Bafo BF-2010 User manual

User’s Manual
1394/USB Combo hard disk enclosure
BF-2010

1394/USB Combo hard disk Enclosure User’s Manual 1
CONTENT
1. Introduction-----------------------------------------------------------------------------------2
2. Package Content---------------------------------------------------------------------------2
3. Product Features---------------------------------------------------------------------------2
4. System Requirements-------------------------------------------------------------------2
5. LED Function Description--------------------------------------------------------------3
6. Hard Disk Installation--------------------------------------------------------------------3
6.1 HDD installation (3.5”) ---------------------------------------------------4
6.2 HDD installation (2.5”) ---------------------------------------------------5
7. Driver Installation--------------------------------------------------------------------------7
7.1 Windows®98 Driver Installation---------------------------------------7
7.2 Windows®98 Driver Un-Installation--------------------------------12
7.3 Troubleshooting---------------------------------------------------------13
7.4 Windows®ME Driver Installation------------------------------------14
7.5 Windows®ME Driver Un-Installation-------------------------------18
7.6 Troubleshooting---------------------------------------------------------19
7.7 Windows®2000 Driver Installation----------------------------------20
7.8 Windows®2000 Driver Un-Installation-----------------------------23
7.9 Troubleshooting---------------------------------------------------------24
7.10 MAC Driver Installation------------------------------------------------25
7.11 MAC Driver Un-Installation-------------------------------------------27
8. FAQ----------------------------------------------------------------------------------------------27
9. Disclaimer-----------------------------------------------------------------------------------28
10. FCC Statement----------------------------------------------------------------------------28
11. Technical Support-----------------------------------------------------------------------28

1394/USB Combo hard disk Enclosure User’s Manual 2
1. Introduction
This 1394/USB Combo hard disk enclosure provides an easy to carry and flexible
interface solution for people to add more storage space to PC.
This device supports both USB 1.1 standard and IEEE1394a compliance interface,
enables people to easily connect to Desktop PC or Notebook without opening cover.
For more flexible, this enclosure can content both 3.5” HDD and 2.5” HDD.
2. Package Content
Hardware:
§1394/USB Combo hard disk enclosure
§Power adaptor (DC-12V)
§USB A-B cable
§IEEE1394 6 pin to 6 pin cable
§IEEE1394 6pin to 4pin adaptor
§IDE 40pin to 40pin flat cable (for 3.5” HDD)
§IDE 40pin to 44pin flat cable (for 2.5” HDD)
§Metal sheet to stand 2.5” HDD
§Mylar Film
§Screws
Software:
§Driver software CD
§User’s Manual
3. Product Features
§USB specification revision 1.1 compliant
§IEEE1394a compliance
§Dual mode to contain both 3.5” HDD and 2.5” HDD
§Portable 3.5” or 2.5” hard disk, easy way to backup files
§SupportATAPI-4 compatible 3.5” and 2.5” hard disk
4. System Requirements
PC
§IBM PC 486DX4-100 MHz or higher or compatible system
§Available USB port or IEEE1394 6pin or 4pin port
§CD-ROM drive
§Windows®98SE, Windows®ME, Windows®2000
MAC
§Power PC G3, G4, or i-Mac
§Available USB port or IEEE1394 6pin or 4pin port
§CD-ROM drive
§Mac OS 9.1 or higher

1394/USB Combo hard disk Enclosure User’s Manual 3
5. LED Function Description
1394/USB Enable
DeviceAccess
Power Indicator

1394/USB Combo hard disk Enclosure User’s Manual 4
6. Hard disk Installation
6.1HDD installation (3.5” HD)
6.1.1 Follow the steps below to install 3.5” hard disk.
6.1.2 Open the USB Hard disk enclosure (Figure 1 ~ 2)
Figure 1 Figure 2
6.1.3 Assemble the 3.5” hard disk. (Figure 3~ 4)
Figure 3 Figure 4
6.1.4 Screwing HD together with housing (Figure 5)
Figure 5 Figure 6
6.1.5 Close the hard disk enclosure. (Figure 6 ~ 7)

