INSTRUCTION MANUAL
!9
/-0"$3/5&1'*,,2&.2/1
6*3)*.3&(1"3&%-&"241*.(31".2%4$&1
DIBT Approval Z-65.11-355

 12-11-2014 "(&

Trained personnel may only perform installation, initial start-up and maintenance.
All applicable European and national regulations regarding installation of electrical equipment must be adhered to.
• The device may only be connected to supply power complying with the specifications included in the technical data and on the
serial plate.
• The device must be disconnected from all sources of power during installation and maintenance work!
• The device may only be operated under the conditions specified in the operating instructions!

The MAXIMAT V C, compact overfill sensor, is used as an overfill monitoring device for permanently installed containers used for
the storage of non-flammable, water endangering liquids.
It is equipped with three different output circuits:
• A binary output for controlling a coupling relay or the digital input at a PLC
• A 0 to 20 mA current output for controlling an analog input channel, e.g. a programmed logic controller (PLC)
• Self-monitoring measuring circuit in combination with the MAXIMAT SHR C... measuring transducer with a 2 wires connection.
00,*$"3*/.2
Note that stored liquids may not tend to deposit and to stick on. The minimal specific weight is 0.7 kg/L.
Designed for oils, emulsified solutions and for non-conductive liquids.

Main power supply: 15...26 V DC; caution: DC current circuit should be protected by a fuse of 250 mA
Power consumption: approx. 3 W
Ambient temperature: -20...+60°C
Operating pressure: atmospheric, 0.8...1.1 bar
Terminal housing: PBT, fibre glass reinforced, IP 65 acc. EN 60 529
Process connection: Adjustable union with threaded BSP 2" or flange /PN10
Terminals: screw connectors, IP 20; max. wire cross-section 2.5 mm2
Cable gland: M20x1.5 [cable Ø 5...9 mm]
Outputs:
• Switch [+DO / -DO]: optocoupler NPN, maximum 30 mA
• Switch [+AO / -AO]: current 0...20 mA
Configuration: with 4 DIP switches
Lighting signal: 1 LED inside the terminal housing for correct operating system
DIP Switches: 0&1"3*.(-/%&    
Binary output ON ON ON OFF
Curent output / PLC OFF OFF OFF OFF
MAXIMAT SHR C OFFOFFOFFOFF
= Default setting
Indicators: Green LED on the connector PCB
LED illuminated = Run
LED off = Alarm / error
&"241*.($*1$4*3'/142&6*3)
Maximal inductance: approx. 5 mH
Maximal capacitance: approx. 0.5 µF
-"1+
in accordance with low-voltage directive (2006/95/CE) and EMC directives (2004/108//EG)
001/5",
DIBT Z-65.11-355, for overfilling detection WHG § 19, and VLAREM II
/3&
The accompanying “General Building Supervisory Approval N° Z-65.11-355” is an integral part of the operating instructions and all
stipulations contained therein must be adhered to!
/3&
&241&3/&7"-*.&3)&
26*3$)2&33*.(2#&'/1&
26*3$)*.(2400,80/6&1/.

 12-11-2014 "(&
Weld on union


 12-11-2014 "(&


The maximum allowable fill-level of any given tank can be
determined, for example, in accordance with TrbF 280 no. 2.2.
Triggering level A is then calculated in accordance with attachment
1, or the approval guidelines for overfill inhibitors (ZG-ÜS).
Dribbling quantities and switching delay times must be taken into
consideration. Switching delay time can be adjusted at the
MAXIMAT SHR C measuring transducer within a range of 0.3
to 3 seconds.
Installation length L determines the fill-level monitor’s triggering
point. Dimensions are calculated as follows:
H = tank height
A = triggering level
B = connector
E = immersion depth, table E
S = triggering point
L = H - A + B + E + 3
S = L - E – 3
Guide tubes included with MAXIMAT V .3L and MAXIMAT V .4L
adjustable level monitors are supplied 50 mm longer than dimension
L, so that the fill-level monitor can be adapted to correspond to
triggering level A during installation. It is thus possible to readjust
dimension L. After the triggering point has been set, the locking
screws are tightened and sealed against tampering. Due to the fact
that this seal is not removed during periodic testing, dimension L is
always fixed, i.e. no readjustment is necessary
