Bosch DSA E-Series (E2700) User manual

DSA E-Series (E2700)
DSA-N2E7Xx-xxAT | DSX-N1D6Xx-12AT | DSX-N6D6Xx-60AT
en Installation manual

DSA E-Series (E2700) Table of contents | en 3
Bosch Sicherheitssysteme GmbH Installation manual 2015.10 | V2 | DOC
Table of contents
1Safety 5
1.1 Safety message explanation 5
1.2 Safety precautions 5
1.3 Important safety instructions 5
1.4 Warning Notices 7
1.5 Caution Notices 9
1.6 Notices 9
2About this guide 11
3Registering for E-Series 12
4Preparing for an E2700 controller-drive tray installation 13
4.1 Key terms 13
4.2 Gathering items 13
4.2.1 Basic hardware 13
4.2.2 E2700 configuration cables and connectors 14
4.2.3 Tools and other items 15
4.3 Things to know – copper cables and sas cables 15
4.4 Things to know –taking a quick glance at the hardware in a E2700 controller-drive tray
configuration
16
5Ethernet network interface cards for the E2700 controller-drive tray 21
6Installing the E2700 controller-drive tray 22
6.1 Things to know – general installation 22
6.2 Procedure – installing the E2712 controller-drive tray 22
6.3 Procedure – installing drives in the E2712 controller-drive 26
7Connecting the E2700 controller-drive tray to the hosts 27
7.1 Key terms 27
7.2 Things to know – storage array configuration specifications for the E2700 controller-
drive tray
27
7.3 Things to know – host channels 27
7.4 Procedure – connecting the controller-drive tray to the expansion drive trays 29
7.5 Connecting to the network 31
7.6 Connecting to the management hosts 31
8Installing the drive trays for the E2700 controller-drive tray configurations 33
8.1 Things to know – general installation of drive trays with the E2700 controller-drive tray 33
8.2 Procedure – installing the DE1600 drive trays 33
8.3 Procedure – installing drives in the DE1600 drive trays 37
8.4 Procedure – installing the DE6600 drive tray 38
8.5 Procedure – installing drives on the de6600 drive tray 45
8.6 Things to know – connecting the power cords 47
8.7 Procedure – connecting the power cords 48
9Connecting the E2700 controller-drive tray to the drive trays 49
9.1 Key terms 49
9.2 Things to know – E2700 controller-drive tray 49
9.3 Things to know – drive trays 50
9.4 Things to know – drive tray cabling configurations for the E2712 controller-drive tray 50
10 Connecting the ethernet cables 53
10.1 Key terms 53
10.2 Things to know – connecting Ethernet cables 53
10.3 Procedure – connecting Ethernet cables 53

4en | Table of contents DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
11 Connecting the power cords 54
11.1 Things to know – AC power cords 54
11.2 Procedure – connecting AC power cords 54
12 Turning on the power and checking for problems in an E2700 controller-drive tray
configuration
55
12.1 Procedure –turning on the power to the storage array and checking for problems in a
E2700 controller-drive tray configuration
55
12.2 Things to know –LEDs on the E2712 controller-drive tray 56
12.3 Things to know – general behavior of the LEDs on the controller-drive tray 60
12.4 Things to know – service action allowed LEDs 62
12.5 Things to know –LEDs on the DE6600 drive tray 63
12.6 LEDs on the DE6600 drive drawers 66
12.7 LEDs on the DE6600 drives 67
12.8 General behavior of the LEDs on the drive trays 67
12.9 Things to know –seven segment display sequence code definitions on the E2700
controller-drive tray
69
12.10 Things to know –seven segment component failure identifications for the E2700
controller-drive tray
69
12.11 Things to Know – Lock-Down Codes for the Controller-Drive Tray 70
12.12 Things to know – seven-segment display use cases 72
12.13 Things to know – seven-segment display for the ESMs on the drive trays 74
13 Regulatory compliance statements 75
14 Trademark information 76
15 Additional documentation 77

