BALCO DY200223 User manual

Workshop
Power Station
with LED Lights
Instruction
Manual
DY200223

2
After Sales Support
1300 663 907 Model Number DY200223
[e-mail]
AUS
Pack Contents
• 1x Workshop Power Station With LED Lights
• 1x Detachable Tool Holder
• 4x Wood Screws
• 5x Screws to attach Tool Holder
• 1x Mounting Template
• 1x Instruction Manual

3
After Sales Support
1300 663 907 Model Number DY200223
Model Number DY200223 [e-mail]
AUS
Table of Contents
Product Overview
Welcome
General Safety Instructions
Features / Technical Specications
Instructions
FAQ’S
Maintenance & Disposal
4
6
7
8
9-12
13
14
Version 1.0
Product complies to: AS/NZS CISPR 15:2011
AS/NZS 3105:2014+A1:2017
AS/NZS 60598.1:2017
AS/NZS 60598.2.4:2005 Inc A1
AS/NZS 3112:2017
AS/NZS 3133:2013 Inc A1–2
AS/NZS 3100:2017
SAA-122268-EA

4
After Sales Support
1300 663 907 Model Number DY200223
[e-mail]
AUS
23
4 5
6
1
1. Light switch
2. 4 x standard socket outlets
3. Illuminated power on/o switches
4. Tool holder for small tools
5. 2 x wide spaced outlets
6. LED work lights with 90°rotation
Product Overview

Model Number DY200223 5

6
After Sales Support
1300 663 907 Model Number DY200223
[e-mail]
AUS
Congratulations on choosing to buy a Balco product. By doing so you now have
the assurance and peace of mind that comes with purchasing a product made
by one of the leading manufacturers. All products brought to you by Balco
are manufactured to the highest standards of performance and safety and, as
part of our philosophy of customer service and satisfaction, are backed by our
comprehensive 1 year warranty. We hope you will enjoy using your purchase for
many years to come.
Welcome

7
After Sales Support
1300 663 907 Model Number DY200223
Model Number DY200223 [e-mail]
AUS
General Safety Instructions
Read this manual thoroughly before rst use and keep it in a safe place for future
reference, along with the purchase receipt and carton. The safety precautions
enclosed herein reduce the risk of re, electric shock and injury when correctly
adhered to. Follow all instructions and take notice of all warnings to reduce the
risk of re or electric shock.
• Carefully follow all instructions for assembly and mounting. Test the strength of
attachment to the wall before using the product.
• Do not place heavy tools on the tool holder. The tool holder is designed for small
tools only.
• The Workshop Power Station contains no serviceable parts. Opening the product
will void your warranty.
• Always exercise caution when operating any electrical device.
• Keep away from liquids, oils, petrol, and all chemicals.
• For indoor use only.
• Do not look directly into the LEDs when operating.
• Keep away from children.
• Do not use if power supply cable becomes damaged or broken.
• The external exible cable or cord of this product cannot be replaced; if the cord is
damaged, the product shall be destroyed.
• Long-life LED lights are not replaceable.
• Turn o when not in use.
• Supervise young children to ensure they do not play with the product.
• The Workshop Power Station should not be plugged into an extension lead or
another power board.

8
After Sales Support
1300 663 907 Model Number DY200223
[e-mail]
AUS
Voltage: 10A, 240V AC 50Hz
Max Load: 2400W
Power Cord: 1.8m 1.0mm
Tool holder: Max weight 4kg
LED output: 720 Lumens total
Dimension: 563mmx130mmx63mm
Weight: 1011g incl cord and plug
Features
Technical Specifications
• 4 x standard socket outlets
• 2 x wide spaced socket outlets
• Illuminated power on / o switches
• Powerful LED work lights
• Work lights with 90° rotation
• Wall mounting
• Detachable tool holder with 32 storage options for small tools
• Overload protection

9
After Sales Support
1300 663 907 Model Number DY200223
Model Number DY200223 [e-mail]
AUS
Assemble the tool holder
1. Attach the tool holder to the power board using 5 screws provided
2. Thread the power cable behind the tool holder
Instructions

10
After Sales Support
1300 663 907 Model Number DY200223
[e-mail]
AUS
1. Find a suitable location to mount the power board. Use the included
wood screws
Note: Ensure the Workshop Power Station is being mounted close enough to
utilise a suitable power point
2. Measure holes for 4 wood screws using a spirit level, with 100mm
spacing. Alternatively, use the provided mounting template. Fit the
supplied wood screws
Note: Mounting the powerboard onto plaster or masonry may require
additional screws and components
3. Line up the mounting holes on the back of the power board and place
on to the screws. Gently push down
Mounting
Instructions

11
After Sales Support
1300 663 907 Model Number DY200223
Model Number DY200223 [e-mail]
AUS
1. Use your hand to rotate the LED lights to the desired position
Tip: Attach the power board to the wall above your workbench, and position
the lights to provide work lighting for small tasks
2. Switch the LED lights on using the switch marked“LIGHTS”
Instructions
Using the LED Lights

12
After Sales Support
1300 663 907 Model Number DY200223
[e-mail]
AUS
1. Ensure the switch above the socket is switched o
2. Plug in your device
3. Switch the socket on, using the switch above it
4. When you have nished using the appliance, switch the socket o
Tip: Keep your cables out of the way by threading them behind the
tool holder
Instructions
Using the Power sockets

13
After Sales Support
1300 663 907 Model Number DY200223
Model Number DY200223 [e-mail]
AUS
Questions Answers
Is this product compatible with 15A
sockets?
No. The maximum current of 10A applies to
this product. This current output applies to
most household electrical items.
What are wide spaced outlets? Wide spaced outlets allow you to use larger
power sockets without blocking the others
on the power board. This ensures you can
have up to 6 sockets connected at one
time.
Can I plug the Workshop Power Station
into extension leads or other power
boards?
No. The Workshop Power Station should
not be plugged into an extension lead or
another power board.
Can I use the tool holder to carry heavy
power or hand tools?
The tool holder is only designed to carry
small tools – such as a screwdrivers etc.
Please do not overload with excessive
weight.
Can the Workshop Power Station be
mounted outdoors?
No. The Workshop Power Station is for
indoor use only. It should only be mounted
in an area where it is protected from any
moisture.
Can I replace the LED’s? No. The long-life LED’s in this product are
not replaceable.
How far can the LED lights be rotated? The LED lights can be rotated up to 90˚
which can provide work lighting for small
tasks.
FAQ’S

14
After Sales Support
1300 663 907 Model Number DY200223
[e-mail]
AUS
Maintenance & Disposal
Cleaning
To clean the unit, ensure it is unplugged from power, and no devices are plugged
in to it. Wipe the fascia down with a damp cloth and make sure it is completely dry
before using again
Disposal
At the end of its working life, do not throw this product out with your household
rubbish. Electrical and electronic products contain substances that can have
a detrimental eect on the environment and human health if disposed of
inappropriately. Observe any local regulations regarding the disposal of electrical
consumer goods and dispose of it appropriately for recycling. Contact your local
authorities for advice on recycling facilities in your area.
Please keep the original packaging carton and materials in a safe place. It will help
to prevent any damage if the product needs to be transported in the future. In the
event it is to be disposed of, please recycle all packaging material where possible.
If you require another copy of this instruction manual, please visit
www.balcobrands.com to obtain an electronic copy.

Model Number DY200223 15
