access LED
USB Jack
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 4
-
--
- .
..
.
6.1 Follow the steps below to install 3.5” hard disk.
6.2 Remove the rubber pad and release the screws, then open the USB Hard disk
enclosure (Figure 1 ~ 2)
Figure 1 Figure 2
6.3 Assemble the 3.5” hard disk with the PCB and fasten the screws. (Figure 3~ 4)
Figure 3 Figure 4
6.3Close the hard disk enclosure (Figure 5~6)
Figure 5 Figure 6
6.4Close the hard disk enclosure and fasten the screws.
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 5
Figure 7 Figure 8
Figure 9
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 6
/
//
/0
00
0
/$6 7
8
41
7.1.1 Connect the USB port of USB2.0 to IDE 3.5” hard disk enclosure to PC
with USB cable.
7.1.2 The “Add New Hardware Wizard” dialog box will appears as below, click
“Next” to continue.
7.1.3 Choose “Search for the best driver for your device (Recommended)”
then click “Next”.
7.1.4 Select “Specify a location” and type D:\DRIVER\BF-2003\WINDOWS (D:
represents CD-ROM) in the dialog box, then click “Next”
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 7
7.1.5 Windowswill search the driver for this device. Make sure the driver that
Windowsfound is “D:\DRIVER\BF-2003\WINDOWS\TPP300.INF” then
click “Next”.
7.1.6 Click “Finish” to complete the installation procedure of “BAFO USB
Storage Adapter”
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 8
7.1.7 Connect the USB port of USB2.0 to IDE 3.5” hard disk enclosure to PC
with USB cable. System will auto detect the device and load the driver
then create a new device and name of “(E:)” at desktop as shown below.
7.1.8 After Windows
®
installed all the driver, you have to check “My
Computer”-“Control Panel”-“System”-”Device Manager” to make sure
the driver has already installed. Then, in the “Disk Drives” it will show a
“FUJITSU MHM2050AT” (This model number will vary with different
Hard Disk),in the “Hard disk controllers” it will show a “BAFO Storage
Adapter Bridge Module”, and in the “Universal Serial Bus controller” it
will show a new item of “BAFO USB Storage Adapter ”
.
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 9
/
//
/ 6 7
6 7 6 7
6 7
8
88
8
41
4141
41
7.2.1 Click on “Add/Remove Programs” of “Control Panel” to un-install it. The
“Add/Remove Program Properties” dialog show as below. Select “BAFO
USB Storage Adapter” and click on “Remove” then click “OK” to
continue.
7.2.2 Click “Yes” to confirm un-installation.
7.2.3 Click on “Yes” to restart computer and complete uninstall procedure.
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 10
/
//
/ #,&
#,&#,&
#,&
If the Hard Disk (brand new HD) didn't show in “My Computer” after the driver is
being successfully installed, please go to “MS-DOS Prompt”,FDISK and
FORMAT the new hard disk. (Please refer to MS-DOS instruction.)
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 11
/'
/'/'
/' 6 7
6 7 6 7
6 7
8
88
8
(906 7
8
7.4.1 Connect the USB port of USB2.0 to IDE 3.5” hard disk enclosure to PC
with USB cable. System will auto detect the device and load the driver
then create a new device and name of “Local Disk (E:)” at desktop as
shown below.
7.4.2 You should check “My Computer”-“Control Panel”-“System”-”Device
Manager” to make sure the driver has already installed. Then, in the
“Disk Drives” it will show a “FUJITSU MHM2050AT” (This model
number will vary with different Hard Disk),in the “Hard disk
controllers” it will show a “Storage Adapter Bridge Module”, and in the
“Universal Serial Bus controller” it will show a new item of “USB Mass
Storage Device”.
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 12
/
//
/ #,&
#,&#,&
#,&
After the driver be successfully installed, but the hard disk does not shown at
“My Computer”. If it is a brand new hard disk, please go to “MS-DOS
Prompt” and FDISK, FORMAT new hard disk. (Please refer to MS-DOS
instruction)
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 13
/-
/-/-
/- 6 7
6 7 6 7
6 7
8
88
8
(906 7
8
7.6.1 Connect the USB port of USB2.0 to IDE 3.5” hard disk enclosure to PC
with USB cable. System will auto detect the device and load the driver
then create a new device of “Local Disk (E:)” at desktop as shown below.
7.6.2 You could check “My Computer”-“Control Panel”-“System”-”Device
Manager” to make sure the driver has already installed. Then, in the
“Disk Drives” it will show a “FUJITSU MHM2050AT USB Device” (This
model number will vary with different Hard Disk),and in the
“Universal Serial Bus controller” it will show a new item of “USB Mass
Storage Device”.
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 14
//
////
// #,&
#,&#,&
#,&
7.7.1 After you have successfully installed the driver, but there is no new hard
disk shown at “My Computer”.
