BAK C-2300 User manual

OPERATING MANUAL
Hot-Air Blower COMPACT
SAFETY
Danger to life when opening the tool, as live components and connec-
tions are exposed. The device must be disconnected from the mains sup-
ply before opening. Electric work shall only be operated by qualified
personal (according to TRBS 1203).
Danger of fire and explosion if the hot air blower is installed and used
incorrectly, particularly near flammable materials and explosive gases.
Not suitable for hazardous locations! The minimal air flow must not be
undercut.
Danger of burns
Do not touch heating element pipes and nozzles when hot. Let the device
cool down. Do not point the hot air jet at persons or animals.
The mains voltage specified on the device’s type plate must correspond
to the mains voltage. Tools with a fix connection must be connected to a
separator (e.g. mains switch).
Special connecting conditions ac-
cording to IEC/EN 61000-3-11;
Zmax = 0,039Ω+ j 0,025Ωfor short
time rating (30 minutes);
Zmax = 0,026Ω+ j 0,016Ωfor con-
tinous operation.
Consult your local electricity supplier if necessary.
GFCI/RCCB: for personal protection on building sites we strongly rec-
ommend to connect the tool to a GFCI (Ground Fault Circuit Interrupter)
or to a RCCB (Residual Current Circuit Breaker).
Device in protection class II“
The device must be supervised when in operation. The heat can reach
flammable materials that are out of view.
Protect the device from damp and wet!

BAK Thermoplastic Welding Technology AG 2
WARRANTY AND LIABILTY
Warranty and liability apply from the date of purchase (documented by the in-
voice/delivery note) according to the currently valid general terms of business
from BAK. BAK refuses to honour any warranty for devices which are not in
their original condition. BAK devices may never be reconfigured and/or modified.
BAK reserves the right to deny any responsibility if this is ignored. No liability
can be assumed by BAK for incorrect installation and/or use as well as natural
wear and tear of components (e.g. heating elements).
Note:
This operating manual must be available to the installation and operating person-
nel at all times. Read these operating instructions carefully before installing and
using the device.
Copyright:
This document must not be disclosed to third parties without the explicit written
approval of BAK. Any forms of reproduction or copying and electronic storage
are prohibited.
CONVENTIONAL APPLICATION
This BAK hot air heater is a modular unit which creates process heat in industrial
environments. The device is suitable for continuous operation. The blower can be
used as hand tool, bench tool or can be built into machines and installations.
Their installation and the working process shall only occur after observance of
every safety arrangement for the provided place of installation and application.
The accordance with the effective edition of the equipment and operations safety
(GPSG) and the machine standards (MRL) must be guaranteed.

BAK Thermoplastic Welding Technology AG 3
INSTALLATION
1.0. INSTALLATION / Connection (only be conducted by a qualified
person)
(thermal security class 1 according to EN 60519-1, paragraph 13.8)
1.1. Connection for model 400VAC:
- L1 = black
- L2 = brown
-N = blue
1.2. When installing the tool, ensure that:
- the electrical protection is aligned to the nominal current.
- only cold air up to a max. of 50°C / 122°F is fed to the device.
- no (warm air) back pressure develops.
- the air intake (9) is not covered and the tool can take in the air with
no problems.
- the device is not positioned within the hot air jet of a different device.
1.3. When built in vertical (Blow off opening downwards) it is important that
the device cannot suck in hot air.
1.4. Protect the device from vibration and shock. For mechanical movements
use absorber against the impacts.
1.5. When fixing, the thread inserts M5 (11) on the underside of the device
should be used.
1.6. At high foaling of the intake air (e.g. textile factory) a BAK-stainless steel
filter should be used.
2.0. OPERATION
2.1. Make sure that the hot air can flow freely. Warmth backflow can occur
damage on the device (risk of fire!).
2.2. Allow the blower to cool the unit after using.
STANDARD DESIGN
The hot air blower is equipped with a control electronic to control the temperature
and the speed level. It is also provided with a built-in potentiometer as well as an
integrated heating element and device protection.