DSA E-Series (E2700) Safety | en 5
Bosch Sicherheitssysteme GmbH Installation manual 2015.10 | V2 | DOC
1 Safety
1.1 Safety message explanation
!
Warning!
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
!
Caution!
Indicates a hazardous situation which, if not avoided, could result in minor or moderate
injury.
Notice!
Indicates a situation which, if not avoided, could result in damage to the equipment or
environment, or data loss.
1.2 Safety precautions
!
Caution!
Installation should only be performed by qualified service personnel in accordance with
applicable local codes.
!
Caution!
The Low Voltage power supply unit must comply with EN/UL 60950. The power supply must
be a SELV-LPS unit or a SELV - Class 2 unit (Safety Extra Low Voltage - Limited Power
Source).
1.3 Important safety instructions
Read, follow, and retain for future reference all of the following safety instructions. Follow all
warnings before operating the device.
– Clean only with a dry cloth. Do not use liquid cleaners or aerosol cleaners.
– Do not install device near any heat sources such as radiators, heaters, stoves, or other
equipment (including amplifiers) that produce heat.
– Never spill liquid of any kind on the device.
– Take precautions to protect the device from power and lightning surges.
– Unless qualified, do not attempt to service a damaged device yourself. Refer all servicing
to qualified service personnel.
– Install in accordance with the manufacturer's instructions in accordance with applicable
local codes.
– Use only attachments/accessories specified by the manufacturer.
– Protect all connection cables from possible damage, particularly at connection points.
– Do not defeat the safety purpose of a polarized or ground‑type plug.
– Permanently connected devices must have an external, readily operable mains plug or
all‑pole mains switch in accordance with installation rules.
– Pluggable devices must have an easily accessible socket-outlet installed near the
equipment.
– Unplug the unit from the outlet before cleaning. Follow any instructions provided with the
unit.

6en | Safety DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
– Any openings in the unit enclosure are provided for ventilation to prevent overheating and
ensure reliable operation. Do not block or cover these openings.
– Do not place the unit in an enclosure unless proper ventilation is provided, or the
manufacturer's instructions have been adhered to.
– Install the unit only in a dry, weather-protected location.
– Do not use this unit near water, for example near a bathtub, washbowl, sink, laundry
basket, in a damp or wet basement, near a swimming pool, in an outdoor installation, or
in any area classified as a wet location.
– To reduce the risk of fire or electrical shock, do not expose this unit to rain or moisture.
– Never push objects of any kind into this unit through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electrical shock.
– Power supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, playing particular attention to cords and
plugs, convenience receptacles, and the point where they exit from the appliance.
– Operate the unit only from the type of power source indicated on the label. Use only the
power supply provided or power supply units with UL approval and a power output
according to LPS or NEC Class 2.
– Do not open or remove the cover to service this unit yourself. Opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to qualified
service personnel.
– Be sure the service technician uses replacement parts specified by the manufacturer.
Unauthorized substitutions could void the warranty and cause fire, electrical shock, or
other hazards.
– Safety checks should be performed upon completion of service or repairs to the unit to
ensure proper operating condition.
– Observe the relevant electrical engineering regulations.
– When installing in a switch cabinet, ensure that the unit and the power supply units have
sufficient grounding.
– Connect the unit to an earthed mains socket.
– Use proper CMOS/MOS-FET handling precautions to avoid electrostatic discharge (ESD).
– For protection of the device, the branch circuit protection must be secured with a
maximum fuse rating of 16A. This must be in accordance with NEC800 (CEC Section 60).
– Disconnect the power before moving the unit. Move the unit with care. Excessive force or
shock may damage the unit and the hard disk drives.
– All the input/output ports are Safety Extra Low Voltage (SELV) circuits. SELV circuits
should only be connected to other SELV circuits.
– If safe operation of the unit cannot be ensured, remove it from service and secure it to
prevent unauthorized operation. In such cases, have the unit checked by Bosch Security
Systems.
– Disconnect power supply and arrange for the device to be serviced by qualified personnel
in the following cases, because safe operation is no longer possible:
– The power cable/plug is damaged.
– Liquids or foreign bodies have entered the device.
– The device has been exposed to water or extreme environmental conditions.
– The device is faulty despite correct installation/operation.
– The device has fallen from a height, or the housing has been damaged.
– The device was stored over a long period under adverse conditions.
– The device performance is noticeably changed.

