Balt 14805 User manual

Balt 4' x 8' Framed

Magnetic Gloss Black Glass

Dry-Erase Whiteboard

Instruction Manual

1234567890123456789012345678901212345678901234567890123456789012123456789012

Trimmed Glass Boards

Assembly Instructions

Part Drawing Description Qty

Hardware List

P1 Glass Board 1 EA

P2 Tray 1 EA

ETrimmed Glass Board

A L Clip

C PlasticAnchor

D CS Screw

Part Drawing Description Qty

E DrywallAnchor

B Self Drilling Screw

ForDry Wall

1/4”Predrill

ForMasonryWalls

ForStudWalls

1/8”Predrill

1/4”Predrilll

TYPE WALL

3” 16”min.

24”max.

Edge of

Board WallMountLocationsonBoard

Measurethe lengthandwidthofyour newboard. Determine thewall centerline andheight

offthe floorthat youwant your newboard tobe located. Holdyour boardup inpositionand

drawa lineunder thebottom oftheboard andparallelwiththefloor. Ifyour wallhas studs,

determine the centerlineof the studs. Itis recommendedthatyou tieinto asmany studs

as possible when mounting your board. .

aring to InstallPreparing to Install Your New Glass Board

NOTE: The proper installation of your board will require at least two people.

Tools required: Tape measure, chalkline, electric drill / screwdriver, drill and

screwdriver bits, stud finder and level. .

1.)

Illustration#1

2.) Measure1” upfromyour line anddraw asecondparallelline. Youwill needto drill 3/16”

diameterholes inthe backleg oftheTray extrusionfor yourmounting Screws(D). See

Detail#2A forlocation. Follow therecommended holelocations, correctwall mount

anchorsand correctpredrill foryour typewall fromPage2. AttachTray(P2) tothe

wall using the correct mounting hardware for your type wall. .

Illustration#2

1”

Bottomof

Board Line

Detail #2A

Drill 3/16” diameter screw

holeson thisline

1”

Illustration#3

Illustration#4

Illustration#5

3.)

4.)

5.)

PlaceBoard (P1)into the wallmounted

Tray(P2) boardgroove.

Mark a line along the top edge of the board.

Drawaline 1” down from thetop line.

Installthe L-Clips(A)using the

recommended mount spacingand the

correct hardware foryour type wall.

Topof

Board Line

1”

Make sure your L-Clips (A) are pushed up. Place the Glass Board (P1) back into the board

groovein theTray(P2). Push the L-Clipsdownand secureto the topof theboard using Self

Drilling Screws (B) as shown in illustration #6. .

Illustration#6

TrimmedGlass Board_03-31-16

WWW.MYBINDING.COM