1394/USB Combo hard disk Enclosure User’s Manual 5
Figure 7
6.2 HDD installation (2.5” HD)
6.2.1 Glue Mylar film to metal sheet (Figure 8)
6.2.2 Screwing 2.5” HDD at metal sheet, 44 pin connector close to screw hole
which far away from long shape of ellipse (Figure 9)
Figure 8 Figure 9
6.2.3 Connect 40-44 pin flat cable to 40pin connector of PCB (Figure 10)
6.2.4 Connect power connector of 40-44 pin flat cable to power connector of PCB
(figure 11)
Figure 10 Figure 11
6.2.5 Connect 40-44 pin flat cable to 44pin connector of 2.5” HDD (Figure 12)

1394/USB Combo hard disk Enclosure User’s Manual 6
6.2.6 Combine metal sheet and enclosure with screws (Figure 13)
Figure 12 Figure 13
6.2.7 Close hard disk enclosure (Figure 14 ~ 15)
Figure 14 Figure 15

1394/USB Combo hard disk Enclosure User’s Manual 7
7Driver Installation
Attention: Only the USB need to install the driver, IEEE1394 does not need to
install any driver.
7.1 Windows®98 Installation
7.1.1 Connect the USB port of 1394/USB Combo hard disk enclosure to PC
with USB cable.
7.1.2 The “Add New Hardware Wizard” will appear as below, click on“Next” to
continue.
7.1.3 Choose “Search for the best driver for your device (Recommended)”
then click “Next”
7.1.4 Select “Specify a location” and type D:\DRIVER\BF-2010\WINDOWS (D:
represents CD-ROM) in the dialog box, then click “Next” (In this procedure,
you have to put thedriverCD into your CD-ROM)

1394/USB Combo hard disk Enclosure User’s Manual 8
7.1.5 Windows®will search the driver for this device. Please make sure the driver
that Windows®found is
“D:\DRIVER\BF-2010\WINDOWS\BFUSBWDM.INF”, and then click
“Next”.
7.1.6 Click “Finish” to complete the setup procedure to install the“BAFO
USB-ATA/ATAPI Bridge Controller” driver.
7.1.7 After Windows®had finished installed the driver for the“BAFO
USB-ATA/ATAPI Bridge Controller”it will start to install the driver for the
“BAFO USB-ATA/ATAPI Mass Storage”. Click “Next” to continue.

1394/USB Combo hard disk Enclosure User’s Manual 9
7.1.8 Choose “Search for the best driver for your device (Recommended)”
and click “Next”
7.1.9 Click on “Specify a location” and type
“D:\DRIVER\BF-2010\WINDOWS” at dialog box, then click “Next”
7.1.10 Windows®will search the driver for this device, please make sure the driver
that Windows®found is
“D:\DRIVER\BF-2010\WINDOWS\BFUSBMSD.INF” thenclick “Next”

1394/USB Combo hard disk Enclosure User’s Manual 10
7.1.11 Click “Finish” to finish the installation procedure.
7.1.12 After Windows®installed all the driver, you have to check “My
Computer”-“Control Panel”-“System”-”Device Manager” to make sure
the driver has already installed. Then, in the “Disk Drives” it will show a
“FUJITSU MHM2050AT” (This model number will vary with different
Hard Disk),in the“Hard disk controllers” it will show a “BAFO
USB-ATA/ATAPI Mass Storage Controller”, and in the “Universal Serial
Bus controller” it will show a new item of “BAFO USB-ATA/ATAPI
Bridge Controller”

1394/USB Combo hard disk Enclosure User’s Manual 11
7.1.13 Double click on “My Computer” icon on the desktop, if the driver has
already installed and can work properly, you can see a new DISK icon and
named “E:”appears on the desktop.
.