DSA E-Series (E2700) Safety | en 7
Bosch Sicherheitssysteme GmbH Installation manual 2015.10 | V2 | DOC
1.4 Warning Notices
!
Warning!
Risk of electrical shock
If there is evidence of fire, water, or structural damage, never turn on the power to the
equipment.
!
Warning!
Risk of electrical shock
Before removing or installing a power supply, turn off the power switch, and unplug the
power cord.
!
Warning!
Risk of exposure to laser radiation
Do not disassemble or remove any part of a Small Form-factor Pluggable (SFP) transceiver
because you might be exposed to laser radiation.
!
Warning!
Risk of bodily injury
The battery can weigh up to 10.9 kg (24 lb). When you remove the battery, be prepared to
support its weight. If the battery is dropped, the impact might cause bodily injury, including
deep puncture wounds caused by the battery pins.
!
Warning!
Risk of bodily injury
If the bottom half of the cabinet is empty, do not install components in the top half of the
cabinet. If the top half of the cabinet is too heavy for the bottom half, the cabinet might fall
and cause bodily injury. Always install a component in the lowest available position in the
cabinet.
!
Warning!
Risk of bodily injury
Attach the stability foot before moving the cabinet. If you do not attach the stability foot, the
cabinet might become unstable, or it might fall. This problem is most likely to occur when the
cabinet is moved along inclined surfaces or over uneven surfaces.
!
Warning!
Risk of bodily injury
Only move a populated cabinet with a forklift or adequate help from other persons. Always
push the cabinet from the front to prevent it from falling over.
A fully populated cabinet can weigh more than 909 kg (2000 lb). The cabinet is difficult to
move, even on a flat surface. If you must move the cabinet along an inclined surface, remove
the components from the top half of the cabinet, and make sure that you have adequate help.
!
Warning!
Risk of fire or chemical burn
Before disposing of a used battery, review the battery warning label. The label reads: The
battery used in this device may present a risk of fire or chemical burn if mistreated. DO NOT
disassemble, heat above 60ºC (140ºF), crush or puncture, short circuit external contacts, or
dispose of in fire or water. Use appropriate charger only. Replace only with original batteries.

8en | Safety DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
!
Warning!
Risk of bodily injury
Only move a populated cabinet with a forklift or adequate help from other persons. Attach
the stability foot before moving the cabinet. If you do not attach the stability foot, the cabinet
might become unstable, or it might fall. Always push the cabinet from the front to prevent it
from falling over.
A fully populated cabinet can weigh more than 636 kg (1420 lb). The cabinet is difficult to
move, even on a flat surface. If you must move the cabinet along an inclined surface, remove
the components from the top half of the cabinet, and make sure that you have adequate help.
!
Warning!
Risk of bodily injury
A qualified service person is required to make the DC power connection according to NEC
and CEC guidelines.
!
Warning!
Risk of bodily injury
An empty tray weighs approximately 56.7 kg (125 lb). Three persons are required to safely
move an empty tray. If the tray is populated with components, a mechanized lift is required to
safely move the tray.
!
Warning!
Risk of bodily injury
Each tray has more than one power cord. To remove all electrical current from the devices,
make sure that all of the power cords are disconnected from the power source and that the
two-pole 20-amp circuit breaker for the storage array has been disconnected.
!
Warning!
Risk of bodily injury
Each tray has more than one power cord. To remove all electrical current from the devices,
make sure that all of the power cords are disconnected from the power source.
!
Warning!
Risk of bodily injury
Do not use equipment in the cabinet as a shelf or work space.
!
Warning!
Hazardous moving parts
Keep away from moving fan blades.
!
Warning!
Risk of bodily injury
High leakage current earth connection essential before connecting supply.

