Bambi ZP5388 User manual

OPERATION MANUAL
ZP5388
Remote control
Our products are suitable for the following standard:
GB6675,GB19865
ASTM-F963,CPSIA
EN71 AND EN62115

2. Before use：
3. Specification
1. Directory
External dimensions
User’s proper age
Loading limitation
Speed
Battery Spec
Power Mode
Charging Spec
Charging Time
Power life
Fuse Spec
116*73*50cm
suitable for children
around 3-8years old
30 KGS
3 km/hr
6V, 7AH
(or 6V, 7AH *2 or 12V 7AH*1)
Rechargeable
6V 1000mA
(or 12V 1000mA)
8-12 hours.
280 times charging.
Self-resetting fuse
Please read carefully before using our product manual, which tells you the
detailed installation and correct use, Then can avoid damage and injury caused
by improper operation . Particularly important is that it tells you a lot about safety
precautions, Please memorize these and guide your child with patience. Please
place the instructions in easily accessible place for future reference.
Specification
Charging method
Fuse
Safety Precautions
Maintenance and repair
Before use
Parts
Exploded Diagram
Assembly diagram
Notice when using
Trouble Shooting
11. Care and maintenance
12.Trouble Shooting
(1). Adults should check regularly (once every two weeks suggested), wires,
plugs, electrical, housing, steering systems, fastening is normal or not,
If there is any problem,then stop use until the fully restored
(2). Clean vehicles please use soft, dry cloth to wipe, can not use water or
fuel cleaning, that will lead to corrosion switch and caused switch failure.
(3). This product cannot store in the high-temperature places or near the fire,
or in moist places, The product should be covered in the snowy and rainy
days..
(4). Charge the battery fully if you will store it for a long time, then charge it
every 3 month, in this way you can extent the lifetime of the battery.
(5). Stop using,pls take off the battery from the motorcycle and make the
switched on “OFF” position.Also cut off the power. Keep the battery in
proper place.Donnot allow children play the battery.
(6). When maintenance,donnot revise the motorcycle’s circuit and structure.
The key parts should be maintained and guided by the professional staff.
(7). Don’t recharge the non-rechargeable batteries, don’t mix the old and new
or different types of batteries. Pay attention to the Positive and negative.
(8). In the unstable supply voltage region. We recommended to install voltage
stabilizer to protect the battery
The vehicle does not move.
1.Check forward and back switch is in neutral position switch or not.
(Middlle of the switch is neutral position)
2. Check the power’s positive and negative cord is plugged firmly
3.Fuse melted or jump off.
4.Check the charger is pluging into the charging hole or not.If yes,the
motorcycle will cut off automatically.After pluging off the charger,then can use.
5.Foot switch or manual button is stuck down then cannot press ?
6.Whether there is debris stuck wheels
The vehicle moves slowly.
1.Whether battery power is sufficient, If so,need timely charge.
2. Whether there is debris stuck wheels
3.Whether the vehicle is overloaded.
4.Whether the charger is broken then the battery cannot be charged.
The battery cannot be fully charged.
1.Check the charger is ok or not.When chargring,the charger will be warm is
normal.
2.Checkthe battery is ok or not.
3..Check the charger or the battery connection is loose or not.