1394/USB Combo hard disk Enclosure User’s Manual 12
7.2 Windows®98 un-installation
7.2.1 Put the driver software CD into the CD-ROM and open it. Run the
D:\DRIVER\BF-2010\WINDOWS\Uninst.EXE program to un-install the
driver.
7.2.2 Click “Yes” to remove driver.
7.2.3 Remove the USB cable and click “OK”.
7.2.4 Click on “Yes” to restart computer and complete uninstall procedure.

1394/USB Combo hard disk Enclosure User’s Manual 13
7.3 Troubleshooting
If the Hard Disk (brand new HD) didn't show in “My Computer” after the driver is
being successfully installed, please go to“MS-DOS Prompt”,FDISK and
FORMAT the new hard disk. (Please refer to MS-DOS instruction.)

1394/USB Combo hard disk Enclosure User’s Manual 14
7.4 Windows®ME installation
7.4.1 Connect the USB port of 1394/USB Combo hard disk enclosure to PC
with USB cable. The “Add New Hardware Wizard” will appears as below,
click “Automatic search for a better driver (Recommended)” then click
“Next” to install the driver. (In this procedure, you have to put the driver CD
into your CD-ROM).
7.4.2 Windows®will search the driver for this device, please make sure the driver
that Windows®found is
“D:\DRIVER\BF-2010\WINDOWS\BFUSBMSD.INF”, then click “Next”
7.4.3 Windows®will search the suitable driver for this device and installed it.
7.4.4 Click “Finish” to finish installing“BAFO USB-ATA/ATAPI Bridge
Controller” driver.

1394/USB Combo hard disk Enclosure User’s Manual 15
7.4.5 After Windows®had finished installed the driver for the“BAFO
USB-ATA/ATAPI Bridge Controller”it will start to install the driver for the
“BAFO USB-ATA/ATAPI Mass Storage”. Then click “Next” to continue.
7.4.6 Choose “Automatic search for a better driver (Recommended)”, then
click “NEXT”.
7.4.7 Windows®will search the driver for this device, please make sure the driver
that Windows®found is
“D:\DRIVER\BF-2010\WINDOWS\BFUSBMSD.INF” thenclick “Next”

1394/USB Combo hard disk Enclosure User’s Manual 16
7.4.8 Click “Finish” to finish this installation.
7.4.9 After Windows®installed all the driver, you have to check “My
Computer”-“Control Panel”-“System”-”Device Manager” to make sure
the driver has already installed. Then, in the “Disk Drives” it will show a
“FUJITSU MHM2050AT” (This model number will vary with different
Hard Disk), in the“Hard disk controllers” it will show a “BAFO
USB-ATA/ATAPI Mass Storage Controller”, and in the “Universal Serial
Bus controller” it will show a new item of “BAFO USB-ATA/ATAPI
Bridge Controller”

1394/USB Combo hard disk Enclosure User’s Manual 17
7.4.10 Double click on “My Computer” icon on the desktop, if the driver has
already installed and can works properly, you can see a new disk icon and
named “E:”appears on the desktop.

1394/USB Combo hard disk Enclosure User’s Manual 18
7.5 Windows®ME un-installation
7.5.1 Put the driver software CD into the CD-ROM and open it. Run the
D:\DRIVER\BF-2010\WINDOWS\Uninst.EXE program to un-install the
driver.
7.5.2 Click “Yes” to remove driver.
7.5.3 Remove USB cable and click “OK”.
7.5.4 Click on “Yes” to restart computer and complete uninstall procedure.

1394/USB Combo hard disk Enclosure User’s Manual 19
7.6 Troubleshooting
After the driver be successfully installed, but the hard disk does not shown at “My
Computer”. If it is a brand new hard disk, please go to “MS-DOS
Prompt” and FDISK, FORMAT new hard disk. (Please refer to MS-DOS
instruction)