DSA E-Series (E2700) Safety | en 9
Bosch Sicherheitssysteme GmbH Installation manual 2015.10 | V2 | DOC
1.5 Caution Notices
Caution!
Potentially hazardous material
The battery pack contains sealed lead acid batteries that might be considered hazardous
material. If you recycle a used battery pack that is not damaged, use the proper facilities.
Handle the battery pack according to all applicable regulations.
Caution!
Potentially hazardous material
If the used battery pack is physically damaged or is leaking, DO NOT ship the battery pack to
a recycling center. Handling a damaged battery pack exposes you and others to potentially
hazardous material. Dispose of the damaged battery pack according to all applicable
regulations.
Caution!
Pinching hazard
As you push the canister into the slot, ensure that your fingers are not pinched between the
lever and the canister. The lever automatically moves toward the closed position as the
canister is pushed into its slot.
Caution!
Potentially hazardous material
The battery pack contains sealed lithium ion batteries that might be considered hazardous
material. If the used battery pack is physically damaged and is leaking, DO NOT ship the
battery pack to a recycling center. Handling a damaged battery pack exposes you and others
to potentially hazardous material. Dispose of the damaged battery pack according to all
applicable regulations. If you recycle a used battery pack that is not damaged, use the proper
facilities. Handle the battery pack according to all applicable regulations.
Caution!
Electrical grounding hazard
This equipment is designed to permit the connection of the DC supply circuit to the earthing
conductor at the equipment.
Caution!
Possible hazard exists
Do not remove more than one canister from the enclosure while power to the enclosure is
turned on.
1.6 Notices
Notice!
This is a class A product. In a domestic environment this product may cause radio
interference, in which case the user may be required to take adequate measures.

10 en | Safety DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
Notice!
Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be
held liable for any damage that results from missing video information.
To minimize the risk of losing information, we recommend multiple, redundant recording
systems, and a procedure to back up all analog and digital information.
Disposal
Your Bosch product has been developed and manufactured using high-
quality materials and components that can be reused.
This symbol means that electronic and electrical devices that have reached
the end of their working life must be disposed of separately from
household waste.
In the EU, separate collecting systems are already in place for used
electrical and electronic products. Please dispose of these devices at your
local communal waste collection point or at a recycling center.
Notice!
Do not dispose batteries in household waste. Dispose of batteries only at suitable collection
points and, in the case of lithium batteries, mask the poles.
!
Caution!
Battery replacement - For qualified service personnel only
A lithium battery is located inside the unit enclosure. To avoid danger of explosion, replace
the battery as per instructions. Replace only with the same or equivalent type recommended
by the manufacturer. Dispose of the replaced battery in an environmentally friendly way and
not with other solid waste. Refer all servicing to qualified service personnel.
Do not place this unit on an unstable stand, tripod, bracket, or mount. The
unit may fall, causing serious injury and/or serious damage to the unit.
Information on sales, delivery, storage, and working life period
No restrictions or conditions apply for the sale or delivery of this product.
If stored under the specified conditions, the storage period is not restricted.
If used for the specified purpose in compliance with the safety instructions and technical
specifications, the working life period of the product is in accordance with normal
expectations for this type of product.
Information on equipment use
Device is for professional installation only. Operation of the devices is not intended for
personal or household use. There are no restrictions to use the device in commercial and
industrial areas, except those mentioned in the Safety information.

DSA E-Series (E2700) About this guide | en 11
Bosch Sicherheitssysteme GmbH Installation manual 2015.10 | V2 | DOC
2 About this guide
This manual is written for professional system integrators and PC technicians. It provides
information for the installation and use of the E2700 controller-drive tray running with
SANtricity® Storage Manager software version 11.20, including all attached drive trays.
To access the SANtricity® Storage Manager software, go to the online product catalogue.
Installation, configuration and maintenance should be performed by experienced and qualified
technicians only.
Conventions in this manual:
For simplicity, the following product names will be used for the following units also described
in this manual:
– DE1600 for the DSAE‑Series 12-bay expansion unit
– DE6600 for the DSAE‑Series 60-bay expansion unit
See also
– Additional documentation, page 77

12 en | Registering for E-Series DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
3 Registering for E-Series
Before you begin the installation, register your E-Series storage system by using the
registration form shipped with the system. The enclosure serial number is located on two
places on each enclosure: the large UL label attached to the top of an enclosure, and a silver
label attached to the front of the enclosure, either on the bottom lip or the right ear. In both
of these places, the enclosure serial number is identified by the text “Serial ” or “S/N ”.
Record the serial number of the integrated controller-drive tray for later use. This serial
number is required to initiate any support request for your system.
Notice!
The SANtricity® Storage Manager software is also referred to as the storage management
software.