7.7.2 If it is a brand new hard disk, please go to “Control
Panel”-“Administrative Tools”-“Computer Management”-“Disk
Management” and then choose the new HD. Then follow the step to
FDISK and FORMAT this new hard disk.
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 15
/1
/1/1
/1 6 7
6 7 6 7
6 7
8
88
8
:%
:%:%
:%
(906 7
8
:%
7.8.1 Connect the USB port of USB2.0 to IDE 3.5” hard disk enclosure to PC
with USB cable. System will auto detect the device and load driver then
create a new device of “Local Disk (E:)” at “My Computer” as shown
below.
7.8.2 You could check “My Computer”-“Control Panel”-“System”-”Device
Manager” to make sure the driver has already installed. Then, in the
“Disk Drives” it will show a “FUJITSU MHM2050AT USB Device” (This
model number will vary with different Hard Disk),and in the
“Universal Serial Bus controller” it will show a new item of “USB Mass
Storage Device”.
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 16
/4
/4/4
/4 #,&
#,&#,&
#,&
If you have successfully installed the driver, but can’t see the new hard disk on “My
Computer “, please check the following points.
7.9.1 Go to the “Control Panel-Administrative Tools-Computer”
“Management-Disk Management”, and then choose the new HD. Then
following the steps to FDISK and FORMAT the hard disk.
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 17
/$
/$/$
/$ 2
7.10.1 Turn on your Apple computer and make sure that the USB port is enabled
and work properly.
7.10.2 Plug the USB2.0 to IDE 3.5” hard disk enclosure to your MAC, the
system will auto convert the HDD to the Macintosh PC Exchange format.
7.10.3 After the step, you can see the “NEW VOLUME” icon appear on the
desktop
7.10.4 To make sure the USB2.0 to IDE 3.5” hard disk enclosure can works
properly, you have to check the “Apple System Profiler”-“Devices and
volumes”, you can see two items under the USB item
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 18
1
11
1 23
23 23
23
Q: After driver installed, there is no new hard disk model name show at “Disk
Drivers” of “Device Manager” or “Universal Serial Bus controllers” does not
have “USB Mass Storage Device” appear.
A: Adjust jumper of hard disk to “Cable Select” or other setting and try again.
Q: If a brand new hard disk has been installed at enclosure. It shows “USB Mass
Storage Device” in “Universal Serial Bus controllers”, but there is not any new
hard disk at “Disk drivers”.
A: Please FDISK and FORMAT hard disk.
Q: When transferring file and system hang-up.
A: Set “Never” at “Turn Off hard disk” of “Power Management” of “Device Manager”.
4
44
4)
) )
)
Information in this document is subject to change without notice. The manufacturer
does not make any representations or warranties (implied or otherwise) regarding the
accuracy and completeness of this document and shall in no event be liable for any
loss of profit or any other commercial damage, including but not limited to special,
incidental, consequential, or other damages.
No part of this document may be reproduced or transmitted in any form by any means,
electronic or mechanical, including photocopying, recording or information recording
and retrieval systems without the express written permission of the manufacturer.
All brand names and product names used in this document are trademarks, or
registered trademarks of their respective holders.
$
$$
$ )
) )
)
This device generates and uses radio frequency and may cause interference to radio
and television reception if not installed and used properly. This has been tested and
found to comply with the limits of a Class B computing device in accordance with the
specifications in Part 15 of FCC Rules. These specifications are designed to provide
reasonable protection against such interference in a residential installation. However,
there is no guarantee that interference will not occur in a particular installation. If this
device does cause harmful interference to radio or television reception, which can be
determined by plugging the device in and out, the user can try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the device and receiver.
Connect the computer into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help. Consult the
dealer or an experienced radio/TV technician for help.
USB 2.0 to IDE 3.5” hard disk Enclosure User’s Manual 19
$$
$$$$
$$#55
#55#55
#55
If you encounter any technical problem, please contact us through:
Taiwan First Line Electronics Corp.
4F, No. 36-1, Huang Hsi Street, Shilling Dis. Taipei, Taiwan, R.O.C.
Web site: www.bafo.com.tw
OR
Quality Computer Accessories Inc. NJ
70 Ethel Road West, Unit 1, Piscataway, NJ 08854, USA
Web site: www.bafo.com
Other Bafo Enclosure manuals
Popular Enclosure manuals by other brands
HighPoint
HighPoint RocketStor 6421AS Quick installation guide
Taurus
Taurus Dual-Bay Storage Enclosure for 3.5" Serial ATA Hard... user manual
GlassCrafters
GlassCrafters EPIC Series installation instructions
StarTech.com
StarTech.com InfoSafe SAT2510BU2B instruction manual
Manhattan
Manhattan 130042 installation guide
ENIYOU
ENIYOU ENIYOU-808RlJ user manual