9. Fused tube
10. Charging
The vechile use self-tapping fuse.
When overloading or improper use,the fuse will be automatically cut off in
10-20 seconds.and then will automatically connect the power.
To avoid the cutting off,please pay attention:
(1). The maximum weight limited of the motorcycle is 30KG.
(2) Not stall the car running or heavy trailer behind.
(3). May not liquid immersion,it may cause the short circuit.
(4).Donnot revise the vehicle’s circuit or the structure.
(1). Like the below picture,put the charger into the vechile’s charing hole.
(2).Like the picture, The power plug into the matched stable AC power.
Attention when charging:
1.To assure the safety, Adults should do the battery charging,
2. First using , fully charged,need to charge another 8-12 hours.
3. Charge the battery if the vehicle runs slower, can charge 8-12 hours.But
cannot charge over 15 hours.
4. Cannot open or decompose the battery and charger, should use the
matched charger and battery.
5.When charging,cannot upside down the battery.
6.Before charging, check the charger ,battery and the plug is ok or not.If
broken,no use. After repaired,then can use.
7. Charge the battery fully if you will store it for a long time, then charge it
every 3 month, in this way you can extent the lifetime of the battery.
4. Cautions For Safety
(1). The product must be assembled by adults. Before use check whether the adult
assemble correctly according to the instructions.
(2). To avoid injury to small parts, children under 3 years old prohibited.
(3). Children should stay away from the plastic bags, prevent children from covering
the head leading to choking hazard
(4). When using, Children should wear safety helmets and must be guarded and
guided by adults, and not to leave the child alone to avoid accidents.
(5). The motorcycle is for one person.The maximum weight limited of the motorcycle
is 30KG. suitable for over 3 years to 8 years old children, Non-overloading.
(6). The motorcycle should drive on the plat surface It is prohibited to drive on streets,
slopes or any other dangerous places.
(8). When the motorcycle moving, user should not be free to turn forward, backward
switch, After the motorcycle stopped,then can switch the forward and backward
switch.
(9). Do not reverse push and lateral pull the motorcycle in the normal driving to
prevent the rollover risk.
(10). The battery charger to be operated by an adult, do not let children charge the
battery.
(11). Do not directly wash the motorcycle with water or rain the motorcycle.To prevent
water damage to the motor circuit
(12). Adults should check regularly (once every two weeks suggested), wires, plugs,
electrical, housing, steering systems, fastening is normal or not, If there is any
problem,then stop use until the fully restored.
(13). The motorcycle battery and the charger is not a separate toy, donnot let the
children play the battery and charger.
(14). Please use the matched battery and charger, and a stable charging voltage to
ensure safe when charging, and extend battery life.
(15). Spare parts exchange should be operated by an adult, because the battery is
very heavy, and the internal acidic electrolyte, if any leakage should avoid contact
with liquid, and need a professional disposition. If accidental contact with the
electrolyte, it is timely at least 15 minutes rinse with cold water and seek medical
treatment.
(16). Avoid the short circuit of the power, to prevent the risk of burning.
(17) .This product cannot store in the high-temperature places or near the fire, prevent
plastic parts melt, charging away from flammable materials to prevent fires.
(18). Shall not use the different specifications fuse.
(19). Don’t recharge the non-rechargeable batteries, don’t mix the old and new or
different types of batteries. Shall not be casually discarded, attention to
environmental protection.
(20). No using or long-term no use the motorcycle, please pull out the battery on the
red line, the switch is "off" position, to ensure circuit safety.
(21). Donnot exposure the motorcycle to the sun or using the motorcycle in the rainy
days.
(22). Keep the package bags in the proper place for further use because there is
important information on it.

1
2
6
5
7
9
8
10
3
4
11
12
14
13
BODY x1
WINDSHIELD x1
hubcap x4
FRONT WHEEL x2
Driving wheel x2
hubcap x4
Insert parts x7
12mm spacer x7
Steering wheel x1
5*40 Machine screws x1
5MM nut x1
10 mm nut x4
MIRROR x2
SEAT x1
4*16 self-tapping screw x4
Charger x1
1
2 3
45
6
6
6
9
9
9
9
9
1
4
4
4
11
11
11
12
12
12
13
13
13
13
13
6
9
9
4
11
12
13
13
2
10
10
7
7
3
10
10
8
8
8
6
6
6
6
7
7
9
9
9
9
9
9
9
8
8
8
1
2
3
4
4
4
4
11
11
11
11
12
12
12
12
13
13
13
13
13
13
10
10
10
10
13
6. Exploded Diagram
7. Product Assembly Chart

5. PARTS DRAWING
3
BODYx1 WINDSHIELDx1
hubcapx4
FRONT WHEELx2 Driving wheelx2 hubcapx4
Insert parts x7
12mm spacer x7Steering wheelx1
5*40 Machine screwsx1
5MM nutx1
10 mm nutx4
MIRRORx2
SEATx1
4*16 self-tapping
screwx4
1
4
8
5
2
6
10 11 12 13 14
9
7
3
Chargerx1
8. THE USE OF INFORMATION
(1). The car has the music and Remote Control function.
(2). Charge the battery if the vehicle runs slower than normal.Charge the battery for 8-12
hours.But cannot over 15 hours. It is normal that the power charger and the battery
become warmer while the battery is on charging.
(3).The car has these functions: Refer to Picture (1)
Function：1.The car has the foot step function.First, turn on the power,and then step
the footstep by foot,the car can drive.
2.FORWARD/BACKWARD function.Press FORWARD,the car will go front.
Press BACKWARD,The car will go back.
3.The steering wheel has the music and horn function.
4.The vehicle has the power switch.To use, turn on the power switch. No
use,then turn off the power switch.
（2）
（1）
MP3 HOLE
FORWARD/BACKWARD
SWITCH
POWER
REMOTE CONTROL
SWITCH
FOOT STEP
VOLUME
AA1.5V
AA1.5V