DSA E-Series (E2700) Preparing for an E2700 controller-drive tray installation | en 13
Bosch Sicherheitssysteme GmbH Installation manual 2015.10 | V2 | DOC
4 Preparing for an E2700 controller-drive tray
installation
Storage arrays consist of a E2700 controller-drive tray model and can have eight or twelve
drive trays in a cabinet:
Use this document to install the E2700 controller-drive tray model and all necessary drive
trays for your configuration.
Notice!
Possible hardware damage
To prevent electrostatic discharge damage to the tray, use proper antistatic protection when
handling tray components.
4.1 Key terms
storage array
A collection of both physical components and logical components for storing data. Physical
components include drives, controllers, fans, and power supplies. Logical components include
disk pools, volume groups, and volumes. These components are managed by the storage
management software.
controller-drive tray
One tray with drives, one or two controllers, fans, and power supplies. The controller-drive
tray provides the interface between a host and a storage array.
controller
A circuit board and firmware that is located within a controller tray or a controller-drive tray. A
controller manages the input/output (I/O) between the host system and data volumes.
drive tray
One tray with drives, one or two environmental services modules (ESMs), power supplies, and
fans. A drive tray does not contain controllers.
environmental services module (ESM)
A canister in the drive tray that monitors the status of the components. An ESM also serves as
the connection point to transfer data between the drive tray and the controller.
4.2 Gathering items
Before you start installing the controller-drive tray, you must have installed the cabinet in
which the controller-drive tray will be mounted.
Use the tables in this section to verify that you have all of the necessary items to install the
controller-drive tray.
Notice!
Possible hardware damage
To prevent electrostatic discharge damage to the tray, use proper antistatic protection when
handling tray components.
4.2.1 Basic hardware
Item

14 en | Preparing for an E2700 controller-drive tray installation DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
Cabinet
– Make sure that your cabinet meets the installation site
specifications of the E2700 storage array components.
For more information, refer to the “Storage System Site
Preparation Guide”.
– Depending on the power supply limitations of your cabinet,
you might need to install more than one cabinet to
accommodate the different components of the E2700
storage array.
For instructions on installing the cabinet , refer to the
installation guide for your cabinet for instructions on
installing the cabinet.
DE1600 drive tray with end caps that are packaged separately.
This drive tray can be used with all variations of the E2700
controller-drive tray.
DE6600 drive tray (shown with the separately packaged
mounting rails attached). This drive tray can be used with all
variations of the E2700 controller-drive tray.
Mounting rails and screws
The mounting rails that are available with the drive tray are
designed for an industry-standard cabinet.
iSCSI switch (optional)
Gigabit Ethernet switch for Management (optional)
IP cameras/encoders with iSCSI capabilities
4.2.2 E2700 configuration cables and connectors
Item
AC power cords
The controller-drive tray and the drive trays ship with power
cords for connecting to an external power source, such as a wall
plug. Your cabinet might have special power cords that you use
instead of the power cords that ship with the controller-drive tray
and the drive trays.
RJ-45 Ethernet cable
This cable is used for 10-Gb/s iSCSI connections.

DSA E-Series (E2700) Preparing for an E2700 controller-drive tray installation | en 15
Bosch Sicherheitssysteme GmbH Installation manual 2015.10 | V2 | DOC
Ethernet cable
SAS cables
The HD Mini-SAS (SFF-8644) to Mini-SAS (SFF-8088) SAS cables
connect each controller expansion port to the drive tray(s).
Serial cable
This cable is used for support only. You do not need to connect it
during initial installation.
DB9-to-PS2 adapter cable
This cable adapts the DB9 connector on commercially available
serial cables to the PS2 connector on the ESM for drive trays in
the storage array. This cable is used for support only. You do not
need to connect it during installation.
Mini-USB connector
This cable adapts the DB9 connector on commercially available
serial cables to the PS2 connector on the controller. This cable is
used for support only. You do not need to connect it during
installation.
4.2.3 Tools and other items
You may need the following equipment:
– Labels: Help you to identify cable connections and lets you more easily trace cables from
one tray to another.
– A cart: Holds the tray and components.
– A mechanical lift (optional)
– A Phillips screwdriver
– A flat-blade screwdriver
– An anti-static protection
– A flashlight
4.3 Things to know – copper cables and sas cables
The controller-drive tray supports SAS drive connections and SAS, or iSCSI host connections.
Notice!
Your cables might look slightly different from the ones shown. The differences do not affect
the performance.
10-Gb/s iSCSI cable connection