BAK Thermoplastic Welding Technology AG 4
SPECIAL DESIGNS
- Temperature control via external potentiometer, controller or SPS.
- Air quantity control with external potentiometer, 5-10 VDC or PWM signal
- Internal temperature control unit
- Internal or external thermocouple
- Special heating elements (power, voltage)
INFORMATION AND ADVICE
The BAK group and its authorised service centres offer free support and assis-
tance in the area of applications technology.
Our specialists will be pleased to help you.
Customer service and orders:
BAK Thermoplastic Welding Technology AG
Industriestrasse 6
CH-6064 Kerns/Switzerland
Telefon: [phone]
Telefax: [phone] 22 51
E-Mail: [e-mail]
ACCESSORIES
Get the best results by using BAK-accessories and spare parts.
Further information can be found in our brochures.
MAINTENANCE
Control and clean the air intake (9) and the optional BAK stainless steel filter of
the device regularly.
Check power supply cord and plug for any possible mechanical damages.

BAK Thermoplastic Welding Technology AG 5
SERVICE AND REPAIR
Repairs should only be carried out by authorized BAK service centres. These
guarantee a professional and reliable 24-hour repair service with original spare
parts. A heating element can be changed by qualified personal.
If the main connection of the device is damaged, it should be replaced by the
manufacturer, from an authorized BAK service centre or a qualified person to
avoid danger.
SHIPPING
For repairs, please return the device appropriately packed for transport to your
next BAK service centre.
Shipping to CUSTOMER ACCOUNT.
Technical modifications reserved. In case of doubt, consultation with BAK is
required. Images and drawings may deviate from the original. Changes reserved.
DISPOSAL
Electrical tools, equipment and packaging should be supplied for en-
vironmental appropriate recycling.
Do not dispose electrical tools in household refuse.
EU Countries only: Pursuant to EU Directive 2002/96/EC on waste
electrical and electronic equipment (WEEE) and its implementation
in national law, out-of-use electrical tools have to be collected sepa-
rately and be supplied for environmental appropriate recycling.

BAK Thermoplastic Welding Technology AG 6
TECHNICAL DATA
Technical Data:
C-2300
C-3100
C-3700
C-4700
C-6100
Voltage
VAC
230
400 (2Ph + N)
Frequency
Hz
50 / 60
Power
kW
2,3
3,1
3,7
4,7
6,1
Electricity
A
10
13,5
16
11,8
15,3
Max. temperature
°C /
°F
650 /
1202
800 /
1472
650 / 1202
Min. air volume
l/min
400
350
400
550
Max. air volume at 20°C
l/min
940
800
930
960
950
Max. temperature at full air volume
°C /
°F
260 /
500
520 /
968
440 /
824
480 /
896
630 /
1166
Stat. pressure
Pa
450
Noise level (LpA)
db
73 (with 1m distance)
Air inlet
Ø mm
102,5
Blow off opening
Ø mm
62/74
Dimensions(LxWxH)
mm
322 x
138 x
180
360 x
138 x
180
322 x
138 x
180
360 x 138 x 180
Weight incl. cable
kg
2,8
3,1
2,8
3,1
Conformity symbol
Protection class II
Please ask for special heating elements (power, voltage).

BAK Thermoplastic Welding Technology AG 7
red/brown
black/white
blue/green
1
4
2
3
8
7
6
5
9
11
10
DEVICE DESCRIPTION
1. Power supply cord
2. Blower ON –OFF
3. Heater ON –OFF
4. Removable handle
5. Potentiometer for air volume
control
6. Potentiometer for temperature
control
7. Type plate (back side of the de-
vice)
8. Heating element tube
9. Air intake
10. Installation regulator (optional)
11. Six M5 drilled and tapped holes
for fixing into installation (Di-
mensions on the underside of
the device)
PINOUT SCHEME FOR SPECIAL DESIGNS
Control cable for external temperature control:
- digital signal (PWM 10-24 VDC max. cycle time 1 se-
cond)
+ = brown
- = white
Control cable for external potentiometer for temperature or
speed control:
Control cable for external speed control:
- digital rpm= 15VDC, l/max = 10mA; PMW/1-
10KHz/50-100% (50% minimum air-flow)
- analogue 5-10VDC; (5VDC = minimum air-flow)
+ = green
- = white
Warning:For analogue and digital speed control, the minimum air-flow must be guaran-
teed when
the hot-air blower is running.
Signal line for external speed indicator:
- 1 impulse per revolution
- open collector exit
+ = brown
- = white
Compensating line for 'K' type internal thermocouple:
+ = green
- = white

BAK Thermoplastic Welding Technology AG 8