16 en | Preparing for an E2700 controller-drive tray installation DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
1Active SFP transceiver
2Copper cable with RJ-45 connector
SAS cable connection with SFF-8644 connector
1SAS cable
2SFF-8644 connector
4.4 Things to know –taking a quick glance at the hardware in a
E2700 controller-drive tray configuration
The E2700 systems always come with eight or twelve hard drives. At least two drives are
required for proper operation.
This section provides an overview of hardware described in this document.
Observe the following:
– The top of the controller-drive tray is the side with labels.
– The configuration of the host ports might appear different on your system depending on
which host interface card configuration is installed.
E2700 controller-drive tray – front view
97001-03
!
1
2
3
4
5
6
1End cap Locate LED
2End cap Service action required LED
3End cap over-temperature LED
4End cap Power LED
5End cap Standby power LED
6Drive canister

DSA E-Series (E2700) Preparing for an E2700 controller-drive tray installation | en 17
Bosch Sicherheitssysteme GmbH Installation manual 2015.10 | V2 | DOC
E2700 controller-drive tray – rear view
(right-rear sub plate with a two-port 1-Gb/s or 10-Gb/s iSCSI host interface card)
17
11 12
13
8
1 2 5 7
9 10
6
23 24
25
4
3
18 19 20 21 22
iSCSI
Host
S
S
SL
S
A
Lnk Lnk
LnkLnk
Port 2Port 1
Ch 4 Ch 3
Drive Expansion
L
1E2700 controller canister
2Seven-segment display
3USB port
4Serial port
5Ethernet port 1 link rate LED
6Ethernet port 2 link active LED
71 GbE Ethernet management port 2
8SFF-8644 SAS host connector 1
9SAS host 1 link up LED
10 SAS host 1 link fault LED
11 SAS host 2 link up LED
12 SAS host 2 link fault LED
13 SFF-8466 SAS host connector 2
14 SAS expansion link 1 fault LED
15 SAS expansion link 1 up LED
16 SFF-8644 SAS connector 1 (expansion)
17 Power-fan canister
18 Battery service action required LED
19 Battery charging LED
20 Controller service action allowed LED
21 Controller service action required LED
22 Cache active LED
23 AC power connector
24 On/off switch

18 en | Preparing for an E2700 controller-drive tray installation DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
25 Right rear sub plate (see below)
E2700 right-rear sub plate with a two-port 1-Gb/s or 10-Gb/s iSCSI host interface card
49006-08
78 91 2
3
4 5
6
1Host interface card channel 3 fault LED
2Host interface card channel 3 link up LED
3iSCSI host interface card channel 3
4iSCSI host interface card channel 4 fault LED
5Host interface card channel 4 link up LED
6iSCSI host interface card channel 4
7SAS expansion port 1 fault LED
8SAS expansion port 1 link up LED
9SFF-8644 SAS port 1 (expansion)
Notice!
Possible equipment damage
You must use the supported drives in the drive tray to ensure proper operation. For
information about supported drives, contact a Technical Support Representative.
Notice!
Risk of equipment malfunction
To avoid exceeding the functional and environmental limits, install only drives that have been
provided or approved by the original manufacturer. System integrators, resellers, system
administrators, or users of the controller-drive tray can install the drives.

DSA E-Series (E2700) Preparing for an E2700 controller-drive tray installation | en 19
Bosch Sicherheitssysteme GmbH Installation manual 2015.10 | V2 | DOC
DE1600 drive tray – front view
!
97001-01
31
2
1Left end cap (has the drive tray LEDs)
2Drives
3Right end cap
DE1600 drive tray with AC power option - rear view
97002-01
AC
DC
!
AC
DC
!
2 3 4 5 761
98 10
11
1ESM A canister
2Expansion port SFF-8088 connector 1 (IN)
3Expansion port SFF-8088 connector 2 (IN)
4Seven-segment display indicators
5Serial connector
6Ethernet connector
7Expansion port SFF-8088 connector (OUT)
8Power-fan canister
9Power connector
10 Power switch
11 ESM B canister

20 en | Preparing for an E2700 controller-drive tray installation DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
DE6600 drive tray – front view with bezel
!
92036-01
DE6600 drive tray – front view with bezel removed
92034-04
!
DE6600 drive tray – rear view
92056-07
!
2 3 4 5 6 11
1Fan canisters
2ESM A
3ESM B
4Expansion port SFF-8088 connectors (IN)
5Expansion port SFF-8088 connector (OUT)
6Power canisters
